USER MANUAL ZHP62370XA ZANUSSI

(4), massima (5). Usare la velocità maggiore in caso di particolare concentrazione di vapori di cucina. Consigliamo di accendere l’aspirazione 5 minuti prima di iniziare a cucinare e di lasciarla in funzione a cottura terminata per altri 15 minuti circa. ILLUMINAZIONE Disinserire l’apparecchio dalla rete elettrica. Attenzione! Prima di toccare le lampade sincerarsi che siano fredde. Sostituire la lampada danneggiata con una dello stesso tipo così come specifi cato nell’etichetta caratteristica o vicino alla lampada stessa sulla cappa (E14).14 www.zanussi.com SAFETY INSTRUCTIONS Caution! Closely follow the instructions set out in this manual. All responsibility, for any eventual inconveniences, damages or fires caused by not complying with the instructions in this manual, is declined. The extractor hood has been designed exclusively for domestic use. Caution! Do not connect the appliance to the mains until the installation is fully complete. Before any cleaning or maintenance operation, disconnect hood from the mains by removing the plug or disconnecting the mains electrical supply. Always wear work gloves during the maintenance, installation and lighting operations. The appliance is not intended for use by children or persons with impaired physical, sensorial or mental faculties, or if lacking in experience or knowledge, unless they are under supervision or have been trained in the use of the appliance by a person responsible for their safety. This appliance is designed to be operated by adults, children should be monitored to ensure that they do not play with the appliance. This appliance is designed to be operated by adults. Children should not be allowed to tamper with the controls or play with the appliance. Never use the hood without effectively mounted grating! The hood must NEVER be used as a support surface unless specifi cally indicated. The premises where the appliance is nstalled must be suffi ciently ventilated, when the kitchen hood is used together with other gas combustion devices or other fuels. The ducting system for this appliance must not be connected to any existing ventilation system which is being used for any other purpose such as discharging exhaust fumes from appliances burning gas or other fuels. The fl aming of foods beneath the hood itself is severely prohibited. The use of exposed fl ames is detrimental to the fi lters and may cause a fi re risk, and must therefore be avoided in all circumstances. Any frying must be done with care in order to make sure that the oil does not overheat and ignite. Caution! Accessible parts of the hood may became hot when used with cooking appliance. With regards to the technical and safety measures to be adopted for fume discharging it is important to closely follow the regulations provided by the local authorities. The hood must be regularly cleaned on both the inside and outside (AT LEAST ONCE A MONTH). This must be completed in accordance with the maintenance instructions provided in this manual). Failure to follow the instructions provided in this user guide regarding the cleaning of the hood and fi lters will lead to the risk of fi res. Do not use or leave the hood without the lamp correctly mounted due to the possible risk of electric shocks. We will not accept any responsibility for any faults, damage or fi res caused to the appliance as a result of the non-observance of the instructions included in this manual. Warning! Failure to install the screws or fixing device in accordance with these instructions may result in electrical hazards. ENVIRONMENT CONCERNS Recycle the materials with the symbol . Put the packaging in applicable containers to recycle it. Help protect the environment and human health and to recycle waste of electrical and electronic appliances. Do not dispose appliances marked with the symbol with the household waste. Return the product to your local recycling facility or contact your municipal offi ce department for household waste or the shop where you purchased this product. USE The hood is designed to be used either for exhausting or fi lter version . INSTALLATION The mains power supply must correspond to the rating indicated on the plate situated inside the hood. If provided with a plug connect the hood to a socket in compliance with current regulations and positioned in an accessible area, after installation. If it not fi tted with a plug (direct mains connection) or if the plug is not located in an accessible area, after installation, apply a double pole switch in accordance with standards which assures the complete disconnection of the mains under conditions relating to over-current category III in accordance with installation instructions. Warning! Before re-connecting the hood circuit to the mains supply and checking the efficient function, always check that the mains cable is correctly assembled.15 www.zanussi.com The minimum distance between the supporting surface for the cooking equipment on the hob and the lowest part of the range hood must be not less than 43cm from electric cookers and 65cm from gas or mixed cookers. If the instructions for installation for the gas hob specify a greater distance, this must be adhered to. MAINTENANCE ATTENTION! Before performing any maintenance operation, isolate the hood from the electrical supply by switching off at the connector and removing the connector fuse. Or if the appliance has been connected through a plug and socket, then the plug must be removed from the socket. The cooker hood should be cleaned regularly (at least with the same frequency with which you carry out maintenance of the fat fi lters) internally and externally. Clean using the cloth dampened with neutral liquid detergent. Do not use abrasive products. DO NOT USE ALCOHOL! Warning! Failure to carry out the basic cleaning recommendations of the cooker hood and replacement of the fi lters may cause fi re risks. Therefore, we recommend observing these instructions. The manufacturer declines all responsibility for any damage to the motor or any fi re damage linked to inappropriate maintenance or failure to observe the above safety recommendations. Grease fi lter - The grease fi lter must be cleaned once a month using non aggressive detergents, either by hand or in the dishwasher, which must be set to a low temperature and a short cycle. When washed in a dishwasher, the grease fi lter may discolour slightly, but this does not affect its fi ltering capacity. NON-washable activated charcoal fi lter The saturation of the charcoal fi lter occurs af- ter more or less prolonged use, depending on the type of cooking and the regularity of cleaning of the grease fi lter. In any case it is necessary to replace the cartridge at least every four mounths. The charcoal fi lter may NOT be washed or regener- ated. Clack!

Ok!16 www.zanussi.com CONTROLS The hood is fi tted with a control panel with aspiration speed selection control and a light switch to control cooking area lights. OFF! ON!

suction power (4), Maximum suction power (5). Use the high suction speed in cases of concentrated kitchen vapours. It is recommended that the cooker hood suction is switched on for 5 minutes prior to cooking and to leave in operation during cooking and for another 15 minutes approximately after terminating cooking. LIGHTING Disconnect the hood from the electricity. Warning! Prior to touching the light bulbs ensure they are cooled down. Replace the old light bulb with the one of the same type as specifi ed in the feature label or near the light lamp on the hood (E14).17 www.zanussi.com
