USER MANUAL DO2831G DOMO

CONDITIONS DE GARANTIE

This appliance has a two year warranty period. During this period the manufacturer is responsible for any failures which are the direct result of construction failure. When these failures occur the appliance will be repaired or replaced if necessary. The warranty will not be valid when the damage to the appliance is caused by wrong use, not following the instructions or repairs executed by a third party. The warranty will only be valid if the warranty application has been completed by the dealer at the time of purchase. All parts, such as brushes and batteries, which are subject to wear, are excluded from the warranty.

	DO2831G
Type nr. Apparaat
N° de modèle de l'appareil DO2831G
Type nr des Gerätes
Type nr. of appliance
Naam
Nom
Name
Name
Adres
Adresse
Adresse
Address

Aankoopdatum

Date d'achat

Kaufdatum

Date of purchase

RECYCLAGE INFORMATIE

RECYCLING INFORMATIONEN

RECYCLING INFORMATION

The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall be brought to the applicable collection point for recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling of this product, please contact your local city office, your household waste disposal service or the shop where you purchased the product.

INSTALLATIE VAN DE MICROGOLFOVEN

1) To ensure sufficient ventilation, the distance should be at least 10cm , side of oven to the wall, the top of oven to the ceiling or cabinet should
2) Do not place any object on the top of oven.
3) The position of the oven shall be such that it picture disturbance or noise may occur
3) The oven shall be so installed that the plug is

of back of oven to the wall or cabinet. Wall or cabinet should be at least 20~cm be at least 20~cm .

is far from the TV, Radio or antenna as accessible.

UTENSILS GUIDE

Material of container Micro

Heat resistant glass Yes
Ceramic Yes
Normal glass No
Heat resistant plastic Yes
Normal_plastic No
Plastic film Yes
Metal dish No

1. Safety lock
2. Viewing window
3. Glass turntable
4. Timer
5. Control button
6. button opening door

4

5

Notes:

3

6

1. The oven cannot be activated without the door properly closed. This is a safety feature, never intend to damage it.

IMPORTANT SAFEGUARDS

appliance:

1. Read all instructions before using.
2. Make sure the voltage in your living area corresponding to the one shown on the rating label of the appliance. And the wall socket is properly grounded.
3. To reduce the risk of fire in the oven cavity:

A. Do not overcook the food.
B. Remove wire twist-ties from paper or plastic bags before placing bags in the oven.
C. Do not heat oil or fat for deep drying as the temperature of oil cannot be controlled.

D. After use wipe the waveguide cover with remove any food splashes and grease. B to cause smoke or catch fire.
E. If materials inside the oven should smok oven off and disconnect the power supp
G. Close supervision is necessary when using paper or other combustible material.

In a damp cloth, followed by dry cloth to.
uilt-up grease may overheat and begin
le or ignite, keep oven door closed, turn
y.

disposable containers made from plastic,

1. To reduce the risk of explosion and sudden

A. Do not place sealed containers in the oven or teat are considered to be sealed conta
B. When boiling liquid in the oven, use about 20 seconds at the end of cooking liquids.

boiling:

en. Baby bottles fitted with a screw cap funers.

the wide-mouthed container and sta to avoid delayed eruptive boiling of

1. Never operate the oven further if the door is damaged or the oven malfunction or supply cord is damaged. Return the appliance to the nearest authorised service centre for repair and maintenance. Never try to adjust or repair the oven yourself.
2. If the supply cord is damaged it must be replaced by the manufacturer or its service agent or a qualified technician in order to avoid a shock hazard.
3. After cooking, the container is very hot. Using gloves to take out the food and avoist steam burns by directing steam away from the face and hands.
4. Slowly lift the furthest edge of dishes cover and microwave plastic wrap and carefully open popcorn and oven cooking bags away from the face.
5. To prevent the turntable from breaking

A. Let the turntable cool down before cleaning.
B. Do not place hot foods or utensils on the cold turntable.
C. Do not place frozen foods or utensils on the hot turntable.

1. Make sure the utensils do not touch the interior walls during cooking.
2. Do not store food or any other things inside the oven.
3. Do not operate the oven without any liquid or food inside the oven. This would do damage the oven.
4. This appliance is not intended for use by young children or infirm persons without supervision.
5. Only allow children to use the oven without supervision when adequate instructions have been given so that the child is able to use the oven in a safe way and understand the hazards of improper use.
6. Any accessories not recommended by the manufacturer may cause injuries to persons.
7. Do not use outdoors.
8. Eggs with shell, Full hard boiled eggs, potatoes, sausages, chestnuts needs to be peeled or pierced before cooking.
9. The contents of feeding bottles and baby food jars are to be stirred or shaken and the temperature is to be checked before consumption, in order to avoid burns.
10. Save these instructions.

Maximum time is 30 minutes.

1. Function control knob

Your micro wave oven has 9 different power levels :

MICROWAVE

1.High : 100% of the power is used, can be used
2. M. High : 85% of the power is uded
3. Med : 66% of power use, for slow cooking
4. M. low: 40% of te power is used.
5. Defrost: 37% of the power is used, for defrosting food.
6. Low: 17% of the power is used, can be used for keeping warm.
d for fast cooking.

GRILL

grill : only the heating element is used. Can be used for the roasting of meat, poultry or sandwiches.

combinaion 1 : combination of 30% microwave and 70% grill.

For the preparation of sandwiches or chops.

combination 2 : combination of 49% microwave and 51% grill

For the preparation of small chicken or meat.

combination 3 : combinatio, of67 % microwave and 33% grill.

For the preparation of large chicken, duck, etc.

COOKING PROCEDURE

Put the plug in the power socket.

Place the food on the glass turntable and close the door

Choose the desired power level with the function control knob.

Adjust the timer. When you want to use the timer for less than 2 minutes, you first need to turn the timer passed 3 minutes and then turn it back to the desired time.

The oven will turn on. The operation can be stopped at anytime by opening the door.

When closing the door, the oven will start operating again

A bel signal will be heard when the selected time has passed.

Attention : when you remove the food out of the oven before the bel signal, make sure to turn the timer to “0”. This is to prevent the oven to start operating again without food in it.

We recommend to use oven gloves when removing cooked food from the oven. Remarks when defrosting food:

The defrost function is one of the possibilities of your oven. This is safer than defrosting at room temperature, this way you'll prevent the development of harmful

DO2831C

bacteria.

1. Turn the function control knob to the "defrost 2. Select the time, depending on the frozen food time than normal cooking. Turn over the food a the doneness. When you can cut the frozen foo enough.

CLEANING AND MAINTENANCE

Below steps are recommended after each use. Never use any scoring pads, or aggressive cle Remove the plug from the socket and let the ov Remove the turning ring and turntable and cle Use a soft moist cloth to clean the door, the ins When oil or soap has been spilled in the micro otherwise smoke can occur during the next use.

ners to clean the oven. en cool down completely. n them in warm soapy water. ide , the outside and the control panel wave oven this must be cleaned up,

When the inside of the micro wave oven has a bad small you can put a cup of water in it with a bit of lemon and let this boil inside the micro wave for about 5-7 minutes. This will most likely remove the bad smell.

Dry all parts thoroughly and place them back in the oven.

REPAIR

All repairs can only be done by a qualified person. Don't ever try to repair your micro wave you run the risk of being exposed to micro wave, which can be hazardous for your health.
