USER MANUAL WF42H5100AW SAMSUNG

Thank you for purchasing this Samsung product.

11 Unpacking your washer

11 Overview of your washer

13 Location considerations

13 Alcove or closet installation

13 Undercounter installation (washer only)

14 With optional pedestal base or stacking kit

15 Important note to installer

OPERATING INSTRUCTIONS

19 Loading your washer

19 Washing clothes: Basic Instructions

WASHING A LOAD OF LAUNDRY

20 Overview of the control panel

25 Washing clothes using the cycle selector

29 Cleaning the exterior

29 Cleaning the interior

29 Cleaning the dispensers

29 Storing your washer

30 Cleaning the debris filter

31 Cleaning the door Diaphragm

31 Preserving the top cover and the front frame

37 Fabric care chart

40 Helping the environment

40 Declaration of conformity

40 Specification BETTER_WF42H5200-03397D-01_EN.indd 2 2018/8/14 10:41:29English _3

Congratulations on your new Samsung washer. This manual contains important

information on the installation, use, and care of your appliance. Please take time

to read this manual to take full advantage of your washer’s many benefits and

WHAT YOU NEED TO KNOW ABOUT SAFETY INSTRUCTIONS Warnings and Important Safety Instructions in this manual do not cover all possible conditions and situations that may occur. It is your responsibility to use common sense, caution, and care when installing, maintaining, and operating your washer.

IMPORTANT SAFETY SYMBOLS AND PRECAUTIONS What the icons and signs in this user manual mean: WARNINGHazards or unsafe practices that may result in severe personal injury or death.To reduce the risk of fire, explosion, electric shock, or personal injury when using your washer, follow these basic safety precautions:CAUTIONHazards or unsafe practices that may result in minor personal injury or property damage.Do NOT attempt.Do NOT disassemble.Do NOT touch.Follow directions explicitly.Unplug the power plug from the wall socket.Make sure the machine is grounded to prevent electric shock.Call the service center for help. Note These warning signs are here to prevent injury to you and others.Please follow them explicitly.After reading this section, keep it in a safe place for future reference.Read all instructions before using the appliance. SAVE THESE INSTRUCTIONS BETTER_WF42H5200-03397D-01_EN.indd 3 2018/8/14 10:41:294_English

SAVE THESE INSTRUCTIONS CALIFORNIA PROPOSITION 65 WARNING WARNING:

Cancer and Reproductive Harm - www.P65Warnings.ca.gov.

Important safety precautions WARNING: To reduce the risk of fire, electric shock, or injury to persons when using your appliance, follow basic precautions, including the following:1. Read all instructions before using the appliance.2. Do not wash or dry articles that have been previously cleaned in, washed in, soaked in, or spotted with gasoline, dry-cleaning solvents, other flammable or explosive substances as they give o vapors that could ignite or explode.3. Do not allow children to play on or in the appliance. Close supervision of children is necessary when the appliance is used near children.4. Before the appliance is removed from service or discarded, remove the door to the washing or drying compartment.5. Do not reach into the appliance if the drum is moving.6. Do not install or store this appliance where it will be exposed to the weather.7. Do not tamper with controls.8. Do not repair or replace any part of the appliance or attempt any servicing unless specifically recommended in the user-maintenance instructions or in published user-repair instructions that you understand and have the skills to carry out.9. Do not add gasoline, dry-cleaning solvents, or other flammable or explosive substances to the wash water. These substances give o vapors that could ignite or explode.10. Under certain conditions, hydrogen gas may be produced in a hot water system that has not been used for 2 weeks or more. HYDROGEN GAS IS EXPLOSIVE. If the hot water system has not been used for such a period, before using a washer or combination washer-dryer, turn on all hot water faucets and let the water flow from each for several minutes. This will release any accumulated hydrogen gas. As the gas is flammable, do not smoke or use an open flame during this time. safety information BETTER_WF42H5200-03397D-01_EN.indd 4 2018/8/14 10:41:29English _5

SAVE THESE INSTRUCTIONS

seVere WArninG siGns For instALLAtion

Plug the power cord into an AC 120 V / 60 Hz / 10 A wall socket or higher and use the

socket for this appliance only. In addition, do not use an extension cord.

- Sharing a wall socket with other appliances using a power strip or extending the power

cord may result in electric shock or fire.

- Do not use an electric transformer. It may result in electric shock or fire.

- Ensure that the power voltage, frequency and current are the same as those of the

product specifications. Failing to do so may result in electric shock or fire.

The installation of this appliance must be performed by a qualified technician or service

- Failing to do so may result in electric shock, fire, an explosion, problems with the

Remove all foreign substances such as dust or water from the power plug terminals and

contact points using a dry cloth on a regular basis.

- Unplug the power plug and clean it with a dry cloth.

- Failing to do so may result in electric shock or fire.

Plug the power plug into the wall socket in the right direction so that the cord runs towards

- If you plug the power plug into the socket in the opposite direction, the electric wires

within the cable may be damaged and this may result in electric shock or fire.

This appliance must be properly grounded.

Do not ground the appliance to a gas pipe, plastic water pipe, or telephone line.

- This may result in electric shock, fire, an explosion, or problems with the product.

- Never plug the power cord into a socket that is not grounded correctly and make sure

that it is in accordance with local and national codes.

Do not install this appliance near a heater or inflammable material.

Do not install this appliance in a humid, oily or dusty location, in a location exposed to direct

sunlight and water (rain drops).

Do not install this appliance in a location where gas may leak.

- This may result in electric shock or fire.

Plug the power plug into the wall socket firmly. Do not use a damaged power plug,

damaged power cord or loose wall socket.

- This may result in electric shock or fire.

Do not pull or excessively bend the power cord.

Do not twist or tie the power cord.

Do not hook the power cord over a metal object, place a heavy object on the power cord,

insert the power cord between objects, or push the power cord into the space behind the

- This may result in electric shock or fire.

Do not pull the power cord when unplugging the power plug.

- Unplug the power plug by holding the plug.

- Failing to do so may result in electric shock or fire. WARNING BETTER_WF42H5200-03397D-01_EN.indd 5 2018/8/14 10:41:296_English

SAVE THESE INSTRUCTIONS When the power plug or power cord is damaged, contact your nearest service center.

CAution siGns For instALLAtion

This appliance should be positioned in such a way that it is accessible to the power plug.

- Failing to do so may result in electric shock or fire due to electric leakage.

Install your appliance on a level and hard floor that can support its weight.

- Failing to do so may result in abnormal vibrations, noise, or problems with the product.

Unplug the power plug when the appliance is not being used for long periods of time or

during a thunder/lightning storm.

- Failing to do so may result in electric shock or fire.

seVere WArninG siGns For usinG If the appliance is flooded, cut the power immediately and contact your nearest service

If the appliance generates a strange noise, a burning smell or smoke, unplug the power

plug immediately and contact your nearest service center.

- Failing to do so may result in electric shock or fire.

In the event of a gas leak (such as propane gas, LP gas, etc.), ventilate immediately without

touching the power plug. Do not touch the appliance or power cord.

- Do not use a ventilating fan.

- A spark may result in an explosion or fire.

Do not wash items contaminated with gasoline, kerosene, benzene, paint thinner, alcohol or

other flammable or explosive substances.

- This may result in electric shock, fire or an explosion.

Do not open the washer door by force while it is operating (high-temperature washing/

- Water flowing out of the washer may result in burns or cause the floor to be slippery.

This may result in injury.

- Opening the door by force may result in damage to the product or injury.

Make sure to remove the packaging (sponge, styrofoam) attached to the bottom of the

washer before using it.

Do not insert your hand under the washer.

- This may result in injury.

safety information CAUTIONWARNINGBETTER_WF42H5200-03397D-01_EN.indd 6 2018/8/14 10:41:29English _7

SAVE THESE INSTRUCTIONS Do not touch the power plug with wet hands.

- This may result in electric shock.

Do not turn the appliance o by unplugging the power plug while an operation is in

- Plugging the power plug into the wall socket again may cause a spark and result in

electric shock or fire.

Keep all packaging materials well out of the reach of children, as packaging materials can

be dangerous to children.

- If a child places a bag over their head, they may result in suocation.

Do not let children or infirm persons use this washer unsupervised.

- Failing to do so may result in electric shock, burns or injury.

Do not insert your hand or a metal object under the washer while it is operating.

- This may result in injury.

Make sure the detergent drawer is closed before you put laundry into the washer or remove

laundry from the washer.

- If the detergent drawer is open, you could strike the drawer with your head and injure

Do not attempt to repair, disassemble, or modify the appliance yourself.

- Do not use any fuse ( such as cooper, steel wire, etc.) other than the standard fuse.

- When repairing or reinstalling the appliance is required, contact your nearest service

- Failing to do so may result in electric shock, fire, problems with the product, or injury.

If any foreign substance such as water has entered the appliance, unplug the power plug

and contact your nearest service center.

- Failing to do so may result in electric shock or fire.

When the water supply hose comes loose from the faucet and floods the appliance, unplug

- Failing to do so may result in electric shock or fire.

If any foreign substance enters the appliance, unplug the power plug and contact you

nearest service center.

- Failing to do so my result in electric shock or fire.

BETTER_WF42H5200-03397D-01_EN.indd 7 2018/8/14 10:41:298_English

SAVE THESE INSTRUCTIONS CAution siGns For usinG When the washer is contaminated by a foreign substance such as detergent, dirt, food

waste, etc., unplug the power plug and clean the washer using a damp and soft cloth.

- Failing to do so may result in discoloration, deformation, damage or rust.

The front glass may be broken by a strong impact. Take care when using the washer.

- When the glass is broken, it may result in injury.

After a water supply failure or when reconnecting the water supply hose, open the faucet

Open the faucet slowly after a long period of non-use.

- The air pressure in the water supply hose or the water pipe may result in damage to a

part or in water leakage.

If a drain error occurs during an operation, check if there is a draining problem.

- If the washer is used when it is flooded because of a draining problem, it may result in

electric shock or fire due to electric leakage.

Insert the laundry into the washer completely so that laundry does not get caught in the

- If laundry gets caught in the door, it may result in damage to the laundry or the washer,

or result in water leakage.

Ensure that the faucet is turned o when the washer is not being used.

- Ensure that the screw on the water supply hose connector is properly tightened.

- Failing to do so may result in property damage or injury.

Take care that the Rubber Seal and the Front Door Glass are not contaminated by a foreign

substance (e.g. waste, thread, hair, etc.).

- If a foreign substance is caught in the door or the door is not completely closed, it may

cause a water leakage.

Open the faucet and check if the water supply hose connector is firmly tightened and that

there is no water leaking before using the product.

- If the screws or the water supply hose connector are loose, it may result in water leak.

The product you have purchased is designed for domestic use only.

The use for business purposes qualifies as product misuse. In this case, the product will not

be covered by the standard warranty provided by Samsung and no responsibility can be

attributed to Samsung for malfunctions or damages resulting from such misuse.

If the wash is not started and the laundry is left for a period of time after you have added

detergent or applied stain remover or pre-treatment onto the laundry, the laundry may be

Select the recommended cycle and temperature on the basis of the laundry items, sort the

laundry by color on the basis of its colorfastness and select the appropriate cycle.

Make sure that foreign objects such as pins, buttons and coins are removed from clothing

items when adding laundry to the washer. Wash dirty laundry separately from relatively

clean items and wash fragile items separately from tougher textiles.

If an item is stained, wash it as soon as possible. Use stain remover or detergent only after

testing the colorfastness of the item by applying a small quantity to an inside seam.

safety information CAUTIONBETTER_WF42H5200-03397D-01_EN.indd 8 2018/8/14 10:41:29English _9

SAVE THESE INSTRUCTIONS Do not stand on top of the appliance or place objects (such as laundry, lighted candles,

lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance.

- This may result in electric shock, fire, problems with the product, or injury.

Do not operate the appliance with wet hands.

- This may result in electric shock.

Do not spray volatile material such as insecticide onto the surface of the appliance.

- As well as being harmful to humans, it may also result in electric shock, fire or problems

Do not place an object that generates a electromagnetic field near the washer.

- This may result in injury due to a malfunction.

Since the water drained during a high-temperature wash or drying cycle is hot, do not touch

- This may result in burns or injury.

Do not wash, spin or dry water-proof seats, mats or clothing (*).

- Do not wash thick, hard mats even if the washer mark is on the care label.

- This may result in injury or damage to the washer, walls, floor or clothing due to

abnormal vibrations.

* Woolen Bedding, rain covers, fishing vests, ski pants, sleeping bags, diaper covers,

sweat suits, and bicycle, motor cycle, car covers, etc.

Do not operate the washer when the detergent box is removed.

- This may result in electric shock or injury due to water leakage.

Do not touch the inside of the tub during or just after drying as it is hot.

- This may result in burns.

Do not insert your hand into the detergent dispenser after opening it.

- This may result in injury as your hand may be caught.

Do not place any objects (such as shoes, food waste, animals) other than laundry into the

- This may result in damage to the washer, or injury and death in the case of pets due to

the abnormal vibrations.

Do not press the buttons using sharp objects such as pins, knifes, fingernails, etc.

- This may result in electric shock or injury.

Do not wash laundry contaminated by oils, creams or lotions usually found in skincare

shops or massage clinics.

- This may result in the rubber seal becoming deformed and water leakage.

Do not leave metal objects such as a safety pin or hair pin, or bleach in the tub for long

- This may cause the tub to rust.

- If rust starts appearing on the surface of the tub, apply a cleansing agent (neutral) to the

surface and use a sponge to clean it. Never use a metal brush.

BETTER_WF42H5200-03397D-01_EN.indd 9 2018/8/14 10:41:2910_English

SAVE THESE INSTRUCTIONS Do not use dry cleaning detergent directly and do not wash, rinse, or spin laundry

contaminated by dry cleaning detergent.

- This may result in spontaneous combustion or ignition due to the heat of the oxidation of

Do not use hot water from water cooling/heating devices.

- This may result in problems with the washer.

Do not use natural hand-washing soap for the washer.

- If it hardens and accumulates inside the washer, it may result in problems with the

product, discoloration, rust or bad odors.

Do not wash large laundry items such as Bedding in the washing net.

- Failing to do so may result in injury due to abnormal vibrations.

- Place smaller items, such as lace socks and lingerie in the washing net.

Do not use hardened detergent.

- If it accumulates inside the washer, it may result in water leakage.

Do not wash throw rugs or doormats.

- If you wash throw rugs or doormats, the sand will accumulate inside the washer. It may

result in error such as no draining.

Take care that children’s fingers are not caught in the door when closing it. This may result

seVere WArninG siGns For CLeAninG Do not clean the appliance by spraying water directly onto it.

Do not use the strong acid cleaning agent.

Do not use benzene, thinner or alcohol to clean the appliance.

- This may result in discoloration, deformation, damage, electric shock or fire.

Before cleaning or performing maintenance, unplug the appliance from the wall socket.

- Failing to do so may result in electric shock or fire.

safety information WARNINGBETTER_WF42H5200-03397D-01_EN.indd 10 2018/8/14 10:41:29English _11

installing your washer

UNPACKING YOUR WASHER Unpack your washer and inspect it for shipping damage. Make sure you have received all the items

shown below. If your washer was damaged during shipping, or you do not have all of the items, contact

1-800-SAMSUNG (726-7864).

To prevent personal injury or strain, wear protective gloves whenever lifting or carrying the unit.

Packing materials can be dangerous to children. Keep all packing material (plastic bags, polystyrene,

etc.) well out of the reach of children.

Certain internal parts are intentionally not grounded and may present a risk electric shock only during

servicing. Service personnel – Do not contact the following parts while the appliance is energized:

Control board, heat sink, motor, inlet valve and pump.

OVERVIEW OF YOUR WASHER Parts supplied

Bolt Hole Covers Hose Guide Plastic Zip Hose Tie Water Supply Hoses

Tools needed for installation

Philips screwdriver Level Adjustable Plier Measuring tape

Parts needed (Sold separately) • If you lose an accessory and want to purchase a replace ment, contact the Samsung service center (1-800-SAMSUNG(1-800-726-7864)).• The design of the parts and accessories may dier from the pictures above.Their design is subject to change without notice for product improvement.• Do not reuse old hoses. Only use new water supply hoses when you install the washing machine. Old water supply hoses can leak or burst causing flooding and property damage.• Conrm that there are rubber washers inside each coupling of the water supply hoses. anti-slip pads Wrench

* Bolt hole covers : The number of bolt hole covers depends on the model (3~6 covers).

Filter cover WARNINGWARNING 01 Installing your washer BETTER_WF42H5200-03397D-01_EN.indd 11 2018/8/14 10:41:3112_English

BASIC LOCATION REQUIREMENTS Electrical • 120 Volt 60 Hz 10 AMP fuse or circuit breaker• Individual branch circuit serving only your washer is recommended.• Your washer is equipped with a power cord.NEVER USE AN EXTENSION CORD. Grounding

ELECTRICAL GROUNDING IS REQUIRED FOR THIS APPLIANCE. This appliance must be grounded. In the event of malfunction or breakdown, grounding will reduce the risk of electric shock by providing a path of least resistance for electric current.This appliance is equipped with a power cord having a three-prong grounding plug for use in a properly installed and grounded three-prong outlet.The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances.An improperly connected equipment-grounding conductor can increase the risk of electrical shock. Check with a qualified electrician or serviceman if you are not sure whether the appliance is properly grounded. Do not modify the plug provided with the appliance – if it does not fit the outlet, have a proper outlet installed by a qualified electrician. IMPORTANT SAFETY PRECAUTIONS • To prevent unnecessary risk of fire, electrical shock or personal injury, all wiring and grounding must be done in accordance with the National Electrical Code ANSI/FNPA, No. 70 Latest Revision and local codes and ordinances. It is the personal responsibility of the appliance owner to provide adequate electrical service for this appliance.NEVER CONNECT THE GROUND WIRE TO PLASTIC PLUMBING LINES, GAS LINES, OR HOT WATER PIPES. Water Using bad quality water may cause the water supply valve to operate abnormally.To correctly fill your washer in the proper amount of time, water pressure of 20-116 psi (137-800kPa) is required.Water pressure less than 20 psi may cause water valve failure, may not allow the water valve to shut o completely, or may extend the fill time beyond what your washer controls allow, causing your washer to turn o. A time limit is built into the controls to prevent extensive flooding in your home if an internal hose becomes loose.The water faucets must be within 4 feet / 122 cm of the back of your washer to match the inlet hoses provided with your washer.Accessory inlet hoses are available in various lengths up to 10 feet/305 cm for faucets that are further away from the back of your washer.To avoid the possibility of water damage:• Have water faucets easily accessible.• Turn o faucets when the washer is not in use.• Periodically check that there is no leakage from the water inlet hose fittings.CHECK ALL CONNECTIONS AT THE WATER VALVE AND FAUCET FOR LEAKS. installing your washer CAUTIONCAUTIONWARNINGWARNINGBETTER_WF42H5200-03397D-01_EN.indd 12 2018/8/14 10:41:31English _13

The recommended height of the standpipe is 18 in/46 cm. The drain hose must be routed

through the drain hose clip to the standpipe. The standpipe must be large enough to accept the

outside diameter of the drain hose. The drain hose is attached at the factory.

For best performance, you must install your washer on a solidly constructed floor. Wood floors

may need to be reinforced to minimize vibration and/or unbalanced load situations. Carpeting

and soft tile surfaces are contributing factors to vibration which can cause your washer to move

slightly during the spin cycle.

Never install your washer on a platform or weakly supported structure.

Location considerations

Do not install your washer in areas where water may freeze, since your washer will always retain

some water in its water valve, pump, and hose areas. Freezing water can damage the belts,the

pump, hoses and other components.

Alcove or closet installation

MINIMUM CLEARANCES FOR CLOSET AND ALCOVE INSTALLATIONS:

Sides – 1 in / 25 mm

Rear – 5.9 in / 150 mm

Top – 17 in / 432 mm

Closet Front – 2 in / 51 mm

If the washer and dryer are installed together, the closet front must have at least a 72 in² (465

cm²) unobstructed air opening. Your washer alone does not require a specific air opening.

B. Side view - closet or confined area

Undercounter installation (washer only)

01 Installing your washer 1 in.(2.5 cm)27 in.(68.6 cm)1 in.(2.5 cm)39 in.(99.1 cm) b 2 in.(5 cm)33 in.(83.8 cm)5.9 in.(15 cm)17 in.(43.2 cm) a 1 in.(2.5 cm)27 in.(68.6 cm)1 in.(2.5 cm)1 in.(2.5 cm)27 in.(68.6 cm)BETTER_WF42H5200-03397D-01_EN.indd 13 2018/8/14 10:41:3114_English

installing your washer

With optional pedestal base or stacking kit

Required Dimensions for Installation With Pedestal (Model No : WE357*)

Required Dimensions for Installation With Stacking Kit (Model No : SK-5A)

51.2 in. (130 cm) to clear open door

additional space. BETTER_WF42H5200-03397D-01_EN.indd 14 2018/8/14 10:41:32English _15

IMPORTANT NOTE TO INSTALLER Please read the following instructions carefully before installing the washer.

These instructions should be retained for future reference.

We recommend you hire a professional to install this washer.

Installation flow chart Selecting a locationRunning a Calibration mode (Refer to the following description) Finish the installationRemoving the shipping bolts (*Drum only)Connecting the water and the drainAdjusting the levelling feetPowering your washing machine[Running a test cycle]Run a test cycle (Rinse+Spin) with small amount of laundary (about 4~5 Towels) Yes Please check again before steps. No Does your washer have excess vibration or noise? STEP 1

Removing the Shipping Bolts

Before using your washer, you must remove all shipping bolts from the

1. Loosen all the bolts with the wrench.

2. Slide the bolt and spacer up and remove the bolt with the spacer

through the hole in the rear wall of your washer. Repeat for each

3. Cover the holes with the supplied Bolt Hole Covers (See page 11).

4. Keep the shipping bolts and spacers for future use.

Selecting a Location

Before you install your washer, make sure the location:

• Has a hard, level surface.

• Is away from direct sunlight.

• Has adequate ventilation.

• Will not freeze (tempuratures are never below 32 °F or 0 °C).

• Is away from heat sources such as oil or gas.

• Has enough room for the power cord.

• Doesn’t have any carpeting that will obstruct ventilation openings.

01 Installing your washer BETTER_WF42H5200-03397D-01_EN.indd 15 2018/8/14 10:41:3216_English

installing your washer

Installing your Washer

To connect the water hoses to the faucets:

1. Connect one end of each water hose to the Hot or Cold tap.

2. Turn the fittings by hand until they are tight, and then tighten them by just

an additional two-thirds of a turn with a spanner. Do not overtighten the

fittings. You can damage them.

3. When done, pull the water hoses up and down to check if they are

4. Put the other ends of the hoses into a bucket and open the taps for 10-

15 seconds to remove impurities. When done, close the taps.

5. Tighten Coupling by hand until it is snug.

6. Then tighten two-thirds of a turn with pliers.

7. Run water in a bowl or basin to get rid of any debris inside hose. Check

for HOT and Cold water supply.

8. Connect one end of the COLD/HOT water supply hoses to the each

COLD/HOT water supply intakes at the back of the washer.

9. Tighten Coupling by hand until it is snug.

10. Then tighten two-thirds of a turn with pliers.

11. For proper operation, make sure both Hot & Cold hoses from faucets are

connected to the corresponding Hot / Cold water inlets on the washer.

HOT COLD COLD (Left)

Water BETTER_WF42H5200-03397D-01_EN.indd 16 2018/8/14 10:41:33English _17

12. Connect the other ends of the water hoses to the corresponding

inlets on the rear of the machine as specified. Make sure the hot

water hose is connected to the hot inlet, and the cold water hose

13. Repeat step 2 above on the other fittings. Make sure both water

hoses are connected properly. See the ‘4E’ information code for

14. Open both faucets, and check if there is a leak.

If you do not want to use the hot water hose, insert the inlet cap

into the hot water inlet. In this case, you must select Tap Cold

for the water temperature. All other water indicators turn o.

To prevent water hoses from being bent or kinked, make sure

there is at least a 6 inch (150 mm) space between the washer

Wall standpipe drain system

1. The drain hose must be placed into a wall standpipe drain system.

To keep the end of the drain hose bent, use the supplied hose

guide (A). Secure the guide to the wall using a hook to ensure

2. Open the water tap and check if there are any leaks around the

connection areas. If there are water leaks, repeat thesteps above.

A WARNING 01 Installing your washer

BETTER_WF42H5200-03397D-01_EN.indd 17 2018/8/14 10:41:3418_English

3. Slide your washer into position.

4. Level the washer by manually adjusting the levelling feet..

When your washer is level, tighten the locking nuts using the

wrench or (-) flathead screwdriver.

5. Plug the power cord into a 3-Prong, well grounded 120 volt

60Hz approved electrical outlet protected by a 10-amp fuse

or comparable circuit breaker.

Your washer is grounded through the third prong of the

power cord when plugged into a three-prong grounded

Your washer must be leveled on all four sides. A carpenter’s

level should be used on all four corners of your washer. We

recommend you recheck your washer after a dozen or so

washes to make sure it’s still level.

Avoid damage to the legs. Do not move the washer unless

the Locking-nuts are fastened to the bottom of the washer.

Make sure that you install your washing

machine correctly by running the

Rinse+Spin cycle after the installation is complete.

Your Samsung washing machine automatically detects the weight of the laundry.

For more accurate weight detection, please run Calibration Mode after the installation.

To run Calibration Mode, follow these steps:

1. Turn on the washer.

2. Press the Temp. button and Delay End button simultaneously for at least 3 seconds.

3. Remove any contents in the tub and close the door.

4. Press the Start/Pause button.

5. The drum rotates clockwise and counterclockwise for approximately 3 minutes.

6. When Calibration Mode is finished, the “En/End” appears on the display and the washing

machine turns o automatically. The washing machine is now ready for use.

installing your washer Levelling LegLocking Nut BETTER_WF42H5200-03397D-01_EN.indd 18 2018/8/14 10:41:35English _19

operating instructions

To reduce the risk of fire, electric shock, or injury to persons, read the IMPORTANT SAFETY INSTRUCTIONS before operating this appliance.

• Fill the tub with dry, unfolded clothes evenly around in order to enhance washing eciency and prevent

excess wear, or wrinkling of the load.

• Wash delicate items such as bras, hosiery, and other lingerie in the Delicates cycle with similar

• When washing big bulky items or a few smaller items that don’t fill the tub completely – a rug, a pillow,

stued toys, or one or two sweaters, for example – add a few towels to improve tumbling and spin

During the spin cycle, the washer may add additional water to redistribute the clothes and correct an

inbalance inside the drum.

• To ensure good cleaning result when washing heavily soiled loads, do not overload your washer.

” light is ON (see page 23), you can add or remove laundry items during a wash.

1. Press the Start/Pause Button.

2. Wait for the Door Lock light to go out (5 seconds).

3. Add the item, close the door, and press the Start/Pause Button.

After a 10-second pause, the cycle will resume.

To ensure thorough cleaning, add items within five minutes of starting the wash cycle.

WASHING CLOTHES: BASIC INSTRUCTIONS

1. Press the Power button, open the door, and then load the washer.

Push the laundry into the drum completely to prevent the laundry from being caught in the door or

from falling out of the drum.

3. Add detergent and additives to the dispenser (see pages 27~28).

4. Select the appropriate cycle and options for the load (see pages 20~22).

5. Press the Start/Pause Button.

The drum automatically rotates and measures the weight of the laundry without supplying water in

order to adjust the wash time. (The rotating display on the display panel indicates that the weight of the

laundry is being measured.)

6. The Wash Indicator light will illuminate.

7. The estimated cycle time will appear in the display.

The time may fluctuate to indicate the time remaining in the cycle better.

The actual time required for a cycle may dier from the estimated time in the display depending on the

water pressure, water temperature, detergent, and laundry.

8. Before your washer starts to fill, it will make a series of clicking noises to check the door lock and do a

• When the cycle is complete, the Door Lock light will go out and “End” will appear in the display.

• DO NOT attempt to open the door until the Door Lock light is o. To add a forgotten item, see the

“Loading your Washer” section above.

• When your washer is restarted after a pause, expect a delay of up to 15 seconds before the cycle

• Pressing the Power button cancels the cycle and stops your washer.

The Wash, Rinse, and Spin indicator lights will illuminate during those portions of the cycle.

Do not place anything on top of your washer while it is running.

02 operating instructions CAUTIONWARNINGWARNING BETTER_WF42H5200-03397D-01_EN.indd 19 2018/8/14 10:41:3520_English

washing a load of laundry

oVerVieW oF tHe ControL pAneL Cycle Selector

Select the appropriate cycle for the type of load.

This will determine the tumble pattern and spin speed for the cycle.

To minimize wrinkling of laundry, select the Perm Press cycle.

normAL - For most fabrics including cottons, linens, and normally soiled

HeAVy duty - For sturdy, colorfast fabrics and heavily soiled garments.

sAnitiZe - For heavily soiled, colorfast garments. This cycle heats the water

to 150 °F to eliminate bacteria.

If you select pause during the heating portion of the Sanitize Cycle, your

Washer door will remain locked for your safety.

ALLerGen - This course is applied to remove dust mites, pet dander or

other allergic substances of the fabric. (Only for WF42H5200A*models)

rinse + spin - Use for loads that need rinsing only or to add rinse-added

fabric softener to a load.

beddinG - For bulky items such as blankets, comforters and sheets. When

you are washing bulky items, use liquid detergent.

QuiCk WAsH - For lightly soiled garments needed quickly.

perm press - For wash-and-wear, synthetic fabrics, and lightly to normally

deLiCAtes - For sheer fabrics, bras, lingerie silk, and other handwash only

fabrics. For best results, use liquid detergent.

ACtiVe WeAr - Use this cycle to wash exercise wear such as sports

jerseys, training pants, shirts/tops and other performance clothing. This cycle

provides eective soil removal with gentle action for special fabric care. (Only

for WF42H5100A*models)

The large Digital Display is easy to use. It provides instructions and

diagnostics while keeping you updated on the cycle status and time

Press the button repeatedly to cycle through the dierent water temperature

Hot - Whites and heavily soiled, colorfast items.

Warm - Colorfast items. When warm rinse is selected, only the final rinse will

The other rinses will be cold to conserve energy.

Eco Warm - Moderately soiled, colorfast items; most wrinkle-free items.

Cold - Brightly colored, very lightly soiled items.

Press the button repeatedly to cycle through the dierent spin speed options.

(All Lamp Turn O)  No Spin  Low  Medium  High )

To minimize wrinkling of wrinkle free and no iron fabrics, DO NOT use

overload your Washer.

High - Use for underwear, t-shirts, jeans and sturdy cottons.

Medium - Use for jeans, wrinkle-free or wash-and-wear items and synthetics.

Low - Use for delicate items needing a slow spin speed.

No Spin - Drains your Washer without spinning. Use for extremely delicate

items that cannot tolerate any spin.

(All Lamp Turn O) - The laundry remains soaking in the final rinse

water. Either a drain or spin cycle must be performed to unload the laundry.

Press the button to select the soil level/washing time.

(Light  Normal  Heavy)

Heavy - For heavily soiled loads.

Normal - For moderately soiled loads. This setting is best for most loads.

Light - For lightly soiled loads.

Press these buttons to select dierent cycle options.

Extra Rinse - Add an additional rinse at the end of the cycle to remove

laundry additives and perfumes more thoroughly.

Extra Spin - Add additional time to remove more water from loads.

Spin Only - The option to start only Spin of each course.

Steam - Press this button to use the Steam Wash function. Steam Wash is

available with the Normal, Heavy Duty, Bedding, Sanitize and Allergen cycles.

For heavily soiled, colorfast garments, Steam Wash improves stain treatment

and uses less water (See page 26). (Only for WF42H5200A* models.)

Sound - When you activate the Sound o function, the “Sound [

My Cycle - Choose your favorite cycle including temperature, spin, soil level,

options, etc. (see page 23)

Delay End - Any cycle can be delayed for up to 24 hours in one-hour

increments. Displayed hour indicates the time at which the wash will be

ended. (See page 23).

Self Clean+ - Use to clean dirt and possible mold from the drum. Regular

use (after every 40 washes) is recommended. No detergent or bleach is

needed (see page 32).

Smart Care - This function enables you to check the status of the washing

Press to pause and restart programs.

Press once to turn your washer on, press again to turn your washer o. If

the washer is left on for more than 10 minutes without any buttons being

touched, the power automatically turns o.

03 washing a load of laundry

Child Lock prevents children from playing with your washer.

Once you have activated the Child Lock function, the control panel cannot be activated,

preventing children from playing with the washer.

Activating the Child Lock function

Press and hold both the Soil Level and Spin buttons simultaneously for 3seconds.

• When you activate the Child Lock function, the door locks and the “Child Lock

• If you press the START/PAUSE button after you have activated the Child Lock function , none of

the buttons will work except for the POWER button.

• If you press a button when the buttons are locked, the “Child Lock

Pausing the Child Lock function

When the door is locked or the buttons are locked by the Child Lock function, you can pause the

Child Lock operation for 1 minute by pressing and holding both the Soil Level and Spin buttons

simultaneously for approximately 3 seconds.

• If you pause the Child Lock mode temporarily, the door lock is released for 1 minute for user

convenience. During this period, the “Child Lock

• If you open the door after the minute is over, an alarm sounds for up to 2 minutes.

• If you close the door within the 2 minutes, the door is locked and the Child Lock function is

reactivated. If you close the door after the 2 minutes, the door is not locked automatically and

Deactivating the Child Lock function

Press and hold both the Soil Level and Spin buttons simultaneously for approximately 6seconds.

• When you deactivate the Child Lock function, the door is unlocked and the “Child Lock

• The Child Lock function prevents children or the inrm from accidently operating the washer and

injuring themselves.

• If a child enters the washing machine, the child may become trapped and suocate.

• Once you have activated the Child Lock function, it continues working even if the power is turned

• Opening the door by force can result in injury due to damage to the product.

To add laundry after you have activated the Child Lock function, you must first pause or deactivate the

Child Lock function.

If you want to open the door of the washing machine when the Child Lock function is activated:

• Pause or deactivate the Child Lock function.

• Turn the washing machine o and then on again.

washing a load of laundry CAUTIONWARNINGBETTER_WF42H5200-03397D-01_EN.indd 22 2018/8/14 10:41:36English _23

You can add or take out laundry items even after the wash has started, as long as the “ ” light

is on. Pushing the START/PAUSE button unlocks the door, unless the water is too hot or if there

is too much water in your washer. If you are able to unlock the door and wish to continue the

wash cycle, close the door, and then press the START/PAUSE button.

You can set the washing machine to start your wash automatically at a later time, choosing a delay time.

The hour displayed indicates the time at which the wash will be ended.

1. Set your wash cycles.

2. Press the Delay End button repeatedly until the delay time is set.

3. Press the START/PAUSE button. The “Delay End

” indicator will be lit, and the clock will begin

counting down until it reaches the set time.

4. To cancel a Delay End function, press the POWER button and then turn the washing machine on

Lets you save a custom wash cycle (temperature, spin, soil level, etc.) and then recall and use it

with one button convenience.

To save a cycle and selected options as your My Cycle, follow these steps:

1. Select the cycle using the Cycle Selector dial.

2. After cycle selection, set each option.

See page 38~39 for available option settings with each cycle.

3. You can then store the selected cycle and options by pressing and holding the My Cycle

button for longer than 3 seconds. The cycle and options you select will be displayed the next

time you choose the My Cycle function.

4. Press the My Cycle button to load and use the saved My Cycle options. The “My Cycle” light

will indicate activation. Also, the chosen course and option lights will flicker

You can change the “My Cycle” settings by repeating the process above.

The washer displays the last settings used the next time you choose “My Cycle”.

If you press My Cycle and release it within 3 seconds, the previously saved

options appear. If you press and hold My Cycle for 3 second or longer, the currently set

and options are saved and the LED blinks for 3 seconds.

The Sound O function can be selected during all courses.

03 washing a load of laundry

BETTER_WF42H5200-03397D-01_EN.indd 23 2018/8/14 10:41:3624_English

This function enables you to check the status of the washing machine using a smartphone.

1. To enable the Smart Care function

press and hold the Sound button for 3 seconds within 10

seconds after turning the power on by pressing the Power

2) WF42H5100A* model

Press Smart Care button to use.

2. If the Smart Care function is activated, the LED on the

window display rotates for 2 or 3 seconds and then the

Smart Care indicator is lit on the display.

3. Run the Smart Care app on your smart phone.

The Smart Care function is optimized with Galaxy and iPhone

5. Focus your smart phone’s camera on the display panel of

the washing machine.

6. If the smart phone’s camera is focused on the display

panel of the washing machine, the panel and error

message is automatically recognized and the error type

and countermeasures are displayed on the smart phone.

7. If the smartphone fails to recognize the error code more

than twice, please enter the error code displayed on the

display panel of the washer manually into the Smart Care

Downloading the Smart Care app

• Download the Samsung Laundry App into your mobile phone from the Android market

or Apple App store. (Search word : Samsung Smart Washer/Dryer)

Precautions when using Smart Care

• If a lighting device (e.g. uorescent or lamp) is reected on the display panel of the

washing machine, the result on the display panel may not be recognized easily.

• If an error occurs more than twice, please manually enter the error code displayed on the

display panel of the washing machine into the Smart Care app.

• If the angle of the smartphone camera and the display panel of the washing machine is

incorrect, the error may not be recognized properly.

Please try to hold the smart phone at an angle to the display panel as shown by the

WF42H5100A*WF42H5200A*

washing a load of laundry

BETTER_WF42H5200-03397D-01_EN.indd 24 2018/8/14 10:41:36English _25

Washing clothes using the cycle selector

Your new washing machine makes washing clothes easy, using Samsung’s “Fuzzy Control”

automatic control system. When you select a wash program, the machine will set the correct

temperature, washing time, and washing speed.

1. Turn on your sink’s water tap.

2. Press the Power button.

4. Load the articles of clothing one at a time loosely into the drum, without overfilling it.

6. Add detergent, softener, and pre-wash detergent (if necessary) into the appropriate

7. Use the Cycle Selector to select the appropriate cycle according to the type of material:

NORMAL, HEAVY DUTY, BEDDING, SANITIZE,ALLERGEN(Only for WF42H5200A*

model), RINSE+SPIN,QUICK WASH, PERM PRESS, DELICATES, ACTIVE WEAR(Only for

WF42H5100A* models). The relevant indicators will illuminate on the control panel.

8. At this time, you can control the wash temperature, the number of rinse cycles, the spinning

speed, and the delay time by pressing the appropriate option button.

9. Press the Start/Pause button on the Cycle Selector and the wash will begin. The process

indicator will light up and the remaining time for the cycle will appear in the display.

1. Within 5 minutes of starting a wash, it is possible to add/remove laundry items to/from the

2. Press the Start/Pause button to unlock the door.

3. The door cannot be opened when the water is too HOT or the water level is too HIGH.

4. After closing the door, press the Start/Pause button to restart the wash.

When the cycle is finished:

After the total cycle has finished, the power will turn o automatically.

03 washing a load of laundry

BETTER_WF42H5200-03397D-01_EN.indd 25 2018/8/14 10:41:3626_English

usinG steAm WAsH If you select steam, the steam acts at the most eective times for the detected amount of laundry,

maximizing the eect of the steam, increasing the wash temperature, enhancing the Soak eect, and

improving wash performance. (Only for WF42H5200A* models)

2. Press the Power button.

3. Turn the Cycle Selector and select a Steam Cycle. (The Deep Steam course automatically selects

4. Press the Steam button.

5. Add detergent to the dispenser tray and add fabric softener up to the marked line.

6. Press the Start/Pause button.

: The washer automatically selects the optimal wash conditions by sensing the weight of the laundry.

Steam may not necessarily be visible during the steam cycles. Steam may not be present during the

entire steam wash cycle.

AtC (Auto temperAture ControL)

ATC is the control function that the washer controls water temperature with temperature sensor (thermistor).

Because there are numerous water temperatures depending on the customer’s environments ( cold

areas, warm areas, various water temperature, settings of heater temperature, etcs), ATC function in

our washer maintains the certain level of wash temperature to output the best washing performance at

are the regulation and UL course. Since new

washers must reduce the amount of energy usage at first priority, customers will notice more cold

water entering the washer. But This is Normal, not a problem.

, Hot temperature is similar to acceptable adult bath-water temperature and

warm temperature is similar to comfortable swimming-pool water temperature.

If customers want to wash clothes in specific water temperature, customers should choose a dierent

at each temperature ( Hot/Warm/Eco Warm )

washing a load of laundry

BETTER_WF42H5200-03397D-01_EN.indd 26 2018/8/14 10:41:36English _27

DETERGENT USE Your Washer is designed to use high eciency (HE) detergents.

• For best cleaning results, use a high eciency detergents such as

Tide HE, Wisk HE, Cheer HE, or Gain HE*. High eciency detergents

contain suds suppressors that reduce or eliminate suds. When fewer

suds are produced, the load tumbles more eciently and cleaning is

Regular detergent is NOT recommended. Please use HE detergents

Reducing the amount of detergent may reduce the quality of cleaning. It is important to pre–treat

stains, sort carefully by color and soil level, and avoid overloading.

* Brand names are trademarks of their respective manufacturers.

FEATURES Automatic dispenser

Your washer has separate compartments for dispensing

detergent and color-safe bleach, chlorine bleach, and

fabric softener. Add all laundry additives to their respective

compartments before starting your washer.

The automatic dispenser MUST ALWAYS be in place before

you start your washer.

DO NOT open the automatic dispenser when your washer is

• Never exceed the manufacturer’s recommendations when

• This compartment holds liquid detergent for the main wash

cycle, which the washer adds to the load at the beginning

Before using powdered detergent, remove the Liquid

Detergent holder from the compartment. Powdered

detergent will not dispense from the Liquid Detergent

Detergent compartment

• Pour the recommended amount of laundry detergent directly into the detergent compartment

before starting your washer.

03 washing a load of laundry

(Liquid chlorine bleach only)

1. Add chlorine bleach to the bleach compartment.

DO NOT exceed the MAX FILL line.

2. Avoid splashing or over–filling the compartment.

3. Your washer automatically dispenses bleach into the tub at

the appropriate time.

4. The dispenser automatically dilutes liquid chlorine bleach

before it reaches the wash load.

• Never pour undiluted liquid chlorine bleach directly onto

the load or into the tub. It is a powerful chemical and

can cause fabric damage, such as weakening of the

fibers or color loss, if not used properly.

• Oxi-type boosters or color-safe bleach can be added to

the drum prior to adding laundry.

• Put the laundry into the drum only after confirming

that the oxi-type boosters or color-safe bleach has

completely entered the hole of the drum.

• To use powdered detergent and powder oxi-type

boosters or powdered color-safe bleach at the same

time, it is more eective to put them in the drum

together before adding the laundry. When you use

powdered detergent, remember to remove the Liquid

Detergent holder from the detergent compartment.

Fabric softener compartment

1. Pour the recommended amount of liquid fabric softener into the softener compartment.

For smaller loads, use less than one capful.

2. Dilute the fabric softener with water until it reaches MAX FILL in the compartment.

3. The dispenser automatically releases liquid fabric softener at the proper time during the rinse

• Use the softener compartment ONLY for liquid fabric softeners.

• DO NOT use a Downy Ball* in the Fabric softener compartment of this washer. It will not

be added at the appropriate time.

Use the detergent compartment.

* Brand names are trademarks of their respective manufacturers.

If you overfill the detergent, bleach, or softener compartments, the contents of the

compartment will automatically be released into the washer. This could damage any

garments that are in the drum.

washing a load of laundry

compartment BETTER_WF42H5200-03397D-01_EN.indd 28 2018/8/14 10:41:37English _29

maintaining your washer

Certain internal parts are intentionally not grounded and may present a risk electric shock only during

servicing. Service personnel – Do not contact the following parts while the appliance is energized:

Control board, heat sink, motor, inlet valve and pump.

CLEANING THE EXTERIOR Turn o the water faucets after finishing the day’s washing.

This will shut o the water supply to your washer and prevent the unlikely possibility of damage from

escaping water. Leave the door open to allow the inside of your washer to dry out.

Use a soft cloth to wipe up all detergent, bleach or other spills as they occur.

Clean the following as recommended below:

Control Panel – Clean with a soft, damp cloth. Do not use abrasive powders or cleaning pads. Do not spray

cleaners directly on the panel.

Cabinet – Clean with soap and water.

CLEANING THE INTERIOR Clean the interior of your washer periodically to remove any dirt, soil, odor, mold, mildew, or bacterial

residue that may remain in your washer as a result of washing clothes.

Failure to follow these instructions may result in unpleasant conditions, including odors and/or permanent

stains on your washer or laundry.

Hard water deposits may be removed, if needed. Use a cleaner labeled “Washer safe”.

CLEANING THE DISPENSERS You may need to clean the automatic dispenser periodically to remove

laundry additive buildup.

1. Pull out the Liquid Detergent holder from the detergent compartment.

2. Remove the siphon cap from the fabric softener and bleach

3. Wash all of the parts under running water.

4. Clean the dispenser recess with a soft brush.

5. Reinsert the siphon cap and push it firmly into place.

6. Push the Liquid Detergent holder back into place.

7. Run a Rinse+Spin cycle without any load in your washer.

STORING YOUR WASHER Washers can be damaged if water is not removed from hoses and internal components before storage.

Prepare your washer for storage as follows:

• Select the Quick Wash cycle and add bleach to the automatic dispenser. Run your washer through the

cycle without a load.

• Turn the water faucets o and disconnect the inlet hoses.

• Unplug your washer from the electrical outlet and leave your washer door open to let air circulate inside

• If you store your washer in below–freezing temperatures, make sure you allow time for any leftover water

in your washer to thaw before use. WARNING 04 maintaining your washer

Siphon cap BETTER_WF42H5200-03397D-01_EN.indd 29 2018/8/14 10:41:3830_English

CLEANING THE DEBRIS FILTER We recommend cleaning the debris filter when water does not drain well or the “5E” error message is displayed.

1. Unplug the washing machine from the power supply.

2. Gently press the top area of the filter cover to open.

3. Holding the drain cap, pull the drain tube that

is hooked on the guide hook to the front. Do

not pull the drain tube with excessive force.

4. Place a bowl under the washing machine to

catch any remaining water. Then, hold the

drain tube with one hand, and turn the drain

cap counter clockwise with the other hand to

separate it from the drain tube.

5. Drain the remaining water completely.

6. Turn the debris cap counterclockwise, and then pull

the debris cap and debris filter assembly out of the

7. Wash any dirt or other material from the

debris filter. Make sure the drain pump

propeller behind the debris filter is not

8. When you have finished cleaning the filter, insert the debris

cap and filter assembly back into the washer. Turn the

debris filter cap clockwise until the indicator on the debris

filter cap is in the 12 o’clock position, pointing to the

indicator on the washer.

9. Re-attach the emergency drain cap to the drain tube, and

then hook the tube to the hook guide.

10. Re-install the filter cover.

For models with the safety filter cap

• To open, push in, and then turn the safety lter cap

counterclockwise. The spring in the cap will make

opening the cap easy.

• To close, turn the safety lter cap clockwise. As you

turn the cap, the spring will make a rattling sound. The

rattling sound is normal.

maintaining your washer

Debris filter BETTER_WF42H5200-03397D-01_EN.indd 30 2018/8/14 10:41:39English _31

CLEANING THE DOOR DIAPHRAGM

1. Open the washer door and remove any clothing or items from the washer.

2. Check if there are any foreign substances on the grey

Diaphragm  between the lid and the drum.

To check this, turn the Diaphragm  out.

3. If there are any foreign substances, remove them.

4. If you find stained areas, wipe them down using the procedure below:

a) Carefully combine ¾ cup (177 mL) of liquid chlorine bleach with 1 gal. (3.8 L) of warm

b) Wipe the Diaphragm area with the dilute solution using a damp cloth.

c) Let stand 5 minutes.

d) Wipe down the area thoroughly with a dry cloth and let the washer interior air dry with

• Wear rubber gloves when cleaning for prolonged periods.

• Refer to the bleach manufacturer’s instructions for proper use.

PRESERVING THE TOP COVER AND THE FRONT FRAME Do not place any heavy or sharp objects or a detergent box on the washing machine. They can scratch or

damage its top cover. Keep them in the pedestal (if purchased) or in a separate storage box.

Since the entire washing machine has a high-gloss finish, the surface can be scratched or damaged.

Avoid scratching or damaging the surface when using the washing machine.

04 maintaining your washer

BETTER_WF42H5200-03397D-01_EN.indd 31 2018/8/14 10:41:3932_English

Self Clean+ is a self-cleaning cycle that removes mold that may occur inside the washing machine.

1. Press the Power button.

2. Press the Self Clean+ button.

• Once the Self Clean+ button is pressed, the only

function that can be set is Delay End.

3. Press the Start/Pause button.

• When you press the Start/Pause button, Self

• Using Self Clean+, you can clean the drum, tub and diaphragm without using a cleansing

• Never use Self Clean+ when laundry is in the washing machine. It may cause damage to the

laundry or a problem with the washing machine.

• Ifyouwanttouseadrumcleansingagent,useonly1/10oftheamountofthedrum

cleansing agent recommended by the cleansing agent manufacturer. (When using a

powder-type cleansing agent , remove the liquid detergent

The Self Clean+ Auto Indicator Function

• If the “Self Clean+” button is lit after a wash, it indicates

that tub (drum) cleaning is required. In this case, remove

the laundry from the washing machine, turn the power on,

and clean the drum by running Self Clean.

• If you do not run Self Clean+ after every 40 washes, the

“Self Clean+” indicator turns o after one hour. However,

the “Self Clean+” indicator will light again after five

washes. Not running Self Clean+ at this point will not cause

a problem with the washing machine.

• Although the Self Clean+ Auto Indicator appears once a

month or so, the frequency may dier depending on the

number of times the washing machine is used.

maintaining your washer

WF42H5100A*WF42H5200A* WF42H5100A*WF42H5200A*CAUTION BETTER_WF42H5200-03397D-01_EN.indd 32 2018/8/14 10:41:40English _33

CHECK THESE SOLUTIONS IF YOUR WASHER…

PROBLEM SOLUTION Will not start. • Make sure the door is firmly closed.

• Make sure your washer is plugged in.

• Make sure the water source faucets are open.

• Make sure to press the Start/Pause Button to start your washer.

• Make sure the Child Lock is not activated. See page 22.

• Before your washer starts to fill, it will make a series of clicking noises

to check the door lock and do a quick drain.

• Check the fuse or reset the circuit breaker

Has no water or not enough

• Turn both faucets on fully.

• Make sure the door is tightly closed.

• Straighten the water inlet hoses.

• Disconnect hoses and clean the screens. Hose filter screens may be

• Open and close the door, then press the Start/Pause Button.

Has detergent remains in

the automatic dispenser

after the wash cycle is

• Make sure your washer is running with sucient water pressure.

• Make sure the Detergent Selector dial is in the upper position when

using granular detergent.

Vibrates or is too noisy. • Make sure your washer is set on a level surface. If the surface is not

level, adjust your washer feet to level the appliance.

• Make sure that the shipping bolts are removed.

• Make sure your washer is not touching any other object.

• Make sure the laundry load is balanced.

Stops • Plug the power cord into a live electrical outlet.

• Check the fuse or reset the circuit breaker.

• Close the door and press the Start/Pause Button to start your

For your safety, your washer will not tumble or spin unless the door is

• Before your washer starts to fill, it will make a series of clicking noises

to check the door lock and do a quick drain.

• There may be a pause or soak period in the cycle. Wait and it may

• Check the screens on the inlet hoses at the faucets for obstructions.

Clean the screens periodically.

BETTER_WF42H5200-03397D-01_EN.indd 33 2018/8/14 10:41:4034_English

PROBLEM SOLUTION Fills with the wrong

• Turn both faucets on fully.

• Make sure the temperature selection is correct.

• Make sure the hoses are connected to the correct faucets.

• Check the water heater. It should be set to deliver a minimum 120°F

(49 °C) hot water at the tap. Also check the water heater capacity

• Disconnect the hoses and clean the screens. The hose filter screens

• As your washer is filling, the water temperature may change as

the automatic temperature control feature checks incoming water

temperature. This is normal.

• While your washer is filling, you may notice just hot and/or just

cold water going through the dispenser when you have selected

cold or warm wash temperatures. This is a normal function of the

automatic temperature control feature as your washer determines the

temperature of the water.

Door locked or will not

• Press the Start/Pause Button to stop your washer.

• Your washer door will remain locked during the heating portion of the

• It may take a few moments for the door lock mechanism to

Does not drain and/or spin. • Check the fuse or reset the circuit breaker.

• Straighten the drain hoses. Eliminate kinked hoses. If there is a drain

restriction, call for service.

• Close the door and press the Start/Pause Button. For your safety,

your washer will not tumble or spin unless the door is closed.

• Make sure the debris filter is not clogged.

Load is too wet at the end

• Use the High or Extra High spin speed.

• Use high eciency detergent to reduce over–sudsing.

• The load is too small. Very small loads (one or two items) may

become unbalanced and not spin out completely.

Leaks water. • Make sure the door is firmly closed.

• Make sure all hose connections are tight.

• Make sure the end of the drain hose is correctly inserted and secured

to the drainage system.

• Avoid overloading.

• Use high eciency detergent to prevent over–sudsing.

Has excessive suds. • Use high eciency detergent to prevent over-sudsing.

• Reduce the detergent amount for soft water, small or lightly soiled

• Non-HE detergent is NOT recommended.

Has an odor. • Excessive suds collect in nooks and crannies and can cause foul

• Run cleansing cycles to sanitize the machine periodically. (Sanitize

Cycle or Self Clean+)

• Clean the door seal (Diaphragm).

• Dry the interior of your washer after the total cycle has finished.

BETTER_WF42H5200-03397D-01_EN.indd 34 2018/8/14 10:41:40English _35

INFORMATION CODES The washer may display information codes to help you better understand what is occurring with your

ERROR CODE MEANING & SOLUTION UE Unbalanced load prevented your washer from spinning.

Redistribute the load, press the Start/Pause button.

dE The door is open when the washer is running.

Close the door tightly and restart the cycle. If the code reappears, call customer

Your washer failed to lock or unlock the door.

HE A water temperature control problem. (Heater control problem)

Call customer service.

LE Your washer has tried to fill, but has not reached the proper water level.

Call customer service.

When washer displays “LE”, washer do draining for 3 minutes,At this time,

Power button is invalid.

5E Your washer is not draining. This can also mean that the unit senses a small clog

1. Turn o the unit for 10 seconds and then turn it on again.

2. Select the Spin Only cycle.

3. Press the Start/Pause to drain the water.

If it still does not drain, call for service.

4E Your washer has tried to fill but was unsuccessful.

Make sure the water faucets are open all the way. Check for bent hoses. Check the

inlet screens on the hoses. If you are using a Flood Safety Device, please remove

the device and connect the water hoses directly to the unit.

Check if the hot water supply hose is connected.

You must connect the hot water supply hose because hot water is supplied by the

Auto Temperature Control (A.T.C.) function if the temperature of the cold water is

When washer displays “4E”, washer do draining for 3 minutes. At this time,

Power button is invalid

The hot/cold water hose connection is not correct.

Please connect the hot/cold water hose connection correctly.

OE A fault is detected in the water level sensor.

Call customer service.

1E The Water Level sensor is not working properly.

Call customer service.

When washer displays “1E”, washer do draining for 3 minutes,At this time,

Power button is invalid

Call customer service.

A temperature sensor problem.

Restart the cycle. If the code reappears, call customer service..

Restart the cycle. If the code reappears, call customer service.

High/Low voltage detected.

Restart the cycle. If the code reappears, call customer service.

AE A Communication error between the SUB(Sensor) PBA and the MAIN PBA Call customer service.

A Communication error between the MAIN PBA and the INVERTER PBA.

Call customer service.

8E A MEMS sensor problem.

Call customer service.

Call customer service.

Too many suds are detected during the wash session. The unit is put on hold until

the amount of suds have been reduced. The unit will then go back to operating.

For any codes not listed above, call 1–800–726–7864 (1–800–SAMSUNG)

BETTER_WF42H5200-03397D-01_EN.indd 36 2018/8/14 10:41:40English _37

FABRIC CARE CHART The following symbols provide garment care direction. The Clothing care labels include symbols for

washing, bleaching, drying and ironing, or dry cleaning when necessary. The use of symbols ensures

consistency among garment manufacturers of domestic and imported items. Follow care label directions to

maximize garment life and reduce laundering problems.

Wash Cycle Special Instructions

Normal Line Dry/ Hang to Dry Do Not Wash

Drip Dry Do Not Wring

Gentle/Delicates Dry Flat Do Not Bleach

Hand Wash Heat Setting Do Not Tumble Dry

Cold Any Heat Dry Clean

No Heat/Air Do Not Dry Clean

Line Dry/ Hang to Dry

Bleach (when needed)

Tumble Dry Cycle Medium Dry Flat

** The dot symbols represent appropriate wash water temperatures for various items. The temperature

range for Hot is 105° - 125 °F / 41° - 52 °C, for Warm 85° - 105 °F / 29° - 41 °C and for Cold 60° - 85°F

/ 16° - 29 °C. (Wash water temperature must be a minimum of 60 °F / 16 °C for detergent activation and

eective cleaning.) The clothes washer can not ensure these temperatures because the actual temperature

of the water entering your washer is dependent on water heater settings and regional water supply

temperatures. For example, cold water entering the home in the northern states during winter may be

40°F / 4 °C which is too cold for eective cleaning. The water temperature in this situation will need to be

adjusted by selecting a warm setting, adding some hot water to the MAX FILL line or using your washer’s

heating option, if available.

CYCLE CHART Use this chart to set the best cycle and option for you laundry.

Model: WF42H5100A* (

HELPING THE ENVIRONMENT

• Your washer is manufactured from recyclable materials. If you decide to dispose of it, please observe

local waste disposal regulations. Cut o the power cord so that the appliance cannot be connected

to a power source. Remove the door so that animals and small children cannot get trapped inside the

• Do not exceed the detergent quantities recommended in the detergent manufacturers’ instructions.

• Use stain removal products and bleaches before the wash cycle only when necessary.

• Save water and electricity by only washing full loads (the exact amount depends upon the program used).

DECLARATION OF CONFORMITY This appliance complies with UL2157.

SPECIFICATION TYPE FRONT LOADING WASHER DIMENSIONS Div Inches (mm)

C. Depth with door open 90°

SAMSUNG WASHER Limited WArrAnty to oriGinAL Consumer purCHAser WitH prooF oF purCHAse

This SAMSUNG brand product, as supplied and distributed by SAMSUNG ELECTRONICS AMERICA, INC.

(SAMSUNG) and delivered new, in the original carton to the original consumer purchaser, is warranted by

SAMSUNG against manufacturing defects in materials or workmanship for the limited warranty period,

starting from the date of original purchase, of:

One (1) year parts and labor,

Three (3) years stainless tub part (Part Only),

Ten (10) years washing DD motor part (Part Only)

This limited warranty is valid only on products purchased and used in the United States that have been

installed, operated, and maintained according to the instructions attached to or furnished with the product.

To receive warranty service, the purchaser must contact SAMSUNG at the address or phone number

provided below for problem determination and service procedures. Warranty service can only be performed

by a SAMSUNG authorized service center. The original dated bill of sale must be presented upon request as

proof of purchase to SAMSUNG or SAMSUNG’s authorized service center to receive warranty service.

SAMSUNG will provide in-home service within the contiguous United States during the warranty period

at no charge, subject to availability of SAMSUNG authorized servicers within the customer’s geographic

area. If in-home service is not available, SAMSUNG may elect, at its option, to provide transportation of the

product to and from an authorized service center. If the product is located in an area where service by a

SAMSUNG authorized servicer is not available, you may be responsible for a trip charge or required to bring

the product to a SAMSUNG authorized service center for service.

SAMSUNG will provide in-home service within the contiguous United States during the warranty period

at no charge, subject to availability of SAMSUNG authorized servicers within the customer’s geographic

area. If in-home service is not available, SAMSUNG may elect, at its option, to provide transportation of the

product to and from an authorized service center. If the product is located in an area where service by a

SAMSUNG authorized servicer is not available, you may be responsible for a trip charge or required to bring

the product to a SAMSUNG authorized service center for service.

To receive in-home service, product must be unobstructed and accessible to the service agent.

During the applicable warranty period, a product will be repaired, replaced, or the purchase price refunded,

at the sole option of SAMSUNG. SAMSUNG may use new or reconditioned parts in repairing a product, or

replace the product with a new or reconditioned product. Replacement parts and products are warranted

for the remaining portion of the original product’s warranty or ninety (90) days, whichever is longer. All

replaced parts and products are the property of SAMSUNG and you must return them to SAMSUNG.

BETTER_WF42H5200-03397D-01_EN.indd 41 2018/8/14 10:41:4142_English

This limited warranty covers manufacturing defects in materials or workmanship encountered in normal

household, noncommercial use of this product and shall not cover the following: damage that occurs in

shipment, delivery, installation, and uses for which this product was not intended; damage caused by

unauthorized modification or alteration of the product; product where the original factory serial numbers

have been removed, defaced, changed in any way, or cannot be readily determined; cosmetic damage

including scratches, dents, chips, and other damage to the product’s finishes; damage caused by abuse,

misuse, pest infestations, accident, fire, floods, or other acts of nature or God; damage caused by use of

equipment, utilities, services, parts, supplies, accessories, applications, installations, repairs, external wiring

or connectors not supplied or authorized by SAMSUNG; damage caused by incorrect electrical line current,

voltage, fluctuations and surges; damage caused by failure to operate and maintain the product according

to instructions; in-home instruction on how to use your product; and service to correct installation not in

accordance with electrical or plumbing codes or correction of household electrical or plumbing (i.e., house

wiring, fuses, or water inlet hoses). The cost of repair or replacement under these excluded circumstances

shall be the customer’s responsibility.

Visits by an authorized servicer to explain product functions, maintenance or installation are not covered

by this limited warranty. Please contact SAMSUNG at the number below for assistance with any of these

EXCLUSION OF IMPLIED WARRANTIES IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW. Some states do not allow limitations on how long an implied warranty lasts, so the above limitations

or exclusions may not apply to you. This warranty gives you specific rights, and you may also have other

rights, which vary from state to state.

LIMITATION OF REMEDIES YOUR SOLE AND EXCLUSIVE REMEDY IS PRODUCT REPAIR, PRODUCT REPLACEMENT, OR REFUND OF THE PURCHASE PRICE AT SAMSUNG’S OPTION, AS PROVIDED IN THIS LIMITED WARRANTY.

SAMSUNG SHALL NOT BE LIABLE FOR SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES,

exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions may

not apply to you. This warranty gives you specific rights, and you may also have other rights, which vary

from state to state.

SAMSUNG does not warrant uninterrupted or error-free operation of the product. No warranty or guarantee

given by any other person, firm, or corporation with respect to this product shall be binding on SAMSUNG.

To obtain warranty service, please contact SAMSUNG at:

Samsung Electronics America, Inc. 85 Challenger Road

Ridgefield Park, NJ 07660

SAMSUNG WASHER LIMITED WARRANTY TO ORIGINAL PURCHASER This SAMSUNG brand product, as supplied and distributed by SAMSUNG ELECTRONICS CANADA, INC.

(SAMSUNG) and delivered new, in the original carton to the original consumer purchaser, is warranted by

SAMSUNG against manufacturing defects in materials and workmanship for a limited warranty period of:

One (1) year part and labor, Ten (10) years washing DD motor (Part only)

This limited warranty begins on the original date of purchase, and is valid only on products purchased

and used in the Canada. To receive warranty service, the purchaser must contact SAMSUNG for problem

determination and service procedures. Warranty service can only be performed by a SAMSUNG authorized

service center. The original dated bill of sale must be presented upon request as proof of purchase to

SAMSUNG or SAMSUNG’s authorized service center. SAMSUNG will provide in-home service during the

warranty period at no charge, subject to availability within the Canada. In-home service is not available in all

To receive in-home service, product must be unobstructed and accessible to the service agent. If service

is not available, SAMSUNG may elect to provide transportation of the product to and from an authorized

SAMSUNG will repair, replace, or refund this product at our option and at no charge as stipulated herein,

with new or reconditioned parts or products if found to be defective during the limited warranty period

specified above. All replaced parts and products become the property of SAMSUNG and must be returned

to SAMSUNG. Replacement parts and products assume the remaining original warranty, or ninety (90)

days, whichever is longer.This limited warranty covers manufacturing defects in materials and workmanship

encountered in normal, noncommercial use of this product and shall not apply to the following: damage

that occurs in shipment; delivery and installation; applications and uses for which this product was not

intended; altered product or serial numbers; cosmetic damage or exterior finish; accidents, abuse, neglect,

fire, water, lightning, or other acts of nature or God; use of products, equipment, systems, utilities, services,

parts, supplies, accessories, applications, installations, repairs, external wiring or connectors not supplied

or authorized by SAMSUNG that damage this product or result in service problems; incorrect electrical

line voltage, fluctuations and surges; customer adjustments and failure to follow operating instructions,

maintenance and environmental instructions that are covered and prescribed in the instruction book;

product removal and reinstallation; problems caused by pest infestations. This limited warranty does not

cover problems resulting from incorrect electric current, voltage or supply, light bulbs, house fuses, house

wiring, cost of a service call for instructions, or fixing installation errors. SAMSUNG does not warrant

uninterrupted or error-free operation of the product.

BETTER_WF42H5200-03397D-01_EN.indd 43 2018/8/14 10:41:4144_English

Some provinces do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation

of incidental or consequential damages, so the above limitations or exclusions may not apply to you.

This warranty gives you specific rights, and you may also have other rights, which vary from province to

Visits by a Service Engineer to explain functions, maintenance or installation is not covered by warranty.

Please contact your Samsung call agent for help with any of these issues.

www.samsung.com/ca_fr/support (French)

Visits by a Service Engineer to explain functions, maintenance or installation is not covered by warranty.

Please contact your Samsung call agent for help with any of these issues.

Code No. DC68-03397D-01_EN
