USER MANUAL IF1040 Ices

Thank you for your purchasing this fan. Please read all instructions carefully and keep for future use.

Dear Customer,

Please read these operating instructions through carefully before connecting your device to the mains, in order to avoid damage due to incorrect use. Please pay particular attention to the safety information. If you pass the device on to a third party, these operating instructions must also be handed over.

STRUCTURE

1.FRONT GUARD

2.SPINNER

3.BLADE

4.GUARD MOUNTING NUT

5.REAR GUARD

6.MOTOR HOUSING

1. OSCILLATION KNOB

8.STAND

9.SPEED SWITCH

10.BASE

ASSEMBLY

1. Loosen Guard Mounting Nut from the Motor Housing.
2. Position rear guard firmly to motor housing and then fasten by turning guard mounting nut clockwise tightly.
3. Push the blade along motor shaft. fasten it firmly with spinner by turning counter clockwise.
4. Hang the front guard to Rear Guard with the position fixer provided at the rim of Guard. and then fix together with clips provided.

OSCILLATION CONTROL

1. Push the oscillation knob to oscillate.
2. Pull the oscillation knob to stop.

CAUTION

1. Read and retain these instructions for future use.
2. Improper installation may result in the risk of fire, electric shock, or serious injury to persons.
3. Power plug must be removed from power socket before cleaning, servicing, maintenance and when moving from one location to another.
4. The fan should be placed on a flat and stable surface when operating to avoid overturning.
5. The fan should not be placed in a damp place or where humidity is high (such as in a bathroom).
6. Do not insert fingers or other objects through the fan guard.
7. Unplug from mains if not in use.
8. This is not a toy. Keep out of reach of children.
9. The appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been

given supervision or instruction concerning the use of the appliance by a person responsible for their safety.

1. Children should be supervised to measure that they do not play with the appliance.
2. If the cord is damaged, it should be replaced by service agent or qualified technician.

TECHNICAL DETAILS

Model No.: IF-1040

Power consumption: 50W

Main Voltage: 220-240V~50Hz

INFORMATION ON WASTE DISPOSAL FOR CONSUMERS OF ELECTRICAL & ELECTRONIC EQUIPMENT.

This mark on a product and/or accompanying documents indicates that when it is to be disposed of, it must be treated as Waste Electrical & Electronic Equipment (WEEE).

Any WEEE marked waste products must not be mixed with general household waste, but kept separate for the treatment, recovery and recycling of the materials used.

For proper treatment, recovery and recycling; please take all WEEE marked waste to your Local Authority Civic waste site, where it will be accepted free of charge.

If all consumers dispose of Waste Electrical & Electronic Equipment correctly, they will be helping to save valuable resources and preventing any potential negative effects upon human health and the environment, of any hazardous materials that the waste may contain.
