Bluetooth Headset ANC FlexMic 126-36 - Earphones SANDBERG - Free user manual and instructions

Type de produit	Bluetooth Headset with Active Noise Cancellation
Modele	Bluetooth Headset ANC FlexMic 126-36
Marque	Sandberg
Dimensions (largeur x hauteur x profondeur)	Approx. 180 x 190 x 80 mm
Poids	Approx. 210 g
Alimentation	Rechargeable lithium-ion battery, 500 mAh
Autonomie (lecture audio avec ANC desactivee)	Up to 25 hours
Autonomie (lecture audio avec ANC activee)	Up to 20 hours
Temps de charge	Approx. 2 hours
Version Bluetooth	Bluetooth 5.0
Portee Bluetooth	Up to 10 meters
Reduction de bruit active (ANC)	Yes, with adjustable level
Microphone	FlexMic with noise cancellation, rotating arm
Controles	On-ear buttons: volume, play/pause, ANC toggle, call answer/end
Connectivite	Bluetooth multipoint (up to 2 devices), 3.5 mm aux input
Entretien et nettoyage	Wipe with a soft, dry cloth. Do not use solvents or water.
Securite	Do not expose to high temperatures or moisture. Keep away from small children.
Pieces detachees et reparabilite	Battery replaceable by authorized service center. Ear cushions detachable and replaceable.
Contenu de la boite	Headset, USB charging cable, 3.5 mm audio cable, carrying case, user manual
Garantie	2 years limited warranty

Frequently Asked Questions - Bluetooth Headset ANC FlexMic 126-36 SANDBERG

How do I pair the headset with my phone?

Turn on the headset and press the Bluetooth button until the LED flashes. On your phone, search for 'Sandberg 126-36' and select to pair.

Can I use the headset while it is charging?

Yes, the headset supports pass-through audio, but we recommend charging fully for best performance.

How do I adjust the ANC level?

Press the ANC button on the headset to cycle through off, low, and high noise cancellation modes.

The microphone is not picking up my voice well. What should I do?

Ensure the FlexMic arm is positioned close to your mouth, and that the microphone hole is not obstructed. Also check that the mute function is off.

What is the battery life with ANC on?

Approximately 20 hours of continuous playback with ANC enabled. Battery life may vary based on volume and usage.

Does the headset support multipoint connection?

Yes, it can connect to two devices simultaneously, such as a phone and a laptop. You can easily switch between them.

How do I reset the headset to factory settings?

To reset, turn off the headset, then press and hold the Volume + and ANC buttons for 5 seconds until the LED flashes red.

Can I replace the ear cushions?

Yes, the ear cushions are detachable. They can be gently pulled off and replaced with new ones (available as accessories).

Is the headset water-resistant?

The headset is not water-resistant. Avoid exposure to rain or excessive moisture to prevent damage.

What does FlexMic mean?

FlexMic refers to the flexible microphone arm that can be adjusted to different positions for optimal voice pickup. It also includes noise cancellation for clearer calls.

USER MANUAL Bluetooth Headset ANC FlexMic 126-36 SANDBERG

Black and white photo of a pair of audio headphones with earbuds and microphone, no visible text or symbols.

Bluetooth Headset ANC FlexMic

Quick guide

126-36

Double Quality Tested

www.sandberg.world

Product preview

1. “+”

2. "-"

3. "0"

Technical line drawing of a mechanical component with no visible text or symbols

1. "M" 7. Boom mic port

1. LED indicator

2. Microphone

3. USB-C charging port

Button Short	press Long press Quick double press Quick triple press
O Play/Pause; Pick up / hang up call Power on/off; Reject call		Dial back Activate voice assistant
+ Volume up Next track
- Volume down Previous track
M ANC/ENC	Switch between ANC/ENC modes:Off (by default) - “ZERO”High mode - “ONE”Low mode - “TWO”Transparency mode - “THREE”	Low latency mode

Charge

Pairing

1

2

"Connected"

LED indicator overview

LED color	Pattern	Meaning
BLUE	ON	Waiting for pairing (Power on)
BLUE	Flash slow	Connected
RED	Constant	Charging the battery (in OFF mode)
OFF	OFF	Bluetooth mode deactivated (Power off)

ENC (Environmental Noise Cancellation)

Ensuring clear voice by cancelling, unwanted sound when making a call or playing a game.

External sound

Human voice

ANC/ENC

DIGITAL NOISE CANCELLATION

ANC High mode

Reducing engine and other low-frequency noises when traveling on airplanes, trains etc.

ANC Low mode

Reducing the human voice and other intermediate frequency noise. Recommended for indoor use such as coffee shops and shopping malls etc.

Transparency Mode

Lets outside sound in, so you can hear what's going on around you without taking off the headphone.

ANC Off

Suitable for outdoor walking or cycling to obtain a safer auditory perception.

ENC

Ensuring clear voice by cancelling, unwanted sound when making a call or playing a game.

CE

Declaration of Conformity

Manufacturer: Sandberg A/S

Address: Bregneroedvej 133D, 3460 Birkeroed, Denmark

Product description: Bluetooth Headset

Product name/Type no: Sandberg Bluetooth Headset ANC FlexMic / 126-36

We declare under our sole responsibility that the products, to which this declaration relates, are in conformity with the Council Directives on the approximation of the laws of the EEC Member States relating to the following:

(EMC) 2014/30/EU

(RED) 2014/53/EU

(RoHS 2.0) 2011/65/EU

Following standards were applied:

EMC: EN 301 489-1 V2.2.0

EN 301 489-17 V3.2.0

RED: EN 62479:2010

EN 60950-1:2006

EN 60950-1: A11:2009

EN 60950-1: A1:2010

EN 60950-1: A12:2011

EN 300 328 V2.1.1

RoHS: EN 62321 Ed1.0:2013

Date: 22 ^nd October 2021

Location: Birkeroed, Denmark

Name: Anders Petersen

CE letter of conformity

Sandberg®

Support

http://helpdesk.sandberg.world

Warranty

There is a five-year warranty on your Sandberg product. Please read the warranty terms and register your new Sandberg product at www.sandberg.world/warranty

5

Years Warranty
