USER MANUAL BR 1201 BRENNENSTUHL

(IEC 6F22)/ Alkaline

Batterie (IEC 6LR61)

oder MN1604

Max. Strom: < 20 mA (Alarm)

Battery Powered Photoelectric Smoke Detector BR 1201

Important:

Read and keep these operating instructions. Make note of and follow the safety instructions.

Instructions

These operating instructions must be read completely and carefully. They are a component of your newly purchased, battery-operated, photoelectric smoke detector and contain important information concerning its operation and maintenance. In the following, it will be referred to only as the smoke detector. All safety notices are to be observed in the use of this product. If you have any questions concerning the use of this product, contact your dealer or our service office. These operating instructions are to be kept and must if necessary be passed on to third parties. Additionally, the smoke detector must be kept in proper operating condition.

BR 1201 Operating Instructions

Technical Data

Device: BR 1201

Testing certificates: VdS tested, EN 14604

Protection class: IP 20

Power: 9 V DC carbon zinc (IEC

6F22)/ alkaline battery

(IEC 6LR61) or MN1604

Max. voltage: < 20 mA (Alarm)

Ambient temperature: 0°C - 40°C

Relative humidity: 10%-90%

Sound level, signal: 85 dB (3 m distance)

Battery life: Min. 1 year

Selecting the mounting location

NOTICE: It is recommended that you install multiple smoke detectors in your residence or building. In order to provide minimal protection, it is

recommended that multi-floor buildings have one smoke detector installed per floor.

WARNUNG: The smoke detector should be mounted on the pathways to the bedrooms (stairways, hallways, entry ways, etc.). Please make sure that it can be heard well from the bedrooms. If an unfavourable location is chosen, the smoke detector can be largely ineffective in the case of a fire. This can reduce the time needed to get to safety in the event of a fire, endangering your life.

Operating Instructions BR 1201

TIP: To be that the location chosen is acoustically favourable, set off a test alarm.

A smoke detector should be installed in every living space and in every basement room in order to provide an expanded degree of protection. In the following rooms and mounting locations, mounting can lead to problems:

Site/Type Reason

Kitchen/Bath Cooking steam and humidity (humidity of 90%)

Garages Combustion engines (cars, etc.)

Moisture prone Moist air from dryers, steam, rooms etc. (humidity 90%)

Dusty rooms The smoke detector's measuring sensors can become fouled very quickly.

Sites with strong Air currents from fans, open air currents windows, ventilation, etc.

Rooms with Rooms below 0°C or higher extreme temperatures than 40°C

Rooms with high The smoke detector's measu-incidence of ing sensors can become fouled insect pestsr very quickly.

BR 1201 Operating Instructions

do 20m al todi idh. 1.00" be y Lum.

smoke detector for optimal protection

smoke detector for minimal protection

bed- room bath- room kitchen Entrance bed- room bed- room bed- room living- room

Operating Instructions BR 1201

Smoking rooms Cigar or pipe smoke, which does come from fire, cannot be differentiated from other fires by a smoke detector.

In all rooms, there are certain points that must be noted when mounting a smoke alarm.

Site Description

Ceilingmount Mount the smoke alarm on the ceiling in a central position.

IMPORTANT: Areas in which there is no air circulation should be avoided, e.g. in the vicinity of window sills, curtains, furniture, etc. A minimum distance of 30 cm should be maintained. The smoke alarm should be mounted at least 30 cm from walls and corners. These hinder smoke movement and in the case of fire, the alarm only sounds when the smoke concentration is very high.

Mounting near ceiling lamps (e.g. halogen systems, fluorescent lamps) especially those

BR 1201 Operating Instructions

with a dimmer function, is also to be avoided.

30 mm

Roof peak In areas with sloping and

peaked roofs, the smoke alarm must be mounted 90 cm from the highest peak, since air does not move in the slope/point. This results in the smoke being detected too late.

90 cm 60 cm Smoke

NOTE:

Mounting on a roof beam is ideal.

Installation and set-up of smoke alarm

NOTE: The enclosed mounting equipment is suitable for concrete slabs. For other subsurfaces, suitable mounting equipment should be purchased from a specialty shop.

Operating Instructions BR 1201

NOTE: An alarm can simply be stopped by removing the battery from the battery clip. The smoke alarm is powered by a battery and needs no other electrical power supply.

Changing / inserting batteries Action Description

Removing housing To take out a battery, the housing must be turned counterclockwise. The housing can then be removed and the battery is freely accessible.

Removing the Remove the battery from the old battery battery compartment. Remove the battery clip from the battery terminals.

Connect the IMPORTANT: The correct poles new battery of the battery must be connected to the smoke detector's battery clip.

Insert battery Insert the connected battery in the battery compartment.

BR 1201 Operating Instructions

Function check/test Action Description

Performing IMPORTANT: The function test function test should be performed weekly.

For the function test, press the button for 10 seconds. A loud pulsating alarm should sound, which should then fall silent when the button is released. The LED should blink rapidly during the functiontests.

Description Funktion

Function button Press to perform a function test.

LED Signals operational readiness

Maintenance

The smoke alarm is largely maintenance free except for changing the battery. When a tone starts sounding once every minute, the battery is nearly dead and needs to be replaced immediately.

This warning continues for a period of 7 days before the battery is completely discharged.

After this, there is no more power supply.

Operating Instructions BR 1201

WARNUNG: If the LED doesn't blink once per minute, this indicates the battery is completely empty.

IMPORTANT: After changing the battery, a function test should be performed.

Replacement date:

Smoke detectors should be replaced every 10 years.

Escape plan

It is recommended that all residents of a building collaborate on an escape plan. Think carefully about an escape route that will under no circum stances be blocked during a fire.

This should be both the fastest and safest route into the open.

Cleaning

The smoke detector should be regularly cleaned of dust. This can be done with a vacuum cleaner.

Vacuum all sides of the smoke detector. The product must be cleaned with a dry, lint-free cloth.

Do not use abrasive cleaners or chemicals (solvents, gasoline, etc.).

BR 1201 Operating Instructions

Disposal

When this product has reached the end of its operational lifetime, it cannot be disposed of in the regular household waste. This product must be taken to a collection site for the processing of electrical and electronic devices for disposal. Inquire with your city or municipal government about options for the environmentally sound and proper disposal of the product.

At the end of their operational life, batteries must be dropped off free of charge at the collection sites in your city or township or in a battery specialty shop.

Guarantee and Service

We grant a 3 year guarantee on this article. Repairs must be done by authorised dealers.

Damages from improper use, disregarding the operating instructions and parts subject to wear are excluded from the guarantee.

Operating Instructions BR 1201

Service address:

For further information please see our

Service/FAQ section at www.brennenstuhl.com

Declaration of Conformity

The CE-label was affixed in compliance with the following In European guidelines:

2004/108/EG EMV-guideline

Manufacturer:
