USER MANUAL Powerstation PRO Mophie

made for smartphones and tablets

mophie

user manual

English 04
French 16
Italian 31
German 44
Spanish 58
Japanese 72
Korean 84

Simplified Chinese 96

Traditional Chinese 105

EN

Welcome

You've just joined the elite group of individuals who demand the best. With the workstation PRO, you will have confidence that you'll have all the power you need when and where you need it. With an impact and splash resistant design, 6,000 mAh capacity and small form-factor – you can be assured that no matter how extreme your weekend gets, all your gear will have the power it needs come Monday.

Because the workstation is universal and will work with most USB devices, its hard to be specific about how much additional power you will get – it depends on what kind of battery you are charging and what you're using it for. But at 6000mAh, rest assured that this thing will keep you going for hours and hours.

IP65 Rated

When we say this thing is rugged, we mean it. With a rating of IP65, the powerstation PRO has been tested using international standards for dust and water resistance (IP = Ingress Protection). A rating of 65 means that this device is totally dust-proof (with the ports closed) and resistant to water being sprayed at it with a water-jet. Getting the powerstation PRO wet is no big deal (even in the shower*), but don't try taking a bath with it.

*Do not take it in the shower. And, don't get it wet while your charging anything.

Package Contains

• morphie juice pack workstation PRO
• User manual
• Micro USB Cable
  The opportunity to go for days without a power outlet

Features

With completely reengineered battery and electronics, the workstation can charge your device at super-fast speeds. The workstation has brains, beauty and brawn - everything you've ever wanted from a travel companion.

Here's a rundown of why this is the perfect device:

1. 6000 mAh device that is compatible with just about anything.
2. Ultra-rugged design means it goes where you go – no questions asked.
3. High-density, high-output battery charges at speeds of up to 2.1 amps. That's 4 times faster than traditional USB batteries!
4. Capable of charging the power hungry iPa and other large USB-powered devices.

5. Check the fuel tank with the 4 LED charge status indicator – always know before you go!

6. Rechargeable for over 500 cycles (way better than average and that's full cycles, partials don't count. go ahead, top it off.)

7. Built-in short circuit, overcharge and temperature protection. mophie's got your back.

Compatibility

The workstation has been designed principally with Apple products in mind - specifically the iPhone, iPod touch and iPad. We have done extensive testing on these products and can assure you that this device is fully compatible with all versions of the above. If you'd like to try it with your blueberry or slidekick, be our guest, but we do not guarantee the outcome. If you do try it, feel free to give us a call and let us know what happened - could be exciting. As always, please read through all of the warnings in this manual very carefully before using this product.

Charging your workstation

Connect your workstation using the included micro USB cable. You can charge your workstation using your computer or using a third party "Works with iPhone" USB wall adaptor. You can even use your iPad wall adaptor, which is the fastest method currently available. (The LEDs located on the top of the device will blink when charging, after 30 seconds the lights will turn off. Press the status indicator before you disconnect to make sure you are fully charged.)

Charging your device using the workstation

We've included a USB A to micro USB cable. You can use this cable to charge the workstation, or, use it backwards to charge any micro-usb device. Chances are, if it's not Apple, its micro-USB. If you're device isn't micro-USB – you'll have to bring your own cable to the party. This way, the workstation can play with whichever device and connector you have lying around, not limited to what we choose to ship it with. In order to charge your device, you will need to have a USB cable compatible with your device. These come standard with all Apple products as well as most other smartphones, tablets and MP3 players.

Checking the status of the workstation

You can check the amount of juice your workstation has by pressing the button on the side of the device. There are 4 total LEDs. When the button is pressed the LEDs will illuminate for several seconds. LEDs means that the workstation is fully charged and one LED means that it's almost empty.

To keep your workstation operating to its fullest potential, make sure to do the following:

1. Keep your workstation dry and away from moisture and corrosive materials.

2. Do not wash the powerstation with harsh chemicals, soaps or detergents. Just wipe the case with a soft, water-dampened cloth. Wipe the pins gently with a soft, dry cloth.

3. Re-charge your workstation once every three months when not in use, and remember to charge it for one hour before putting it away the first time.

Warranty

At mophie, we are dedicated to making the best quality products we can. To back this up, this product is warranted for 1 full year from date of purchase. This warranty does not affect any statutory or that you may be entitled to. Keep a copy of your purchase receipt as proof of purchase. Be sure to register your product at mophie.com to activate. Failure to register your product and/or provide proof of purchase may void the warranty.

Customer Service

Telephone: 1-888-8mophie International: [phone] Web: www.mophie.com/cs Service Hours: 9am to 6pm M-F EST

Warning

Read all instructions and warnings prior to using this product. Improper use of this product may result in product damage, excess heat, toxic fumes, fire or explosion, for which damages you ("Purchaser"), and not mophie, LLC ("Manufacturer") are responsible.

The powerstation should be operated only in open-air conditions. It should not be operated in an enclosed, unventilated space such as a carrying bag, pocket, or purse. Failure to follow these instructions may cause damage to the workstation by overheating.
Do not store battery in high temperature environment, including intense sunlight heat. Do not place battery in fire or other excessively hot environments.
Be cautious of excessive drops, bumps, abrasions or other impacts to this battery. If there is any damage to the battery such as dents, punctures, tears, deformities or corrosion, due to any cause, discontinue use and contact manufacturer or dispose of it in an appropriate manner at your local battery recycling center.
Do not disassemble this battery or attempt to re-purpose or modify it in any manner.
Do not expose this battery to moisture or submerge it in liquid. Keep battery dry at all times.

Do not attempt to charge battery using any method, apparatus or connection other than the device's USB connector. For questions instructions for the various ways to charge the workstation refer to this manual's "Charging your device using the workstation and "use summary" sections.
Do not attempt to replace any part of this battery.
If this battery is intended by Purchaser to be used by a minor, purchasing adult agrees to provide detailed instructions and warnings to any minor prior to use. Failure to sole responsibility of purchaser, who agrees to indemnify Manufacturer for any unintended use/misuse by a minor.
All batteries have gone through a thorough quality assurance inspection. If you find that your battery is excessively hot, is emitting odor, is deformed, abrased, cut or is experiencing or demonstrating an abnormal phenomenon, immediately stop all battery use and contact Manufacturer.
For extended storage, first charge your battery for one hour.
Never dispose of batteries in the garbage. Disposal of batteries in the garbage is unlawful under state and federal environmental laws and regulations. Always take used batteries to your local battery-recycling center.

Legal

This Battery is meant for use only in conjunction with the appropriate mobile device. Please consult your device packaging to determine whether this Battery is compatible with your particular mobile device. Manufacturer is not responsible for any damages to any mobile device incurred through the use of this product.

Manufacturer shall not in any way be liable to you or to any third party for any damages you or any third party may suffer as a result of use, intended or unintended, or misuse of this battery in conjunction with any device or accessory other than the appropriate mobile device for which this battery is designed. Manufacturer will not be responsible for any damages you or any third party may suffer as a result of misuse of this battery as outlined above. If you are responsible for battery use with an unintended mobile device and damages result from such use, you agree to indemnify Manufacturer for any resulting injuries to any third part(ies).

mophie, mophie juice pack workstation and the morphie logo are registered in the U.S. Patent and Trademark Office and are registered and pending in other countries. morphie loves you and do more are pending trademarks in the U.S. and other countries. iPod, iPhone and iPad are trademarks of Apple Inc., registered in the U.S. and other countries. All rights reserved. Patents: morphie.com/patents

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

NOTE: This equipment has been tested and fo to comply with the limits for a Class B digital device pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced technician for help.

CAUTION: To comply with the limits of the CI digital device, pursuant to Part 15 of the FCC Rules, this device is comply with Class B limits. All peripherals must be shielded and grounded. Operation with non-certified peripherals or non-shielded cables may result in interference to radio or reception.

MODIFICATION: Any changes or modifications of this device could void the warranty.

FAQ

Will the workstation charge my iPhone?

You bet. The workstation is fully compatible with every iPhone.

Can I charge my iPad with the workstation?

Yes, the workstation can provide hours of charge to an iPad. It will not, however, provide a complete charge to the iPad.

Will the workstation charge my device?

The workstation has been designed principally with Apple products in mind – specifically the iPhone, iPod touch and iPad. If you'd like to try it with your blueberry or slidekick, be our guest, but we do not guarantee the outcome.

Which port is used for charging the workstation and which port is used to charge my device?

Connect your cable using the bigger, rectangular USB port to charge your device. The smaller, micro USB port is used to recharge the workstation.

Can I charge the workstation from a computer's USB port?

Yes, the workstation will charge from any high-current USB port - which are available on most computers. Lower current available ports on some computers, as well as USB ports on keyboards and hubs, may not effectively charge the workstation.

Why aren't the LEDs blinking while the powerstation is charging?

After connecting to a power source, the LED indicator will start blinking to indicate charging. The lights will turn off after 30 seconds allowing for a good night's rest. Remember to check the status indicator before you disconnect to make sure you are fully charged.

How many charge cycles do you get in the workstation?

The workstation is rechargeable for over 500 cycles (These are full cycles. Partial cycles don't cou full. So, you can charge your workstation 10 % of the way 10 times before it counts as a complete cycle.) Don’t be afraid to top it off!

Can I charge my device while charging the workstation?

Sorry. This device does not have pass-through capability. Please charge the workstation separately from other devices.

What is mophie's return policy?

mophie reserves the right to claim a 20 % restocking fee upon return. Visit mophie.com for a full “Return Policy.”
