USER MANUAL CAV246BK SABA

Thank you for choosing SABA quality. This product has been developed by our team of professional and according to European regulations. In order to get the most out of your new appliance, we recommend that you read this instruction manual carefully and keep it for future reference.

TABLE OF CONTENTS

Safety instructions 14

Technical data 16

Illustrated structure 17

Operation of thermoelectric cooler 18

Particular precautions 19

Maintenance 19

Troubleshooting 20

Disposal of old electrical appliances 22

Safety instructions

Read these safety instructions carefully before using your appliance and keep safe for future reference.

• This appliance is designed to be used for domestic and similar purposes such as:
• kitchens used by employees in shops, offices and other working environments;
  -farms;
• use by guests in hotels, motels and other residential environments;
• other bed and breakfast-type accommodation;
• CAUTION: Keep the ventilation openings unobstructed inside the casing and within the housing.
• CAUTION: Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.
• CAUTION: Do not damage the refrigeration circuit.
• CAUTION: Do not use electric appliances inside the wine storage compartment, unless these are of a type recommended by the manufacturer.
• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.

Children must not play with the appliance. Cleaning and user maintenance must not be carried out children unless they are supervised.

• If the power cable is damaged, it must be replaced by the manufacturer, its After-Sales service or a similarly qualified person to avoid any hazards.
• WARNING: To avoid any risk of instability, the appliance must be installed on the ground, on a flat, horizontal surface making sure the vents are not obstructed.
• Do not store explosive substances such as aerosols containing flammable propellants in this appliance.
• This appliance is designed for storing wine only.
• Concerning the information relative to the installation, handling, maintenance and disposal of the appliance, please refer to the following paragraph in the manual.
• The lamp is non-replaceable. Please contact the after-sales service if it is out of order
• To avoid damage to the environment or human health caused by the uncontrolled disposal of electrical waste, please recycle the appliance responsibly to encourage the reuse of material resources. The appliance must be disposed of in a secure way at public disposal sites provided for this purpose.
• Old appliances may contain CFCs which destroy the ozone layer. Please contact your nearest waste disposal centre for more details on the correct disposal procedures.

Technical data

Model SABA CAV246BK
Category of household refrigeration appliances:	Category 10
Energy efficiency class C
Annual energy consumption 190kWh/yr
Usable compartment volume 65L
Automatic defrost
Climate class + ambient temperature range	N / SN (from +16°C to +32°C)
Acoustic emissions 37dB(A)
Power supply 220V-240V / 50Hz	70W
Storage capacity 24 bottles
Dimension 300 W x 594 D x 845	H (mm)
Weight 18.3kgs
Type of installation	Free standing

Illustrated structure

Control panel

1. Light

2. Door

3. Fan Mask

4. light button

3.Shelf

1. C/F button

4.Foot

1. LCD display

2. Ream cover

3. T° set up button

4. Handle

5. T° set down button

Operation of thermoelectric cooler

• The temperature is adjusted in the range of 11^ - 18^ in the cabinet.
• When the power is connected, cooling system starts to work.
• The temperature you want can be set by touching the "T" set up button and "T" set down button. When the inside temperature is higher than the set point, cooling system will work normally until the inside temperature is lower than the set point, the cellar enters into functional cycles.
• The Light can be turned OFF or ON by touching the "Light button". If your forget turning off the light, it will be turned off after 10 min.

NOTE:

After you setting the temperature, the LCD display will return to show the temperature in the cooler, but it could turn to the point that you have set gradually.

Particular precautions

• In order to function at its potential, this wine cooler needs to be placed on flat floor, with 2cm spaces at each side and 10cm at the backside.
• Use the adjustable foot (iron case) to place the cooler fully horizontal.
• Avoid direct sunshine and high ambient temperature.
• Do not place heavy articles on the top of the cellar.

Maintenance

• Turn off power supply before cleaning cabinet.
  Take out wines and shelves, and then clean the cabinet with soda water then with clean water.
• Do not use soap or detergent for the cabinet.
• Clean the cellar regularly.

The lamp is not changeable by user; contact aftersales service or repair center if it is out of order.

Troubleshooting

Symptoms Possible cause Solutions
No cooling • Plug not put inLow voltageFuse broken	• Put in the plugEnsure normal voltage• Change fuse
Not coldenough temperatureinside • The refrigeratoris placed too nearheat source;Bad ventilation;Fans don't work;The door is notclosed tightlyor opened toofrequently or fortoo long time.	• Keep the refrigeratoraway from sunshine orother heat source;• Place the refrigeratorin the area with goodventilation and keepthings away from thefans;• Check whether the plugis connected or changethe fan;• Close the door tightlyand don't open thedoor too frequently orfor too long time.
Peculiarsmell insiderefrigerator • Check whetherthere is any sourinside	• Wrap the source or takeit out

Symptoms Possible cause Solutions
Inside light flash	· Set temperature higher than inner temperature; · The automatic defrost function start to work	· Adjust the adjustor · Normal function. No repair needed
Frost on the cold sink	· Too much humidity or too low temperature inside the case	· Output the plug, stop the power, and defrost by hand, Connect power again when the ice thaws

Disposal of old electrical appliances

The European directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE), requires that old household electrical appliances must not be disposed of in the normal unsorted municipal waste stream. Old appliances must be collected separately in order to optimize the recovery and recycling of the materials they contain, and reduce the impact on human health and the environment.

The crossed out "wheeled bin" symbol on the product reminds you of your obligation, that when you dispose of the appliance, it must be separately collected.

Consumers should contact their local authority or retailer for information concerning the correct disposal of their old appliance.
