USER MANUAL Z31894 SILVERCREST

Unit of weight7 GB/IE

Battery compartment cover

Insulation strip Technical data Measuring range: 0.2–50 kg / 0.5–110 lb Gradation: 0.05 kg / 0.1 lb Battery: 1 x 3 V CR2032 Included items 1 Luggage scale 1 3 V CR2032 1 Instructions for use8 GB/IE Safety instructions This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and under- stand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision. Check the product for damage before use. Never use a damaged product.9 GB/IE Safety instructions for batteries Keep batteries away from children. Do not leave batteries lying around. They could be swallowed by children or pets. In the event of swallowing a battery, contact a doctor immediately. Never recharge, short-circuit and / or open non-recharge- able batteries. Never throw batteries into fire or water. Otherwise there is danger of explosion. When inserting the battery, ensure the correct polarity! The correct polarity is shown inside the battery compartment. Otherwise there is danger of explosion.10 GB/IE Do not subject the batteries to extreme environmental conditions or tempera- tures, such as those near heating radiators. There is then a danger of leaking. Remove spent batteries from the device immediately. Otherwise the battery is more likely to leak! Always replace both batteries. Use only batteries of the same type. Check regularly to make sure the batteries in the device are not leaking. Spent or damaged batteries may irri- tate the skin on contact; so always wear suitable protective gloves in these circumstances! Do not let the fluid from a leaking battery come into contact with your skin, eyes or mucous membranes. In11 GB/IE the event of contact with fluid leaking from a battery, thoroughly flush the affected area with water and / or seek the advice of a doctor! If necessary, clean the contacts on the batteries and on the device itself before inserting them. Remove the batteries from the device if it will not be used for a prolonged period. Dispose the batteries according to the disposal instructions. Preparing for use Note: Before first use remove the insulation strip

(see Fig. A).12 GB/IE Inserting / replacing batteries (s. Fig. C) Note: Make sure you insert the batteries with the correct polarity. Operation Weighing Unlock the buckle

through the grip of the article of luggage and then lock the buckle. Before lifting the article of luggage, press the ON / OFF / ZERO button

to switch on the device. The strap must not be under tension when the device is switched on. After switching on, two signal tones are sounded.13 GB/IE Note: In the LC display

, the weight “0.00 kg / 0.0 lb“ should appear. If it does not, you can reset the display to “0.00 kg / 0.0 lb” by pressing the ON / OFF / ZERO button again. Now slightly raise the scale with the article of luggage. Make sure the scale is horizontal and balanced. The LC display now shows the weight of the article of luggage; after 2–3 seconds the display is frozen and displayed for approx. 1 minute. During this time the word HOLD (H)

appears in the display. Then the device switches off by itself. Note: The heavier the article of lug- gage, the longer the weighing process lasts. Press the ON / OFF / ZERO button while the weight is being displayed14 GB/IE to reset the display to “0.00 kg / 0.0 lb“. You will hear a signal. Now you may start another weighing process. Press the ON / OFF / ZERO button and hold for approx. 3 seconds to switch off the device. After switching off, a signal tone is sounded. Changing the unit of weight Press the UNIT button

to change the unit of weight between kg and lb. Begin the weighing process as described in section “Weighing“.15 GB/IE Troubleshooting = Fault = Reason = Solution

= The scale is overloaded. = Remove the overload. = stays on in the LC display. = The overload has caused a malfunc- tion of the weighing process. = Switch the scale off and then on again.

= The batteries are too weak. You cannot bring the scale into use. = Replace the batteries (see section “Inserting / replacing batteries“).16 GB/IE = The device cannot be switched on. = The batteries may be spent. = Exchange the batteries (see section “Inserting / replacing batteries“). If the device still cannot be switched on, please contact the service centre. Note: This device has delicate electronic components. Therefore interference may occur when it is near devices which trans- mit radio signals. If errors occur in the display, remove any such devices from the vicinity of the product. In the case of such malfunctions, remove the batteries briefly and then insert them again.17 GB/IE Cleaning Clean the product using a slightly moist, fluff-free cloth. Disposal The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities. Contact your local refuse disposal authority for more details of how to dispose of your worn-out product. To help protect the environment, please dispose of the product properly when it has reached the end of its useful life and not18 GB/IE in the household waste. Infor- mation on collection points and their opening hours can be obtained from your local authority. Faulty or used batteries must be recycled in accordance with Directive 2006 / 66 / EC. Return the batteries and / or the device through the appropriate collection facilities. Pb Hg Environmental damage through incorrect disposal of the batteries! Batteries may not be disposed of with the usual domestic waste. They may contain toxic heavy metals and are subject to hazardous waste treatment rules and reg- ulations. The chemical symbols for heavy metals are as follows: Cd = cadmium,19 GB/IE Hg = mercury, Pb = lead. That is why you should dispose of used batteries at a local collection point. Warranty The device has been manufactured to strict quality guidelines and meticulously examined before delivery. In the event of product defects you have legal rights against the retailer of this product. Your legal rights are not limited in any way by our warranty detailed below. The warranty for this device is 3 years from the date of purchase. Should this device show any fault in materials or manufacture within three years from the date of purchase, we will repair or20 GB/IE replace it - at our choice - free of charge to you. The warranty period begins on the date of purchase. Please keep the original sales receipt in a safe location. This document is required as your proof of purchase. This warranty becomes void if the device has been damaged or improperly used or maintained. The warranty applies to faults in material or manufacture. This warranty does not cover product parts subject to normal wear, thus possibly considered consuma- bles (e.g. batteries) or for damage to fragile parts, e.g. switches, rechargeable batteries or glass parts. EMC21 FI Määräysten mukainen käyttö ... Sivu 22 Osien kuvaus ......................................... Sivu 22 Tekniset tiedot ....................................... Sivu 23 Toimituksen sisältö ............................. Sivu 23 Turvallisuusohjeet ............................... Sivu 24 Paristojen turvallisuusohjeet ....................... Sivu 25 Käyttöönotto .......................................... Sivu 27 Paristojen käyttö / vaihto ........................... Sivu 28 Käyttö Punnitseminen ............................................. Sivu 28 Painoyksikön vaihto ................................... Sivu 30 Virheiden korjaaminen ................... Sivu 31 Puhdistus ................................................... Sivu 33 Hävittäminen ......................................... Sivu 33 Takuu ........................................................... Sivu 3522 FI Matkalaukkuvaaka Määräysten mukainen käyttö Tämä vaaka on tarkoitettu matkatavaroiden punnitsemiseen. Tuote on tarkoitettu vain yksityiseen käyttöön. Osien kuvaus
