650 - Loudspeaker BRAVEN - Free user manual and instructions

Product type	Portable Bluetooth speaker
Brand	Braven
Model	650
Category	Speaker
Dimensions	15.9 cm x 6.4 cm x 4.5 cm
Weight	360 g
Power supply	AC adapter 5 V DC, 1 A (included)
Battery life	Up to 20 hours (playback at medium volume)
Speaker power	6 W (2 x 3 W)
Max sound level	95 dB at 0.5 m
Frequency response	180 Hz - 13 kHz (±3 dB)
Bluetooth range	10 m (line of sight)
Bluetooth profile	A2DP
Hands-free function	Yes (built-in microphone)
Device charging	Yes (USB port, up to 1 A)
Daisy chain connection	Yes (via 3.5 mm audio cable)
Battery indicator	Yes (check button, white/blue/red LED)
Auto power off	After 30 minutes without active Bluetooth connection
Maintenance	Wipe with a soft, dry cloth
Safety	Do not expose to water, do not open, indoor use only

Frequently Asked Questions - 650 BRAVEN

How to pair my phone with the Braven 650 speaker?

Turn on the speaker, enable Bluetooth on your phone, press and hold the pairing button until the LED flashes rapidly, select "BRAVEN" from your phone's Bluetooth device list, and enter "0000" if a code is requested.

What to do if the speaker produces no sound?

Check that the speaker volume and your phone volume are high enough. Make sure the Bluetooth connection is active and the speaker is not in standby mode. If using a 3.5 mm cable, ensure it is fully inserted on both ends. Some phones reduce volume when connected via Bluetooth, refer to your device's manual.

How to check the speaker's battery level?

Press the battery check button on the left side of the speaker. The LED lights up: white for 50-100%, blue for 10-50%, red for 0-10% charge.

Can I charge a smartphone with the Braven 650 speaker?

Yes, the speaker can charge USB devices (phones, MP3 players) up to 1 A. Connect your device's cable to the full-size USB port on the left side of the speaker. Make sure the speaker is powered on. The speaker's battery can charge a typical smartphone to about 80-100%.

How to make a hands-free call with the speaker?

During an incoming call, press the phone/pairing button to answer. The built-in microphone allows you to speak. To hang up, press this button again or use your phone's end call button.

Is the Braven 650 speaker waterproof or water resistant?

No, the speaker is not waterproof. Avoid any exposure to moisture, rain, or liquids. Do not use it near a bathtub, pool, or in a damp basement.

How to connect multiple Braven speakers together (daisy chain)?

Use a 3.5 mm audio cable to connect the line out of one paired speaker to the line in of another Braven speaker. The first speaker remains the Bluetooth receiver, and sound is played on all speakers connected in series. You can adjust the volume independently on each speaker.

What does rapid flashing of the LED during pairing mean?

Rapid flashing indicates that the speaker is in pairing mode. Once pairing is successful, the LED flashes slowly or stays steady. If pairing fails, the LED may turn off or flash differently.

How to save the speaker's battery?

The speaker automatically powers off after 30 minutes without an active Bluetooth connection. You can also turn it off manually with the power switch. Reducing the playback volume also extends battery life.

Where to find replacement parts for the Braven 650 speaker?

Spare parts are not sold separately by the manufacturer. In case of issues, contact Braven customer service or an authorized repair center. Opening the speaker voids the warranty and may present electrical risks.

USER MANUAL 650 BRAVEN

TROUBLESHOOTING....10

DEVICE SPECIFICATIONS....11

WARNINGS & CAUTIONS 12

LEGAL INFORMATION 13

GET TO KNOW YOUR BRAVEN

BATTERY INDICATOR LIGHT BATTERY CHECK BUTTON

3.5 MM AUDIO-OUT JACK (daisy-chain)

EXTERNAL USB CHARGING PORT

• Before using your BRAVEN speaker for the first time, charge it until the Power/Sync Light turns off, indicating a full charge (typically 2 to 4 hours).
• For the fastest charge, plug the included USB-to-Micro-USB cable into the included wall power adapter. Plug the Micro-USB connector end into the BRAVEN Charging Port.
• You can also charge using a powered USB port on a computer, but charge time will be longer than when charging from a wall outlet.

CHARGE INDICATOR LIGHTS:

To check your BRAVEN's battery charge level press the Battery Check Button located on the left side of your speaker. The Battery Indicator Light will illuminate indicating the current battery charge level.

White light = 50 - 100 % charge

Blue light = 10 - 50 %

Red light = 0 - 10 %

ASSEMBLE THE POWER ADAPTER

The power adapter comes fitted with the appropriate adapter for the US region. To change to any other region adapter follow these steps:

1. To remove an adapter head, pull the release latch back on the base unit and slide the head up and out.

2. Select the appropriate power adapter for your region and slide the adapter head into the plug base until you hear a "click".

3.

4.

POWER ADAPTER REGIONS:

USA
Japan
Mexico

EU
Philippines
Russia

UK
Hong Kong
Singapore

Australia
New Zealand
China

TURN ON & SYNC

1. Slide the power switch up to the "on" position. You will hear the BRAVEN power up sound.
2. Activate Bluetooth on the phone or device you are pairing with (see your device's instruction manual for information on activating its Bluetooth settings).
3. Press and hold the Pairing Button on the BRAVEN speaker until the Sync Status Light begins to flash rapidly and you hear the BRAVEN sync sound.

1. Go to your phone or device's Bluetooth® settings and select the BRAVEN device from the list.

2. If asked for a passcode enter "0000"

You only need to do this once for each device you are syncing to your BRAVEN speaker. Your BRAVEN speaker will remember the last 8 devices it has paired with.

NOTE: If the BRAVEN does not have an active Bluetooth* connection and is left on, it will shut itself off after 30 minutes. To restart the BRAVEN you will need to slide the switch to the "off" position and then back to the "on" position.

6 ENGLISH BRAVEN

CHARGING EXTERNAL DEVICES

BRAVEN is designed to charge USB devices that draw from 0.3A - 1A (most cell phones & mp3 players. Tablets and other 2A devices cannot be charged by your BRAVEN speaker) using the full-sized USB port on the left side of the speaker. To use external charging:

1. Turn the BRAVEN power switch on.
2. Plug the USB power cable that came with your phone, mp3 player, or other mobile device into the USB port on the BRAVEN speaker.
3. Plug the other end of the cable into your mobile device, and it will immediately begin charging.

APPROXIMATE CHARGING CAPACITY

On a full charge, without music playing, your BRAVEN speaker can charge external devices to the following approximate levels:

BRAVEN 650 – will charge a typical smartphone approximately 80-100% (depending on model and battery size)

BRAVEN 625s - will charge a typical smartphone approximately 70-90% (depending on model and battery size)

BRAVEN 600 - will charge a typical smartphone approximately 50-70% (depending on model and battery size)

SPEAKERPHONE

You can use your BRAVEN speaker as a conference calling device if your phone supports this feature.

When the BRAVEN is synced via Bluetooth ^® with your phone and a call comes in, the speaker will beep. Music, if playing, will pause, and your ringtone will play over the speaker.

ANSWERING A CALL

Press the Phone/Pairing Button on the BRAVEN to answer the call over the speaker. The call will be answered using the BRAVEN's microphone and speakerphone.

If you press the answer button on your phone, some phones may answer via the mobile device and not the BRAVEN speaker. You may need to manually select the BRAVEN speaker as the audio source to use it as the speakerphone. (Consult your Bluetooth® device's user manual for instructions on selecting an audio source.)

Press the Phone/Pairing Button again to end the call.

Alternatively, you may press the end call button on your mobile phone to end the call.

Once the call is ended, your music will resume playing if your mobile phone allows this feature.

DEVICE CONTROL

While playing music and movies you can pause and skip tracks forward and back by using the following buttons on the BRAVEN speaker.

Pause: Press the Phone/Pairing/Pause Button for 0.5 seconds. Press again to resume playback.

Skip to next track: Press the Volume Up/Skip Track Button for 3 seconds.

Skip back: Press the Volume Down/Skip Back Button for 3 seconds. (To skip to the previous track instead of to the beginning of the current track, press and hold the Volume Down Button within the first few seconds of the current song)

DAISY-CHAINING

You can daisy-chain multiple BRAVEN speakers together for increased sound.

• Using the included 3.5mm audio cable, connect the line-out of your paired BRAVEN speaker to the line-in port of another BRAVEN speaker.
• You can also connect via line-out to non-BRAVEN or non-Bluetooth®-enabled speaker systems (home, car, office, overhead systems, other portable speakers, etc.).
• The paired BRAVEN speaker acts as a Bluetooth ^* receiver, and audio will play on both the BRAVEN and on the linked speaker systems. Volume can be controlled independently on each speaker and on the paired device.

TROUBLESHOOTING

I CAN'T HEAR ANYTHING FROM MY SPEAKER

1. BRAVEN audio levels can be controlled independently, both on the speaker and the Bluetooth ^® source device. Check the volume levels on both devices to ensure that they are turned up sufficiently.
2. If using the 3.5mm cable, check that the cable is fully inserted into both your device and the BRAVEN speaker.
3. Some devices experience volume loss when connected to speakers through Bluetooth*. (Please refer to your device's owner's manual for further information.)

THE SIGNAL IS CUTTING OUT

1. A Bluetooth ^® signal can be affected by objects that obstruct the BRAVEN from a clear path to the playing device to which it is paired. Ensure that your listening environment is conducive to the 33-foot (10-meter) Bluetooth ^® range between your BRAVEN and your playing device.

I'M UNABLE TO PAIR WITH MY DEVICE

1. Check that the device you are attempting to pair with is Bluetooth ^® compatible.
2. Follow TURN ON & SYNC instructions on page 6.

DEVICE SPECIFICATIONS

	BRAVEN 650 625s 600 BRAVEN BRAVEN
PLAY TIME	20 hours* 16 hours* 12 hours*
DRIVERS	6W (3W per channel) 6W (3W per channel) 6W (3W per channel)
DECIBEL RATING	95 dB at 0.5m 95 dB at 0.5m 95 dB at 0.5m
FREQ. RESPONSE	180Hz - 13kHz +/- 3dB 180Hz - 13kHz +/- 3dB 180Hz - 13kHz +/- 3dB
POWER ADAPTER	Output: DC 5V 1A Output: DC 5V 1A Output: DC 5V 1A
SIZE	15.9cm x 6.4cm x 4.5cm 16cm x 6.5cm x 4.6cm 15.85cm x 6.4cm x 4.5cm
WEIGHT	12.6 oz. (360g) 11.6 oz. (330 g) 12 oz. (340g)
BLUETOOTH RANGE	10m/33 ft. (line of sight) 10m/33 ft. (line of sight) 10m/33 ft. (line of sight)

*Approximate play time based on playing audio at medium levels over Bluetooth. Song genre, tempo and volume will affect play time.

WARNINGS & CAUTIONS

To reduce the risk of fire or electric shock, do not expose the BRAVEN to rain or moisture. The BRAVEN should not be exposed to dripping or splashing, and objects filled with liquids, such as vases, should not be placed on or near it. Do not use near bathtubs, washbowls, kitchen sinks, laundry tubs, in a wet basement, near a swimming pool, or anywhere else that water is present. As with any electronic products, use care not to spill liquids into any part of the product. Liquids can cause a failure and/or a fire hazard. The power supply must be used indoors only. It is neither designed nor tested for charging outdoors, in recreation vehicles, or on boats. Make no modifications to the product or accessories. Unauthorized alterations may compromise safety, regulatory compliance, and system performance, and will void the warranty. Do not place any flame sources, such as lighted candles, on or near the BRAVEN. The BRAVEN contains small parts that may be a choking hazard and is not suitable for children under age 3. Before use, fully charge the battery using the supplied power adapter. Do not continue charging the battery if it does not reach full charge within the specified charging time. Overcharging may cause the battery to become hot, rupture, or ignite. If you see any heat deformation or leakage, properly dispose of the battery. Do not attempt to charge the battery in temperatures outside the range of 32°-104°F (0°-40°C). If the battery begins to leak, do not allow the liquid to come in contact with your skin or eyes. If contact has been made, wash the affected area with plenty of water and seek medical attention immediately. Do not expose the product or battery to excessive heat, including direct sunlight or fire and storage or use inside cars in hot weather, where it can be exposed to temperatures in excess of 115°F (60°C). Doing so may cause the battery and power supply to generate heat, rupture, or ignite. Using the product in this manner also may result in a loss of performance and a shortened life expectancy. Extended exposure to direct sunlight may damage the external appearance and material qualities. Do not step on, throw, or drop batteries or the power supply or device, or expose them to a strong shock. Do not pierce, crush, dent, or deform the batteries or power supply in any way. If either becomes deformed, properly dispose of it. Do not short-circuit batteries. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way: such as power supply cord or plug is damaged; liquid has been spilled or objects have fallen into the BRAVEN; the BRAVEN has been exposed to rain or moisture, does not operate normally, or has been dropped. Do not attempt to service the BRAVEN yourself. Opening or removing covers may expose you to dangerous voltages or other hazards and will void the manufacturer's warranty. To prevent risk of fire or electric shock, avoid overloading wall outlets, extension cords, or integral convenience receptacles. Do not place your BRAVEN on high surfaces such as shelves. During music playback the BRAVEN may vibrate and move which could cause the speaker to shift and fall off of the edge. Your Bluetooth device (mobile phone, music player, tablet, laptop, etc.) must support the A2DP Bluetooth profile in order to work wirelessly with your new BRAVEN SIX Series speaker. The A2DP profile is supported by most recent mobile products with built-in Bluetooth capability. Please refer to your device's user manual for details and instruction regarding the Bluetooth profiles it supports.

12 ENGLISH

LEGAL INFORMATION

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:—Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help.

This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

TABLE DES MATIÈRES

FAMILIARISEZ-VOUS AVEC L'ENCEINTE BRAVEN.... 3

RECHARGER VOTRE BRAVEN....4

MISE SOUS TENSION ET SYNCHRO....6

RECHARGE DE DISPOSITIFS EXTERNES....7

MODULE MAINS LIBRES 8

CONTRÔLE DE DISPOSITIFS ET CONNEXION EN GUIRLANDE....9

GUIDE DE DÉPANNAGE 10

CARACTÉRISTIQUES TECHNIQUES DU DISPOSITIF....11

AVERTISSEMENTS ET MISES EN GARDE 12

INFORMATIONS JURIDIQUES....13

FAMILIARISEZ-VOUS AVEC L'ENCEINTE BRAVEN

VOYANT DE LA BATTERIE TOUCHE DE VÉRIFICATION DE LA BATTERIE

PRISE DE SORTIE AUDIO 3,5 MM (connexion en guirlande)

PORT USB POUR RECHARGE DE DISPOSITIF EXTERNE

TOUCHE DE TÉLÉPHONE/APPARIEMENT/PAUSE

CÔTÉ GAUCHE CÔTÉ DROIT

INTERRUPTEUR MARCHE/ARRÊT

VOYANT D'ALIMENTATION/ D'ÉTAT DE LA SYNCHRO

PORT DE RECHARGE DE L'ENCEINTE BRAVEN

TOUCHE POUR AUGMENTER LE VOLUME/PASSER À LA PISTE SUIVANTE

PRISE D'ENTRÉE AUDIO 3,5 MM

TOUCHE POUR DIMINUER LE VOLUME/ RECULER LA MUSIQUE

RECHARGER VOTRE BRAVEN

VOLUME SU/SALTA TRACCIA

JACK INGRESSO AUDIO 3,5 MM

VOLUME GIÙ/TORNA INDIETRO

RICARICARE IL TUO BRAVEN

REGIONI:

STATI UNITI
GIAPPONE
MESSICO

UNIONE EUROPEA
FILIPPINE
RUSSIA

REGNO UNITO
HONG KONG
SINGAPORE

AUSTRALIA
NUOVA ZELANDA
CINA

國家：

美國
日本
墨西哥

欧盟
菲律宾
俄羅斯

英國
香港
新加坡

澳大利亞
新西蘭
中國

繁體中

BRAVEN

開機和配對

地域：

USA
日本
メキシコ

欧州連合
フィリピン
ロシア

英国
香港
シンガポール

オーストラリア
ニュージーランド
中国

日本語

BRAVEN

電源オン ハンク

SUPPORT: www.braven.com/support

EMAIL: [e-mail]

PHONE: 1-877-9 BRAVEN (1-877-927-2836)

TWITTER: @bravenproducts

FACEBOOK: facebook.com/bravenproducts
