Product type	Marine diesel engine
Brand	Volvo Penta
Model	MD2020B
Number of cylinders	3
Bore	67 mm
Stroke	64 mm
Displacement	0.68 liter
Idle speed	850 ± 25 rpm
Engine weight (dry, without oil and water)	116 kg
Cooling system	Freshwater closed with seawater heat exchanger
Engine oil capacity (with filter)	3.4 liters
Engine oil quality	API CD, SAE 15W/40 or 20W/50
Freshwater circuit capacity	3.0 liters
Thermostat	Start opening at 75°C, full opening at 87°C
Electrical system	12 V
Alternator	14 V / 60 A (840 W)
Starter	0.7 kW
Recommended battery	70 Ah
Fuses	15 A (4 fuses in relay box)
Fuel	Diesel compliant with EN 590
Maximum inclination (operation)	20° aft, 30° lateral
Transmission	Sailboat drive 120S-D (reduction 2.48:1)
Drive oil capacity	2.8 liters
Drive weight	28 kg
Maintenance	Oil change every 100 h, fuel filter every 200 h, coolant every 2 years

Frequently Asked Questions - MD2020 VOLVO

How to start the Volvo MD2020 engine?

Before starting, open the seacock and fuel valve, check oil and coolant levels. Put the control lever in neutral. Turn the key to position II (preheating) for 10 to 30 seconds, then to position III to start. Release as soon as the engine runs.

What engine oil to use and when to change it?

Use API CD quality oil, viscosity SAE 15W/40 or 20W/50. Oil change with filter replacement should be done every 100 service hours, or at least once a year. For a new engine, first oil change at 20-50 hours.

How to check and top up coolant?

Check the level when the engine is cold. The level should be just below the filler neck or between the MIN and MAX marks on the expansion tank. Use a 50% Volvo Penta antifreeze and 50% clean water mixture for protection down to -40°C. Never open the cap on a hot engine.

What to do in case of an audible alarm?

The audible alarm sounds for high temperature, low oil pressure, or charging failure. Press the confirmation button to stop the audible alarm; the light flashes until repair. In case of high temperature, reduce speed; if oil pressure is low, stop the engine immediately.

How to drain the drive oil (120S-D)?

Remove the dipstick, then remove the drain plug on the propeller housing to let the oil drain. Check the O-ring condition. Screw the plug back and fill with API CD SAE 15W/40 oil up to the MAX mark on the dipstick.

When to change the seawater pump impeller?

The impeller should be inspected and replaced if cracked or worn, at least once a year or every 200 hours. For winter storage, remove it and store in a cool place. Always carry a spare impeller onboard.

How to bleed the fuel system?

Open the bleed screw on the fuel filter three turns. Operate the priming pump until fuel flows without bubbles. Tighten the screw. Then loosen the injector nuts and crank the engine with the starter until fuel comes out, then retighten.

Which battery to use and how to maintain it?

Use a 70 Ah, 12 V battery. Check electrolyte level (5-10 mm above plates) and top up with distilled water if necessary. Clean terminals and grease them. In winter, ensure it is fully charged to prevent freezing.

How to winterize the engine?

With the boat in water, drain engine and transmission oil, change filters. Haul the boat, clean the drive, drain drive oil. Flush seawater circuit, remove impeller. Check antifreeze in freshwater circuit. Disconnect batteries and charge them. Remove and store propellers.

What is the recommended cruising speed?

For good economy, maintain engine speed 300 to 500 rpm below maximum speed. The full load speed range is 3200 to 3600 rpm for the MD2020. Avoid continuous operation at full throttle.

USER MANUAL MD2020 VOLVO

MANUEL D'INSTRUCTIONS

MD2010, MD2020, MD2030, MD2040

Bienvenue à bord

BL = Bleu OR = Orange

LBL = Bleu clair R = Rouge

BN = Brun SB = Noir

LBN = Brun clair W = Blanc

GN = Vert Y = Jaune

GR = Gris

Sections non indiquées = 1,0 mm²

*American Wiring Gauge

Rapport mm2/AWG*

mm2AWG

1,0 1,516 (17)

2,515 (16)

1013

167

5

BL = Bleu OR = Orange

LBL = Bleu clair R = Rouge

BN = Brun SB = Noir

LBN = Brun clair VO = Violet

GN=Vert W=Blanc

GR=Gris Y=Jaune

Sections non indiquées = 1,0 mm²

ASTM D 975 N° 1-D et 2-D

JIS KK 2204

MS2L-D. 0°
MS2A-D 7°
