USER MANUAL 5HA-196 X FAGOR

ONE-YEAR LIMITED WARRANTY

For one year from the date of purchase, provided this product is operated and maintained in accordance with the instructions attached to or furnished with the product, Fagor America Inc. will replace parts and provide labor to correct defects in materials or workmanship. Service has to be provided by a Fagor America Inc. designated service company. Please contact Fagor America at 1 800 207 0806 or by email at infoappliances@fagoramerica.com

THIS LIMITED WARRANTY DOES NOT COVER

1. Repairs when the product is used in other than normal, single family household use.

2. Damage resulting from accident, alteration, misuse, abuse, fire, acts of God, improper

installation, installation not in accordance with local electrical and plumbing codes, or use not approved by Fagor America.

3. Replacement parts or repair labor costs if the product is operated outside of the

United States/Canada

4. Pick up/delivery. This product is designated to be repaired at home.

FAGOR AMERICA WILL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES Some states do not allow the exclusion or limitation of incidental or consequential damages so this exclusion or limitation may not apply to you. This warranty gives you specific legal rights and you may also have other rights which vary from state to state.

IF YOU NEED SERVICE

Please contact Customer Care at Fagor America at 1.800.207.0806 or email Fagor America at infoappliances@fagoramerica.com CUSTOMER SERVICE Write the model and serial number on the lines below, you’ll need them in the event of a service call. The model and serial number are located inside the door at the bottom Model: ________________________________ Serial: _________________________________ Date Purchased: _________________________ Store: __________________________________ Should you need service or have any questions about this product, don’t hesitate to contact FAGOR AMERICA Customer Service at 1-800-207-0806

C60T408A1 21/5/08 08:58 Página 3 Dear client, You are now the proud owner of a FAGOR oven and we would like to thank you for the confidence you have shown in us. FAGOR provides you with a new generation of domestic appliances that contribute to an improvement in your quality of life thanks to our range of innovative, easy to use and environmentally-friendly products. The range of FAGOR products offers you a wide selection of cooking hobs, range hoods, microwave ovens, dishwashers, washing machines, and refrigerators that you can combine with your new oven. Before using your oven for the first time, we recommend you read the user manual carefully. You will find information you will need to make the most of your new FAGOR oven. Please pay special attention to all the safety advice and to the comments on how to use and care for your oven correctly. At the same time, we recommend you keep this manuals in a safe place as you may find it useful in the future if you need to consult it. If you pass the appliance on to another person, please be sure to enclose the manual. Warm greetings and welcome to the family of FAGOR clients. FAGOR America Inc.

08:58 Página 6 IMPORTANT SAFETY INSTRUCTIONS When properly cared for, your new Fagor oven has been designed to be a safe, reliable appliance. Read all instructions carefully before using this oven. These precautions will reduce the risk of burns, electric shock, fire and injury to persons. When using kitchen appliances, basic safety precautions must be followed, including the following:

This appliance must be properly installed and grounded by a qualified technician. Connect only to properly grounded outlet. See electric preparation and connection instructions in the Installation Instructions. This appliance should be serviced only by a qualified service technician. Contact the nearest authorized service center for inspection, repair or adjustment. Do not repair or replace any part of the oven unless specifi cally recommended. Refer service to an authorized service center. Do not operate this appliance if it is not working properly or if it has been damaged, until an authorized technician has inspected it. Install or locate this appliance only in accordance with the Installation Instructions. Use this oven only as intended by the manufacturer. If you have any questions, contact the manufacturer. Do not cover or block any openings on this appliance. Use this appliance only for its intended use as described in this manual. Do not use corrosive chemicals, vapors, or nonfood products in this appliance. This type of oven is specifically designed to heat or cook. It is not designed for industrial or laboratory use. The use of corrosive chemicals in heating or cleaning will damage the appliance. In the event that personal clothing or hair catches fire, DROP AND ROLL IMMEDIATELY to extinguish flames. This oven is intended for residential use only. It is not approved for outdoor use.

C60T408A1 21/5/08 08:58 Página 7

REGARDING PET BIRDS

Birds have very sensitive respiratory systems. Keep pet birds out of the kitchen or other rooms where kitchen fumes could reach them. During Self- Clean mode, fumes that may be harmful to birds are released. Other kitchen fumes, such as from overheating margarines and cooking oils, may also be harmful.

Do not allow children to use this appliance unless closely supervised by an adult. Children and pets should not be left alone or unattended in the area where the appliance is in use. Never allow children to sit or stand on any part of the oven.

Do not store items of interest to children above the oven. If children should climb onto the appliance to reach these items, they could be seriously injured. To reduce the risk of fire in the oven cavity:

1. Do not store flammable materials in or near the oven.

2. Do not use water on a grease fire. Smother fi re or use a dry chemical or foamtype extinguisher.

3. Have a fire extinguisher readily available and highly visible next to any cooking

appliance. Be sure you know how to use it.

4. Do not overcook food. Carefully attend oven if paper, plastic or other combustible

materials are placed inside the oven.

5. Do not use the cavity for storage purposes. Do not leave paper products, cooking

utensils or food in the cavity when not being used.

6. If materials inside the oven should ignite, keep oven door closed. Turn oven off and

disconnect the circuit at the circuit breaker box.

7. Do not block any vent openings.

8. Be sure the blower fan runs when the oven is in operation. If the fan does not

operate, do not use the oven. Call an authorized service center.

9. Never use the oven to warm or heat a room. This can damage the oven parts.

10. For personal safety, wear proper clothing. Loose fitting garments or garments with

hanging sleeves should never be worn while using this appliance.

C60T408A1 21/5/08 08:58 Página 8 SAFETY PRECAUTIONS

Tie long hair so that it doesn’t hang loose.

The heating elements may be hot even though they are dark in color. Interior surfaces of an oven become hot enough to cause burns.

During and after use, do not press or let clothing or other flammable materials contact the heating elements or the interior surfaces of the oven until they have had sufficient time to cool.

The trim on the top and sides of the oven door may become hot enough to cause burns.

Use care when opening the door. Open the door slightly to let hot air or steam escape before removing or replacing food.

Do not heat unopened food containers. Buildup of pressure may cause the container to burst and result in injury.

Always place oven racks in desired location while oven is cool. If a rack must be moved while oven is hot, do not let potholder contact the heating elements.

Use only dry potholders. Moist or damp potholders on hot surfaces may result in burns from steam. Do not let potholders touch hot heating elements. Do not use a towel or other bulky cloth.

C60T408A1 21/5/08 08:58 Página 9

2. INSTALLATION AND ASSEMBLY

1. Cut the plastic film covering the entire package.

2. Carefully remove all the oven’s protective elements: top cover, edge protection

and polystyrene base. With respect to the conservation of the environment, we recommend you follow the advice given in section “6. Environmental Note”. Free-Standing Ovens 5HA-196 X

1. The measurements of the furniture unit in which

the oven is to be mounted must coincide with those indicated in the diagrams, depending on whether the unit is wall-mounted or floor-based. -Figure 19 C60T408A1 21/5/08

08:58 Página 10 Free-Standing Ovens 5HA-200 LX 5HA-200 RX IMPORTANT: -The measurements of the figure 1 or 2 must be taken in consideration to mount the oven -Once the oven is placed in the space, fasten it to the unit with the 2 “A”screws like in the figure. -Do not hang from the door when it is opened.

C60T408A1 21/5/08 08:58 Página 11

2. At the back of the oven you will find cable “A” which is used to make the electrical

connection in this way: Oven Wire Color House Wire Color Black Black (L1) White Red (L2) White (Neutral) & Green/Cooper (Ground)

WARNING: before starting to make any connections, check the following:

• that the mains voltage corresponds to the voltage indicated on the feature identification plate B, figure 2.
• that the electrical mains the oven is to be connected to is powerful enough for the maximum power the oven absorbs, indicated on the feature identification plate. ELECTRICAL SPECIFICATIONS Model Volts Watts Amps

3. After it is plugged in, place the oven into the gap, taking special care not to leave

any surplus cable on top of the oven.

4. A switch must be placed in the most accessible site possible in order to

disconnect the oven, with a minimum of 3 mm between the contacts.

5. Fasten the oven to the unit with the 2 screws provided.

-Figure 26. If the cooking function selector is not at position “0”, turn it to “0” and set the time on the oven( section 7.1).

08:58 Página 12 3.1. BEFORE USING THE OVEN FOR THE FIRST TIME Adjusting the Clock If the programmer on your new oven includes a clock, we recommend that you set the correct time (section7.1) after connecting the oven to the electrical mains or after a cut in the power supply. First Cleaning Before using your new oven for the first time, make sure you have removed any possible labels or protective plastic. Heat it up with nothing in it for about 30 minutes, with the door closed. Adjust the cooking functions selector in position and set a temperature of 5000F. At the beginning, the oven may give off a strange smell. Furthermore, you may notice a little smoke. All of this is normal. This is the way to remove any possible remains of grease from the inside of the oven left over from the manufacturing process. Once the oven has cooled down, clean it following the instructions given in section “4. Cleaning and Maintenance”. Before using any of the accessories for the first time, clean with water, a little soap and a cloth.

C60T408A1 21/5/08 08:58 Página 13

1. Function Selector

2. Temperature Selector

3. Programmer

Cooking Function Selector Your oven offers different cooking functions. With the cooking function selector, you will be able to select the most suitable cooking function at any time for the preparation of the food in question. If your oven has retractable controls, the cooking function selector can be turned to the left or right without any problem. These controls can be hidden and revealed again in any position by just pushing the control. *Number of functions differ depending on the model.

C60T408A1 21/5/08 08:58 Página 14 Read below only the description of those functions coinciding with the symbols appearing on your function selector: Traditional Heat: With this function, the heat comes from both above and below, heating the food in the traditional way. Gentle Grill or Gentle Grill with rotating spit: Only the central part of the grill resistance is connected, allowing you to save power when toasting smaller portions of food. Place the items in the central part of the grill. Strong Grill: The action of the grill covers the entire surface of the tray, allowing you to toast large trays or several items of food at the same time. This setting is suitable for cooking the same food as with the gentle grill but covering the whole entire surface of the tray. Very appropriate for all types of toasting. Strong Grill with Fan: Special option that allows toasting of food and an even distribution of the heat with a fan. Ideal for grilling large roasts. In this way, roast meats take on a golden colour all over Traditional Heat with Fan: The heat comes from both the top and the bottom of the oven and the fan distributes the temperature evenly. You can cook different dishes on different levels at the same time without mixing smells or flavours. Thawing: This heats the resistances to a very low temperature, so as to achieve an even and fast thawing of frozen food. The thawing function can be used with any type of frozen food. Turbo Plus: The oven is heated with the circular resistance located at the back. The fan drives the hot air around the oven to distribute the heat more evenly. Ideal for working with different trays at various heights. Pizza: The strong heat coming from the bottom and the even distribution of the temperature from the fan gives pizzas a particularly crispy base. Celeris: Suitable for those dishes that need the oven to be pre-heated. With this function the oven is heated to the chosen temperature in as little time as possible. Once the oven has reached the temperature set, the thermostat pilot light goes out, indicating that the oven is ready to be used for any other cooking function.

C60T408A1 21/5/08 08:58 Página 15 The general power pilot light will remain on whenever any cooking function is selected.

Temperature Selector With the temperature selector, you can adjust the cooking temperature at any time to the most suitable for preparing the food in question. The controls turn to the right from 1000F up to 5000F. The thermostat pilot light will go out when the selected temperature is reached and then it will come on and off from time to time while cooking to keep the right temperature.

3.3. OPERATION OF THE OVEN

Follow these steps to turn on your oven:

1. Place the food in the oven, on the recommended

tray and level (see tables on pages 20-23).

2. Select a cooking function using the cooking

function selector (see tables on pages 20-23). For example:

3. Set a temperature by turning the temperature

selector or following the instructions given in the timer operating section (see tables on pages 20-23). For example: 4000F.

C60T408A1 21/5/08 08:58 Página 16

4. To set the programmer, follow the instructions provided in the specific user

5. Once the cooking is finished, do not forget to turn the function selector back

to the “0” position and the temperature selector to the lowest position “ “ 3.4. ACCESORIES The oven has 5 different levels on which to place the accessories. These levels are engraved at the entrance to the cavity. If you wish, you can acquire additional accessories by requesting them from our Official Technical Service. Your oven comes from the factory with some of the accessories described below: Baking Tray Aluminium tray ideal for baking. Standard Tray For all kinds of food. Deep Tray The new deep tray is suitable for cooking dishes with a large amount of sauce or gravy, ideal for juicy cakes, frozen food and large roasts.

C60T408A1 21/5/08 08:58 Página 17 Grille with Non-Tip Safety Catch The new grille with its non-tip safety catch can be slid out of its housing about three quarters of the way without it tipping over. Catch You will be able to remove food easily from inside the oven. In addition, it gives you the possibility of using it at any of the 5 levels available in the oven. This grille can be used to hold any kind of container with food to be roasted or toasted. It is also used for making roasts directly on the slats of the grille, in which case we recommend you place a tray underneath the grille to collect any juices given off by the meat and to keep your oven clean. The grille has to be slid into place on the side slots with the catches facing down, as indicated in the figure. Removable tray, Total Accessibility With the new “Removable tray, Total Accessibility”, food handling is more convenient and easier thanks to the carefully studied design allowing the trays to slide in and out smoothly. The trays can be taken completely out of their housing for total accessibility. In addition, they remain totally stable so that you can work and handle them in total safety, reducing the risk of burns. This will make it easier for you to remove food from inside the oven. This new total extraction system can be placed on any of the bottom 4 levels of the oven, multiplying the cooking potential even more.

C60T408A1 21/5/08 08:58 Página 18 Inserting the trays inside the oven:

1. Insert the “Removable tray, Total Accessibility”

onto the side slots as far as it will go; you will have to raise it lightly to get past the catches. Bear in mind that the round pegs go on the back.

2. Next, pull out the telescopic runners as far as

3. Then fit any of the trays inside the 4 upper catches

on the telescopic runners. If you wish you can also insert the grille with its non-tip safety feature on top of the combination of the “Removable Tray”, but with the catches facing upwards.

4. Insert the whole set inside the oven completely.

Removing the trays from inside the oven: Once cooking has been completed, slide the tray and grille set out, you can then do one of two things, as required: a. Remove only the tray from inside the oven. b. Remove the whole set from inside the oven. To do so, you will have to lift the “Removable tray, Total Accessibility” slightly to get past the catches that prevent it from tipping over. Remember that the “Removable tray, Total Accessibility” set of tray and/or grille with its non-tip safety feature can be placed on any of the 5 lower levels.

C60T408A1 21/5/08 08:58 Página 19

3.5. PRACTICAL ADVICE AND COOKING TABLE

Suggestions and Practical Tips for Baking PROBLEM Cakes and pastries do not rise enough POSSIBLE REASON

• Wrong function selected

• The oven has not been pre-heated enough The roast or the baking is very pale

• Inappropriate mold material SOLUTION
• Check the function selected against the temperature shown in the table
• Check the table for any preheating recommendations

• Check the temperature selected against the temperature shown in the table; increase it slightly if necessary
• Use only dark molds The roast or the baking is very dark

• Temperature too high

• Check the temperature selected against the temperature shown in the table; reduce it slightly if necessary The roast or the baking is very dry

• The cooking time is very long because the temperature selected is too low

• Check the temperature selected against the temperature shown in the table The roast or the baking is very wet

• Too much liquid in the dough

• Check the temperature selected against the temperature shown in the table; increase it slightly if necessary.
• Prepare the dough with less liquid.

08:58 Página 20 Tables FOOD PROGRAM TEMPERATURE TIME FOOD POSITION PREHEATING

MEAT AND POULTRY

Veal 3,31 lb 210oC 410oF 50-60 min

Pork loin 3,31 lb 220oC 428oF 50-60 min

Roasted chicken 2,76 lb 230oC 446oF 50-60 min

Roasted rabbit 2,64 lb 210oC 410oF 25-35 min

Roasted lamb 2,2 lb 220oC 428oF 40-50 min

Pork leg 3,31 lb 180oC 356oF 85-95 min

Pork ribs 3,31 lb 220oC 428oF 30-40 min

Turkey legs (2) 170oC 338oF 40-50 min

Turkey 8,8 lb 190oC 374oF 115-125 min

Caramel custard 150oC 302oF 30-40 min

Sponge cake 180oC 356oF 25-35 min Yes Pears baked in wine 240oC 464oF 50-60 min

Pastries 220oC 428oF 8-12 min

ACCESSORIES C60T408A1 21/5/08 08:58 FOOD Página 21 PROGRAM TEMPERATURE TIME FOOD POSITION PREHEATING Roasted red peppers 2,76 lb 210oC 410oF 30-40 min

Stuffed tomatoes (4) 220oC 428oF 15-19 min

Stuffed courgettes (2) 200oC 392oF 25-35 min

Roasted fish 2,2 lb 220oC 428oF 13-17 min

Baked salmon (4) 250oC 482oF 8-10 min Yes Baked cod 3,31 lb 220oC 428oF 7-9 min Yes Pizza 220oC 428oF 18-22 min Yes Bread 220oC 428oF 18-22 min

Buns 210oC 410oF 15-19 min Yes

FISH AND SEAFOOD

ACCESSORIES C60T408A1 21/5/08 08:58 FOOD Página 22 PROGRAM TEMPERATURE TIME FOOD POSITION PREHEATING

MEAT AND POULTRY

Veal 3,31 lb 190oC 374oF 50-60 min

Pork loin 3,31 lb 200oC 392oF 50-60 min

Roasted chicken 2,76 lb 210oC 410oF 50-60 min

Roasted rabbit 2,64 lb 230oC 446oF 25-35 min

Roasted lamb 2,2 lb 200oC 392oF 40-55 min

Pork leg 3,31 lb 150oC 302oF 85-95 min

Pork ribs 3,31 lb 200oC 392oF 30-40 min

Turkey legs (2) 150oC 302oF 40-50 min

Turkey 8,8 lb 170oC 338oF 115-125 min

Caramel custard 150oC 302oF 30-40min

Sponge cake 180oC 356oF 15-25min

Pears baked in wine 220oC 428oF 50-60min

Pastries 200oC 392oF 8-12min

DESSERTS THAWING For all kinds of food 75oC 165oF

ACCESSORIES C60T408A1 21/5/08 08:58 FOOD Página 23 PROGRAM TEMPERATURE TIME FOOD POSITION PREHEATING Roasted red peppers 2,76 lb 190oC 374oF 30-40 min

Stuffed tomatoes (4) 200oC 392oF 15-19 min

Stuffed courgettes (2) 180oC 356oF 25-35 min

Roasted fish 2,2 lb 200oC 392oF 13-17 min Yes Baked salmon (4) 240oC 464oF 8-10 min Yes Baked cod 3,31 lb 210oC 410oF 7-9 min Yes Pizza 200oC 392oF 18-22 min

Bread 200oC 392oF 18-22 min

Buns 220oC 428oF 13-17 min Yes

FISH AND SEAFOOD

ACCESSORIES C60T408A1 21/5/08

OVEN CLEANING AND

The Outside of the Oven Ovens with stainless-steel front: Clean the outside of the oven preferably with warm water and a little washing liquid. Abundant rinsing is recommended. Dry it immediately afterwards with a soft cloth. If any stains are difficult to remove we recommend you use products specifically designed for stainless steel. Test the product on a small area before you apply it to the entire surface. Follow the manufacturer's indications closely.

08:58 Página 25 The Inside of the Oven In order to ensure the continued aesthetic attractiveness of your oven in the long term, you should clean the inside of it regularly, preferably every time you use it; this way you will avoid the generation of smoke and unpleasant odours in subsequent uses. a. Ovens with “Slide” enamel: Our new “Slide” enamel ensures minimal adherence of any food to the internal surfaces of the oven, becoming easy to clean. Clean the inside of the oven while it is still warm using hot water with a little soap or a solution of water and vinegar; after cleaning, dry the inner walls thoroughly with a soft cloth. For in-depth cleaning or if the dirt is particularly difficult to remove, we recommend the use of specialized oven-cleaners, following the manufacturer’s instructions. Only use specialized oven-cleaners on a cold oven. b. Ovens with self-cleaning panels: In ovens with self-cleaning panels the rear plate and the side panels are coated with a self-cleaning enamel that eliminates fat and grease while the oven is operating. These side panels are reversible, which doubles the lifetime of their catalytic coating. Sometimes, the largest splashes do not disappear until the oven has been turned on and off several times. When the self-cleaning elements of your oven no longer clean themselves well enough, it will be necessary to regenerate them. To do so, please follow the steps outlined below:

Remove the accessories and containers from the inside of the oven. Thoroughly clean the oven surfaces that are not self-cleaning. Place the function selector to position Adjust the oven temperature to 5000F. We recommend you leave the oven operating for between 30 and 60 minutes, depending on the degree of dirt and grime on the self-cleaning parts.

6. Clean off any remnants of salt from the self-cleaning elements using a slightly

damp sponge (water only). The self-cleaning elements of the oven will be completely functional again.

C60T408A1 21/5/08 08:58 Página 26

WARNING: Never clean the rear plate or the side panels with special oven-cleaners.

If you wish to clean the side walls on the inside of the oven, you will first have to take out the grilles and the self-cleaning panels located behind them (follow the instructions given in the section “4.1.4. How to clean the side grilles”). Clean the side walls on the inside of the oven while it is still warm using hot water with a little soap; dry the walls carefully with a soft cloth. For in-depth cleaning or if the dirt is particularly difficult to remove, we recommend the use of specialised oven-cleaners, following the manufacturer’s instructions. Only ever use specialized oven-cleaners on a cold oven.

WARNING: Never apply this product to the oven’s self-cleaning surfaces.

Making the cleaning of the inside of the oven easier:

Connect the interior lamp. To do so: turn the temperature selector to the “0” position and the function selector to any function, the light will then be on.

If you want to clean the glass cover protecting the oven lamp: unscrew the cover and clean it, preferably with washing liquid. Once it is clean, replace the lamp cover following the procedure described.

C60T408A1 21/5/08 08:59 Página 27 Model 5HA-196 X

It is possible to remove the oven door easily. Follow the steps described below very carefully: Removing the door:

1. Open the door fully.

2. Completely unscrew

the bolts in the hinges.

3. Close the oven door gently until you hear the catch engage; once you reach

the position of the catch, take hold of the door with both hands and continue to push it closed while pulling upwards at the same time to lift the hinges from their slots. The door will then be released. Installing the door after cleaning:

1. Align the hinges with their slots until they

hook into place, as indicated in the figures.

2. Open the door fully, and push the bolts down

completely to their original position. The door will then be correctly installed.

08:59 Página 28 In some ovens it is possible to fold down the grill in the roof of the oven.

WARNING: the oven must be cold.

Folding the grill down:

1. Lift up the grill rod.

2. Press it in towards

the back of the oven. Re-inserting the grill after cleaning:

1. Press the grill’s rod towards the back of the oven and hook the grill back

into place in its support.

Accessories Soak the accessories immediately after use in a normal household detergent. Any adhered food scraps can be easily removed with a sponge or a soft brush.

Side Grilles The grilles can be removed for cleaning. To do so, follow the steps described below: Removing the grilles:

1. Press the grille’s upper rod downwards to

unhook it from the support on the side panel.

C60T408A1 21/5/08 08:59 Página 29

2. Turn the grille as shown in the figure and pull

it outwards to remove it.

3. If your oven is self-cleaning, unhook the panel located behind the grille.

Clean the grilles in the dishwasher. To eliminate any stubborn dirt you can use rougher cleaning sponges or brushes. Re-inserting the grilles after cleaning: Replace the grilles on the side walls by following the steps indicated above but in reverse order.

REPLACING THE BULB OF THE INTERIOR LIGHT You can replace the bulb for the oven’s interior light if it stops working. You can obtain heat-resistant 25W replacement bulbs capable of withstanding 6000F from the Official Technical Service or from a specialized electrical store. To replace the bulb do the following:

1. Disconnect the oven from the power mains. If necessary, let the oven cool

2. Unscrew the cover over the lamp by turning

3. Replace the bulb with one of the same type.

4. Replace the glass cover on the lamp following the procedure described.

5. Re-connect the oven to the power mains.

C60T408A1 21/5/08 08:59 Página 30

5. TROUBLESHOOTING

There may be small anomalies that do not necessarily mean the existence of a product failure and so do not require a Technical Service call. These small anomalies are often easy to correct. In order to avoid an unnecessary call of a Service Engineer, check to see if the failure you have encountered is included in the table below:

C60T408A1 21/5/08 08:59 Página 31 The oven is NOT working. The •No power supply. luminous symbols are not lit.

• The oven is not connected. The oven is NOT working.

• The timer control is in position “0” or The oven is making a series of •Several reasons. beeps.

WHAT TO DO

• Check the status of the electrical installation.
• Turn the selector manually or set the desired cooking time.
• Read the timer’s user manual carefully.

• Several hours have passed with the oven operating, without any timer button being pressed.
• Interruption of the power supply, with the function selector not in position “0”.
• Oven installed with the function selector not in position “0”.

• Turn the function selector to the “0” position. The oven is NOT working. symbol is flashing. Oven just installed, or interruption in the power supply, with the function selector not in position “0”. Set the clock to the right time and the oven will start. The oven is NOT working. symbol is flashing. The time pre-set for cooking has elapsed. Turn the function selector and The temperature selector to the “0” position. The oven is NOT working. symbol is lit. Oven blocked with the function selector in position “0”. Release the timer as indicated in the “Child Safety Lock” part of the timer’s user manual. The oven IS working, but the symbol is flashing. The time set for the oven alarm has elapsed. The oven light is NOT working.

• The lamp is not operational. •Change the bulb.
• The oven is not connected or
• Connect the oven or check your electrical system has a fault and the fuse has tripped. if the fuse has tripped. Smoke comes out when in use.

• Oven temperature is too high.
• Greasy oven. The oven is NOT working. symbol is flashing.

• Turn the function selector to the “0” position and set the clock to the right time.

• Reduce the oven temperature.
• Clean the oven. The oven makes a noise after The oven fan is operating cooking is completed. (even with the oven off), to cool down the temperature in the surroundings. This is absolutely normal. The interior glass of the oven door is misted up and dripping. Push the accessory further in to prevent it coming into contact with the glass. An accessory (grille, tray) is in contact with the glass.

C60T408A1 21/5/08 08:59 Página 32 Pre-heat the oven only where this is indicated in the recipe or in the cooking table for the dish you want to make.

It is better to use dark baking molds, preferably enamelled in black, as these materials absorb heat particularly well.

If you wish to bake a batch of several cakes, you should do so one after the other. As the oven is already hot, the baking times of second and subsequent cakes are shorter. You can also prepare two cakes simultaneously by placing rectangular molds side by side.

If using the oven continuously for a long time, you can switch it off 5 or 10 minutes before the time indicated and take advantage of the residual heat to finish preparing the food.

If your oven includes the “Gentle Grill” function, use it to prepare small amounts of grilled food, placing the food in the central part of the tray or grille.

C60T408A1 21/5/08 08:59 Página 33 Timer function selector button “+”button “-“ button Time adjustment buttons Automatic disconnection indicator symbol Cooking duration indicator symbol Stop Cooking time indicator symbol Beeper indicator symbol Time adjustment indicator symbol Screen NET Compatible oven indicator symbol Child safety lock indicator symbol

C60T408A1 21/5/08 08:59 Página 34

7.1 CLOCK

When the oven is connected to the mains electricity or following an interruption in the power supply, the symbol will flash, providing that the function selector is in the “0” position; if not, turn the selector to “0” and follow the procedure described below to set the time. WRONG RIGHT To set the time:

1. Press the button

and the symbol will start flashing.

2. Set the time by pressing the

and/or Example: Current time 12:30:00. buttons. After a few seconds the symbol will go off and the screen will display the time set. The appliance will be ready for use.

C60T408A1 21/5/08 08:59 Página 35 With this function, the oven turns itself off automatically when the pre-set cooking time has elapsed. To set the cooking duration time:

1. Select a cooking function and set a temperature.

2. Press the button

and the symbol will start flashing.

3. Set the desired duration by pressing the

and/or buttons (maximum 10 hours). Example: I want the timer to operate the oven automatically for 45 minutes. After a few seconds, the function will be activated, the oven will start working, the symbol will remain lit and the screen will display the time remaining until conclusion of the cooking. If you wish to display the time, press the button several times until the symbol flashes. The screen will display the current time for a few seconds and will then go back to displaying the countdown of time remaining before cooking finishes.

C60T408A1 21/5/08 08:59 Página 36 Once the pre-set time has elapsed, the oven will turn itself off automatically and start to beep for 60 seconds while the symbol flashes. After this time, the oven will stop beeping but the symbol will continue to flash. Press any button to stop it flashing. If you wish to stop the beeping before the 60 seconds are up, press any button.

WARNING: when you do this, the oven will automatically switch to manual operation

and will continue working. Therefore, if you wish to stop cooking, do not forget to turn the function selector and the temperature selector to the “0” position. To change the cooking duration time: Press the button and the symbol pressing the and/or buttons. will start flashing. Change the time by To cancel the cooking duration time:

1. Press the button

and the symbol will start flashing.

2. Press the button

until the time displayed on the screen is “0:00”. After a few seconds the symbol will go off and the screen will display the current time. The cooking duration function will have been cancelled.

“Auto-Stop Cooking” With this function, you can set your oven to switch itself off automatically at a particular time. The “auto-stop cooking” function is used simultaneously with the “cooking duration” function so that the oven switches itself on and off automatically after operating for the desired time. To set the auto-stop cooking time:

1. Select a cooking function and set a temperature.

2. After you have set the cooking duration time,

press the button and the symbol will start flashing. Example: Current time 12:30, cooking time pre-set for 45 minutes.

C60T408A1 21/5/08 08:59 Página 37

3. Set the time you want cooking to stop by pressing the

and/or buttons. Example: I want cooking to be finished by 2:30. After a few seconds the function will be activated and the oven will start working as programmed. Once the oven has started operating, the screen will display the time remaining until conclusion of the cooking. If you wish to display the time, press the button several times until the symbol flashes. The screen will display the current time for a few seconds and will then go back to displaying the countdown of time remaining before cooking finishes. Once the pre-set time has elapsed, the oven will turn itself off automatically and start to beep while the symbol flashes. To switch it off, press any button;

WARNING: when you do this, the oven will automatically switch to manual operation

and will continue working. Therefore, if you wish to stop cooking, do not forget to turn the function selector and the temperature selector to the “0” position. To change the auto-stop cooking time: Press the button until the symbol starts blinking. The screen will show the time when the cooking will finish, you can modify it pushing the and/or buttons. To cancel the auto-stop cooking time:

1. Press the

button until the symbol starts flashing. The screen the time cooking is to stop. will display

2. Press the

button until the time indicated on the screen stops changing. It will then be showing the current time plus the pre-set cooking duration time. The auto-stop cooking function will have been cancelled but the oven will start ope rating in line with the pre-set cooking duration time.

Timer The oven has a built-in countdown beeper function. This works with the oven on or off as it has no impact on the operation of the appliance. In this way, you can use it for any oven operation or for any other matter.

C60T408A1 21/5/08 08:59 Página 38 To set the Timer:

1. Press the button several times

until the symbol starts flashing.

2. Set the countdown time by pressing the

and/or buttons. Example: I want the timer to ring in 45 minutes. After a few seconds, the function will be activated, the symbol will remain lit and the screen will go back to its previous situation. Once the time set has elapsed, the oven will start to beep for 60 seconds while the symbol flashes. After this time, the oven will stop beeping but the symbol will continue to flash. Press any button to stop it flashing. If you wish to stop the beeping before the 60 seconds are up, press any button.

WARNING: If the oven is working, remember that the beeper function does not stop it

operating. Therefore, if you wish to stop cooking, do not forget to turn the function selector and the temperature selector to the “0” position. To change the countdown time, follow the procedure described for setting the timer. To cancel the timer:

1. Press the button several times

until the symbol starts flashing

2. Press the

button until the time displayed on the screen is “0:00”. After a few seconds the symbol will go off and the screen will go back to its previous situation. The beeper function will have been cancelled.

08:59 Página 39 “Cancellation of timer functions” If you wish to cancel all the timer functions set, press the button for a few seconds. The symbols corresponding to these functions will turn off to indicate that they are not active. If the oven is on at the time, then it will continue operating manually once the timer functions have been cancelled; if you want to switch it off, turn the selector function to the “0” position.

WARNING: Switching the oven off by turning the selector function to the “0” position

cancels all the timer functions except the “Beeper” function as this works with the oven on or off.

7.3 SAFETY FUNCTIONS

“Automatic Power-Off” If you have not pressed any timer button for few hours with the oven on, then it will turn itself off automatically for safety reasons. When the oven has been turned off in this way, it will beep to indicate the error and the symbol will start to flash. To disable this automatic power-off indication, turn the selector function to the “0” position and the symbol will stop flashing.

“Child Safety Lock” You can block the oven timer so that it cannot be manipulated by children.

C60T408A1 21/5/08 08:59 Página 40 To set the timer blocking mechanism: Press both the and the buttons simultaneously for a few seconds until the symbol remains lit. The oven timer will be blocked. If the cooking function selector was at the “0” position when the timer was blocked, then it will not be possible to turn the oven on. If on the other hand the oven was working at the time, you will be able to change the selected cooking function and set the temperature but you will not be able to operate the timer. To release the timer blocking mechanism: Press both the and the buttons simultaneously for a few seconds until the symbol goes off. All of the timer functions will then be available again.

C60T408A1 21/5/08 08:59 Página 41

7.4 TIMER BEEPING

You have the option of turning off timer beeping sound. To do so, proceed as follows: To turn beeping off: Press the button and, holding it down, press the seconds. Beeping will be turned off. button for a few To turn beeping on: Press the button and, holding it down, press the seconds. Beeping will be turned on again.

button for a few C60T408A1 21/5/08 08:59 Página 42

C60T408A1 21/5/08 08:59 Página 43 FOURS SOMMAIRE

Tomates farcies (4) 220oC 428oF 15-19 min Non Courgettes farcies (2) 200oC 400oF 25-35 min Non Tomates farcies (4) 200oC 392oF 15-19 min Non Courgettes farcies (2) 180oC 356oF 25-35 min Non

PROGRAMA TEMPERATURA TIEMPO

POSICIÓN ALIMENTO PRECALENACCESORIOS TAMIENTO Tomates rellenos (4) 220oC 428oF 15-19 min

Tomates rellenos (4) 200oC 392oF 15-19 min
