USER MANUAL DO 7047 S DOMO

Close-up of a pink and white electric iron with visible branding (no text or symbols on the iron itself)

GARANTIEVOORWAARDEN

CONDITIONS DE GARANTIE

This appliance has a two year warranty period. During this period the manufacturer is responsible for any failures which are the direct result of construction failure. When these failures occur the appliance will be repaired or replaced if necessary. The warranty will not be valid when the damage to the appliance is caused by wrong use, not following the instructions or repairs executed by a third party. The warranty will only be valid if the warranty application has been completed by the dealer at the time of purchase. All parts, which are subject to wear, are excluded from the warranty.

Type nr. Apparaat

RECYCLING INFORMATIONEN

RECYCLING INFORMATION

The symbol ☒ on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall be brought to the applicable collection point for recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling of this product, please contact your local city office, your household waste disposal service or the shop where you purchased the product.

INFORMACE O RECYKLACI ODPADU

If the supply cord is damaged, it must be replaced by manufacturer of its service agent or a similarly qualified person in order to avoid a hazard.

Technical diagram of a steam iron with numbered parts for identification

Line drawing of a boat with a person on top, accompanied by a geometric shape (no text or symbols)

Strijken met stoom

Line drawing of a steam iron (no text or symbols)

Technical diagram of a steam iron with numbered parts for identification

Illustration of a person riding a boat with a triangular shape nearby (no text or symbols)

Repassage à vapeur

Line drawing of a steam iron with visible steamers and handle (no text or symbols)

Technical diagram of a steam iron with numbered parts for identification

Simple line drawing of a boat on a speedboat with a triangular shape nearby (no text or symbols)

Line drawing of a steam iron with visible steam drop and handle (no text or symbols)

Technical diagram of a steam iron with numbered parts for identification

1. Soleplate

2. Side

3. Side cover

4. Water reservoir

5. Spray opening

6. Water filling opening

7. Steam control button

8. Steam shot button

9. Spray button

10. Lead protection

11. Power supply lead

12. Back

13. Housing

14. Indication lamp

15. Temperature dial

16. Self-cleansing button

IMPORTANT

Carefully read these instructions before using the iron. Save the manual, so that you can refer to it later.

This appliance is suitable for use in the household and in similar areas, such as:

- Personnel's kitchen corner in shops, offices and similar professional places.

- Farms.

• Hotel and motel rooms and other areas with a residential character.

- Guest rooms or similar.

Take care: the appliance cannot be used with an external timer or a separate remote control.

This appliance is not for use by children or persons with a physical, sensorial or mental impairment. Also people with limited experience or knowledge are not permitted to use this appliance unless they have received the necessary instructions or are supervised by a person taking responsibility for their safety.

Make sure that children cannot play with the appliance.

BEFORE USING

Check whether or not the mains voltage specified on the appliance's rating plate corresponds with the mains power supply.

Fully unroll the electric lead before use.

Place the appliance on a sturdy, even surface or ironing board.

Never immerse the appliance in water or any other liquid.

The iron must always be set to ‘MIN’ before you place or remove the plug from the socket.

Wait until the iron has cooled off completely before putting it away.

Never pull on the mains lead, always gold the plug itself.

To prevent overloading the fuse, never plug another appliance with an equal mains voltage into the same electrical fuse group.

SAFETY INSTRUCTIONS

This appliance produces steam with a high temperature. Always take great care when handling the appliance and warn others of the possible danger.

Only use the appliance for its intended purpose.

Make sure the electric lead does not come into contact with the (hot) metal soleplate of the iron.

Always remove the plug from the socket before (re) filling the iron with water or when you are not using it.

Do not attempt to repair the appliance yourself.

If the electric lead is damaged it must be repaired or replaced by the manufacturer or by its after sales service centre or by a qualified person, in order to prevent all risk of accidents.

Take good care if turning the appliance upside down; you can suffer burns through the hot water in the reservoir, escaping steam or through touching the iron underneath.

If the iron is not functioning correctly, remove the plug immediately from the mains socket and allow the appliance to be checked by the manufacturer, its service point or a similarly qualified person.

Your iron has been designed for placing in a vertical position resting on its back end when not in use. Never leave the iron unattended when plugged in. Never place the iron on an unprotected surface, this includes in the vertical position resting on its back end.

USING THE IRON THE FIRST TIME

Remove the plastic protecting the soleplate (if it is present) and clean the soleplate with a soft non-abrasive cloth.

Some parts of the iron have been lightly greased, that will cause the iron to emit a slight odour and a little bit of smoke when first used. This is normal and will not take place again.

Keep the soleplate smooth and avoid scratches. Do not iron over metal surfaces with the soleplate: the edge of the ironing board, buttons or zips.

Temperature choice

Check the ironing instructions on the clothing you want to iron.

If a piece of clothing does not have a label with ironing instructions, but you are familiar with the material, you can then make use of the overview here below (fig B).

Material with a special shiny layer or other extra finishes must be ironed using the lowest temperature.

If your item of clothing consists of several types of fabric always use the lowest temperature corresponding to the type of fabric you have. A piece of clothing, for

example, 60% polyester and 40% cotton must be ironed using the temperature settings for polyester without steam (fig B).

Take care to sort your washing out properly, checking the type of material

Fig. B

• Nylon and acetate
  • Wool, silk and combined materials
  ••• Cotton and linen (with steam)

and selecting the correct temperature needed for ironing. Start with the items of clothing that require a low temperature and finish of with the washing requiring the highest temperature(s).

Wool and other delicate materials such as silk, velvet, etc. are best ironed using an ironing cloth in order to prevent damage to the material.

Filling the water reservoir

Remove the plug from the mains socket.

Adjust the steam-generating dial to the setting without steam (0).

Fill the water reservoir through the opening (fig 2) to the maximum level MAX.

If you live in an area with hard water it is advisable to use demineralised or distilled water. Do not use any chemically modified or perfumed water. Never store the iron with if its reservoir is full.

Simple line drawing of a boat with a person on the side and a triangular shape nearby (no text or symbols)

Steam ironing

Fill the iron as described.

Plug the appliance into the mains socket.

Steam ironing is only possible if the highest temperature is set: ( ·s ).

If you select a lower temperature the water supply will be automatically shut off by the drip-stop so that no water is able to escape via the soleplate.

Wait until the indicator lamp goes out, that means the selected temperature has been reached. Adjust the steam adjustment dial to the desired setting.

In between ironing and when you have finished ironing your clothing place the iron in an upright position resting on its back end.

After ironing remove the plug from the mains socket, pour the remaining water out of the reservoir and leave the iron to cool off in a vertical position.

Spraying

The spray button can be used at all times, with or without steam ironing, as long as the water reservoir is filled up. When using the spray button for the first time press it in repeatedly in order to activate it.

Steam shot

Through means of the steam shot you can remove tough creases.

Adjust the temperature dial to MAX (fig 3) and wait until the indicator lamp goes out.

Press on the stem shot button. Wait a few seconds so the steam penetrates the material before pressing again.

Line drawing of a steam iron with car body and handle (no text or symbols)

Please Note: Do not use the steam shot more than three times in a row so that the best quality steam is achieved.

Repetitive use of the steam shot function will lower the

iron's heat. For this reason, always pay attention to the temperature indicator lamp before and after using this function.

ERROR MESSAGES AND SOLUTIONS

The iron does not warm up.

The temperature dial must be set to the correct temperature. Adjust the setting to a higher temperature than MIN.

The iron fails to provide steam

The water reservoir is empty. Adjust the settings on the steam dial to ‘0’ and add water. Allow the iron enough time to warm up and readjust the temperature dial to the position marked steam ironing ( ·s ).

The steam generating function is not working

The water reservoir must be filled to a minimum of one quarter. The temperature dial must be set to steam ironing ( ·s ). The iron must be in a horizontal position.

Press the steam-generating button for a second or two. Allow a short break between each blast of steam. Make sure that you press the steam-generating button in completely.

Spray function is not working

The water reservoir must be filled to a minimum of one quarter. For further information please see: ‘Filling the water reservoir’.

POPIS ŽEHLIČKY

S ŽEHLIČKY

Illustration of a person on a boat with a triangular shape nearby (no text or symbols)

ŽEHLENÍ PÁROU

Line drawing of an iron iron (no text or symbols)
