USER MANUAL HF 60 Heaven Fresh

Heaven Fresh®

HF 60 IONIC VEHICLE AIR PURIFIER

PURIFICATEUR D'AIR IONIQUE POUR VÉHICULES HF 60

Black portable ice cream device with coiled cord and connector, no visible text or symbols on body

INSTRUCTION MANUAL

MODE D'EMPLOI

HEAVEN FRESH

©2010, HFEF-CANUS-HF 60-01/10

Thank you for purchasing the efficient Heaven Fresh HF 60 Ionic Vehicle Air Purifier.

CAUTION

This device should be used in 12V DC vehicles only. Do not use in 24V DC vehicles. Unplug the unit from the 12-volt cigarette socket when the vehicle engine is running at low speeds for an extended period. This will prevent damage resulting from sudden voltage surges from the battery during low load conditions.

The effectiveness of this device will be reduced when the vehicle windows are open. To prolong service life it is advisable to turn off the HF 60 when not operating the vehicle.

Keep this device dry. If moisture accidentally enters the unit, please dry it • thoroughly inside and out before using it.

Clean the HF 60 exterior cover with mild detergent only. Do not use alcohol, benzene or other strong solvents, as they will do damage to the cover.

PRODUCT OVERVIEW

The HF 60 generates thousands of negative ions that bind with allergens, • microbes and other pollutants (including bacteria, cigarette smoke, vehicle emissions, odours, etc.) removing them from the air, keeping it fresh and clean. Purified, negative ion-rich air will help to keep drivers alert and comfortable on long trips.

The ergonomic and compact design will enhance the appearance of your vehicle's dashboard without obstructing your view.

OPERATING INSTRUCTIONS

Use the adhesive strip provided to secure the HF 60 firmly on the dashboard with the six air outlets facing the interior of the vehicle.

Insert the unit's DC plug into the cigarette lighter socket. Move the switch, located on the side of the device, to the [ON] position. The green light will appear when in operating mode. Turn the switch to the [OFF] position to stop operation.

Note: In some vehicles the power to the cigarette lighter socket will cut off when the vehicle is not operating.

CLEANING & MAINTENANCE

The unit will need cleaning about every two months. Please clean as follows:

1. Unplug from the socket. Hold the top of the unit with one hand and using the other hand carefully remove the upper cover by inserting a small coin into the two release slots located at the rear of the unit and twisting slightly. It is not necessary to remove the lower part of the unit from the dashboard for cleaning. Be careful not to break the four positioning locks inside the base of the unit.

Close-up of mechanical components with a white tool inserted, no visible text or symbols

1. Use a cotton swab dipped in alcohol to wipe the electrode needles and the dust collector plate with the six holes. Be careful not to damage the internal electronic circuitry.

2. Important: Please be sure to remove any remaining moisture with a small dry cloth and allow the unit to dry thoroughly before closing the cover. You can operate the device after it is thoroughly dry.

COMPONENTS

12V DC plug Air Intake

Close-up of a black handheld device with coiled cable and connector, no visible text or symbols

Close-up of a black electronic device with a cable and labeled buttons (ON, OFF) on its side, no readable text or symbols beyond the labels.

Indicator lightAir oONOFF Switch

Black plastic electronic device casing with ventilation slots and a small rectangular base (no visible text or symbols)

Cover release slots

TECHNICAL SPECIFICATIONS

Model HF 60

Rated voltage DC 12V

Power consumption 2W

Negative Ion output Max. 100,000/cm³

Active oxygen output 0.01 ppm - 0.4ppm

Dimensions 5.6" (L) × 4.5" (W) × 1.5" (H)

Weight 0.4 lbs (180g)

Applicable area Designed for vehicle interiors including automobiles, trucks and RVs.

Close-up of a mechanical component with a white tool inserted, showing no visible text or symbols.

Close-up of a black cable with a coiled cable and connector (no text or symbols visible)

Gray ergonomic computer mouse with a logo and cable, no visible text or symbols on the device itself.

Close-up of a black electronic device with a cable and labeled buttons (ON, OFF) on its side, no readable text or symbols beyond the buttons.

Exterior view of a Heiwen brand light case (no text or symbols visible on body)

The HF 60 is subjected to strict testing procedures before leaving the factory. If within one year from the date of purchase the product does not perform according to the specifications, because of factory defects, the purchaser is entitled to free repairs or replacement of parts upon presentation of this warranty (provided that the malfunction or damage to the device and/or parts occurred under normal operating conditions).

What is covered: All parts defective in material and workmanship.

For how long: One year from purchase date.

What we will do: Repair or replace any defective parts.

90-Day Replacement Policy

If, due to manufacturer defect, any part requires repair during the first 90 days after receiving your ionizer, Heaven Fresh will replace it with a new machine.

What You Must Do

1. Contact Heaven Fresh customer support at:

1-866-625-1857

www.heavenfresh.ca

1-800-642-0367

www.heavenfresh.com

for Return Authorization Number.

1. Pack the product in its original carton, and in the same manner in which you received it, or as identical as possible.
2. Include proof of purchase inside box along with the Return Authorization Number.
3. Label and ship the unit, freight pre-paid, to the address below.

Mailing Address:

Heaven Fresh Canada Inc.

50 Venture Dr. Unit 6

Toronto, ON M1B 3L6

Heaven Fresh USA

1701-2 Pearl Street

Waukesha, WI 53186

Other Conditions

The provisions of this warranty are in lieu of any other written warranty whether express or implied, written or oral, including any warranty of merchantability or fitness for a particular purpose. The manufacturer's maximum liability shall not exceed the actual purchase price paid by you for the product. In no event shall the manufacturer be liable for special, incidental, consequential, or indirect damages. This warranty does not cover a defect that has resulted from improper or unreasonable use or maintenance, faulty assembly, accident, natural catastrophes, improper packing, or unauthorized tampering, alteration, or modification as determined solely by us. This warranty is void if the label bearing the serial number has been removed or defaced.

WARRANTY CERTIFICATE / CERTIFICAT DE GARANTIE

WARRANTY CERTIFICATE FOR THE HF 60 IONIC VEHICLE AIR PURIFIER CERTIFICAT DE GARANTIE POUR SYSTÈMES DE L'IONISEUR PURIFICATEUR D'AIR IONIQUE POUR VÈHICULES HF 60

Date of purchase/Date d'achat: ____

Address/Adresse: ____

Telephone/Téléphone: ____

Email/Email: ____

Seller's name/Nom du vendeur: ____

Address/Adresse: ____
