USER MANUAL CD-1586 AudioSonic

Black and white photo of a MP3 audio recording device with two large speakers and a digital display (no visible text or symbols on the device body)

CD-1586

AudioSonic

Dear customer,

Congratulations and thank you for purchasing this high quality product. Please read the instruction manual carefully so that you will be able to make the best possible use of the appliance. This manual includes all the necessary instructions and advice for using, cleaning and maintaining the appliance. If you follow these instructions you will be guaranteed of an excellent result, it saves you time and will avoid problems. We hope you will have a great deal of pleasure from using this appliance.

service You can find all information and spare parts at service.tristar.eu!

An answer to all your questions

Tips and tricks on how to use your product

Order spare parts for your product online

Register for software updates for your product

SAFETY INSTRUCTIONS

• Please read the instruction manual carefully before using the device. Please keep these instructions, the guarantee certificate, the sales receipt and, if possible, the carton with the inner packaging.
• Warning: To reduce the risk of electric shock, do not remove cover (or back). No user-serviceable parts inside. Refer servicing to qualified service personnel.
• Warning: The battery (battery or batteries or battery pack) shall not be exposed to excessive heat such as sunshine, fire or the like.

• Warning: The mains plug is used as disconnect device, the disconnect device shall remain readily operable.

• Invisible laser radiation when open and interlocks defeated. Avoid exposure to beam of laser.

• No naked flame sources such as lighted candles should be placed on the apparatus.
  • Attention should be drawn to environmental aspects of battery disposal.
  • Use of the apparatus in moderate climates.
  • The rating and marking information are located at the bottom of the unit.
• Excessive sound pressure from earphones and headphones can cause hearing loss.
• The AC/DC adaptor of unit shouldn't be obstructed or should be easily accessed during intended use.
  • To be completely disconnect the power input, the mains plug of apparatus shall be disconnected from the mains.
• Caution! Danger of explosion if the battery is incorrectly replaced. Replace only with the same or equivalent type.
  • To prevent fire or shock hazard do not expose this appliance to rain or moisture.

CAUTION

RISK OF ELECTRIC SHOCK DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

THE LIGHTNING FLASH WITH ARROWHEAD SYMBOL, WITHIN AN EQUILATERAL TRIANGLE, IS INTENDED TO ALERT THE USER TO THE PRESENCE OF UNINSULATED "DANGEROUS VOLTAGE" WITHIN THE PRODUCT'S ENCLOSURE THAT MAY BE OF SUFFICIENT MAGNITUDE TO CONSTITUTE A RISK OF ELECTRIC SHOCK TO PERSONS.

THE EXCLAMATION MARK SYMBOL INSIDE AN EQUILATERAL TRIANGLE WARNS THE USER THAT IMPORTANT OPERATING AND SERVICING (TROUBLESHOOTING) INSTRUCTIONS ARE CONTAINED IN THE DOCUMENTATION ACCOMPANYING THE PRODUCT.

The following label has been affixed to the unit, listing the proper procedure for working with the laser beam:

CLASS 1 LASER PRODUCT

Invisible laser radiation when open and interlocks defeated. Avoid exposure to beam.

WARNING LABEL INFORMING OF RADIATION - This label is placed inside the unit. As shown in the illustration. To warn against further measures on the unit. The equipment contains a laser radiating laser rays according to the limit of laser product of class 1.

HEED WARNINGS - All warnings on the appliance and in the operating instructions should be adhered to.

WATER AND MOISTURE - The appliance should not be used near water, for example, near a bathtub, washbowl, kitchen sink, laundrytub, swimming pool or in a wet basement.

VENTILATION - The appliance should be situated so that its location or position does not interfere with its proper ventilation. Do not place on bed, sofa, rug or similar surface that may block the ventilation openings, in a built-in installation, such as a bookcase or cabinet that may impede the flow of air through the ventilation openings.

HEAT - The appliance should be situated away from heat sources such as radiators, stoves, or other appliances (including amplifiers) that produce heat.

POWER SOURCE - The appliance should be connected to a power supply only of the type described in the operating instructions or as marked on the appliance.

POWER CORD PROTECTION - Power supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them.

POWER LINES - An outdoor antenna should be located away from power lines.

OBJECT and LIQUID ENTRY - Care should be taken so that objects do not fall and liquids are not spilled into the enclosure through openings.

ESD WARNING - The display does not function properly or no reaction to operation of any the control may due to the electrostatic discharge. Switch off and unplug the set. Reconnect after a few seconds.

DAMAGE REQUIRING SERVICE - The appliance should be serviced by qualified service personnel when:

a. The power-supply cord or plug has been damaged.
b. Objects have fallen into, or liquid has been spilled into the appliance enclosure.
c. The appliance has been exposed to rain.
d. The appliance has been dropped, or the enclosure damaged.
e. The appliance does not appear to operate normally."

SERVICING - The user should not attempt to service the appliance beyond that described in the user operating instructions. All other servicing should be referred to qualified service personnel.

Notes:

a. Dirty or scratched CD may cause a skipping problem. Clean or replace the CD.
b. If an error display or malfunction occurs, disconnect the AC cord and remove all the batteries. Then turn the power back on.

Notes: CONCERNING COMPACT DISCS.

Since dirty, damaged or warped discs may damage the appliance, care should be taken of the followings items:

a. Usable compact discs. Use only compact disc with the mark shown below.
b. CD compact disc only with digital audio signals.

PartS DeScriPtion

1. Volume control
2. CD door
3. Play / Pause
4. Next forward
5. Prev rewind
6. +10/album
7. Prog./Mem./Mode
8. Stop
9. Source
10. On/Off (power) button
11. USB slot
12. SD/MMC
13. Tuning control
14. Phone jack
15. Aux-in Jack
16. Handle
17. FM Antenna
18. Battery compartment
19. DC in jack

1 16 17 13 2 3 4 5 6 7 8 9 10 14 AudioSonic mp3 15 19 181211

BEFORE THE FIRST USE

• Take the appliance and accessories out the box. Remove the stickers, protective foil or plastic from the device.
- Place the device on a flat stable surface and ensure a minimum of 10 cm. free space around the device. This device is not suitable for installation in a cabinet or for outside use.

POWER SOURCES

AC power

You can power your portable system by plugging the external AC/DC adaptor into the DC inlet at the back of the unit and into a wall AC power outlet. Check that the rated voltage of your appliance matches your local voltage. Make sure that the AC adaptor is fully inserted into the appliance.

Battery power

Insert 8 x "C" size batteries into the battery compartment. Be sure that the batteries are inserted correctly to avoid damage to the appliance. Always remove the batteries when appliance will not be used for a long period of time, as this will cause leakage to the batteries and subsequently damage to your appliance.

Notes:

Use batteries of the same type. Never use different types of batteries together. When using the appliance with batteries, disconnect the AC/DC adaptor.

USE

Radio

• Press the power button to turn on the device.
• Press the source button repeatedly to switch to the tuner mode.
• Use the tuning control button to tune to your radio station, note: turn the knob until you hear a click. When you hold the knob for a several seconds the device will search automatically.
  • Note: fully extend the telescopic antenna and rotate it for the best reception.

Storing your favorite radio station

Tune to your favorite station, press the [prog/mem/mode] button, the memory cell number will flash. Use with the skip buttons the designated memory cell number and confirm with the [prog/mem/mode] button. From now on you can choose your favorite station by using the skip buttons during radio playback.

Play a disc

• Press the power button to turn on the device.
- Press the source button repeatedly to switch to the CD mode.
- Open the CD door, load a disc on the disc tray with the label side facing up and close the CD door.
- Press the [play/pause] button to pause or resume the playback, press the [stop] button to stop the playback.

Play an USB/SD/MMC

• Press the power button to turn on the device.
• Press the source button repeatedly to switch to the USB or card mode.
• Insert an USB tot the USB port or insert a SD/MMC card to the card slot.
• Press the [play/pause] button to pause or resume the playback, press the [stop] button to stop the playback.

Skip tracks

• Press the skip buttons to go to the next or previous track.
• Press and hold the skip buttons to search at a quick rate for a specific point to play.
• Press the [+10/album] button to skip 10 tracks ahead.
  • Press and hold the [+10/album] button to skip to the next album.

Play modes

During playback, pres the [prog/mem/mode] button to switch among several play modes.

For CD

• Press once: repeat a single trak
• Press twice: repeat all tracks
• Press three times: random play mode
• Press four times: introduction play mode
- Press five times: exit

For MP3/USB/SD/MMC

• Press once: repeat a single trak
• Press twice: repeat the directory
• Press three times: repeat all tracks
• Press four times: random play mode
• Press five times: introduction play mode
- Press six times: exit

Programmed play

• A maximum of 20 tracks for CD and 99 tracks for MP3/USB can be programmed in memory in a preferred order.
• Press the [prog/mem/mode] button in the stop mode. "P-01" starts flashing on the display, choose with the skip buttons the desired track and confirm with the [prog/mem/mode] button. Press the [play/pause] button to start your playlist.
• If you want to stop your playlist, first press the [play/pause] button and then the [stop] button.
• Note: if your source contains folders you first have to program the folders (programming the folders is the same as programming tracks)

Aux in

• Connect an external audio source to the device by plugging it in the aux in jack.
• Press the power button to turn on the device.
• Press the source button repeatedly to switch to the Aux mode.
  • Use the native controls on the external audio source to start playing music.

Phone jack

Plug in the headphone and adjust the volume with the volume control, when an external headphone is connected the speakers will be muted.

Caution: listening a high volume for a long time could damage the users ears.

CLEANING AND MAINTENANCE

• Clean the appliance with a damp cloth. Never use harsh and abrasive cleaners, scouring pad or steel wool, which damages the device.
• Never immerse the device in water or any other liquid. The device in not dishwasher proof.

GUARANTEE

• Tristar is not liable for damages occurred through:

o In case the appliance has fallen.
o In case the appliance has been technically changed by the owner or another third party.
o In case of improper use of the appliance.
o In case of normal wear of the appliance.

• By executing repairs the original warranty period of 2 years will not be extended, nor the right to a complied new warranty. This warranty is only legal on European soil. This warranty does not overrule the European directive 2011/83/EU.
  • Always keep your receipt, without this receipt you can not claim any form of warranty.
• Damage caused by not following the instruction manual will lead to avoid of warranty, if this results in consequential damages Tristar will not be liable.
• Tristar will not be liable for material damage or personal injury caused by improper use or if the safety instructions are not properly executed.
• Cleaning, as mentioned in this manual, is the only necessary maintenance for this appliance.
• When the appliance should be repaired, make sure that this will be performed by an authorized company.
  • This appliance may not be amended or changed.
• If problems arise during the 2 years from the date of purchase, which are covered by the factory warranty, you can go back to the point of purchase to replace it for a new one.
• For questions or compliances please contact your retailer "point of purchase."
• This appliance is covered with a 24 month guarantee starting on the date of purchase (receipt).

AudioSonic

Instruction Manual

• Only material or manufacturing defects are included in this warranty.
- If you wish to make a claim please return the entire machine in the original packaging to your dealer together with the receipt.
- Damage to accessories does not mean automatic free replacement of the whole appliance. You can find all information and spare parts www.service.tristar.eu. Broken glass or breakage of plastic parts are always subject to a charge.
- Defects to consumables or parts subject to wearing, as well as cleaning, maintenance or the replacement of these parts are not covered by the guarantee and hence are to be paid!
• The guarantee lapses in case of unauthorized tampering.
• After the expiry of the guarantee repairs can be carried by the competent dealer or repair service against the payment of the ensuing costs.

GUIDELINES FOR PROTECTION OF THE ENVIRONMENT

This appliance should not be put into the domestic garbage at the end of its durability, but must be offered at a central point for the recycling of electric and electronic domestic appliances. This symbol

on the appliance, instruction manual and packaging puts your attention to this important issue. The materials used in this appliance can be recycled. By recycling used domestic appliances you contribute an important push to the protection of our environment. Ask your local authorities for information regarding the point of recollection.

Packaging

The packaging is 100% recyclable, return the packaging separated.

Product

This device is equipped with a mark according to the European Directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE). By ensuring that this product will be correctly processed into waste, it will help prevent possible negative consequences for the environment and human health.

EC declaration of conformity

This device is designed, manufactured and marketed in accordance with the safety objectives of the Low Voltage Directive "No 2006/95/EC", the protection requirements of the EMC Directive 2004/108/EC "Electromagnetic Compatibility" and the requirement of Directive 93/68/EEC.
