SCHTB250 - Hi-Fi System PANASONIC - Free user manual and instructions

Brand	Panasonic
Model	SCHTB250
Category	Hi-Fi Chain (Soundbar with subwoofer)
Product type	2.1-channel home theater system
RMS output power	120 W total (Dolby Digital) - Front: 40 W x 2 (6 Ω), Subwoofer: 40 W (4 Ω)
Power supply	AC 220-240 V, 50 Hz
Power consumption (standby)	0.5 W (Bluetooth standby off); 2.0 W (Bluetooth standby on)
Weight (subwoofer)	4.4 kg
Weight (main unit)	Approx. 2.5 kg (estimate)
Wireless connectivity	Bluetooth® 2.1+EDR, range 10 m, A2DP profile; 2.4 GHz wireless link with subwoofer
Audio inputs	1 x HDMI (ARC), 1 x digital optical, USB port (for software update)
Supported audio formats	LPCM, Dolby Digital, DTS Digital Surround
Sound modes	Standard, Music, Cinema
Special features	HDMI CEC, auto standby, volume limit, dual audio, audio format display
Operating temperature	0°C to +40°C
Operating humidity	20% to 80% RH (no condensation)
Care and cleaning	Soft dry cloth; do not use alcohol, thinner, or benzene
Safety	Do not expose to rain, moisture, or heat sources; do not block ventilation openings
Included accessories	Power cord, remote control with battery, speaker feet (4)

Frequently Asked Questions - SCHTB250 PANASONIC

How do I pair my smartphone via Bluetooth with this system?

Press the PAIRING button on the remote or press and hold the [ button on the main unit until the indicator flashes rapidly. Select 'SC-HTB250' from your device's Bluetooth list. If a code is requested, enter '0000' or '1234'.

Why is the TV sound not coming through the system?

Check that the HDMI cable is connected to an HDMI ARC terminal on the TV. Enable the ARC function in the TV's audio settings. You can also use an optical cable if the TV is not ARC compatible. Make sure the source is set to HDMI or OPTICAL.

How do I adjust the subwoofer level?

Use the SUBWOOFER + and SUBWOOFER - buttons on the remote (models HTB254/HTB250). The level is indicated by the number of lit indicators: 1 (low) to 4 (high).

The remote control does not work, what should I do?

Remove the battery insulation sheet if it's the first use. Check that the battery is correctly installed (+ side up). Replace the battery if necessary (type CR2025). Use the remote within a range of 7 m and within an angle of 30 degrees.

How do I disable the auto standby after 20 minutes?

Press and hold the HDMI (ARC) button for at least 4 seconds. The MUSIC indicator lights up to indicate the function is disabled. Repeat to reactivate.

What should I do if the subwoofer produces no sound?

Make sure the subwoofer is on and the WIRELESS LINK indicator is lit. If the indicator flashes, perform a pairing: press and hold the I/D SET button on the subwoofer for 4 seconds, then quickly press MUTE, SOUND, MUTE, PAIRING on the remote.

How do I read the current audio format?

Press and hold the SOUND button for at least 4 seconds. The indicators show the format: Dolby Digital (MUSIC and CINEMA lit), DTS (HDMI and OPTICAL lit), or PCM (HDMI and OPTICAL lit differently).

Can I use this system with a 4K TV?

Yes, but the system does not pass through 4K video signal. Connect your 4K source directly to the TV via HDMI, then connect the TV to the system via HDMI ARC (or optical) for audio. Set the TV's audio output to Bitstream if necessary.

How do I reset the system to factory settings?

Press and hold the [ /1] (power/standby) button on the main unit for at least 4 seconds. All indicators flash until restart. The remote code returns to 1.

How do I change the remote code to avoid interference?

To switch to code 2: press and hold the PAIRING and SOUND buttons on the remote for 4 seconds (the MUSIC and CINEMA indicators flash). To return to code 1: press and hold PAIRING and DIMMER.

USER MANUAL SCHTB250 PANASONIC

ARC (Audio Return Channel)

40 W pro Kanal (an 6 Ω), 1 kHz, 10% THD

Subwoofer-Kanal

40 W pro Kanal (an 4 Ω), 100 Hz, 10% THD

40 W pro Kanal (an 6 Ω), 1 kHz, 10% THD

DTS Digital Surround™

Appareil principal 15 W

ARC (Audio Return Channel)

"SC-HTB250" o "SC-HTB200".

32 kHz, 44,1 kHz, 48 kHz

Formato audio LPCM, Dolby Digital,

DTS Digital SurroundTM

Dimensioni (L x A x P)

Unità principale

450mm× 51mm× 135mm

Subwoofer attivo HTB254 HTB250

97 mm x 451 mm x 307 mm

Peso

ARC (Audio Return Channel)

Manufactured by: Panasonic Corporation

Kadoma, Osaka, Japan

Importer for Europe: Panasonic Marketing Europe GmbH

Panasonic Testing Centre

Winsberging 15, 22525 Hamburg, Germany

EU
