Product Type Wine Cellar (service cellar)
Brand AVINTAGE
Models AVI47XDZ, AVI48CDZ
Dimensions (W x D x H) 595 x 556 x 887 mm
Net Weight 45 kg
Power Supply 220-240 V / 50 Hz
Energy Class B
Annual Consumption 190 kWh/year
Net Volume 124.4 L
Temperature Range 5 °C to 18 °C (per zone)
Defrost Automatic
Climate Class N/SN (10 °C to 32 °C)
Noise Level 41 dB(A)
Installation Type Built-in column
Refrigerant R600a (isobutane, 30 g)
Interior Lighting LED (0.5 W)
Main Functions Electronic temperature control, digital display, silent/forced cooling mode, anti-vibration and anti-UV system
Maintenance and Cleaning Clean with a soft cloth and warm water; automatic defrost; do not use abrasive products
Safety Child safety (lock not specified), flammable refrigerant, unplug before maintenance
Spare Parts and Repairability Original parts available from authorized after-sales service
General Information Distributor warranty, non-contractual document, made in China

Frequently Asked Questions - AVI47XDZ - AVI48CDZ AVINTAGE

How to adjust the temperature of the wine cellar?
Press the zone selection button (2) to choose the zone, then use the + (4) and - (5) buttons to adjust the temperature degree by degree. The range is 5 °C to 18 °C in each zone.
Can I reverse the door opening direction?
Yes, the door is reversible. Follow the instructions in the manual: remove the hinges, turn the door 180° and reinstall the hinges on the opposite side. Keep all screws.
What to do if the cellar does not cool enough?
Check the set temperature, the ambient temperature (must be between 10 and 32 °C), ensure the door is properly closed, the gasket is tight, and the ventilation grilles are not obstructed.
How to clean my wine cellar?
Unplug the appliance. Clean the interior and exterior with a soft cloth dampened with warm water and mild detergent. Rinse with clean water and dry completely before plugging back in. Do not use solvents or abrasives.
What to do in case of a power outage?
A power outage of 1 to 2 hours does not affect the temperature. For longer outages, minimize door openings. After a stop, wait 3 to 5 minutes before restarting to protect the compressor.
How many bottles can I store?
The net volume is 124.4 L. The maximum capacity varies depending on the bottle type (Bordeaux, Burgundy). In practice, plan for about 30% less than the maximum stated due to the diversity of formats.
The cellar makes a water running sound, is this normal?
Yes, this noise is produced by the circulation of refrigerant gas in the circuit. It is normal. Clicking noises may also occur due to contraction/expansion of the walls.
How to change the LED bulb?
The lighting is LED and cannot be changed by the user. If the LED is defective, contact authorized after-sales service.
Can I use the wine cellar outdoors?
No, the appliance is intended for indoor use only. It must be installed in a dry place, away from sunlight and heat sources.
What are the possible error codes?
The code 'EL' or 'EH' indicates a faulty temperature sensor. In this case, unplug and contact after-sales service. A flashing display means a temperature deviation of more than 5 °C.
