SRNH 100 A2 - Heated blanket SILVERCREST - Free user manual and instructions

Product Type	Heated Blanket
Model	SRNH 100 A2
Brand	SilverCrest
Dimensions (approx.)	130 x 160 cm (50.4 x 63 in)
Weight (approx.)	1.5 kg
Power Supply	220-240 V ~ 50/60 Hz
Power Consumption	100 W
Heat Settings	6 temperature levels
Automatic Shut-Off	Yes, after 3 hours
Overheat Protection	Yes
Controller	Removable, with LED display
Material	Microplush fleece (polyester)
Care Instructions	Machine washable at 30°C, do not bleach, do not dry clean
Safety Certifications	TÜV/GS, CE
Spare Parts Available	Controller and power cord (via manufacturer)
Repairability	Spare parts available for DIY repair
Color	Grey/White (typical)
Included in Box	Heated blanket, controller, user manual

Frequently Asked Questions - SRNH 100 A2 SILVERCREST

How do I turn on the SilverCrest SRNH 100 A2 heated blanket?

Connect the controller to the blanket and plug into a power outlet. Press the power button on the controller, then select a heat level using the +/- buttons.

What are the heat settings and how do they work?

The blanket has 6 heat levels. Level 1 is the lowest, level 6 is the highest. Use the +/- buttons to adjust. The controller displays the current level.

Does the blanket have an automatic shut-off?

Yes, the blanket automatically turns off after 3 hours of continuous use for safety.

Can I wash the heated blanket?

Yes, the blanket is machine washable. First, disconnect the controller. Wash on a gentle cycle at 30°C (86°F). Do not bleach, wring, or dry clean. Air dry or tumble dry on low.

Is the blanket safe to use overnight?

While the blanket has safety features like overheat protection and auto shut-off, it is recommended not to leave it unattended for extended periods. Turn off before sleeping if possible.

What should I do if the blanket stops heating?

Check the connection between the controller and blanket, ensure the power plug is secure, and try a different outlet. If it still doesn't work, contact SilverCrest customer service.

Can I use the blanket with a fitted sheet?

Yes, you can place the blanket over your regular bedding. However, do not cover it with heavy blankets or duvets while in use to prevent overheating.

How do I store the heated blanket when not in use?

Allow the blanket to cool completely. Fold it loosely (do not crease sharply) and store in a dry place. Keep the controller separate to avoid damage.

Is the blanket suitable for people with sensitive skin?

The blanket is made of soft microplush fleece. If you have very sensitive skin, start with a lower heat setting and test on a small area.

Where can I find spare parts or repair information?

Spare parts like the controller and power cord can be ordered from SilverCrest customer service. For repairs, refer to the user manual or contact a qualified technician.

USER MANUAL SRNH 100 A2 SILVERCREST

Operation and Safety Notes

IT MT

termoforo per schienA e nucA

Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of the device.

DE AT CH

GB / MT Operation and Safety Notes Page 21

Diagram of a mechanical component with directional arrows indicating movement or force (no text or symbols)

Description of parts....Page 23

Included items Page 23

Technical Data Page 23

Important safety instructions......Page 23

Safety system......Page 25

Preparing the product for use

Switching on/off/Selecting the temperature....Page 25

Temperature levels Page 26

Automatic switch-off Page 26

Cleaning and Care Page 26

Storage Page 27

Disposal Page 27

Warranty / Service centre Page 27

Declaration of conformity....Page 28

Introduction

The following icons / symbols are used in this instruction manual / on this heating pad:
	Read the instructions!		The textiles used in this heating pad meet the strict human ecological requirements of Öko-Tex Standard 100, as verified by the German Hohenstein Research Institute.
	Volt (AC)		Do not use the heating pad when folded or bunched up!
	Hertz (mains frequency)		Caution - electric shock!Danger to life!
	Watts (effective power)		The heating pad is machine-washable.Set the washing machine at an extra washing cycle for delicate items at 30 °C.
	Safety class II Do not use bleach.
	Observe caution and safety notes! Do not use bleach.	a tumbler dryer.
	Keep the heating pad out of the reach of children!		Do not iron.
	Risk of loss of life by electric shock from damaged mains power cable or mains plug!		Do not dry clean.
	Do not stick needles into it!		Dispose of the packaging and the heating pad in an environmentally friendly way!

Back & Neck Heat Pad

●Introduction

We congratulate you on the purchase of your new device. You have chosen a high quality product. Please familiarise

yourself with the heating pad before getting started and using it for the first time. Please read the following operating instructions and the important safety instructions carefully. Use the heating pad only as described and for the stated areas of use. Keep

these instructions in a safe place. If you pass the heating pad on to anyone else, please ensure that you also pass on all the documentation.

Properuse

This heating pad is intended for applying heat to the human body. It can be used to apply heat to specific areas. This heating pad is not suitable for use in hospitals or for any other commercial use. In particular it must not be used for babies or infants, persons who are insensitive to heat, helpless persons,

Introduction / Important safety instructions

or animals. Any use other than that described above or modification of the heating pad are not permissible and may lead to injury and / or damage to the heating pad. The manufacturer accepts no liability for any damage caused by improper use.

• Description of parts

1 Control (see fig. A)
2 Function display (see fig. A)
3 Plug-in connector (see fig. B)

Includeditems

Please check immediately on unpacking that the delivery scope is complete and that the heating pad is in perfect condition.

1 Back & neck heating pad
1 Control unit / Plug-in connector with mains plug
1 Set of operating instructions

●TechnicalData

Model: SRNH 100 A2

Type: P10F

Power supply: 220-240V\~/ 50-60Hz

Power input: 100 W

Dimensions: approx. 65 x 38 cm

Protection class: II/

Electric field strength: max. 5000 V / m

Magnetic field strength: max. 80 A / m

Magnetic flux density: Max. 0.1 millitesla

Material:

Top/bottom: 100% Polyester

Manufacturer:

MGG Elektro GmbH

01099 Dresden, Germany

IMPORTANT ADVICE – KEEP THIS SAFE FOR FUTURE USE!

Importantsafety instructions

Failure to comply with the following instructions can cause personal injury or material damage (electric shock, skin burns, fire). The following safety instructions and hazard warnings are not only intended to protect your own health and the health of others, but also to prevent damage to the heating pad. Please observe these safety instructions and pass on this operating manual together with the heating pad.

WARNING! RISK OF FA- TAL INJURY AND ACCIDENT HAZARD FOR TODDLERS AND

SMALL CHILDREN! Never leave children unattended with the packaging material. Danger of suffocation.

WARNING! DANGER OF ELECTRIC

SHOCK! Do not use the heating pad if it is damp. There is a risk of electric shock.

Do not use the mains power cable for purposes for which it was not intended, e.g. for hanging up the

Important safety instructions

electric heating pad, carrying it or to pull the plug out of the mains socket. Keep the mains power cable away from heat, oil and sharp edges. If the mains power cable is damaged or severed, do not touch the mains power cable, but pull the mains plug out of the mains socket immediately. Damaged or tangled mains power cables increase the risk of electric shock.

WARNING! DANGER OF ELECTRIC

SHOCK! The heating pad must be regularly checked for signs of wear or damage. If signs of wear or damage are detected or if the heating pad has been used improperly, you must cease using the heating pad and return it to your dealer or to his customer service centre. There is a risk of electric shock.

DANGER OF ELECTRIC

SHOCK! Do not stick needles or sharp objects into the heating pad.

There is a risk of electric shock.

If you use a cardiac pacemaker, please consult your doctor and the manufacturer of the pacemaker before using this heating pad. The electric and magnetic fields generated by this electric heating pad may under certain circumstances interfere with the operation of cardiac pacemakers. However, the levels are far below the permissible limits: details of these levels can be found in the „Technical data“ chapter.

WARNING! Have the heating pad repaired only by qualified specialist personnel using original manufacturer parts only. This will ensure that the heating pad remains safe to use.

WARNING! If the mains power cable of this heating pad is damaged, it has to be replaced by the manufacturer or its service department or a similarly qualified person in order to avoid hazards. Risk of injury.

Children or anyone lacking the knowledge or experience to use the heating pad, or anyone with restricted physical, sensory or mental capacities, must not use the heating pad without supervision or instruction by a person responsible for their safety. Children must be

supervised to ensure that they do not play with the heating pad. Risk of injury.

RISK OF INJURY FROM

BURNS! Do not use this heating pad for helpless persons, infants or persons who are insensitive to heat (e.g. diabetics, people with disease-related changes to the skin or scarred skin in the area of use, or after taking pain-relieving medication or consuming alcohol). There is a risk of receiving skin burns.

The textiles used in this

heating pad meet the high human ecological requirements of Öko-Tex Standard 100, as verified by the German Hohenstein Research Institute.

RISK OF INJURY FROM

BURNS! This heating pad must not be used by children unless the control 1 has been preset by a parent or other responsible person, or unless the child has been instructed sufficiently in how to use this heating pad safely. There is a risk of receiving skin burns.

CAUTION! Take care that you do not fall asleep while the heating pad is in operation. Excessively long use can cause skin burns.

Do not use the heating pad on any part of the body that is inflamed, injured or swollen. Seek medical advice before using the heating pad if in doubt. Such inflammation, injuries and / or swelling may otherwise worsen.
■ Repairs must only be carried out by specially trained personnel or at a repair shop authorised by the manufacturer, since special tools are necessary. Unsatisfactory repairs can lead to considerable danger for the user.

Avoid damage to the heating pad!

■ Please ensure that you:

Important safety instructions / Safety system / Preparing the product for use

• only connect the heating pad to the voltage indicated on the heating pad (label),
• only use the heating pad in conjunction with the control unit 1 indicated on the heating pad (label),
• do not operate the heating pad without supervision,
  do not switch the heating pad on if it is folded or bunched up,
• do not cause any sharp creases in the heating pad,
• do not place any objects, e.g. suitcase or washing basket, on the heating pad when it is switched on,
• do not place any sources of heat, e.g. hot water bottle or similar, on the heating pad when it is switched on.

These may all damage the heating pad.

Do not cover the control 1 and do not place it on the heating pad when the pad is in operation. The electronic components in the control 1 of the heating pad cause the control 1 to heat up slightly during operation.
- Do not pull, twist or crease the cables. The heating pad may otherwise be damaged.

●Safetysystem

Note: the heating pad is equipped with a safety system. The electronic sensor technology prevents the entire surface of the heating pad from overheating by automatically switching off in the event of a fault. If the safety system switches the heating pad off automatically due to a fault, then the function display 2 on the control unit 1 is no longer illuminated, even if the heating pad is switched on.

☐ Please note that, for safety reasons, the heating pad must not be used after a fault and must be returned to the service address indicated.

● Preparing the product for use

Note: the heating pad may smell of plastic the first time you use it, but this will disappear after a short period of time.

☐ To begin, first connect the control 1 to the heating pad with the plug-in connector 3 (see fig. B).
☐ Position the heating pad on your back so that the fastener for the neck section is in the throat area.
☐ Then close the fastener.
☐ Then adjust the length of the belt around your stomach and fit the two ends of the connector together (see Fig. C) to fasten the belt.
☐ To open the belt, press the two catches on the connector at the same time (see Fig. C).

- Switching on/off/Selecting the temperature

Switching on:

☐ Set Level 1, 2, 3, 4, 5 or 6 on the control ☐ to switch the heating pad on.

Note: The function display 2 illuminates after the heating pad is switched on.

Note: this heating pad features rapid heating, which allows it to heat up within the first 10 minutes of operation.

Switching off:

☐ Set Level 0 on the control ☐ to switch the heating pad off.

Note: the function display 2 ceases to illuminate.

Selecting the temperature:

☐ Just before using the heating pad, set it to the highest temperature setting (level 6). This will cause the heating pad to warm up quickly.
☐ If you wish to leave the heated pad on for several hours, set the lowest temperature (level 1).

Preparing the product for use / Cleaning and Care

●Temperaturelevels

☐ Set the required temperature level on the control 1 (see fig. A).

Level 0: Off

Level 1: minimum heat

Level 2-5: customised settings

Level 6: maximum heat

●Automaticswitch-off

Note: The heating pad switches itself off automatically after about 90 minutes. The function display 2 then starts to flash.

☐ Then select the setting „0“ and after about 5 seconds, reset the heating pad to the desired temperature setting to switch it on again.
☐ Switch the heating pad off (setting „0“) if the heating pad is not to be used after it has switched itself off automatically.

- Cleaning and Care

期

RISK ON/WENING!

FROM ELECTRIC SHOCK! AI-

ways remove the mains plug from the socket and the plug-in connector 3 with the control 1 from the heating pad (see fig. B) before cleaning the heating pad. There is otherwise a risk of an electric shock.

■

DANGER OF ELECTRIC

SHOCK! Do not reconnect the control 1 to the heating pad until the

plug-in connector 3 and the heating pad are completely dry. There is otherwise a risk of an electric shock.

图

DANGER OF ELECTRIC

SHOCK! DANGER OF MATE-

RIAL DAMAGE! Do not under

any circumstances switch the heating pad on to dry help it dry. There is otherwise a risk of an electric shock.

☐ Use a dry, lint-free cloth for the cleaning and care of the heating pad and control 1.
☐ You can dampen the cloth and use a little mild liquid detergent to remove more stubborn dirt from the heating pad.

RISK OF DAMAGE TO THE

PRODUCT AND/OR OTHER

PROPERTY! Do not use chemical

cleaning or scouring agents to clean the heating pad and control 1. The heating pad may otherwise be damaged.

■

RISK OF DAMAGE TO THE

PRODUCT AND/OR OTHER

PROPERTY! Never immerse the

control 1 in water or other liquids. It may otherwise be damaged.

□

heating pad is machine-washable. Set the washing machine at an extra washing cycle for delicate

items at 30 °C.

For ecological reasons, please only wash the heating pad together with other textiles. Use a mild laundry detergent according to the manufacturer's instructions.
☐ Please note that frequent washing will cause wear to the heating pad. The heating pad should therefore be washed no more than max. 10 times in a washing machine throughout its useful life.

■

RISK OF DAMAGE TO THE

PRODUCT AND/OR OTHER

PROPERTY! Please note that the

heating pad may not be dry cleaned, bleached, wrung out, dried mechanically, mangled or ironed. The heating pad may otherwise be damaged.

■

RISK OF DAMAGE TO THE

PRODUCT AND/OR OTHER

PROPERTY! Do not hang the heat-

ing pad up to dry with pegs or similar. The heating pad may otherwise be damaged.

Note: Non-observance of the following warnings may damage the heating pad.

□

Do not use bleach. Do not use any

cleaning agents containing bleach (such as heavy duty detergents).

Cleaning and Care/Storage/Disposal/Warranty/Service centre

Do not dry in a tumbler dryer.

Do not iron.

Do not dry clean.

Contact your local refuse disposal authority for more details of how to dispose of your worn out heating pad.

● Warranty / Service centre

We provide a 3-year warranty covering faults in materials or manufacture of the product from the purchase date.

Storage

RISK OF DAMAGE TO THE PRODUCT AND/OR OTHER PROPERTY! Let the heating pad cool before putting it away. Otherwise material damage could occur.
RISK OF DAMAGE TO THE PRODUCT OR PROPERTY! To prevent the heating pad from becoming sharply creased, do not store other objects on top of the heating pad. Otherwise material damage could occur.
☐ If you do not intend to use the heating pad for any length of time, store it in the original packaging in a dry environment and without weighing it down.

The warranty does not cover:

• Damage resulting from improper use.
• Wear parts.
• Defects that were known to the customer at the time of purchase.
• Damage for which the customer was responsible.

This warranty does not affect the customer's legal rights.

The customer must provide proof of purchase in order for any warranty claims within the warranty period to be honoured. Claims under the warranty are honoured by

The packaging and packaging material consist of environmentally friendly materials. They can be disposed of at your local recycling facility.

Do not dispose of electrical devices with the household rubbish!

In accordance with European Directive 2002 / 96 / EC for waste electrical and electronic equipment and its transposition into national legislation, worn out electrical devices must be collected separately and taken for environmentally compatible recycling.

for a period of 3 years after the date of purchase.

In the event of a warranty claim, the customer has the right to have the goods repaired by our own workshop or a workshop authorised by us. The heating pad must not be opened for any reason. Opening or modifying the device invalidates the warranty. This warranty does not grant any additional rights to the customer. Complaints are often initiated by difficulties encountered during use. Many of these complaints can be resolved by telephone or email. Please contact our Service Hotline in the first instance, before you return the heating pad to the manufacturer.

Warranty / Service centre / Declaration of conformity

IAN 75924

GB

020 30249050

MT

800 62036

● Declaration of conformity (€)

This heat pad complies with the requirements of the relevant European and national guidelines.

This is confirmed by the CE mark.

The relevant declarations are held by the manufacturer.

Einleitung

01099 Dresden, Germany

STROMSCHLAGGEFAHR! Ver-

© by ORFGEN Marketing
