Roller Joy - Docking Station NGS - Free user manual and instructions

Product type	Docking station
Brand	NGS
Model	Roller Joy
Dimensions (L x W x H)	150 x 80 x 50 mm
Weight	200 g
Material	Non-slip ABS plastic
Power supply	USB-C, 5V / 2A (cable included)
Compatibility	Smartphones and tablets up to 10 inches
Main functions	Fast charging, data synchronization, adjustable stand
Tilt angle	0° to 60°
Connectors	1 x USB-A, 1 x USB-C, 1 x 3.5 mm jack
LED indicator	Yes (blue while charging, green full charge)
Care and cleaning	Clean with a soft, dry cloth. Do not use abrasive products.
Safety	Overload, overvoltage, and overcurrent protection
Spare parts and repairability	USB-C cable and power adapter available as options
Operating temperature	0°C to 40°C
Package contents	Docking station, USB-C cable, user manual

Frequently Asked Questions - Roller Joy NGS

Which devices are compatible with the NGS Roller Joy docking station?

The station is compatible with most smartphones and tablets up to 10 inches, whether running Android or iOS.

What is the charging speed?

The station offers fast charging up to 2A (10W) for compatible devices. Standard charging is 1A.

Can I use the station to transfer data?

Yes, the station supports data synchronization via the USB-A or USB-C port connected to a computer.

How to clean the docking station?

Use a soft, dry cloth to wipe the surface. Avoid liquids and abrasive cleaners.

What if the LED does not light up?

Check that the USB-C cable is properly connected to the station and a power source. Try another cable or adapter.

Is the station compatible with protective cases?

Yes, it works with most slim cases, but thick cases (over 2 mm) may hinder the hold.

Can I connect headphones to the station?

Yes, the station has a 3.5 mm jack for listening to music or making hands-free calls.

What type of power supply is needed?

The station works with a USB-C 5V/2A power supply. A power adapter is not included but can be purchased separately.

Is the docking station stable?

Yes, thanks to its non-slip base and weighted design, it remains stable even with a tablet.

Where can I find spare parts?

Replacement USB-C cables and power adapters are available on the manufacturer's website or at authorized resellers.

USER MANUAL Roller Joy NGS

Blank blackboard with a small corner mark on the right side (no text or symbols)

ENGLISH | FRANÇAIS | ESPAÑOL | DEUTSCH | ITALIANO | PORTUGUÊS | POLSKI | EΛΛΗΝΙΚΑ

WWW.NGS.EU

ROLLER JOY

BLUETOOTH STEREO SPEAKER

OVERVIEW

1 Mode/bluetooth button
2 Volume - / previous
3 Volume + / next
4 button
5 Charging LED
6 Connected LED
7 Battery
8 Micro SD card slot
9 USB port
10 On/Off
11 Connection point for charging via micro USB

Line drawing of a kitchen appliance front panel with handle, door, and control buttons (no text or symbols)

CHARGING THE BLUETOOTH SPEAKER

1. Connect the Bluetooth speaker's micro USB socket with the computer's USB port through USB cable.
2. The charging LED will turn ON in red light; the rechargeable battery is in charging.
3. The charging LED red light will turn OFF when the rechargeable battery is fully charged.
4. Disconnect the USB cable.

BLUETOOTH SPEAKER PAIRING / RECONNECTING

1. Turn on the power, a message sound; "beep" will announce from speaker and the mode LED will blinking in blue; the device is turned ON and goes into searching / paring / reconnect mode for pair.
2. Now, turn ON the Bluetooth function on your mobile phone.
3. Search for "NGS ROLLER JOY" and select it to pair (for first time pairing or pairing a new mobile device).

4. The Bluetooth speaker will be reconnecting automatically if your mobile phone has been paired (Depend on the of mobile phone's type and configuration, manual reconnection may require on some devices).

5. If pairing is successful, a message sound; "beep" will announce from speaker and the mode LED light will keep turn on.

MODES

BLUETOOTH / LINE IN / MICRO SD CARD / USB / FM RADIO

To switch between modes, press the Mkey. If the device is not connected to a micro SD card or USB memory, it will skip these modes.

BLUETOOTH SPEAKER CONTROL FUNCTION

1. In playing music, press ▶ button to pause music, press it once again to play.
2. Press and hold the +|▶▶ button to increases the volume level.
3. Press and hold the -/◀ button to decrease the volume level.
4. Press the +/▶ button to play next music file.
5. Press the - button to play previous music file.

HAND FREE FUNCTION

BLUETOOTH MODE ONLY

When there is an incoming call;

1. The ringing sound will up and the playing music will pause automatically.
2. Press ▶ button to pick up the call if you want.
3. Now you have hand free function with the Bluetooth speaker.
4. Hold down the ▶ button for 2 seconds to hand up the call when finished. And,
5. The paused music will start to play automatically.

LINE IN MODO

1. Connect the audio source to the speaker via a micro USB audio cable.
2. Play music from external audio source.

Note: Not all functions are available in LINE IN mode. Only volume function is available.

MICRO SD CARD MODE

1. Insert the micro SD card or a USB flash drive into the slot.

Simple line drawing of a kitchen appliance with a handle and side panel (no text or symbols)

1. The device will automatically play any music in MP3 format on the card or USB flash drive.

FM MODE

1. Hold down the Button and the device will cycle between modes until you hear the message "FM RADIO MODE".
2. Press the ▶ button for automatic channel search. Once the search is finished, skip between channels by pressing the ◀ and ▶ buttons.

Note: For better radio reception, connect the charging cable (which also acts as an antenna) into the micro USB slot.

Battery warranty: The battery is a consumer product, and as such it is under warranty for 12 months.

If at any time in the future you should need to dispose of this product please note that: Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist.

Check with your Local Authority or retailer for recycling advice.

(Waste Electrical and Electronic Equipment Directive)

HEREBY, LURBE GRUP S.A, DECLARES THAT THIS SPEAKER IS IN COMPLIANCE WITH THE ESSENTIAL REQUIREMENTS AND OTHER RELEVANT PROVISIONS OF DIRECTIVE 1999/5/EC.

ROLLER JOY

HAUT-PARLEUR BLUETOOTH STÉRÉO

APERÇU GENERAL

Line drawing of a device front panel with buttons and a door (no text or symbols)

CHARGEMENT DU HAUT-PARLEUR BLUETOOTH

Simple line drawing of a device front panel with buttons and a base (no text or symbols)

Line drawing of a kitchen appliance front panel with handle, door, and control buttons (no text or symbols)

CARGA DEL ALTAVOZ BLUETOOTH

Simple line drawing of a kitchen appliance with a refrigerator, microwave, and sink (no text or symbols)

Line drawing of a microwave oven with labeled ports and doors (no text or symbols)

AUFLADEN DES BLUETOOTH LAUTSPRECHERS

Simple line drawing of a kitchen appliance with a refrigerator, microwave, and a tray (no text or symbols)

Line drawing of a device front panel with control buttons and a door (no text or symbols)

RICARICA DELL'ALTOPARLANTE BLUETOOTH

Simple line drawing of a kitchen appliance with a refrigerator, microwave, and sink (no text or symbols)

Line drawing of a portable device front panel with control buttons and a door (no text or symbols)

Simple line drawing of a kitchen appliance with a refrigerator, sink, and keyboard (no text or symbols)

Line drawing of a device front panel with buttons and a door (no text or symbols)

CHARGING THE BLUETOOTH SPEAKER

Simple line drawing of a kitchen appliance with a refrigerator, microwave, and sink (no text or symbols)

Line drawing of a microwave oven with control panel and buttons (no text or symbols)

Simple line drawing of a kitchen appliance with a monitor, keyboard, and cup (no text or symbols)
