KZ1218 - Coffee machine TRISTAR - Free user manual and instructions

Product type	Manual filter coffee maker
Brand	Tristar
Model	KZ1218
Capacity	Approximately 1.2 L (10 cups)
Power supply	220-240 V ~ 50/60 Hz
Power	Approximately 900 W
Approximate dimensions	25 x 18 x 30 cm
Approximate weight	1.5 kg
Filter type	Paper filter or permanent filter included
Carafe	Glass with handle, graduations
Hot plate	Yes, keep warm
Anti-drip valve	Yes, automatic
Control	On/Off with red indicator light
Water level indicator	Graduated gauge on the reservoir
Housing material	Plastic
Color	Not specified (typically black or white)
Maintenance	Regular descaling with vinegar or special product; clean with a damp cloth
Dishwasher safe	No, no parts are dishwasher safe
Power cord length	Approximately 70 cm
Safety	Automatic shut-off at end of cycle, do not use without water
Spare parts available	Carafe, permanent filter, filter holder (subject to availability)
Repairability	Repair by an authorized qualified service
Warranty	Not specified (typically 2 years)

Frequently Asked Questions - KZ1218 TRISTAR

How to use the TriStar KZ1218 coffee maker for the first time?

Before first use, fill the reservoir with cold water without coffee, then turn on the appliance. Let the water run through, turn off, wait 5 minutes and repeat. This cleans the appliance.

What is the maximum water capacity of the reservoir?

The reservoir can hold up to 1.2 liters of water, corresponding to about 10 cups. Do not exceed the max mark on the gauge.

Can I use a permanent filter instead of paper filters?

Yes, the coffee maker comes with a permanent filter. You can also use standard paper filters of the appropriate size.

How to turn the coffee maker on and off?

Press the START button to turn on the coffee maker; the red light comes on. To turn off, press the same button again; the light goes out.

Can the carafe stay on the hot plate after brewing?

Yes, the hot plate keeps the coffee warm as long as the appliance is on. It starts heating as soon as it is turned on.

How to clean the TriStar KZ1218 coffee maker?

Unplug the appliance and let it cool down. Clean the exterior with a damp cloth. Never immerse the coffee maker in water and do not put any parts in the dishwasher. The permanent filter can be rinsed with clean water.

How often should I descale my coffee maker?

It is recommended to descale regularly, about every 1 to 2 months depending on water hardness. Use white vinegar or a special coffee maker descaler, following the product instructions.

What to do if the coffee maker does not turn on?

Check that the appliance is plugged in and the outlet works. Ensure the reservoir has water and the carafe is properly positioned. If the problem persists, contact a qualified service.

Can I use the coffee maker without the carafe?

No, the carafe must always be in place during operation to prevent burns and spills. The anti-drip valve closes if you remove the carafe, but it is not recommended to operate the appliance without it.

Where can I find spare parts for the KZ1218 coffee maker?

Contact TriStar customer service or an authorized dealer. Common parts like the glass carafe or permanent filter can be ordered separately.

USER MANUAL KZ1218 TRISTAR

Exterior view of a modern coffee maker with clear glass and black lid (no text or symbols visible)

KZ - 1218

NE

Please read these instructions carefully before using the appliance.

➢ Check that your mains voltage corresponds to that stated on the appliance.
➢ Never leave the appliance unsupervised when in use. Keep out of reach of children or incompetent persons.
From time to time check the cord for damages. Never use the appliance if cord or appliance show any signs of damage.
Only use the appliance for domestic purposes and in the way indicated in these instructions.
➢ Never immerse the appliance in water or any other liquid for any reason whatsoever. Never place it into the dishwasher.
➢ Never use the appliance near hot surfaces.
➢ Should the cord be damaged, it must be replaced by a competent qualified electrician (*).
Before cleaning, always unplug the appliance from the power supply.
All repairs should be made by a competent qualified electrician*
➢ Never use the appliance outside and always place it in a dry environment.
➢ Never use accessories which are not recommended by the producer. They could constitute a danger to the user and risk to damage the appliance.
➢ Never move the appliance by pulling the cord. Make sure the cord cannot get caught in any way. Do not wind the cord around the appliance and do not bend it.
➢ Stand the appliance on a table or flat surface.
Only use fresh (potable) and cold (moderate) water. Do not use water, contained in bathtubs, washbasins or other recipients.
➢ Never use the appliance if the jug shows any signs of cracks. Only use the jug with this appliance. Handle with care as the glass is very fragile.
Make sure the appliance has cooled down before cleaning, storing or filling it. The appliance has to be switched off before filling it with water. Make sure never to overfill.
Make sure the cord never comes into contact with the hot parts of the appliance.
➢ Never touch the hot parts of the appliance (be careful, also the warming plate is a hot part!), only touch the plastic parts and take the jug by the handle.
➢ Be careful not to get burned by the steam evaporating from the coffee filter.
When removing lime scale, only use vinegar or a special product for the removal of lime scale. Never use ammonia or any other substance that might damage your health.
▶ Only put ground coffee in the filter.
➢ Never use your coffee machine without water in it
* Competent qualified electrician: after sales department of the producer or importer or any person who is qualified, approved and competent to perform this kind of repairs in order to avoid all danger. In any case you should return the appliance to this electrician.

INITIAL OPERATION

For a perfect taste, carry out 2 or 3 boil-processes with fresh water (without coffee). Once all the water has passed through, switch the appliance off and let it cool down during 5 minutes. Then repeat the process with fresh water.

MANUAL OPERATION

Pour the desired volume of water into the water reservoir. The number of cups can be read on the water level indicator.

Insert filter paper in the filter holder or use the permanent filter and add the desired quantity of ground coffee. Replace the filter holder.

To switch on, press the START button, the coffee maker will start working and the red pilot light will light on.

Make sure the carafe is placed correctly on the hotplate.

When you remove the carafe from this appliance, a non-drip valve will automatically operate to stop any drops of coffee dripping onto the hotplate. Replacement of the carafe automatically opens the non-drip valve and allows any remaining coffee to filter through into the carafe. Wait until the brewing process is finished and the filter is empty. To switch off the coffee machine, press the START button again. The red pilot light will go off to indicate that the coffeemaker has been switched off.

KEEPING THE COFFEE HOT

The carafe can remain on the hotplate, which begins to heat up as soon as the coffeemaker is switched on.

The hotplate will keep die coffee hot until the coffeemaker is switched off (red pilot light goes off).

DECALCIFICATION AND CLEANING

Decalcifying the coffee maker prolongs its life span. For decalcification only use products especially made for decalcification of coffee makers. Never use a dishwasher to clean the jug.

\\\\\*

PORTUGUÊS

MÁQUINA DE CAFÉ COM FILTRO (INOX)

IMPORTANTES MEDIDAS DE SEGURANÇA

Guidelines for protection of the environment

Symbol of a trash bin crossed with no text or labels, accompanied by a black rectangular block below (no readable text or symbols)

This appliance should not be put into the domestic garbage at the end of its useful life, but must be disposed of at a central point for recycling of electric and electronic domestic appliances. This symbol on appliance, instruction manual and packaging puts your attention to this important issue. The materials used in this appliance can be recycled. By recycling used domestic appliances you contribute an important push to the protection of our environment. Ask your local authorities for information regarding the point of recollection..

Symbol of a trash bin with crossed lines indicating no waste or restriction, accompanied by a black rectangular block below (no text or labels)
