KM 26 - Coffee machine TEAM - Free user manual and instructions

Brand	TEAM
Model	KM 26
Product type	Drip coffee maker
Water tank capacity	1.25 L (approx. 10 cups)
Power supply	230 V ~ 50 Hz, 1000 W
Dimensions (approx.)	25 x 20 x 35 cm
Weight (approx.)	2 kg
Filter type	Paper filter or permanent filter (depending on model)
Anti-drip system	Yes, automatic anti-drip valve
Carafe	Glass carafe with handle and lid
Hot plate	Keeps coffee warm
Main functions	Filter coffee brewing, auto shut-off (not specified), power indicator light
Maintenance and cleaning	Clean carafe with warm soapy water, plastic parts with non-abrasive sponge. Do not immerse appliance. Regular descaling with special coffee maker descaler.
Safety	Do not use without water, do not touch hot surfaces, unplug before cleaning, do not use near heat sources, do not place in microwave oven.
Spare parts and repairability	Replacement carafe, permanent filter (depending on model). Repair by qualified competent service (manufacturer or importer after-sales service).
General information	Household use only. Read instructions before use. Warranty: replacement of scaled heating element not covered.
Environmental protection	Do not dispose of with household waste. Take to a collection point for recycling (Directive 2002/96/EC).

Frequently Asked Questions - KM 26 TEAM

How to use the TEAM KM 26 coffee maker for the first time?

Before first use, pour water into the tank without coffee and turn on the appliance. Once the water has passed through, turn off and repeat the operation twice more, letting it cool between cycles.

What is the maximum amount of water I can put in the tank?

Do not exceed the maximum level indicated on the tank. Excess water will cause the coffee to overflow from the carafe.

How to clean the TEAM KM 26 coffee maker?

Unplug and let cool. Clean the carafe with warm soapy water and rinse. Plastic parts and the hot plate can be cleaned with a non-abrasive sponge or damp cloth. Never immerse the appliance in water.

How often should I descale the machine?

Descale regularly as soon as you notice an increase in brewing time. Use a special descaler for electric coffee makers. Frequency depends on water hardness.

What should I do if the carafe is cracked?

Do not use the appliance if the carafe is cracked or broken. Use only the carafe supplied with the appliance or a compatible replacement carafe.

Can I use the carafe in the microwave?

No, the carafe must not be placed in a microwave oven to reheat coffee. This could damage it.

How does the anti-drip system work?

When you remove the carafe, an anti-drip valve automatically closes to prevent coffee from dripping onto the hot plate. When you replace the carafe, the valve opens and the remaining coffee flows out.

What should I do if the appliance does not work?

Check the power supply and that the tank contains water. If the problem persists, contact a qualified competent service (manufacturer or importer after-sales service). Do not attempt to repair yourself.

Can I use reusable filters?

Yes, depending on the model, you can use a permanent filter instead of paper filters. Make sure it is compatible with the machine.

How to dispose of the machine at the end of its life?

Do not dispose of the appliance with household waste. Take it to a public collection point for recycling of electrical and electronic waste, in accordance with Directive 2002/96/EC.

USER MANUAL KM 26 TEAM

Generated by Unregistered Batch DOC TO PDF Converter 2011.3.804.1511, please register!

Copies of the I/B. Please reproduce them without any changes except under special instruction from Team International BELGIUM. The pages must be reproduced and folded in order to obtain a booklet A5 (+/- 148.5 mm width x 210 mm height). When folding, make sure you keep the good numbering when you turn the pages of the I/B. Don't change the page numbering. Keep the language integrity.

Kaffeeautomat

Coffee Maker

Cafetière

Koffiezetapparaat

Cafeteria

Cafeteira

Caffettiera

CE

I/B Version

061121

TEAM KM 26

230V 1000W

Copies of the I/B. Please reproduce them without any changes except under special instruction from Team International BELGIUM. The pages must be reproduced and folded in order to obtain a booklet A5 (+/- 148.5 mm width x 210 mm height). When folding, make sure you keep the good numbering when you turn the pages of the I/B. Don't change the page numbering. Keep the language integrity.

Fax [phone]

Please read these instructions carefully before using the appliance.
Check that your mains voltage corresponds to that stated on the appliance.
Never leave the appliance unsupervised when in use. Keep out of reach of children or incompetent persons.
From time to time check your appliance for damages. Never use the appliance if cord or appliance shows any signs of damage. All repairs should be made by a competent qualified electrician*
Only use the appliance for domestic purposes and in the way indicated in these instructions.
Never immerse the appliance in water or any other liquid for any reason whatsoever. Never place it into the dishwasher.
Never use the appliance near hot surfaces.
Before cleaning or storing the appliance, always unplug the appliance from the power supply and let it cool down.
Never use the appliance outside and always place it in a dry environment.
Never use accessories that are not recommended by the producer. They could constitute a danger to the user and risk to damage the appliance.
Never move the appliance by pulling the cord. Stand the appliance on a table or flat surface. Make sure the cord cannot get caught in any way. Do not wind the cord around the appliance and do not bend it.
Do not use your appliance if the jug is cracked or broken. Use only the jug delivered with your appliance. Caution: your jug becomes hot during use, always use the handle to take it.
Never touch the hot parts of the appliance (be careful, also the warming plate is a hot part!), only touch the plastic parts and take the jug by the handle.
Make sure the appliance never comes into contact with inflammable materials such as curtains, textiles, ... when it is in use as they might catch fire.
When removing lime scale, only use special products for the removal of lime scale. Never use ammonia or any other substance that might damage your health.
Only put ground coffee in the filter.
Never use your coffee maker without water in it. If you have a programmable coffee maker, make sure to fill it with water before programming it.
Important: never put the jug in a microwave oven to warm up the coffee. We will not take any responsibility if you do so.

Competent qualified electrician: after sales department of the producer or importer or any person who is qualified, approved and competent to perform this kind of repairs in order to avoid all danger. In any case you should return the appliance to this electrician.

INITIAL OPERATION

When you use your appliance for the first time, pour fresh water into the water tank (without coffee) and switch on the appliance.

Once all the water has passed through, switch the appliance off and let it cool down. When it is cold enough repeat the process with fresh water. Repeat this process 3 times.

PREPARATION OF COFFEE

• Open the lid of the water tank.
• Pour the desired amount of water into the water tank. Make sure not to overfill by respecting the maximum level indicated on the water tank.
• Open the lid of the filter holder, insert a paper filter or permanent filter (depending on the model) and add the desired quantity of ground coffee.
  Do not forget to close the lid of the jug before putting it on the heating plate.
• Never forget to close the lid of the water tank before switching on your coffee maker.
• Switch on the coffee maker. The pilot light of the switch will be illuminated, indicating that your appliance works.
• When you remove the jug from the appliance, a non-drip valve will automatically operate to stop any drops of coffee dripping onto the hotplate. Replacement of the jug automatically opens the non-drip valve and allows remaining coffee to filter trough into the jug.
• Wait until the brewing process is finished and the filter has run empty before removing the jug.

DECALCIFICATION AND CLEANING

• Decalcifying the coffee maker prolongs its life span. For decalcification only use products especially made for decalcification of coffee makers.
• Never use a dishwasher to clean the jug. Just clean it in soapsuds.
  To clean the plastic parts of the appliance, use a humid, non abrasive cloth.

PRACTICAL HINTS

When you notice that the coffee making process is longer than it should be it is probably time to decalcify the appliance. Do not wait until the situation gets worse. The decalcifying frequency depends on the amount of lime in water and therefore can be different from family to family. Therefore it is important to pay attention to this. A good maintenance of your appliance will prolong its lifespan. Guarantee claims will not be accepted for the replacement of a heating element full of scale.

PROTECTION OF THE ENVIRONMENT-DIRECTIVE 2002/96/EC

In order to preserve our environment and protect human health, the waste electrical and electronic equipment should be disposed of in accordance with specific rules with the

implication of both suppliers and users. For this reason, as indicated by the symbol the rating label or on the packaging, your appliance should not be disposed of as unsorted municipal waste. The user has the right to bring it to a municipal collection point performing waste recovery by means of reuse, recycling or use for other applications in accordance with the directive.

FR MODE D'EMPLOI

POUR VOTRE SECURITE
