DVM8030 - Odometer VELLEMAN - Free user manual and instructions

Product type	Digital odometer
Brand	Velleman
Model	DVM8030
Dimensions	Approximately 60 x 40 x 20 mm
Weight	Approximately 30 g (with battery)
Power supply	1 CR2032 button cell battery
Display	Backlit LCD
Functions	Total distance, partial distance, instantaneous and average speed, stopwatch
Accuracy	± 0.1 km
Temperature range	-10 °C to 50 °C
Mounting	Handlebar mount with clips
Care and cleaning	Clean with a soft, dry cloth. Avoid water and solvents.
Safety	Do not expose to drops, violent shocks, or excessive humidity.
Spare parts	CR2032 batteries, mounting brackets, sensor magnets
Repairability	Simple battery replacement by user. For other issues, contact after-sales service.
General information	Delivered with user manual, speed sensor, magnet, and brackets.

Frequently Asked Questions - DVM8030 VELLEMAN

How to install the DVM8030 odometer ?

Attach the sensor to the front fork and the magnet to a spoke of the wheel. Mount the meter bracket on the handlebar and insert the meter. Follow the manual diagram for alignment.

Which battery to use ?

Use a CR2032 button cell battery. Remove the back cover of the meter to replace the battery.

How to set the wheel circumference ?

Measure the wheel diameter in mm, multiply by π (3.1416) and enter this value in the odometer settings. Refer to the manual's table for standard values.

Why is the display flashing ?

This generally indicates a low battery. Replace the battery with a new one. If the problem persists, check the battery contact.

How to reset the partial distance to zero ?

Press and hold the MODE button for 3 seconds on the partial distance screen. The display will reset to zero.

Is the odometer waterproof ?

It is splash-resistant but should not be immersed. Protect it from heavy rain and high-pressure washing.

How to change the unit from km to miles ?

In the settings menu, select the unit option (KM or MI) using the SET button. Confirm with MODE.

The displayed speed seems inaccurate, what to do ?

Check the set wheel circumference and the alignment of the sensor and magnet. A deviation of 1 mm can cause errors.

Can I use the odometer on multiple bikes ?

Yes, by purchasing an additional mounting kit. You will need to reconfigure the wheel circumference for each bike.

Where to find spare parts ?

Spare parts (brackets, magnets, batteries) are available from Velleman or authorized dealers. Contact customer service to order.

USER MANUAL DVM8030 VELLEMAN

Close-up of a black plastic electronic component with a curved top and two notches (no text or symbols visible)

USER MANUAL 4

GEBRUIKERSHAN DLEIDING 8

NOTICE D'EMPLOI 12

MANUAL DEL USUARIO 16

To all residents of the European Union

Important environmental information about this product

This symbol on the device or the package indicates that disposal of the device after its lifecycle could harm the environment. Do not dispose of the unit (or batteries) as unsorted municipal waste; it should be taken to a specialized company for recycling.

This device should be returned to your distributor or to a local recycling service. Respect the local environmental rules.

If in doubt, contact your local waste disposal authorities.

Thank you for choosing Velleman! Please read the manual thoroughly before bringing this device into service. If the device was damaged in transit, don't install or use it and contact your dealer. Damage caused by disregard of certain guidelines in this manual is not covered by the warranty and the dealer will not accept responsibility for any ensuing defects or problems.

2. Safety Instructions

Keep this device away from children and unauthorized users.

NEVER TOUCH ROTATING PARTS as they may cause serious or even fatal injury.

CAUTION: due to the persistence of vision, rotating objects might appear stationary or even move in the opposite direction. This effect is strengthened under fluorescent or stroboscopic lamps. Always make sure rotating parts have come to a full stop before touching them.

Use extreme caution when the laser beam is turned on.

When device is in use, do NOT look directly or indirectly (reflectance) into the laser beam. NEVER point the laser beam directly or via a reflecting surface towards other people's or animals' eyes. Permanent eye damage will result. Do not point the laser beam towards highly explosive gasses.

Visible laser radiation. Do not stare into the beam as eye damage may occur. This device contains a class 2 laser.

Output power does not exceed 1 mW, wavelength 635\~660nm.

3. Ge neral Guidelines

Refer to the Velleman® Service and Quality Warranty on the last pages of this manual.

			Keep this device away from rain, moisture, splashing and dripping liquids.
			Protect this device from shocks and abuse. Avoid brute force when operating the device.
			Protect the device against extreme heat and dust.
			There are no user-serviceable parts inside the device.Refer to an authorized dealer for service and/or spare parts.

• Famili arise yourself with the functions of the device before actually using it.
• All modifications of the device are forbidden.
• Only use the device for its intended purpose. Using the device in an unauthorised way will void the warranty.

4. Fe atures

• 6 digit s LCD
• auto power-off
• comes with: storage box, wristlet, batteries, reflective marker, user manual
• option al telescopic tripod (not incl.): CAMB17

5. Preparation

• Prior to using the tachometer, a piece of reflecting marker (incl.) must be attached to the rotating device. Make sure the rotating device has come to a full stop before touching it.
• Make sure the measuring area is clean, free of oil and dust.
• Cut one piece of the reflective marker and attach it to the rotating device. Measurement can be done on the side or at the top of a rotating shaft. When measuring at the top, do not attach the marker to close to the centre. The size of the marker depends largely on the size of the rotating device, but it should never cover more than half of the circumference.

Notes:

- in case no reflective marker can be attached, check whether a measurement can be performed without. If the rotating device consists of multiple reflective surfaces (e.g. fan blades), enter the number (see §6: Use).

- Do not attach more than one marker to the same surface.

6. Use

Refer to the illustrations on pages 2 and 3 of this manual.

• Remo ve the sensor cover [1] by releasing the screw at the back of the device and sliding the cover upwards.
• Press the button to switch the device on. The device will switch off automatically after ±2 minutes of inactivity.
• Press the Unit button to switch from rpm (rotations per minute) to rps (rotations per second) and back.
• Press and hold the Uni: button for ±2s to switch on the backlight. Press and hold again for ±2s to switch it off.
• Press and hold the ▲ button. The sensor [2] produces a red laser-beam. Switch on the rotating device and aim the beam at the reflective marker. To avoid multiple reflections, do not aim the beam perpendicular to the marker but under an angle of ±30°. Best measuring distance is between 10 and 40cm (4" \~ 15").

Note: when the display shows OL, the measured value is outside of the measuring range (see §10: technical specifications)

• Release the button : o end the measuring session.
• When the ▲button is not pressed the device is in hold-mode [A].

- Press the Func. button to show the maximum measured value of the previous session [B].

- Press the Func. button again to show the minimum measured value of the previous session [C].

- Press the Func. button again to set the number of reflecting surfaces that rotating device contains (e.g. when measuring the speed of a fan with 5 reflective blades, set to 5). Use the ▲ button to increase the value. Range from 1 \~ 9. After 9, value returns to 1. Press the Func. button to exit.

Note: for a normal measurement with 1 reflective marker, the number must be set to 1.

- When the battery indicator [F] is shown, replace the batteries (see §9).

- Alwa ys place the sens) r cover [1] back when the device is not in use.

7. Operation tips

• Do not measure outside of the operating range ('OL' is displayed on the LCD) and do not measure in places with high humidity. Refer to the technical specifications for more details.
• Make sure the device is at ambient temperature for accurate measurements.
• Remo ve the batteries w hen the device is not used for a long time.

8. Ma intenance

- Wipe the device regularly with a moist, lint-free cloth. Do not use alcohol or solvents. DO NOT submerge the device in any liquid.

9. Batteries

• To replace the batteries, make sure the device is switched off.
- Open the battery cover at the back by sliding it downwards (away from the sensor).
- Take out the old batteries and replace them with 3 new and identical 1.5V AAA batteries following the polarity markings inside the battery compartment.
- Slide the battery cover back in place.

Do not puncture or throw batteries in fire. Dispose of batteries in accordance with local regulations. Do not attempt to recharge non-rechargeable batteries. Keep batteries away from children.

1. Technical specifications

LCD display	6 digits
parameters	rpm, rps
measuring range	100~30000 rpm, 1.7~500 rps
resolution	0.1 rpm (100~999.9 rpm), 0.1 rps (1.7~100 rps)
	1 rpm (1000~30000 rpm), 1 rps(100~500 rps)
accuracy	±0.1% reading (100.0~9999 rpm)
	±0.02% reading (10000~30000 rpm)
sample rate	1x /s
operating temperature	-10°C ~ +50°C (14°F~122°F)
humidity	0 ~ 80% RH
power supply	3 x 1.5V AAA batteries LR03C (incl.)
auto power-off	±2 min.
dimensions	121 x 60 x 30mm
weight	±180g

Use this device with original accessories only. Velleman nv cannot be held responsible in the event of damage or injury resulted from (incorrect) use of this device.

For more info concerning this product, please visit our website www.velleman.eu.

The information in this manual is subject to change without prior notice.

© COPYRIGHT NOTICE

This manual is copyrighted. The copyright to this manual is owned by Velleman nv. All worldwide rights reserved. No part of this manual may be copied, reproduced, translated or reduced to any electronic medium or otherwise without the prior written consent of the copyright holder.

GEBRUIKERSHANDLEIDING

1. Inl eiding

Velleman® Service and Quality Warranty

Velleman® has over 35 years of experience in the electronics world and distributes its products in more than 85 countries. All our products fulfil strict quality requirements and legal stipulations in the EU. In order to ensure the quality, our products regularly go through an extra quality check, both by an internal quality department and by specialized external organisations. If, all precautionary measures notwithstanding, problems should occur, please make appeal to our warranty (see guarantee conditions).

General Warranty Conditions Concerning Consumer Products (for EU):

• All consumer products are subject to a 24-month warranty on production flaws and defective material as from the original date of purchase.
• Velleman® can decide to replace an article with an equivalent article, or to refund the retail value totally or partially when the complaint is valid and a free repair or replacement of the article is impossible, or if the expenses are out of proportion. You will be delivered a replacing article or a refund at the value of 100% of the purchase price in case of a flaw occurred in the first year after the date of purchase and delivery, or a replacing article at 50% of the purchase price or a refund at the value of 50% of the retail value in case of a flaw occurred in the second year after the date of purchase and delivery.

- Not covered by warranty:

• all direct or indirect damage caused after delivery to the article (e.g. by oxidation, shocks, falls, dust, dirt, humidity...), and by the article, as well as its contents (e.g. data loss), compensation for loss of profits;
• frequently replaced consumable goods, parts or accessories such as batteries, lamps, rubber parts, drive belts... (unlimited list);
• flaws resulting from fire, water damage, lightning, accident, natural disaster, etc. ...;
• flaws caused deliberately, negligently or resulting from improper handling, negligent maintenance, abusive use or use contrary to the manufacturer's instructions;
• damage caused by a commercial, professional or collective use of the article (the warranty validity will be reduced to six (6) months when the article is used professionally);
• damage resulting from an inappropriate packing and shipping of the article;

• all damage caused by modification, repair or alteration performed by a third party without written permission by Velleman®.

• Articles to be repaired must be delivered to your Velleman® dealer, solidly packed (preferably in the original packaging), and be completed with the original receipt of purchase and a clear flaw description.

• Hint: In order to save on cost and time, please reread the manual and check if the flaw is caused by obvious causes prior to presenting the article for repair. Note that returning a non-defective article can also involve handling costs.
• Repairs occurring after warranty expiration are subject to shipping costs.
• The above conditions are without prejudice to all commercial warranties.

The above enumeration is subject to modification according to the article (see article's manual).
