Product type	Electric floor blower with wheels
Brand	Cecotec
Model	Blowindustry 6000 FlowFloor
Reference	EU01_106746
Power supply	220-240 V~, 50-60 Hz
Power	600 W
Protection class	Class II
Blower speeds	3 positions: 1 (low), 2 (medium), 3 (high)
Maximum air flow	19.5 m³/min
Maximum air speed	3.5 m/s
Acoustic power level	80.6 dB(A)
Service value	0.03 (m³/min)/W
Handle	Foldable handle with release button
Mobility	Integrated wheels for easy transport
Air outlet	Front air outlet with grille
Maintenance	Inlet and outlet grilles cleaned with a brush; exterior with a damp cloth
Safety	Stop at position 0; do not use if the cable is damaged; not recommended near water
Aftersales service and repairability	Repairs by qualified personnel; Cecotec aftersales service [phone]
Intended use	Domestic use only (non-professional)
Origin	Made in China, designed in Spain

Frequently Asked Questions - Blowindustry 6000 Flowfloor CECOTEC

Is the Cecotec Blowindustry 6000 FlowFloor a washing machine?

No, it is an electric blower designed to produce a powerful air flow. It does not wash clothes and should only be used as a blower, in accordance with the instructions in the manual.

What are the different blower speeds?

The selector offers 3 speeds: position 1 = low, position 2 = medium, position 3 = high. Position 0 turns the appliance off.

How do I turn the appliance on and off?

To turn it on, turn the selector to the desired speed (1, 2 or 3). To turn it off, set the selector to 0.

Is this appliance suitable for professional use?

No, it is designed for domestic use only. The instructions advise against use in bars, restaurants, farms, hotels, motels and offices.

How do I adjust the air flow?

The air flow is adjusted using the selector: position 1, 2 or 3. The maximum stated air flow is 19.5 m³/min.

Is the handle foldable?

Yes, the handle is foldable. Simply press the button at the top of the handle to fold or unfold it. It allows you to transport the appliance on its wheels.

How do I clean the blower?

Always unplug the appliance before cleaning. Use a soft, damp cloth for the exterior and a brush to clean the air inlet and outlet grilles.

What should I do if the appliance makes an unusual noise?

Check for dust buildup or a foreign object without disassembling the appliance. If the noise persists, contact Cecotec After-Sales Service at [phone].

What is the power and consumption of the appliance?

The blower has a power of 600 W and a standby consumption of 0 W. It operates on a voltage of 220-240 V~, 50-60 Hz.

What accessories are included?

The box contains the blower and the instruction manual. No additional accessories are mentioned in the instructions.

USER MANUAL Blowindustry 6000 Flowfloor CECOTEC

BLOWINDUSTRY 6000 FLOWFLOOR

Soplador de aire industrial / Industrial air blower

Safety instructions 7

1. Parts and components 38

2. Before use 38

3. Operation 39

4. Cleaning and maintenance 39

5. Troubleshooting 40

6. Technical specifications 40

7. Disposal of old electrical appliances 41

8. Technical support and warranty 41

9. Copyright 42

10. Simplified Declaration of Conformity 42

SOMMAIRE

EN • The coding in this manual is generic and applies to all code variants of the appliance.

Read these instructions thoroughly before using the appliance. Keep this instruction manual for future reference or new users.

• This appliance can be used by children aged 8 years and above and people with reduced physical, sensory, or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children must not play with the appliance. Cleaning and user maintenance should not be carried out by unsupervised children.
• This appliance is designed for domestic use only and is not intended for bars, restaurants, farmhouses, hotels, motels, and offices.
• Failure to strictly follow the instructions in this manual may result in damage to the product or injury.
• If the power cord is damaged, do not use the product; otherwise, there is a great risk of electric shock, or the product may overheat and cause a fire.
• Do not use the product in a dusty or smoky environment.
• Do not place the power cord over edges, corners or any other sharp areas to avoid damage.
• Before using the product, always check that no parts are damaged. If any parts are damaged, do not use it; otherwise, you may suffer an electric shock.
• If the power cord is damaged, it must be replaced by the official Cecotec Technical Support Service or similar qualified personnel to avoid risks.

• If you notice that the product is not working properly or if you think it may have fallen or got wet, please contact the official Cecotec Technical Support Service to check if it is safe to use.

• Before cleaning the appliance or performing any maintenance task, make sure that the product is switched off and unplugged from the mains.

• Do not use the product in places where the ambient temperature is too high.
• Do not use it near swimming pools or any other place where water is present. Do not immerse the product in any liquid or allow water to come in contact with any of its parts.
• Do not allow children to play with the packaging, otherwise they may choke.
• Do not allow children to use or play with the product.
• Place the product on a flat, stable surface.
• Do not wear any clothing that could get caught in the product, e.g. ties, scarves, etc.

INSTRUCTIONS DE SÉCURITÉ

1. Folding handle
2. Knob
3. Wheels
4. Folding handle button
5. Carrying handle
6. Housing
7. Air outlet

NOTE:

The graphics in this manual are schematic representations and may not exactly match the product.

2. BEFORE USE

• This appliance includes a safety package to protect it during transport. Take the appliance out of the box and remove all packaging materials. You can keep the original box and other packaging elements in a safe place. This will help you prevent damage to the product when transporting it in the future. In case the original packaging is disposed of, make sure all packaging materials are recycled accordingly.
• Make sure all parts and components are included and in good conditions. If there is any piece missing or in bad conditions, contact the official Cecotec Technical Support Service immediately.

Box content

• Leaf blower
• Instruction manual

- Do not remove the serial number of the appliance in order to keep a correct traceability of it in case of assistance.

3. OPERATION

Switching on/off

Fig. 2

To switch on the blower, turn the knob to select the desired airflow speed. The blower will run at the selected power.

To switch off the blower, turn the knob to the "0" position.

Airflow speed

To adjust the airflow speed, turn the knob to any of the following positions:

• 1 = low speed.
• 2 = medium speed.
• 3 = high speed.

Picking up/extending the folding handle

Fig. 1

The folding handle can be retracted for easy storage. To do so, press the button on top of the folding handle and press down to store it.

This handle can be used for greater convenience when carrying the appliance. To extend it, press the button on top of the folding handle and pull it upwards. Once extended, you can use it to hold the blower while you move it comfortably using the wheels.

4. CLEANING AND MAINTENANCE

Cleaning

• Before cleaning the product, make sure to unplug it from the mains.
• Use a soft cloth slightly dampened with water to clean the outside of the appliance.
• Clean the air inlet and outlet vents regularly with a brush.

Maintenance

• Make sure that no parts are damaged before and after use.
• Also check that there are no foreign objects; if there are, switch it off and contact the official Cecotec Technical Support Service.

5. TROUBLESHOOTING

Problem	Possible causes	Possible solutions
The product does not work.	The power cord is not properly plugged in.	Plug the power cord back in.
	No power is being supplied to the appliance.	Check that the socket to which the appliance is plugged in is supplied with power.
	The power cord is damaged.	Check the power cord and if you detect any problems with it or any other part of the product, please contact the official Cecotec Technical Support Service.
The product makes unusual noises.	There is too much dust accumulated inside the product.	Clean the product without disassembling the appliance.
	There is a foreign object inside the product.	Switch off the product, unplug the power cord and try to remove the foreign object without disassembling the appliance.
	The product is damaged.	Contact the official Cecotec Technical Support Service.
The product shakes a lot.	There is too much dust accumulated inside the product.	Clean the product without disassembling the appliance.
	There is a foreign object inside the product.	Switch off the product, unplug the power cord and try to remove the foreign object without disassembling the appliance. If you are unable to remove the object, please contact the official Cecotec Technical Support Service.

6. TECHNICAL SPECIFICATIONS

Product reference: EU01_106746

Product: BlowIndustry 6000 FlowFloor

Voltage: 220-240 V\~

Frequency: 50-60 Hz

Power: 600 W

Class II

Description	Symbol	Value	Unit
Fan maximum flow	F	19.5	m3/min
Fan power consumption	P	568.3	W
Service value	SV	0.03	(m3/min)/W
Power consumption on standby mode	PSB	0	W
Fan noise power level	LWA	80.6	dB (A)
Maximum air speed	C	3.5	m/s
Service value measurement standard	IEC 60879:2019
Contact details to obtain more information	Cecotec Innovaciones SL.Av. Reyes Católicos, No 60, 46910,Alfafar (Valencia, Spain)

Technical specifications may change without prior notification to improve product quality. Made in China | Designed in Spain

7. DISPOSAL OF OLD ELECTRICAL APPLIANCES

This symbol indicates that, according to the applicable regulations, the product and/or batteries must be disposed of separately from household waste. When this product reaches the end of its shelf life, you should dispose of the cells/batteries/accumulators and take them to a collection point designated by the local authorities.

Consumers must contact their local authorities or retailer for information concerning the correct disposal of old appliances and/or their batteries.

Compliance with the above guidelines will help protecting the environment.

8. TECHNICAL SUPPORT AND WARRANTY

Cecotec shall be liable to the end user or consumer for any lack of conformity that exists at the time of delivery of the product under the terms, conditions and deadlines established by the applicable regulations.

Repairs should be carried out by qualified personnel.

If at any moment you detect any problem with your product or have any doubt, do not hesitate to contact the official Cecotec Technical Support Service at [phone].

ENGLISH

9. COPYRIGHT

The intellectual property rights over the texts in this manual belong to CECOTEC INNOVACIONES, S.L. All rights reserved. The contents of this publication may not, in whole or in part, be reproduced, stored in a retrieval system, transmitted, or distributed by any means (electronic, mechanical, photocopying, recording or similar) without the prior authorization of CECOTEC INNOVACIONES, S.L.

10. SIMPLIFIED DECLARATION OF CONFORMITY

CE Cecotec Innovaciones hereby declares that this appliance complies with the essential requirements and other relevant provisions of applicable European Union regulations. This appliance has been designed, manufactured and tested in compliance with required safety and quality standards. The full text of the EU Declaration of Conformity can be found on the following website: https://cecotec.es/es/information/declaration-of-conformity
