USER MANUAL G41MHUSB3 R2.0 ASROCK

No part of this installation guide may be reproduced, transcribed, transmitted, or trans-

lated in any language, in any form or by any means, except duplication of documentation

by the purchaser for backup purpose, without written consent of ASRock Inc.

Products and corporate names appearing in this guide may or may not be registered

trademarks or copyrights of their respective companies, and are used only for identifi ca-

tion or explanation and to the owners’ benefi t, without intent to infringe.

Specifi cations and information contained in this guide are furnished for informational use

only and subject to change without notice, and should not be constructed as a commit-

ment by ASRock. ASRock assumes no responsibility for any errors or omissions that may

appear in this guide.

With respect to the contents of this guide, ASRock does not provide warranty of any kind,

either expressed or implied, including but not limited to the implied warranties or condi-

tions of merchantability or fi tness for a particular purpose. In no event shall ASRock, its

directors, offi cers, employees, or agents be liable for any indirect, special, incidental, or

consequential damages (including damages for loss of profi ts, loss of business, loss of

data, interruption of business and the like), even if ASRock has been advised of the pos-

sibility of such damages arising from any defect or error in the guide or product.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY The Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see

www.dtsc.ca.gov/hazardouswaste/perchlorate”

The terms HDMI™ and HDMI High-Defi nition Multimedia Interface, and the HDMI logo

are trademarks or registered trademarks of HDMI Licensing LLC in the United States and

11 South Bridge Controller 27 Internal Audio Connector: CD1 (Black)

I/O PI/O P I/O PI/O P I/O P

anel LAN PortACT/LINK LEDSPEED LED * There are two LED next to the LAN port. Please refer to the table below for the LAN port LED

LAN Port LED Indications

Activity/Link LED SPEED LED Status Description Status Description

Off No Link Off 10Mbps connection

Blinking Data Activity Orange 100Mbps connection

On Link Green 1Gbps connection 1 PS/2 Mouse Port (Green *** 7 USB 3.0 Ports (USB23)2 VGA/D-Sub Port 8 USB 2.0 Ports (USB01) * 3 LAN RJ-45 Port 9 HDMI Port 4 Line In (Light Blue) 10 VGA/DVI-D Port

** 5 Front Speaker (Lime) 11 PS/2 Keyboard Port (Purple) 6 Microphone (Pink) *** Please do not connect USB Keyboard and Mouse on USB 3.0 ports. Besides, USB 3.0 ports

do not support Wake Up function.

** To enable Multi-Streaming function, you need to connect a front panel audio cable to the front

panel audio header. After restarting your computer, you will find “VIA HD Audio Deck” tool on

your system. Please follow below instructions according to the OS you install.

Please click “VIA HD Audio Deck” icon , and click “Speaker”. Then you are allowed to

select “2 Channel” or “4 Channel”. Click “Power” to save your change.

Please click “VIA HD Audio Deck” icon , and click “Advanced Options” on the left side

on the bottom. In “Advanced Options” screen, select “Independent Headphone”, and click

“OK” to save your change.44

Thank you for purchasing ASRock G41MH/USB3 R2.0 motherboard, a reliable moth-

erboard produced under ASRock’s consistently stringent quality control. It delivers

excellent performance with robust design conforming to ASRock’s commitment to

quality and endurance.

This Quick Installation Guide contains introduction of the motherboard and step-by-step

installation guide. More detailed information of the motherboard can be found in the user

manual presented in the Support CD. Because the motherboard specifications and the BIOS software mightbe updated, the content of this manual will be subject to change withoutnotice. In case any modifications of this manual occur, the updatedversion will be available on ASRock website without further notice. Youmay find the latest VGA cards and CPU support lists on ASRock website as well. ASRock website http://www.asrock.com If you require technical support related to this motherboard, please visitour website for specific information about the model you are using.www.asrock.com/support/index.asp 1.1 Package Contents1.1 Package Contents

1.1 Package Contents1.1 Package Contents

1.1 Package Contents

(Micro ATX Form Factor: 9.6-in x 8.4-in, 24.4 cm x 21.3 cm)

ASRock G41MH/USB3 R2.0 Quick Installation Guide

ASRock G41MH/USB3 R2.0 Support CD Two Serial ATA (SATA) Data Cables (Optional)

One I/O Panel Shield55

Platform - Micro ATX Form Factor: 9.6-in x 8.4-in, 24.4 cm x 21.3 cm

- Solid Capacitor for CPU power

CPU - LGA 775 for Intel

supporting Penryn Quad Core Yorkfield and Dual Core

- Supports FSB1333/1066/800/533 MHz

- Supports Hyper-Threading Technology (see CAUTION 1)

- Supports Untied Overclocking Technology (see CAUTION 2)

- Supports EM64T CPU Chipset - Northbridge: Intel

Memory - Dual Channel DDR3 Memory Technology (see CAUTION 3)

- 2 x DDR3 DIMM slots

- Support DDR3 1333(OC)/1066/800 non-ECC, un-buffered

memory (see CAUTION 4)

- Max. capacity of system memory: 8GB (see CAUTION 5)

- Pixel Shader 4.0, DirectX 10

- Max. shared memory 1759MB (see CAUTION 6)

- Three VGA Output options: D-Sub, DVI-D and HDMI

- Supports HDMI Technology with max. resolution up to

- Supports DVI with max. resolution up to 1920x1200 @ 75Hz

- Supports D-Sub with max. resolution up to 2048x1536

- Supports HDCP function with DVI and HDMI ports

- Supports Full HD 1080p Blu-ray (BD) / HD-DVD playback with

- Supports Wake-On-LAN

- Supports LAN Cable Detection

- Supports Energy Efficient Ethernet 802.3az

Rear Panel I/O I/O Panel

- 1 x PS/2 Keyboard Port

- 1 x VGA/DVI-D Port

- 2 x Ready-to-Use USB 2.0 Ports

- 2 x Ready-to-Use USB 3.0 Ports

- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)

- HD Audio Jack: Line in/Front Speaker/Microphone

USB 3.0 - 2 x USB 3.0 ports by ASMedia ASM1042, support USB 1.0/

Connector - 4 x SATAII 3.0 Gb/s connectors (No Support for RAID and

- CPU/Chassis/Power FAN connector

- 24 pin ATX power connector

- 4 pin 12V power connector

- Front panel audio connector

BIOS Feature - 8Mb AMI BIOS

- Supports “Plug and Play”

- ACPI 1.1 Compliance Wake Up Events

- Supports jumperfree

- AMBIOS 2.3.1 Support

- Supports I. O. T. (Intelligent Overclocking Technology)

Support CD - Drivers, Utilities, AntiVirus Software (Trial Version), CyberLink

MediaEspresso 6.5 Trial, ASRock Software Suite (CyberLink

DVD Suite - OEM and Trial; Creative Sound Blaster X-Fi MB -

1. About the setting of “Hyper Threading Technology”, please check page 37

of “User Manual” in the support CD.

2. This motherboard supports Untied Overclocking Technology. Please read

“Untied Overclocking Technology” on page 23 for details.

3. This motherboard supports Dual Channel Memory Technology. Before you

implement Dual Channel Memory Technology, make sure to read the

installation guide of memory modules on page 13 for proper installation.

4. Please check the table below for the CPU FSB frequency and its

corresponding memory support frequency.

CPU FSB Frequency Memory Support Frequency

1333 DDR3 800, DDR3 1066, DDR3 1333

* When you use a FSB533-CPU on this motherboard, it will run at

DDR3 533 if you adopt a DDR3 800 memory module.

WARNING Please realize that there is a certain risk involved with overclocking, including adjusting

the setting in the BIOS, applying Untied Overclocking Technology, or using the third-

party overclocking tools. Overclocking may affect your system stability, or even

cause damage to the components and devices of your system. It should be done at

your own risk and expense. We are not responsible for possible damage caused by

- ASRock APP Charger (see CAUTION 12)

- ASRock XFast USB (see CAUTION 14)

- CPU Frequency Stepless Control (see CAUTION 15)

- ASRock U-COP (see CAUTION 16)

- Boot Failure Guard (B.F.G.)

XP / XP 64-bit compliant

Certifications - FCC, CE, WHQL

- ErP/EuP Ready (ErP/EuP ready power supply is required)

* For detailed product information, please visit our website: http://www.asrock.com88

5. Due to the operating system limitation, the actual memory size may be

less than 4GB for the reservation for system usage under Windows

OS with 64-bit CPU, there is no such limitation.

6. The maximum shared memory size is defined by the chipset vendor and

is subject to change. Please check Intel

website for the latest information.

7. Before installing SATAII hard disk to SATAII connector, please read the

“SATAII Hard Disk Setup Guide” on page 27 of “User Manual” in the support

CD to adjust your SATAII hard disk drive to SATAII mode. You can also

connect SATA hard disk to SATAII connector directly.

8. It is a user-friendly ASRock overclocking tool which allows you to surveil

your system by hardware monitor function and overclock your hardware

devices to get the best system performance under Windows

Please visit our website for the operation procedures of ASRock OC Tuner. ASRock website: http://www.asrock.com

9. Featuring an advanced proprietary hardware and software design,

Intelligent Energy Saver is a revolutionary technology that delivers

unparalleled power savings. In other words, it is able to provide exceptional

power saving and improve power efficiency without sacrificing computing

performance. Please visit our website for the operation procedures of

Intelligent Energy Saver.

ASRock website: http://www.asrock.com

10. ASRock Instant Flash is a BIOS flash utility embedded in Flash ROM.

This convenient BIOS update tool allows you to update system BIOS

without entering operating systems first like MS-DOS or Windows

this utility, you can press <F6> key during the POST or press <F2> key to

BIOS setup menu to access ASRock Instant Flash. Just launch this tool

and save the new BIOS file to your USB flash drive, floppy disk or hard

drive, then you can update your BIOS only in a few clicks without prepar-

ing an additional floppy diskette or other complicated flash utility. Please

be noted that the USB flash drive or hard drive must use FAT32/16/12 file

11. The software name itself – OC DNA literally tells you what it is capable of.

OC DNA, an exclusive utility developed by ASRock, provides a conve-

nient way for the user to record the OC settings and share with others. It

helps you to save your overclocking record under the operating system

and simplifies the complicated recording process of overclocking settings.

With OC DNA, you can save your OC settings as a profile and share with

your friends! Your friends then can load the OC profile to their own system

to get the same OC settings as yours! Please be noticed that the OC

profile can only be shared and worked on the same motherboard.

12. If you desire a faster, less restricted way of charging your Apple devices,

such as iPhone/iPod/iPad Touch, ASRock has prepared a wonderful

solution for you - ASRock APP Charger. Simply installing the APP Charger

driver, it makes your iPhone charged much quickly from your computer

and up to 40% faster than before. ASRock APP Charger allows you to

quickly charge many Apple devices simultaneously and even supports99

continuous charging when your PC enters into Standby mode (S1), Sus-

pend to RAM (S3), hibernation mode (S4) or power off (S5). With APP Charger driver installed, you can easily enjoy the marvelous charging

experience than ever.

ASRock website: http://www.asrock.com/Feature/AppCharger/index.asp

13. SmartView, a new function of internet browser, is the smart start page for

IE that combines your most visited web sites, your history, your Facebook

friends and your real-time newsfeed into an enhanced view for a more

personal Internet experience. ASRock motherboards are exclusively

equipped with the SmartView utility that helps you keep in touch with

friends on-the-go. To use SmartView feature, please make sure your OS

64 bit, and your browser

ASRock website: http://www.asrock.com/Feature/SmartView/index.asp

14. ASRock XFast USB can boost USB storage device performance. The

performance may depend on the property of the device.

15. Although this motherboard offers stepless control, it is not recommended

to perform over-clocking. Frequencies other than the recommended CPU

bus frequencies may cause the instability of the system or damage the

16. While CPU overheat is detected, the system will automatically shutdown.

Before you resume the system, please check if the CPU fan on the

motherboard functions properly and unplug the power cord, then plug it

back again. To improve heat dissipation, remember to spray thermal

grease between the CPU and the heatsink when you install the PC system.

17. EuP, stands for Energy Using Product, was a provision regulated by European

Union to define the power consumption for the completed system. According

to EuP, the total AC power of the completed system shall be under 1.00W in

off mode condition. To meet EuP standard, an EuP ready motherboard and an

EuP ready power supply are required. According to Intel’s suggestion, the EuP

ready power supply must meet the standard of 5v standby power efficiency

is higher than 50% under 100 mA current consumption. For EuP ready power

supply selection, we recommend you checking with the power supply manu-

facturer for more details.1010

Pre-installation PrecautionsPre-installation Precautions

Pre-installation PrecautionsPre-installation Precautions

Pre-installation Precautions

Take note of the following precautions before you install mother-

board components or change any motherboard settings.

1. Unplug the power cord from the wall socket before touching any

component. Failure to do so may cause severe damage to the

motherboard, peripherals, and/or components.

2. To avoid damaging the motherboard components due to static

electricity, NEVER place your motherboard directly on the carpet

or the like. Also remember to use a grounded wrist strap or touch

a safety grounded object before you handle components.

3. Hold components by the edges and do not touch the ICs.

4. Whenever you uninstall any component, place it on a grounded

antstatic pad or in the bag that comes with the component.

5. When placing screws into the screw holes to secure the

motherboard to the chassis, please do not over-tighten the

screws! Doing so may damage the motherboard.

For the installation of Intel 775-LAND CPU,

please follow the steps below. Before you insert the 775-LAND CPU into the socket, please check ifthe CPU surface is unclean or if there is any bent pin on the socket.Do not force to insert the CPU into the socket if above situation isfound. Otherwise, the CPU will be seriously damaged.775-Pin Socket Overview1111

Step 1. Open the socket:

Step 1-1. Disengaging the lever by depressing

down and out on the hook to clear

Step 1-2. Rotate the load lever to fully open po-

sition at approximately 135 degrees.

Step 1-3. Rotate the load plate to fully open po-

sition at approximately 100 degrees.

Step 2. Insert the 775-LAND CPU:

Step 2-1. Hold the CPU by the edges where are

marked with black lines.

Step 2-2. Orient the CPU with IHS (Integrated

Heat Sink) up. Locate Pin1 and the two

orientation key notches.

For proper inserting, please ensure to match the two orientation key

notches of the CPU with the two alignment keys of the socket.

Step 2-3. Carefully place the CPU into the socket

by using a purely vertical motion.

Step 2-4. Verify that the CPU is within the socket

and properly mated to the orient keys.

Step 3. Remove PnP Cap (Pick and Place Cap):

Use your left hand index finger and thumb to

support the load plate edge, engage PnP cap

with right hand thumb and peel the cap from the

socket while pressing on center of PnP cap to

assist in removal. black lineblack line 775-Pin Socket

1. It is recommended to use the cap tab to handle and avoid kicking

2. This cap must be placed if returning the motherboard for after

Step 4. Close the socket:

Step 4-1. Rotate the load plate onto the IHS.

Step 4-2. While pressing down lightly on load

plate, engage the load lever.

Step 4-3. Secure load lever with load plate tab

under retention tab of load lever.

Installation of CPU Fan and HeatsinkInstallation of CPU Fan and Heatsink

Installation of CPU Fan and HeatsinkInstallation of CPU Fan and Heatsink

Installation of CPU Fan and Heatsink

For proper installation, please kindly refer to the instruction manuals of your CPU fan

Below is an example to illustrate the installation of the heatsink for 775-LAND CPU.

Step 1. Apply thermal interface material onto center

of IHS on the socket surface.

Step 2. Place the heatsink onto the socket. Ensure

fan cables are oriented on side closest to the

CPU fan connector on the motherboard

(CPU_FAN1, see page 2, No. 1).

Step 3. Align fasteners with the motherboard

Step 4. Rotate the fastener clockwise, then press

down on fastener caps with thumb to install

and lock. Repeat with remaining fasteners.

If you press down the fasteners without rotating them clockwise,

the heatsink cannot be secured on the motherboard.

Step 5. Connect fan header with the CPU fan

connector on the motherboard.

Step 6. Secure excess cable with tie-wrap to ensure

cable does not interfere with fan operation or

2.3 Installation of Memory Modules (DIMM)

G41MH/USB3 R2.0 motherboard provides two 240-pin DDR3 (Double Data Rate 3)

DIMM slots, and supports Dual Channel Memory Technology. For dual channel

configuration, you always need to install two identical (the same brand, speed,

size and chip-type) memory modules in the DDR3 DIMM slots to activate Dual Channel

Memory Technology. Otherwise, it will operate at single channel mode.

1. It is not allowed to install a DDR or DDR2 memory module into

DDR3 slot;otherwise, this motherboard and DIMM may be damaged.

2. If you install only one memory module or two non-identical memory

modules, it is unable to activate the Dual Channel Memory Technology.

Installing a DIMMInstalling a DIMM Installing a DIMMInstalling a DIMM Installing a DIMM Please make sure to disconnect power supply before adding or

removing DIMMs or the system components.

Step 1. Unlock a DIMM slot by pressing the retaining clips outward.

Step 2. Align a DIMM on the slot such that the notch on the DIMM matches the break

The DIMM only fits in one correct orientation. It will cause permanent

damage to the motherboard and the DIMM if you force the DIMM into the

slot at incorrect orientation.

Step 3. Firmly insert the DIMM into the slot until the retaining clips at both ends fully

snap back in place and the DIMM is properly seated.1414

2.4 Expansion Slots (PCI and PCI Express Slots)2.4 Expansion Slots (PCI and PCI Express Slots)

2.4 Expansion Slots (PCI and PCI Express Slots)

There are 2 PCI slots and 2 PCI Express slots on this motherboard.

PCI slots: PCI slots are used to install expansion cards that have the 32-bit PCI

PCIE1 (PCIE x1 slot) is used for PCI Express cards with x1 lane width

cards, such as Gigabit LAN card, SATA2 card, etc.

PCIE2 (PCIE x16 slot) is used for PCI Express cards with x16 lane

width graphics cards.

If you install the add-on PCI Express VGA card or other PCIE device to PCIE2

(PCIE x16 slot), only D-Sub port will be enabled. DVI-D and HDMI ports will

Installing an expansion cardInstalling an expansion card

Installing an expansion cardInstalling an expansion card

Installing an expansion card

Step 1. Before installing the expansion card, please make sure that the power

supply is switched off or the power cord is unplugged. Please read the

documentation of the expansion card and make necessary hardware

settings for the card before you start the installation.

Step 2. Remove the bracket facing the slot that you intend to use. Keep the screws

Step 3. Align the card connector with the slot and press firmly until the card is

completely seated on the slot.

Step 4. Fasten the card to the chassis with screws.1515

2. If you have installed onboard VGA driver from our support CD to your system

already, you can freely enjoy the benefits of dual monitor function after your

system boots. If you haven’t installed onboard VGA driver yet, please install

onboard VGA driver from our support CD to your system and restart your

1. D-Sub, DVI-D and HDMI ports cannot be connected simultaneously.

You can choose to use two of them only.

2. When you playback HDCP-protected video from Blu-ray (BD) or

HD-DVD disc, the content will be displayed only in one of the monitors.

2.5 Dual Monitor Feature2.5 Dual Monitor Feature

2.5 Dual Monitor Feature2.5 Dual Monitor Feature

2.5 Dual Monitor Feature

This motherboard supports dual monitor feature. With the internal VGA output

support (DVI-D, D-Sub and HDMI), you can easily enjoy the benefits of dual monitor

feature without installing any add-on VGA card to this motherboard. This

motherboard also provides independent display controllers for DVI-D, D-Sub and

HDMI to support dual VGA output so that DVI-D, D-sub and HDMI can drive same or

different display contents.

To enable dual monitor feature, please follow the below steps:

1. Connect DVI-D monitor cable to VGA/DVI-D port on the I/O panel, connect D-Sub

monitor cable to VGA/D-Sub port on the I/O panel, or connect HDMI monitor

cable to HDMI port on the I/O panel.

Right click the desktop, choose “Properties”, and select the “Settings” tab

so that you can adjust the parameters of the dual-monitor according to the

A. Click the “Identify” button to display a large number on each monitor.

B. Right-click the display icon in the Display Properties dialog that you wish

to be your primary monitor, and then select “Primary”. When you use

multiple monitors with your card, one monitor will always be Primary,

and all additional monitors will be designated as Secondary.

C. Select the display icon identified by the number 2.

D. Click “Extend my Windows desktop onto this monitor”.

E. Right-click the display icon and select “Attached”, if necessary.

F. Set the “Screen Resolution” and “Color Quality” as appropriate for the

second monitor. Click “Apply” or “OK” to apply these new values.

G. Repeat steps C through E for the diaplay icon identified by the number

Right click the desktop, choose “Personalize”, and select the “Display

Settings” tab so that you can adjust the parameters of the dual-monitor

according to the steps below.

A. Click the number ”2” icon.

B. Click the items “This is my main monitor” and “Extend the desktop onto

C. Click “OK” to save your change.

D. Repeat steps A through C for the display icon identified by the number

6. Use Daul Monitor. Click and drag the display icons to positions representing

the physical setup of your monitors that you would like to use. The placement

of display icons determines how you move items from one monitor to another.1717

HDCP function is supported on this motherboard. To use HDCP

function with this motherboard, you need to adopt the monitor that

supports HDCP function as well. Therefore, you can enjoy the

superior display quality with high-definition HDCP encryption

contents. Please refer to below instruction for more details about

HDCP stands for High-Bandwidth Digital Content Protection, a

specification developed by Intel

for protecting digital entertainment

content that uses the DVI interface. HDCP is a copy protection

scheme to eliminate the possibility of intercepting digital data

midstream between the video source, or transmitter - such as a

computer, DVD player or set-top box - and the digital display, or

receiver - such as a monitor, television or projector. In other words,

HDCP specification is designed to protect the integrity of content as it

is being transmitted.

Products compatible with the HDCP scheme such as DVD players,

satellite and cable HDTV set-top-boxes, as well as few entertain-

ment PCs requires a secure connection to a compliant display. Due

to the increase in manufacturers employing HDCP in their equipment,

it is highly recommended that the HDTV or LCD monitor you purchase

2.6 Jumpers Setup2.6 Jumpers Setup

2.6 Jumpers Setup2.6 Jumpers Setup

The illustration shows how jumpers are

setup. When the jumper cap is placed on

pins, the jumper is “Short”. If no jumper cap

is placed on pins, the jumper is “Open”. The

illustration shows a 3-pin jumper whose pin1

and pin2 are “Short” when jumper cap is

placed on these 2 pins.

Jumper Setting Description

(CLRCMOS1, 2-pin jumper)

Note: CLRCMOS1 allows you to clear the data in CMOS. The data in CMOS includes

system setup information such as system password, date, time, and system

setup parameters. To clear and reset the system parameters to default setup,

please turn off the computer and unplug the power cord from the power

supply. After waiting for 15 seconds, use a jumper cap to short 2 pins on

CLRCMOS1 for 5 seconds.

ASRock G41MH/USB3 R2.0 Motherboard

2.7 Onboard Headers and Connectors2.7 Onboard Headers and Connectors

2.7 Onboard Headers and Connectors2.7 Onboard Headers and Connectors

2.7 Onboard Headers and Connectors

Onboard headers and connectors are NOT jumpers. Do NOT place

jumper caps over these headers and connectors. Placing jumper caps

over the headers and connectors will cause permanent damage of the

FDD connector (33-pin FLOPPY1)(see p.2 No. 23) Note: Make sure the red-striped side of the cable is plugged into Pin1 side of the

Primary IDE connector (Blue) (39-pin IDE1, see p.2 No. 9) Note: Please refer to the instruction of your IDE device vendor for the details.

Serial ATAII Connectors These four Serial ATAII (SATAII) (SATAII_1: see p.11, No. 16) connectors support SATA data(SATAII_2: see p.11, No. 15) cables for internal storage(SATAII_3: see p.11, No. 13) devices. The current SATAII(SATAII_4: see p.11, No. 14) interface allows up to 3.0 Gb/s data transfer rate.

Serial ATA (SATA) Either end of the SATA data cable

Data Cable can be connected to the SATA /

(Optional) SATAII hard disk or the SATAII

connector on the motherboard.

USB 2.0 Headers Besides two default USB 2.0

(9-pin USB6_7) ports on the I/O panel, there are

(see p.2 No. 19) two USB 2.0 headers on this

motherboard. Each USB 2.0

header can support two USB

(5-pin IR1) optional wireless transmitting

(see p.2 No. 21) and receiving infrared module.

Print Port Header This is an interface for print

(25-pin LPT1) port cable that allows

(see p.2 No. 22) convenient connection of printer

Internal Audio Connectors This connector allows you

(4-pin CD1) to receive stereo audio input

(CD1: see p.2 No. 27) from sound sources such as

a CD-ROM, DVD-ROM, TV

tuner card, or MPEG card.

TPM Header This connector supports a

(17-pin TPM1) Trusted Platform Module (TPM)

(see p.2 No. 7) system, which can securely

store keys, digital certificates,

passwords, and data. A TPM

system also helps enhance

network security, protects

digital identities, and ensures

platform integrity.2121

System Panel Header This header accommodates

(9-pin PANEL1) several system front panel

(see p.2 No. 17) functions.

Chassis Speaker Header Please connect the chassis

(4-pin SPEAKER 1) speaker to this header.

CPU Fan Connector Please connect a CPU fan cable

(4-pin CPU_FAN1) to this connector and match

(see p.2 No. 1) the black wire to the ground pin.

Chassis and Power Fan Connectors Please connect the fan cables

(4-pin CHA_FAN1) to the fan connectors and

(see p.2 No. 8) match the black wire to the

Front Panel Audio Header This is an interface for front

(9-pin HD_AUDIO1) panel audio cable that allows

(see p.2 No. 29) convenient connection and

control of audio devices.

1. High Definition Audio supports Jack Sensing, but the panel wire on

the chassis must support HDA to function correctly. Please follow the

instruction in our manual and chassis manual to install your system.

2. If you use AC’97 audio panel, please install it to the front panel audio

A. Connect Mic_IN (MIC) to MIC2_L.

B. Connect Audio_R (RIN) to OUT2_R and Audio_L (LIN) to OUT2_L.

C. Connect Ground (GND) to Ground (GND).

D. MIC_RET and OUT_RET are for HD audio panel only. You don’t

need to connect them for AC’97 audio panel. 1 2 3 42222

ATX 12V Power Connector Please connect an ATX 12V

(4-pin ATX12V1) power supply to this connector.

20-Pin ATX Power Supply Installation

Though this motherboard provides 24-pin ATX power connector,

it can still work if you adopt a traditional 20-pin ATX power supply.

To use the 20-pin ATX power supply, please plug your

power supply along with Pin 1 and Pin 13.

ATX Power Connector Please connect an ATX power

(24-pin ATXPWR1) supply to this connector.

Though this motherboard provides 4-Pin CPU fan (Quiet Fan) support, the 3-Pin

CPU fan still can work successfully even without the fan speed control function.

If you plan to connect the 3-Pin CPU fan to the CPU fan connector on this

motherboard, please connect it to Pin 1-3.

3-Pin Fan Installation

Pin 1-3 Connected2323

Serial ASerial A Serial ASerial A Serial A TT TT T A (SAA (SA A (SAA (SA A (SA TT TT T A) / Serial AA) / Serial A A) / Serial AA) / Serial A A) / Serial A TT TT T AII (SAAII (SA AII (SAAII (SA AII (SA TT TT T AII) Hard DisksAII) Hard Disks

This motherboard adopts Intel

ICH7 south bridge chipset that supports Serial ATA

(SATA) / Serial ATAII (SATAII) hard disks. You may install SATA / SATAII hard disks on

this motherboard for internal storage devices. This section will guide you to install the

SATA / SATAII hard disks.

STEP 1: Install the SATA / SATAII hard disks into the drive bays of your chassis.

STEP 2: Connect the SATA power cable to the SATA / SATAII hard disk.

STEP 3: Connect one end of the SATA data cable to the motherboard’s SATAII

STEP 4: Connect the other end of the SATA data cable to the SATA / SATAII hard

Driver Installation Guide

To install the drivers to your system, please insert the support CD to your optical drive

first. Then, the drivers compatible to your system can be auto-detected and listed on

the support CD driver page. Please follow the order from up to bottom side to install

those required drivers. Therefore, the drivers you install can work properly.

This motherboard supports Untied Overclocking Technology, which means during

overclocking, FSB enjoys better margin due to fixed PCI / PCIE buses. Before you

enable Untied Overclocking function, please enter “Overclock Mode” option of BIOS setup

to set the selection from [Auto] to [Manual]. Therefore, CPU FSB is untied during

overclocking, but PCI / PCIE buses are in the fixed mode so that FSB can operate under

a more stable overclocking environment.

Please refer to the warning on page 7 for the possible overclocking risk

before you apply Untied Overclocking Technology.2424

The Flash Memory on the motherboard stores BIOS Setup Utility. When you start up

the computer, please press <F2> during the Power-On-Self-Test (POST) to enter

BIOS Setup utility; otherwise, POST continues with its test routines. If you wish to

enter BIOS Setup after POST, please restart the system by pressing <Ctl> + <Alt> +

<Delete>, or pressing the reset button on the system chassis. The BIOS Setup pro-

gram is designed to be user-friendly. It is a menu-driven program, which allows you to

scroll through its various sub-menus and to select among the predetermined choices.

For the detailed information about BIOS Setup, please refer to the User Manual (PDF

file) contained in the Support CD.

tware Supportware Suppor

tware Supportware Suppor

This motherboard supports various Microsoft

operating systems: 7 /

64-bit / XP / XP 64-bit. The Support CD that came with the

motherboard contains necessary drivers and useful utilities that will enhance

motherboard features. To begin using the Support CD, insert the CD into your CD-

ROM drive. It will display the Main Menu automatically if “AUTORUN” is enabled in

your computer. If the Main Menu does not appear automatically, locate and double-

click on the file “ASSETUP.EXE” from the BIN folder in the Support CD to display the

- FSB1333/1066/800/533 MHz

http://www.asrock.com/Feature/SmartView/index.asp

(CLRCMOS1, 2-Pin jumper)

- FSB1333/1066/800/533 MHz

- Gestion jumperless

Certifications - FCC, CE, WHQL

Site web ASRock: http://www.asrock.com/Feature/AppCharger/index.asp

(Micro ATX Form Factor: 9.6-in x 8.4-in, 24.4 cm x 21.3 cm)

- FSB1333/1066/800/533 MHz

- Supporta la tecnologia overclocking “slegata”

- Supporto CPU EM64T Chipset - Northbridge: Intel

- Supporta PXE Pannello I/O Panel

I/O - 1 x porta PS/2 per tastiera

- 1 x Porta VGA/DVI-D

- Suppor AMI legal BIOS

- Supporta “Plug and Play”

- Compatibile con ACPI 1.1 wake up events

- Supporta jumperfree

- Supporta SMBIOS 2.3.1

- Supporto I. O. T. (Intelligent Overclocking Technology)

- Boot Failure Guard (B.F.G.)

Sito ASRock: http://www.asrock.com/Feature/AppCharger/index.asp

- FSB1333/1066/800/533 MHz

- 1 x Puerto VGA/DVI-D

- ACPI 1.1 compliance wake up events

precedentes. Sitio web de ASRock:

http://www.asrock.com/Feature/

AppCharger/index.asp

13. SmartView, una nueva función el explorador de Internet, es la página de

http://www.asrock.com/Feature/SmartView/index.asp

- FSB1333/1066/800/533 MHz

- 1 x porta VGA/DVI-D

http://www.asrock.com/Feature/AppCharger/index.

com/Feature/SmartView/index.asp
