ECO ST - Hand blender IMETEC - Free user manual and instructions

Product type	Immersion blender with whisks and propeller
Brand	Imetec
Model	ECO ST
Power supply	220-240 V ~ 50/60 Hz
Power	500 W (estimated)
Speeds	ECO (low speed) and TURBO/PULSE (high speed)
Maximum dough capacity	600 g of flour and 400 ml of water
Continuous operating time	5 minutes maximum
Included accessories	Whisks (2) and propeller
Cleaning motor unit	Damp sponge, well wrung out
Cleaning accessories	Dishwasher up to 60 °C
Protection class	Class II (double insulation)
Usage	Household use only
Dimensions (estimated)	40 x 10 x 10 cm
Weight (estimated)	1 kg
Warranty	Manufacturer's warranty (see attached sheet)
After-sales service	IMETEC authorized service center
User manual	Available for free download at notice-facile.com

Frequently Asked Questions - ECO ST IMETEC

How to attach the whisks or propeller to the motor unit?

Insert the whisks (5) or propeller (8) into the motor unit (6) until they click. To remove, press the eject button (7).

What speed is recommended for each use?

Use ECO speed to save energy and TURBO/PULSE speed to speed up work.

Can I use the appliance continuously for more than 5 minutes?

No, the continuous operating time must be less than 5 minutes. Let the appliance cool down completely before repeating the cycle.

What is the maximum amount of ingredients for a dough?

Do not work dough with more than 600 g of flour and 400 ml of water.

How to clean the motor unit?

Clean the motor unit (6) and power cord with a damp, well-wrung sponge. Never immerse in water.

Can the whisks and propeller be put in the dishwasher?

Yes, they can be washed in the dishwasher at a maximum temperature of 60 °C.

What to do in case of breakdown or malfunction?

Turn off the appliance, unplug it, and contact an authorized technical service center. Do not tamper with the appliance.

Can I use the appliance near a sink full of water?

No, do not use the appliance near a sink full of water and ensure it does not fall into water.

Can children use this appliance?

The appliance can be used by minors over 12 years of age under supervision. Children must not play with the appliance or perform cleaning without supervision.

Where can I download the full manual?

The full manual is available for free in PDF format at notice-facile.com.

USER MANUAL ECO ST IMETEC

Tel. +39.035.688.111 Fax +39.035.320.149

Dear customer, IMETEC thanks you for having purchased this product. We are certain you will appreciate the quality and reliability of this appliance, designed and manufactured with customer satisfaction in mind. This instruction manual has been drawn up in compliance with the European Standard EN 62079.

IMPORTANT!

Instructions and warnings for a safe use.

Before using this appliance, carefully read the instructions and in

particular the safety warnings, which must be complied with. Keep this manual along with the relative illustrative guide, for the entire life-span of the appliance, for consultation. If the appliance is transferred to third parties, also consign the entire documentation.

Should certain parts of this booklet be difficult to understand or should doubts arise, contact the company before using the product, at the address indicated on the last page.

INDEX

SAFETYWARNINGS page 5

SYMBOLS page 7

DESCRIPTION OF THE APPLIANCE

AND ACCESSORIES page 7

FUNCTIONING page 7

CLEANING THE WHISKS AND HOOKS page 7

CLEANING THE MOTOR BLOCK page 8

USE page 8

DISPOSAL page 8

SERVICE AND WARRANTY

ILLUSTRATIVE GUIDE

TECHNICAL DATA III

SAFETYWARNINGS

• After having removed the appliance from its packaging, verify its integrity based on the drawing and any presence of damage caused by transport. If in doubt, do not use the appliance and contact an authorised service centre.
• The packaging is not a toy for children! Keep the plastic bag out of the reach of children - risk of suffocation!
• Before connecting the appliance, please make sure that the voltage indicated on the identification plate corresponds to that of the mains voltage. The identification plate is found on the appliance.

GB

• This appliance must be used only for the purpose for which it was designed, that is as a BEATER for home use. Any other use is is improper and therefore dangerous.
• This appliance may be used by children below 12 years of age, by persons with reduced physical, sensorial or mental abilities or by unskilled persons only if they have been instructed beforehand concerning its safe use and if they have been informed on the risks linked to the product. Children must play with the appliance. The appliance must not be cleaned or serviced by children without adult supervision. Keep the appliance and the power cable away from the reach of children below 12 years of age when it is on or heating up.

DO NOT use the appliance with damp or wet hands or feet.
DO NOT pull on the power cable or appliance to unplug it from the mains socket.
DO NOT expose the appliance to humidity or weather conditions (rain, sunlight).
- Always unplug the appliance before cleaning or maintenance and whenever you do not need to use it.
- If the appliance is faulty or malfunctions, switch it off and do not tamper with it. Any repairs must only be carried out by an authorised technical service centre.
- If the power cable is damaged, it must be replaced by an authorised technical after-sales centre, so as to prevent all risks.
NEVER submerge the appliance in water and never place it underneath a tap with running water.
- The appliance is not intended to be operated by an external timer, by a separate remote control system or by other similar devices.
DO NOT use the appliance near a washbasin full of water. During use, the appliance must be placed in such a way that it cannot fall into the washbasin.
DO NOT use near the kitchen hob. Be careful that the cable does not touch hot, incandescent surfaces, open flames, pans or other utensils.
NEVER touch the moving parts.

IMPORTANT!

• DO NOT try to touch and/or remove the whisks while the appliance is running.

Turn the appliance off and unplug it before mounting / removing the whisks and when you have finished using it.

DO NOT use the appliance with clothing having wide long sleeves which could get caught in the whisks during use.

SYMBOLS

□	Class II appliance
i	Instruction manual

DESCRIPTION OF THE APPLIANCE AND ACCESSORIES [Fig. A]

1. Speed regulator
   2 Pulse key
   3 Vents
   4 Power supply cable
   5 Whisks
   6 Motor block
   7 Ejector button
   8 Hooks

FUNCTIONING

The ON/OFF controls (1) and (2) can be used in the following modes:

SYMBOL ON PRODUCT	FUNCTION
ECO Low speed, to limit energy consumption during operation.
TURBO / PULSE High speed, to speed up operation.

CLEANING THE WHISKS (5) AND THE HOOKS (8)

Detach the whisks (5) or hooks (8) by pressing the ejector button (7) [Fig B].

The whisks (5) and hooks (8) can be washed:

• by hand, with water and cleanser;
• in the dishwasher; make sure that the temperature of the water does not exceed 60^ .

GB

CLEANING THE MOTOR BLOCK (6)

• Use a moist and well wrung sponge to clean the motor block (6) and the power cable (4).

USE

WARNING:

• Do not obstruct the vents during use (3).
• Do not let water or other objects into the vents (3).
• Continuous operating time must not exceed 5 minutes.
• Before repeating this cycle, let the appliance cool off.

• Do not mix an amount of ingredients exceeding 600 gr. 400ml of water.

• Insert the motor block (6), the whisks (5) or the hooks (8) depending on the operation [Fig. C].

• Insert the whisks (5) or the hooks (8) into the food.
  Plug the power cable (4) into the socket.
• Adjust the speed regulator (1) or (2) as needed.

DISPOSAL

The product is packaged in recyclable materials. Dispose of it in compliance with the environmental protection standards.

The product must be disposed of properly, in accordance with the European standard 2002/96/EC. The recyclable materials contained in the appliance must be recovered, so as to prevent environmental pollution. For further information, contact the waste disposal facility or appliance dealer.

SERVICE AND WARRANTY

To request repairs or purchase spare parts, please contact IMETEC's customer assistance service by calling the free-phone number below (only in Italy) or consulting the website. The appliance is covered by the manufacturer's warranty. For details, read the attached warranty sheet.

Failure to comply with the use and maintenance instructions provided in this user manual will invalidate all and any rights to the manufacturer's warranty.

IMETEC

www.imetec.com

Tenacta Group S.p.A. Via Piemonte 5/11 24052 Azzano S. Paolo (BG) ITALY

Tel. +39.035.688.111 Fax +39.035.320.149
