USER MANUAL FR 2293 WHITE AND BROWN

Many thanks for choosing to purchase a WHITE&BROWN brand product. Thanks to its technology, design and operation and the fact that it exceeds the strictest quality standards, a fully satisfactory use and long product life can be assured.

• Read these instructions carefully before switching on the appliance and keep them for future reference.

Failure to follow and observe these instructions may result in an accident. Failure to follow and observe these instructions may result in an accident.

• Clean all the parts of the product that will be in contact with food, as indicated in the cleaning section, before use.

Use or working environment:

• Place the appliance on a horizontal, flat, stable surface, suitable for withstand high temperatures and away from other heat sources and contact with water.

• Keep the appliance away from flammable material such as textiles, cardboard or paper, etc.

• Do not use the appliance in association with a programmer, timer or other device that automatically switches it on, as there is a risk of fire if the appliance is covered or incorrectly situated.

Electric safety:

• Do not use the appliance if the cable or plug is damaged.

• Ensure that the voltage indicated on the nameplate matches the mains voltage before plugging in the appliance.

• Connect the appliance to a base with an earth socket withstanding a minimum of 10 amperes.

• The appliance's plug must fit into the mains socket properly. Do not alter the plug. Do not use plug adaptors.

• If any of the appliance casings breaks, immediately disconnect the appliance from the mains to prevent the possibility of an electric shock.

• Do not use the appliance if it has fallen on the floor, if there are visible signs of damage or if it has a leak.

• CAUTION: Do not use the appliance near water.

• Do not force the electrical wire.

Never use the electric wire to lift up, carry or unplug the appliance.

• Do not wrap the cable around the appliance.

• Ensure that the electric cable does not get trapped or tangled.

• Do not allow the connection cable to come into contact with the appliance's hot surfaces.

• Check the state of the power cord.
  Damaged or tangled cables increase the risk of electric shock.
• Do not touch the plug with wet hands.

Personal safety:

• Do not touch metal parts or the body when it is operating, as it may cause serious burns.
• The temperature of the accessible surfaces may be high when the appliance is in use.

Use and care:

• Fully unroll the appliance's power cable before each use.
• Never connect the appliance without having first of all filled the oil bowl.
• Do not use the appliance if the on/off switch does not work.
• Do not move the appliance whilst in operation or if the oil is still hot.

Once cooled, transport the appliance using the handles. (Fig.)

• Use the appliance handle/s, to catch it or move it.
• Do not turn the appliance over while it is in use or connected to the mains.
• Respect the MAX and MIN levels (Fig.
• Disconnect the appliance from the mains when not in use and before undertaking any cleaning task.
• This appliance is for household use only, not professional or industrial use.
• This appliance is not a toy. Children should be supervised to ensure that they do not play with the appliance.
• This appliance is intended for adult use. Ensure that this product is not used by the disabled, children or people unused to its handling.
• This appliance should be stored out of reach of children and/or the disabled.
• Do not store or transport the appliance if it is still hot.
• Never leave the appliance unattended while in use.
• If fat is used instead of oil, melt first in a separate recipient.
• If fat has hardened in the pan, make a few holes in the solid fat in order to allow the water, which has been retained in the fat to be released as steam when heated at the minimum thermostat temperature.
• If, for some reason, the oil were to catch fire, disconnect the appliance from the mains and smother the fire using the lid, a cover or a large kitchen cloth... NEVER WITH WATER.
• Turn the thermostat control to the minimum (MIN) setting. This does not mean that the iron is switched off permanently.
• Any misuse or failure to follow the instructions for use renders the guarantee and the manufacturer's liability null and void.

DESCRIPTION

A Lid
B Handle lid
C Temperature regulation thermostat
D Pilot light
E Automatic security switch
F Bevel profiles
G Unit control
H Heating component
I Basket
J Basket handle
K Basket support
L Tank
M Level indicator
N Body
O Reset button
P Plug connection host
Q Plug connection
R Control unit support

USE

Before use:

• Make sure that all the product's packaging has been removed.
• Before using the product for the first time, clean the parts that will come into contact with food in the manner described in the cleaning section.

Oil filling:

• Open the cover.
• Ensure that the electrical equipment is appropriately positioned.
• Pour oil up to the mark indicating the MAXIMUM level on the bowl.
• The appliance must not be used with less oil than that indicated by the MINIMAL mark.

Use:

-Remove the lid. This fryer is not designed to fry with the lid on.
-Remove the basket and attach the handle by pivoting until the rods engage in the housing.
- Before using for the first time, clean the basket and bowl with water and detergent, rinse well to eliminate any leftover detergent and then dry.
- Connect the appliance to the mains.
- The pilot light comes on.

• Select the desired frying temperature using the thermostat control. The indicator light will turn, indicating that the oil is being heated.

• Prepare the food to be fried and place it in the basket, making sure that it does not rise above 34 of its capacity. Allow the food to drain before placing it in the basket.

• Frozen food must be allowed for thaw beforehand. The placing of frozen food or food with high water content in the basket may cause the oil to suddenly spit after a few seconds.

• Wait until the pilot light has gone out which will indicate that the appliance has reached an adequate temperature.

• Slowly place the basket in the bowl to avoid overflowing and splashing. Fry with the lid open or closed, as required.

• When the food has been fried sufficiently, lift the basket and position it in the support in order to allow the excess oil to drain from the food.

• Empty the basket.

• Change the oil approximately every 15 or 20 frying operations, or every 5 -6 months if not used frequently.

• In order to minimize the generation of acrilamida during the frying process, avoid to reach dark brown colours on the fried food, remove any burnt leftovers from the oil container, food rich in scratch (such as potatoes or corns) should not be fried at temperatures higher to 170^ .

Once you have finished using the appliance:

• Select the minimum position (MIN) using the thermostat control.

• Unplug the appliance to the mains.

• Put the cable back in the cable housing.

-Place the basket in the bowl.

• The basket handle may be left affixed or it may be folded into the basket by pressing the rods from the side and twisting it round.

• Close the lid.

Cord housing

• This appliance has a cable compartment situated on its posterior. Carry handle/s:

This appliance has a handle on the side of the body, which facilitates comfortable transport.

Practical recommendations:

• Fry a few pieces of bread to remove the smell of used oil.

• For food with a high water content, it is better and quicker to fry in two lots with less food than in just one.

This will reduce the risk of splashes and spillage.

• This will reduce the risk of splashes and spillage. This system consists of first frying the food until it is reasonably well done and then frying again using very hot oil to brown the food.

• Olive oil with a minimum acidity level is recommendable for frying.
• Do not mix different oils.
• Wash potatoes before frying to stop them from sticking.

Safety thermal protector:

• In the event of overheating, the thermal safety mechanism will be activated and the appliance will stop operating. When this occurs the appliance should be disconnected from the mains and left to cool. Then press the rearming button, situated at the back of the electrical circuit, with the tip of a pen or similar in order to reactivate the appliance (Fig. 1).

CLEANING

• Disconnect the appliance from the mains and let it cool before undertaking any cleaning task.
• Dismantle the appliance as follows:

Take off the lid

Remove the basket and take out the electrical equipment

Remove the bowl

Carefully pour the used oil from the bowl into a container (not the sink), according to the regulations in force for the treatment and disposal of waste.

Pour soapy water into the tank to degrade it.

• Except for the power unit and the mains connection, all the parts can be cleaned with detergent and water or in washing up liquid. Rinse thoroughly to remove all traces of detergent
• Clean the electrical equipment and the mains connection with a damp cloth and dry. DO NOT IMMERSE IN WATER OR ANY OTHER LIQUID.
• Clean the equipment with a damp cloth with a few drops of washing-up liquid and then dry.
• Do not use solvents, or products with an acid or base pH such as bleach, or abrasive products, for cleaning the appliance.
• Do not submerge the appliance in water or any other liquid, or place it under a running tap.
• If the appliance is not in good condition of cleanliness, its surface may degrade and inexorably affect the duration of the appliance's useful life and could become unsafe to use.
• The appliance is suitable for cleaning in hot soapy water or in a dishwasher (using a soft cleaning program):

• Basket
  -Lid
  Tank
• Body

Anomalies and repair

• Take the appliance to an authorised technical support service if problems arise.

Do not try to dismantle or repair without assistance, as this may be dangerous.

• If the connection to the mains has been damaged, it must be replaced and you should proceed as you would in the case of damage.

For EU product versions and/or in case that it is requested in your country:

Ecology and recyclability of the product

• The materials of which the packaging of this appliance consists are included in a collection, classification and recycling system. Should you wish to dispose of them, use the appropriate public containers for each type of material.
• The product does not contain concentrations of substances that could be considered harmful to the environment
• This appliance contains, or could contain, oil. Remember that one should abide by the regulations concerning the elimination of this type of contaminant.

This appliance complies with Directive 2006/95/EC on Low Voltage and Directive 2004/108/EC on Electromagnetic Compatibility.
