ReadyWarm 1500 Max Ceramic Rotate - Fan heater CECOTEC - Free user manual and instructions

Product type	Fan heater
Brand	Cecotec
Model	ReadyWarm 1500 Max Ceramic Rotate
Power	1500 W
Heating element	Ceramic
Oscillation	Automatic rotation (360°)
Heat settings	2 levels (1000 W / 1500 W)
Thermostat	Adjustable (comfort temperature)
Safety	Overheat and tip-over protection
Power supply	220-240 V, 50/60 Hz
Dimensions (L x W x H)	22 x 18 x 28 cm
Weight	1.8 kg
Power cord	1.5 m
Use	Indoor only
Cleaning	Unplug and wipe with a soft, dry cloth
Spare parts	Contact Cecotec customer service
Warranty	2 years

Frequently Asked Questions - ReadyWarm 1500 Max Ceramic Rotate CECOTEC

How to turn the device on and off?

Plug in the device, then use the on/off button to turn it on or off. Select the desired heating mode.

How to adjust the temperature?

Turn the thermostat to set the desired temperature. The device automatically stops once the temperature is reached.

How to activate oscillation?

Press the oscillation (rotation) button to rotate the heater and distribute heat throughout the room.

What is the maximum power and how to select it?

The maximum power is 1500 W. Use the selector to choose between 1000 W and 1500 W according to your needs.

Can the device be used in a bathroom?

No, this heater is designed for indoor use in dry rooms only. Never use it near water.

How to clean the heater?

Unplug the device and wait for it to cool down. Clean the exterior surface with a soft, dry cloth. Do not use abrasive products.

What to do if the device does not heat?

Check that the device is plugged in and the thermostat is set above room temperature. If the problem persists, contact customer service.

Is there overheat protection?

Yes, the device is equipped with overheat protection. If it detects excessive temperature, it automatically turns off.

Can I leave the device on unattended?

It is not recommended to leave the device on unattended, especially around children or pets. Use with caution.

Where can I find spare parts?

For spare parts or accessories, please contact Cecotec customer service via their official website or by phone.

USER MANUAL ReadyWarm 1500 Max Ceramic Rotate CECOTEC

Two rectangular electronic devices with perforated surfaces, one white and one dark gray, against a dark background (no text or symbols visible)

ES · Este producto no es adecuado para calefacción primaria. Este producto está indicado únicamente en lugares abrigados o para una utilización puntual. EN · This product is not suitable for primary heating purposes. This product is only suitable for well insulated spaces or occasional use. FR · Ce produit ne convient pas pour une utilisation en tant que chauffage primaire. Cet appareil a été conçu seulement pour être utilisé dans des espaces intérieurs ou pour une utilisation momentanée. DE · Dieses Produkt ist nicht für als Hauptheizgerät geeignet. Dieses Produkt ist nur für geschützten Orten oder zur gelegentlichen Verwendung geeignet. IT · Questo prodotto non è adatto a riscaldamento primario. Questo prodotto è indicato solamente per luoghi caldi o per uso sporadico. PT · Este produto não é adequado para aquecimento primário. Este produto só é indicado para espaços fechados ou para uso ocasional. NL · Dit product is niet geschikt voor primaire verwarming. Dit product is alleen geschikt voor gebruik op beschutte plaatsen of voor incidenteel gebruik. PL · Ten produkt nie nadaje się do pierwotnego ogrzewania. Ten produkt jest wskazany tylko do miejsc ostoniętych lub do okazjonalnego użytku. CZ · Tento produkt není vhodný pro primární vytápění. Tento výrobek je určen pouze na topení na chráněných místech nebo pro příležitostné použití.

Manual de instrucciones Instruction manual

Safety instructions 9

1. Parts and components 33

2. Before use 33

3. Operation 33

4. Cleaning and maintenance 34

5. Technical specifications 35

6. Disposal of old electrical and electronic appliances 36

7. Technical support and warranty 37

8. Copyright 37

SOMMAIRE

Read these instructions thoroughly before using the device. Keep this instruction manual for future reference or new users.

• Make sure the voltage of your mains supply matches the voltage requirements specified in the rating label of the appliance.
• This device is designed for domestic use only and is not intended for bars, restaurants, farmhouses, hotels, motels, and offices.
• If the power cable is damaged, it must be replaced by the Technical Support Service of Cecotec or similar qualified personnel to avoid risks.

- This symbol means "Do not cover".

- WARNING: to avoid overheating, do not cover the appliance.

- The heating appliance must not be placed immediately below a socket outlet.

- Do not use the heating appliance in the immediate vicinity of a bath, shower, or swimming pool.

- Do not use this heating appliance if it has been dropped.

- Do not use if there are visible signs of damage to the heating appliance.

- Use this heating appliance on a horizontal and stable surface, or fix it to the wall, as applicable.

- Keep the device out of the reach of children under 3 years old, unless constantly supervised.

- Children between 3 and 8 years old should only switch the appliance on or off when it has been placed in its normal, intended operating position and if they have been given supervision or instruction concerning the use of the appliance

in a safe way and understand the hazards involved. Children between 3 and 8 years old should not plug in, adjust, and clean the appliance and should not carry out maintenance tasks.

• WARNING: some of the product's parts may become very hot and cause burns. Particular attention should be paid when children and/or vulnerable people are present.
• WARNING: do not use this heating device in small rooms that are occupied by people who cannot leave the room by themselves, unless permanent supervision is provided.
• WARNING: to reduce the risk of fire, keep textiles, curtains, or other flammable material at least 1 m away from the air outlet.
• Do not insert or allow objects to enter through the ventilation openings, as this may result in electric shock, fire, or damage to the appliance.
• Do not immerse the cable, plug, or any other non-removable part of the appliance in water or any other liquid. Do not expose the electrical connections to water. Always make sure that your hands are dry before operating or adjusting any switches on the product or touching the plug and socket.
• Never leave the device unattended during use.
• One of the most common causes of overheating is the building up of debris or fluff in the appliance. Be sure to clean these accumulations periodically by vacuuming the vents and grilles.
• Do not place the appliance on carpets, and do not place the cable under carpets. Position the cord in such a way as to avoid obstructing passage and cause tripping hazards.
• Do not store it until it cools down. Store it in a cool, dry place when not in use.
• When using, maintain a minimum distance of 50 cm between the window and the wall.

INSTRUCTIONS DE SÉCURITÉ

The graphics in this manual are schematic representations and may not exactly match the device.

2. BEFORE USE

• This device is packaged in a way as to protect it during transport. Take the device out of its box and remove all packaging materials. You can keep the original box and other packaging elements in a safe place. This will help you prevent damage to the device when transporting it in the future. In case the original packaging is disposed of, make sure all packaging materials are recycled accordingly.
• Make sure all parts and components are included and in good conditions. If there is any piece missing or in bad conditions, contact the official Cecotec Technical Support Service immediately.

Box content

• Heater
• Instruction manual

3. OPERATION

Mode selector

Turn the mode selector to select the desired mode:

Symbol	Function
	Off
_T = 0	Medium power mode
	High power mode
	Oscillation with medium power mode
	Oscillation with high power mode

Temperature knob

• Turn the temperature knob clockwise until the desired temperature is reached.
• Turn the temperature knob to the MIN position to switch the appliance off, and then unplug the device.

Anti-tilt switch

The heater is designed to turn automatically off when tipped forward or backward. The unit will automatically turn on once it is returned to its normal upright position.

Do not use the heater on thick and long pile carpets, as the heater may not work because the anti-tilt switch is not activated.

Safety system

• In the event of abnormal overheating, the safety device automatically switches the appliance off. After a short cooling phase, the device is ready for use again.
• If you still observe the same defect as mentioned above, disconnect the plug from the socket and consult your authorised dealer for after-sales service.

During use, do not touch or cover the air outlet. This could cause the unit to overheat and the safety device to operate.

4. CLEANING AND MAINTENANCE

• Before performing any cleaning operation on the appliance, disconnect it from the mains.
• Clean the housing with a slightly damp cloth, vacuum cleaner or dusting brush.
• Never use flammable or abrasive cleaning agents such as benzene or alcohol to clean the appliance.
• Never immerse the appliance in water.
• Clean the air inlet and outlet regularly with a vacuum cleaner.
• If the appliance is not used for a long period of time, it must be protected against excessive dust and dirt. Dismantle the heater and store it in a dry place away from sunlight and dirt.

5. TECHNICAL SPECIFICATIONS

Product reference: 08271/08287

Product: ReadyWarm 1500 Max Ceramic Rotate White / Black

Rated power: 1500 W

Voltage: 220-240 V

Frequency: 50 Hz

Model identifier: 08271_ReadyWarm 1500 Max Ceramic Rotate White / 08287_ReadyWarm 1500 Max Ceramic Rotate Black
Item	Symbol	Value	Unit	Item	Unit
Heating power				Type of heat input, for electric storage local space heaters only (single select)
Rated heat output	P_nom	1.5	kW	Manual heat charge control with integrated thermostat	N/A
Minimum heat output (indicative)	P_min	1.0	kW	Manual heat charge control with room and/or outdoor temperature feedback	N/A
Maximum continuous heat output	P_max,c	1.5	kW	Electronic heat charge control with room and/or outdoor temperature feedback	N/A
Auxiliary electricity consumption				Fan assisted heat output	N/A
At nominal heat output	el_max	0.000	kW	Type of heat output/room temperature control (single select)
At minimum heat output	el_min	0.000	kW	Single stage heat output and no room temperature control	[NO]
In standby mode	el_SB	N/A	kW	Two or more manual stages, no room temperature control	[NO]
				With mechanic thermostat room temperature control	[YES]
				With electronic room temperature control	[NO]
				Electronic indoor temperature control and internal/daily timer	[NO]
				Electronic indoor temperature control and internal/weekly timer	[NO]
				Other control options (multiple selections possible)
				Room temperature control, with presence detection	[NO]
				Room temperature control, with open window detection	[NO]
				With distance control option	[NO]
				With adaptive start control	[NO]
				With working time limitation	[NO]
				With black bulb sensor	[NO]
Contact information:	Cecotec innovaciones SL., Av. Reyes Católicos, 60, 46910, Alfafar, Valencia (Spain)

Technical specifications may change without prior notification to improve product quality. Made in China | Designed in Spain

7. DISPOSAL OF OLD ELECTRICAL AND ELECTRONIC APPLIANCES

This symbol indicates that, according to the applicable regulations, the product and/or batteries must be disposed of separately from household waste. When this product reaches the end of its shelf life, you should dispose of the cells/batteries/accumulators and take them to a collection point designated by the local authorities.

Consumers must contact their local authorities or retailer for information concerning the correct disposal of old appliances and/or their batteries.

Compliance with the above guidelines will help protecting the environment.

8. TECHNICAL SUPPORT AND WARRANTY

Cecotec shall be liable to the end user or consumer for any lack of conformity that exists at the time of delivery of the product under the terms, conditions, and deadlines established by the applicable regulations.

It is recommended that repairs be carried out by qualified personnel.

If at any moment you detect any problem with your product or have any doubt, do not hesitate to contact the official Cecotec Technical Support Service at [phone].

9. COPYRIGHT

The intellectual property rights over the texts in this manual belong to CECOTEC INNOVACIONES, S.L. All rights reserved. The contents of this publication may not, in whole or in part, be reproduced, stored in a retrieval system, transmitted, or distributed by any means (electronic, mechanical, photocopying, recording or similar) without the prior authorization of CECOTEC INNOVACIONES, S.L.

FRANÇAIS

1. PIÈCES ET COMPOSANTS

Img. 1

Product: ReadyWarm 1500 Max Ceramic Rotate White / Black

Nominaal vermogen: 1500 W

Voltage: 220-240 V

Frequentie: 50 Hz

Line drawing of a portable electric heater with labeled parts 1 and 2 (no text or symbols on the device itself)

Fig./Img./Abb./Afb./Rys.1
