USER MANUAL RD43WC4SBACSA2 HISENSE

RB403N4BC1/RB403N4DC1

(Spain/other country)

RB468N4BW1RD-44WC4SBA/CLA2

RB403N4BC1/RB403N4DC1

RGHUOXIWGLFKWHr.ODUVLFKWIROLHHLQ

9HUPHLGHQ6LHGDVVIULVFKHQLFKW

JHIURUHQH1DKUXQJVPLWWHOLQ.RQWDNWPLW

EHUHLWVWLHIJHIURUHQHQ1DKUXQJVPLWWHOQ

6REDOGGLHVHDXIJHWDXWVLQG

*HJHQVWlQGHGDGLHVHGLH2EHUIOlFKH

9HUZHQGHQ6LH]XU5HLQLJXQJNHLQH

9HUGQQXQJVPLWWHO$XWRUHLQLJXQJVPLWWHO

%OHLFKPLWWHOlWKHULVFKHQgOH

6FKHXHUPLWWHORGHURUJDQLVFKHQ

UHLQLJHQ(VLVWHLQIDFKHU]XUHLQLJHQZHQQ

Important safety instructions

General safety and daily use

Don't try to repair the appliance

yourself. It is dangerous to alter the

specifications or modify this product in

any way. Any damage to the cord may

cause short circuit, fire or electric

Pay attention not to damage the

tubing of the refrigerant circuit.

Don't place too much food directly

against the air outlet on the rear wall of

both the refrigerator and freezer

compartment, as it affects sufficient air

recommend that you follow the

Store any food in accordance with the

storage instructions from the

Don't use mechanical devices or any

other means to speed up the defrosting

process, unless they are approved by

It is important to use your

appliance safely. We

This product has been determined to be in compliance with the Low Voltage

Directive(2006/95/EC),the Electromagnetic Compatibility Directive(200

the Eco-Design Directive(2009/125/EC) implemented by Regulation(EC) No

643/2009 of the European Union

This appliance is intended to be used

in household and similar app

-Staff kitchen- areas in shops, offices

and other working environments;

-Farmhouses by clients in hotels,

motels and other residential types of

-Bed and breakfast type of

If you feel that the appliance is not

operating correctly, please check the

Troubleshooting page for assistance. If

still in doubt contact the customer

service help line for assistance or to

arrange a call out by an authorized

Thank you for your choosing our

products. We are sure you will find

your new appliance a pleasure to use.

Before you use the appliance, we

recommend that you read through

these instructions carefully, which

provides details about its usage and

Please ensure that all people using

this appliance are familiar with its

operations and safety features. It is

important that you install the appliance

correctly and pay attention to the safety

instructions carefully.

We recommend that you keep this

user's manual with the appliance for

future reference and retain it to any

Description of the appliance………….9

Using your appliance…………………13

Cleaning and care……………………16

Troubleshooting………………………17

Disposal of the appliance……………19Safety for children and infirm persons

Safety about electricity

Unpack the appliance and check

through the appliance. Should any

damage be evident, don't plug in the

appliance but contact the shop

immediately from which you purchased

it. Keep all packing materials in this

We recommend that you wait for 4

hours before connecting the appliance

to allow the refrigerant to flow back into

The appliance must be applied with

single phase alternating current of

220~240V/50Hz. If the voltage

fluctuates exceeding the upper limit,

A.C. automatic voltage regulator of

more than 350W should be applied to

the refrigerator for safety use.

The mains plug must be accessible

when the appliance is installed.

This appliance must be earthed.

liance is fitted with a fused

plug in accordance with local

standard. The fused plug should be

suitable for use in all houses fitted

with sockets in accordance with

current specifications.

-If the fitted plug is not suitable for

your socket outlets, it should be cut

off and carefully disposed of. To avoid

a possible shock hazard, do not insert

the discarded plug into a socket. If in

doubt contact a qualified, registered

Do not use extension cords or

ltiple sockets which could cause

overloading of wiring circuits and could

Always plug your appliance into its

own individual electrical socket which

has a voltage rating that matched the

Make sure that the plug is not

squashed or damaged. Otherwise

may cause short circuit, electric shock

or overheat and even cause a fire.

Do not insert the mains plug if the

socket is loose, there is a risk of

electric shock or fire.

Don't place hot items near the plastic

components of this appliance.

Frozen food must not be refrozen once

it has been thawed out.

Don't store bottled or canned drinks

(especially carbonated drinks) in the

freezer compartment. Bottles and cans

Do not consume ice popsicles or ice

cubes straight from the freezer as this

can cause freezer burn to the mouth

To avoid items falling and causing

injury or damage to the appliance, do

not overload the door racks or put too

much food in the crisper drawers.

This appliance is not intended

for use by persons (including

children) with reduced physical,

sensory or mental capabilities, or a

lack of experience and knowledge,

unless they have been given

supervision or instruction concerning

the use of the appliance by a person

responsible for their safety. Children

should be supervised to ensure that

they do not play with the appliance.

Keep all packaging away from

hildren to avoid risk of suffocation.

Protect children from being scalded

by touching the very hot compressor at

the rear bottom of appliance

Don't place items on top of the

appliance as this could cause injury

should they fall off.

Never allow children to play with the

appliance by hanging or standing over

or on the doors, racks, shelves and

To avoid the risks that are

always present when using an

electric appliance, we recommend that

you pay more attention to the

instructions about electricity below.

Hisense Refrigerator

3The refrigerant and risk of fire

Installing your new appliance

Ventilation of appliance

75 100100 Before using the appliance for the first

time, you should be informed of the

In order to improve efficiency

of the cooling system and save

energy, it is necessary to maintain

good ventilation around the appliance

for the dissipation of heat. For this

reason, sufficient clear space should

be available around the refrigerator.

Suggest :It is advisable for there to be

at least 75mm of space from the back

to the wall, at least 100mm from its

top,at last 100mm from its side to the

wall and a clear space in front to allow

the doors to open 135°. As shown in

This appliance performs well within

the climate class showed in the table

in the refrigerant circuit. Check

l on the rear of the

appliance to see which refrigerant is

used for your appliance.

If the appliance contains iso-butane

(R600a) refrigerant, which is

environmentally friendly but flammable,

ensure that tubing of the refrigerant

circuit is not damaged during

transportation and installation to avoid

risk of fire caused by leaking

Keep burning candles, lamps and

other items with naked flames and

sources of ignition away from the

appliance and ventilate the room

thoroughly to avoid the risk of fire and

eye injury should any leakage of

refrigerant (R600a) exist.

Do not store products which contain

flammable propellants (e.g. spray

cans) or explosive substances in the

The room space must be at least 1m³

per 8g of refrigerant (R600a). The

amount of refrigerant in your appliance

is indicated on the rating plate inside.

Switch off the appliance and

disconnect it from the mains power

Never unplug the appliance by pulling

on the electrical cord. Always grip the

plug firmly and pull straight out from

the socket to prevent damaging the

Do not operate the appliance without

the light cover of interior lighting.

Any electrical component must be

replaced or repaired by a qualified

electrician or authorized service

engineer. Only genuine spares should

Do not use electrical appliances such

as ice cream makers inside the food

storage compartments of the

appliance, unless they are approved

by the manufacturer.

Do not look direct into the LED light

located in the refrigerator compartment

with optical instruments to avoid eye

injuries. If it is not functioning correctly,

lectrician or replace it in accordance

with the “cleaning and care” chapter.

The appliance contains a

small quantity of refrigerant

(R600a or R134a) 100100 Hisense Refrigerator

+16°C to +43°C It may not work properly if being left at

a temperature above or below the

indicated range for a long period.

Stand your appliance in a dry place to

avoid high moisture.

Keep the appliance out of direct

sunlight， rain or frost. Stand the

appliance away from heat sources

such as stoves, fires or heaters.

Leveling of appliance

For sufficient leveling and air

circulating in the lower rear section of

the appliance, the bottom feet may

need to be adjusted. You can adjust

them manually by hand or by using a

To allow the doors to self-close, tilt

the top backwards by about 10mm.

Installing the door handles

For the convenience of transportation,

the door handles are separately

provided in a plastic bag, you can

install the door handles as follows.

1. Lever screw covers on the left side

of the door, and then put them back to

2. Match the handle on the left side of

the door, keeping axes of screw holes

in the handle and the door in a line, as

3. Fix the handle with the special

screws provided in the plastic bag. And

then install the handle covers.

The side at which the door opens can

be changed, from the right side (as

supplied) to the left side, if the

installation site requires.

Warning! When reversing the door, the

appliance must not be connected to

the mains. Ensure that the plug is

removed from the mains socket..

s you will need 8mm socket wrenchCross-shaped screwdriver8mm wrenchThin-blade screwdriver Note: Before you start lay the

refrigerator on its back in order to

gain access to the base, you should

rest it on soft foam packaging or

similar material to avoid damaging

the backboard of the refrigerator. To

reverse the door, the following steps

are generally recommended.

1. Stand the refrigerator upright.

Open the upper door to take out

door racks (to avoid rack sdamaged)

2. Open part ① on top of the

refrigerator body from right side and

then take down part ③ and part ④ on

the upper door in the same way. Take

down part ② and put it back to the

plastic bag. ③Upper cover of upper door②Upper hinge cover (right)①Upper cover ④Corner cover 3. Disconnect electrical connector① as

well as electrical connector②and then

Note: Please hold the upper door by hand

during step 4 to prevent door dropping.

4. Remove the screws ①, loose

wire②, and remove par③.

5. Remove the upper door and place it

on a smooth surface with its panel

upwards. Lever part①and part④ then

loose screws② , as shown in the

picture. Change handle③ to the right

side, then install screws②, part① and

part④ in turn. Loose screws⑦, detach

and another part⑥ (in the plastic

bag)to the left side with screws⑦.Put

part⑥ just detached back to plastic

② Special self-tapping screws ③ Handle① Handle covers ④ Screw hole covers

⑤ Door holder ⑥ Stop block ⑦ Self-tapping screws

6. Loose screws used to fix the middle

hinge and remove middle hinge. Then

remove the lower door.

Special flange self-tapping screwsEarth wire 1 2

part7. Place the lower door on a smooth

surface with its panel upwards.

Change the handle to the right side

according to step 5. Loose screws⑦，

detach part⑥and part⑤.Turn part⑤by

180°and then install part⑤and part⑥to

corresponding position on left side

together with screws⑦.

② Special self-tapping screws ③ Handle① Handle covers④ Screw hole covers ⑤ Door holder ⑥ Stop block ⑦ Self-tapping screws

8. Change screw hole covers on

middle cover plate from left to right (as

shown in figure below).

9. Place refrigerator flatwise, remove

part③ and then loose screws④.

Remove part ② and part①.

10. Screw out lower hinge, change it to

the near hole site, and then screw up

② Front foot fixed board

④ Self-tapping screws

③ Adjustable bottom feet part

① Lower hinge part（right） Note: washer maystick to lower door.washer Lower hinge part (left)

stick to lower door. Washer 11.Just remount to the step 9,change

part①to left and part②to right and then

fix them with screws④. Finally install

12. Move the lower door and adjust its

position to align lower hole site and

upper hinge axis. Turn the middle

hinge by 180, change the washer on

the axis to the upper side, adjust the

middle hinge to the appropriate

position and then install

13. Screw out The upper hinge axis,

turn the upper hinge over and fix axis

on it. Then place it at side for use.

Hisense Refrigerator

714. Exchange wires both in the left and

right slots of refrigerator body.

15. Move the upper door to appropriate

position, adjust part① and upper door,

Move the connecting wire② in the slot

of upper door from right to left， and

then fix part①and wire② by screws③.

(Please hold upper door by hand when

16. Connect electrical connector① in

accordance with step 3 and then

install part②(which is in the plastic

②upper hing e cover( left )

17.Reverse part① by 180°and install it

onto the right corner of upper door，

then mount part②. (both of which are

taken down in step 2)

18. Take the reed switch out of the

coping block(part③ 6 in step 3)and

mount it on another block for use

(which is with mark “R” in the plastic

bag). Put the coping block just

removed back to the plastic bag.

connector② , and then install part③ .

Install part ① connect the wire

20. Open the upper door, mount door

racks and then close it.

Be sure character side of reed

switch fits well with coping block.

Hisense Refrigerator

8Note: Due to unceasing modification of our products, your refrigerator may be

slightly different from this instruction manual, but its functions and using methods

remain the same. To get more space in the freezer, you can remove drawers (except

lower freezer drawer),installtion bracket and integrative ice maker/twistable ice tray.

View 1 of the appliance

3. Flexible wine rack

6. Fruit and vegetables crisper

9. Upper freezer drawer

10. Upper freezer glass shelf

11. Middle freezer drawer(huge box)

12. Middle freezer glass shelf

13. Lower freezer drawer

14. Adjustable bottom feet

16. Covered dairy rack

Moisture fresh crisper

RB403N4BC1/RB403N4DC1

(Spain/other country) RD-44WC4SQA/CLA2RB403N4CC2 RD-43WC4SBA/CSA2

Upper freezer glass shelf

Middle freezer glass shelf

Integrative ice maker

PartHisense Refrigerator

View 2 of the appliance

Note: Due to unceasing modification of our products, your refrigerator may be slightly

different from this instruction manual, but its functions and using methods remain the same.

To get more space in the freezer, you can remove drawers (except lower freezer

drawer),installtion bracket and integrative ice maker/twistable ice tray.

Optional part list Top LED lightFlexible wine rackWine rackMoisture 0 cool Upper freezer glass shelf

Middle freezer glass shelf Covered dairy rackHandleTwin LED lightPartModelFolded shelfTwist ice makerUpper freezer drawerMy fresh choiceIntegrative ice makerRD-45WC4SBA/CSA2RB449N4ZS2RD-46WC4SBA/CLA2RB468N4AC2RD-46WC4SBA/CLA1RB468N4BC1RD-46WC4SBA/CPA1RB468N4BW1 Cabinet

3. Flexible wine rack

7. Fruit and vegetables crisper

10. Upper freezer drawer

11. Upper freezer glass shelf

12. Middle freezer drawer(huge box)

13. Middle freezer glass shelf

14. Lower freezer drawer

15. Adjustable bottom feet

17. Covered dairy rack

RB403N4BC1/RB403N4DC1

button and the freezer temperature

setting will revert back to the previous

3 seconds until the light comes on.

When the holiday function is

activated, the temperature of the

refrigerator is automatically switched to

15℃ to minimize the energy

Important! Do not store any food in the

fridge during this time.

When the holiday function is on, you

can switch it off by pressing any button

of "Holiday", "Fridge" and "Super Cool

button. The fridge temperature setting

will revert back to the previous setting.

In case of alarm, “Alarm” icon will be

on and there will be buzzing sound.

Press “Alarm” key to clear alarm and

then “Alarm” icon will turn off and stop

When the door of fridge or freezer is

open for over 2 minutes, the door

alarm will sound. In case of door alarm

buzzer will sound 3 times every 1 min

and will stop alarming automatically

To save energy, please avoid keeping

the door open for a long time when

using the appliance. The door alarm

can also be cleared by closing the

If freezer temperature is too high due

to power failure or other reasons, there

will be a temperature alarm and the

freezer temperature setting displays “--

In case of temperature alarm, buzzer

will sound constantly for 10 times and

then stop automatically.

nutrients of fresh food and keep food

Press "Super Freeze" button to

activate the super freeze function. The

In case of the maximum amount of

food to be frozen, please wait about 24

Super freeze automatically switches

off after 26 hours and the freezer

temperature setting displays -24℃.

When super freeze function is on you

can switch off super freeze function by

pressing "Super Freeze" or "Freezer"

Press “Freezer” to set freezer

temperature between -14

as needed, and the control panel will

display corresponding value according

to the following sequence.

Press” Super Cool” button to activate

this function. The light will be

Super cool automatically switches off

after 6 hours and the refrigerator

temperature setting displays 2°C.

When super cool function is on you

can switch it off by pressing “Super

Cool” or “Refrigerator” button and the

refrigerator temperature setting will

revert back to the previous setting.

Super Cool can refrigerate

your food much faster,

keeping food fresh for a

Super Freeze will quickly

lower the temperature

within the freezer so food

will freeze vitamins and

If you are going to be away

for a long period of time, you

can activate this function by

pressing "Holiday" button for

Hisense Refrigerator

-16℃-18℃ -20℃-24℃ -14℃ or

light will be illuminated and the My

Fresh Choice compartment will be set

at -2°C.Using your appliance

● Bottle rackIt is for storing bottled wine or drinks. It can also slide along the shelf if required.

Door rack It is suitable for the storage of

eggs, canned liquid, bottled drinks and packed food, etc. Do not place too many heavy things in the racks The middle door shelf can be placed at different heights according to your requirements. Please take food out of the shelf ●

● Note: There are egg trays in the upper shelf and bottle holder in the lower shelf.Shelf in Refrigerator chamber There are shelves in refrigerator chamber, and they can be taken out to be cleaned. ●

In case of temperature alarm, press “Alarm” button for 3 seconds to check the highest freezer temperature. The temperature value and “Alarm” icon will according to the model.Caution! When power is restored, it is normal that the temperature alarm appears, this can be cleared by pressing “Alarm". Hisense Refrigerator

13 Folded shelf It is made up of fixed part and flexible part. It can be adjusted and folded to

achieve different storage volume as you need. See the picture ●

Note： If you want to spread out

the folded shelf, please press the outer verge of the flexible part first. Note: Please use gentle pressure on left or right side face to move the Bottle rack along the shelf.Crisper of refrigerator chamber

It is suitable for the storage of

fruits and vegetable.

The temperature there can be set

at -2℃,0℃ and 3℃ to meet

It can store various kinds of food

including cheese, meat, fish, fruits,

vegetables and other perishable

food under proper temperature.

Note: Bottled or canned drinks are

not allowed to be stored there.

The temperature there is about 2-

3℃ lower than that in the

refrigerator chamber.

It is used to store fish, meat and

other erodible food.

Note: When selecting the Super

Freeze function, ensure there is no

bottled or canned liquid which

could explode caused by volume

Integrative ice maker

It is used for making ice .

It is a removable accessory which

can be taken out to save space.

There is an ice maker cover to

keep the ice maker clean.

Note: If the ice maker is used for

the first time or has not been used

for a long time, please clean it

2. Pour water into the ice tray and

Pour water into the ice trays and

the water level shall not exceed the

top line as the follow picture shows.

Hisense Refrigerator

If required, it can also be taken

out with its hanger allowing you to

adjust the shelf at different heights

It is for controlling the

temperature of the crisper and

Wine rack can be folded up to

3. Place the ice maker in its original

position.Helpful hints and tips

refrigerator or freezer, the internal

temperature will increase resulting in

the compressor having to work harder

and will consume more energy.

Do cover or wrap the food，

particularly if it has a strong flavor.

Place food properly so that air can

circulate freely around it.

Hints for refrigeration

Meat (All Types) Wrap in polythene

food: wrap and place on the glass shelf

above the vegetable drawer. Always

follow food storage times and use by

dates suggested by manufacturers.

Cooked food, cold dishes, etc.:

They should be covered and may be

placed on any shelf.

Fruit and vegetables:

They should be stored in the special

We recommend that you follow the tips

below to save energy.

Try to avoid keeping the door open

for long periods in order to conserve

Ensure the appliance is away from

any sources of heat (Direct sunlight,

electric oven or cooker etc)

Don't set the temperature colder than

Don't store warm food or evaporating

liquid in the appliance.

Place the appliance in a well

ventilated, humidity free, room. Please

refer to Installing your new appliance

If the diagram shows the correct

combination for the drawers, crisper

and shelves, do not adjust the

combination as this is designed to be

the most energy efficient configuration.

Hints for fresh food refrigeration

Do not place hot food directly into the

Note: If the ice tray is used for the first

time or has not been used for a long

time, please clean it before using.

The twist ice tray is used to make and

deposit ice cubes. You should use it as

1. Pull out the twistable ice tray from

the installation bracket.

2. Pour water into the ice trays and the

water level shall not exceed the

3. Place the filled ice tray back to the

4. When ice cubes form, twist the

knobs clockwise and the ice will drop

into the ice box below.

5. Ice cubes can be stored in the ice

box, if you need them, you can pull out

the ice box and take them out.

Hisense Refrigerator

For hygienic reasons the appliance

(including exterior and interior

accessories) should be cleaned

regularly at least every two months.

Caution! The appliance must not be

connected to the mains during

cleaning. Danger of electrical shock!

Before cleaning switch the appliance

off and remove the plug from the

To maintain good appearance of your

appliance, you should clean it

-Wipe the digital panel and display

panel with a clean, soft cloth.

-Spray water onto the cleaning cloth

instead of spraying directly on the

surface of the appliance. This helps

ensure an even distribution of moisture

-Clean the doors, handles and cabinet

surfaces with a mild detergent and then

wiped dry with a soft cloth.

-Don't use sharp objects as they are

likely to scratch the surface.

-Don't use Thinner, Car detergent,

Clorox, ethereal oil, abrasive cleansers

or organic solvent such as Benzene for

cleaning. They may damage the

surface of the appliance and may

You should clean the appliance interior

regularly. It will be easier to clean when

food stocks are low. Wipe the inside of

the fridge freezer with a weak solution

of bicarbonate of soda, and then rinse

with warm water using a wrung-out

sponge or cloth. Wipe completely dry

before replacing the shelves and

Should have a lid and be stored in the

When first starting-up or after a period

out of use, let the appliance run at

least 2 hours on the higher settings

before putting food in the

Prepare food in small portions to

enable it to be rapidly and completely

frozen and to make it possible to

subsequently thaw only the quantity

Wrap up the food in aluminum foil or

polyethylene food wraps which are

Do not allow fresh，unfrozen food to

touch the food which is already frozen

to avoid temperature rise of the latter.

Iced products， if consumed

immediately after removal from the

freezer compartment, will probably

cause frost burns to the skin.

It is recommended to label and date

each frozen package in order to keep

track of the storage time.

Hints for the storage of frozen food

Ensure that frozen food has been

stored correctly by the food retailer

Once defrosted，food will deteriorate

rapidly and should not be re-frozen. Do

not exceed the storage period indicated

by the food manufacturer.

Switching off your appliance

If the appliance needs to be switched

off for an extended period, the following

steps should be taken prevent mould

Remove the power plug from the

3. Clean and dry the interior thoroughly.

4. Ensure that all the doors are wedged

open slightly to allow air to circulate.

If you experience a problem with your appliance or are concerned that the

appliance is not functioning correctly, you can carry out some easy checks before

calling for service, please see below. You can carry out some easy checks

according to this section before calling for service.

Thoroughly dry all surfaces and

Although this appliance automatically

defrosts, a layer of frost may occur on

the freezer compartment's interior

walls if the freezer door is opened

frequently or kept open too long. If the

frost is too thick, choose a time when

the supply of food stocks are low and

1 . R emove existing food and

accessories baskets, unplug the

appliance from the mains power and

leave the doors open. Ventilate the

room thoroughly to accelerate the

2. When defrosting is completed,

your freezer as described above.

Caution! Don't use sharp objects to

remove frost from the freezer

compartment. Only after the interior is

letely dry should the appliance be

switched back on and plugged back

into the mains socket.

Take care to keep door seals clean.

Sticky food and drinks can cause seals

to stick to the cabinet and tear when

you open the door. Wash seal with a

mild detergent and warm water. Rinse

and dry it thoroughly after cleaning.

Caution! Only after the door seals are

completely dry should the appliance be

Replacing the LED light:

LED light must not be

replaced by the user! If the LED light is

damaged, contact the customer

helpline for assistance. To replace the

, the below steps can be

1. Unplug your appliance.

2. Remove light cover by pushing up

3. Hold the LED cover with one hand

and pull it with the other hand while

pressing the connector latch.

4. Replace LED light and snap it

Hisense Refrigerator

Warning! Don't try to repair the appliance yourself. If the problem persists after you

have made the checks mentioned below, contact a qualified electrician, authorized

service engineer or the shop where you purchased the product.Problem

Check whether the power cord is plugged into the power outlet

Check the fuse or circuit of your power supply, replace if

The ambient temperature is too low. Try setting the chamber

temperature to a colder level to solve this problem.

It is normal that the freezer is not operating during the

automatic defrost cycle, or for a short time after the appliance

is switched on to protect the compressor.

The interior may need to be cleaned

Some food, containers or wrapping cause odours.

The sounds below are quite normal:

Compressor running noises.

Air movement noise from the small fan motor in the freezer

compartment or other compartments.

Gurgling sound similar to water boiling.

Popping noise during automatic defrosting.

Clicking noise before the compressor starts.

Other unusual noises are due to the reasons below and may

need you to check and take action:

The cabinet is not level.

The back of appliance touches the wall.

Bottles or containers fallen or rolling.

It is normal to frequently hear the sound of the motor, it will

need to run more when in following circumstances:

Temperature setting is set colder than necessary

Large quantity of warm food has recently been stored within

The temperature outside the appliance is too high.

Doors are kept open too long or too often.

After your installing the appliance or it has been switched off

A layer of frost occurs in

Check that the air outlets are not blocked by food and ensure

food is placed within the appliance to allow sufficient

ventilation. Ensure that door is fully closed. To remove the

frost, please refer to cleaning and care chapter.

Temperature inside is

You may have left the doors open too long or too frequently; or

the doors are kept open by some obstacle; or the appliance is

located with insufficient clearance at the sides, back and top

Temperature inside is

Increase the temperature by following the "Display controls”

Doors cant be closed

Check whether the top of the refrigerator is tilted back by

10-15mm to allow the doors to self close, or if something inside

Possible cause & Solution

Appliance is not working

compartmentsis preventing the doors from closing.

Water drips on the floor

The water pan (located at the rear bottom of the cabinet) may

not be properly leveled, or the draining spout （ located

underneath the top of the compressor depot） may not be

properly positioned to direct water into this pan , or the water spout is blocked. You may need to pull the refrigerator away

from the wall to check the pan and spout.

The light is not working

The LED light may be damaged. Refer to replace LED lights

in cleaning and care chapter.

The control system has disabled the lights due to the door

being kept open too long, close and reopens the door to

reactivate the lights.

Disposal of the appliance

It is prohibited to dispose of this appliance as household waste.

Packaging materials Packaging materials with the recycle symbol are recyclable. Dispose of the packaging into

a suitable waste collection container to recycle it.

Before disposal of the appliance

1. Pull out the mains plug from the mains socket. 2. Cut off the power cord and discard with the mains plug

Warning! Refrigerators contain refrigerant and gases in the insulation. Refrigerant and

gases must be disposed of professionally as they may cause eye injuries or ignition.

Ensure that tubing of the refrigerant circuit is not damage prior to proper disposal.

Correct Disposal of this product

This symbol on the product or in its packing indicates that this product may

not be treated as household waste. Instead, it should be taken to the

appropriate waste collection point for the recycling of electrical and electronic

equipment. By ensuring this product

is disposed of correctly, you will help prevent potential

negative consequences for the environment and human

health, which could otherwise be caused by the inappropriate waste handling

of this product. For more detailed information about the recycling of this

product, please contact your local council your household waste disposal service, or the shop where you purchased the product.

RB403N4BC1/RB403N4DC1

(Spain/other country)

RB468N4BW1RD-44WC4SBA/CLA2

RB403N4BC1/RB403N4DC1

%RWHOODVGHOHFKH

DXPHQWHGHWHPSHUDWXUD

ODIHFKDGHFRQJHODFLyQGHFDGDSDTXHWH

/LPSLHODVSXHUWDVWLUDGRUHV\

VXSHUILFLHVGHORVFRPSDUWLPHQWRVFRQ

XQGHWHUJHQWHQHXWUR\DFRQWLQXDFLyQ

del compartimento a un nivel más frío para solucionar este problema.

It is normal that the freezer is not operating during the automatic

defrost cycle, or for a short time after the appliance is switched on

to protect the compressor.Podría ser necesario limpiar el interior

3RXUpYLWHUOHVULVTXHVWRXMRXUVOLpV

VHFSRXUpYLWHUOHVWDX[GKXPLGLWppOHYpV

1H[SRVH]SDVODSSDUHLOjODOXPLqUH

GLUHFWHGXVROHLOjODSOXLHRXDXJHO

1LQVWDOOH]SDVODSSDUHLOjSUR[LPLWpGH

VRXUFHVGHFKDOHXUWHOOHVTXHGHV

FXLVLQLqUHVFKHPLQpHVRXUDGLDWHXUV

(QVXLWHLQVWDOOH]OHVSURWHFWLRQV

PRXVVHRXDXWUHPDWL

RB403N4BC1/RB403N4DC1

(Spain/other country)

RB468N4BW1RD-44WC4SBA/CLA2

RB403N4BC1/RB403N4DC1

1HWWR\H]HWVpFKH]VRLJQHXVHPHQW

,OHVWLQWHUGLWGHPHWWUHFHWDSSDUHLODXUHEXWFRPPHQLPSRUWHTXHODXWUHGpFKHWPpQDJHU

4XHVWRDSSDUHFFKLRqVWDWRFRQFHSLWR

VXSRUWHFHVWHOOLULSLDQLFDVVHWWLHFF

RB403N4BC1/RB403N4DC1

(Spain/other country)

RB468N4BW1RD-44WC4SBA/CLA2

RB403N4BC1/RB403N4DC1

VFRPSDUWRFRQJHODWRUHSRVVRFDXVDUH

%HVFKHUPNLQGHUHQWHJHQ

ZRUGHQJHQRPHQQDPHOLMN

VFKRNWHYRRUNRPHQPDJGHDIJHGDQNWH

VFKXLPYHUSDNNLQJRIVRRUWJHOLMN

YROJHQGHVWDSSHQDDQJHUDGHQ

2PJHYLQJVWHPSHUDWXXU

RB403N4BC1/RB403N4DC1

(Spain/other country)

RB468N4BW1RD-44WC4SBA/CLA2

RB403N4BC1/RB403N4DC1

"Holiday" knop 3 seconden

WHEHKRXGHQPRHWXKHWUHJHOPDWLJ

9HHJKHWGLJLWDOHSDQHHOHQZHHUJDYHSDQHHO

PHWHHQVFKRQH]DFKWHGRHN

PRHWHQGHYROJHQGHVWDSSHQJHQRPHQ

+HWEHVWXULQJVV\VWHHPKHHIWGHOLFKWHQXLWJHVFKDNHOGRPGDW

1HVWHFDVRJXDUGHWRGRVRVPDWHULDLV

YROWDJHPH[FHGHUROLPLWHXPUHJXODGRU

as portas se abram a 135°.

Depois instale as tampas das

20. Abra a porta superior, monte as

RB403N4BC1/RB403N4DC1

(Spain/other country)

RB468N4BW1RD-44WC4SBA/CLA2

RB403N4BC1/RB403N4DC1

correcta para as gavetas,

recolar as prateleiras e gavetas.Seque todas as partes.
