DR-MH20SEF - DVD/HDD Recorder JVC - Free user manual and instructions

Product Type	DVD/HDD Recorder
Brand	JVC
Model	DR-MH20SEF
Dimensions (W x H x D)	435 mm x 70 mm x 345.5 mm
Weight	6.1 kg
Power Supply	AC 220-240 V, 50/60 Hz
Power Consumption (Operation)	37 W
Power Consumption (Standby)	19.3 W
Hard Disk Capacity	80 GB
Compatible Disc Formats	DVD-RAM, DVD-RW, DVD-R, DVD Video, Audio CD, Video CD, SVCD, MP3, JPEG
Recording Time (Hard Disk)	XP: approx. 18 h, SP: approx. 35 h, LP: approx. 70 h, EP: approx. 105 h, FR: up to 147 h
Recording Time (DVD 4.7 GB)	XP: 1 h, SP: 2 h, LP: 4 h, EP: 6 h, FR: 1 to 8 h
Audio Recording System	Dolby Digital (2 channels), Linear PCM (XP mode)
Video Compression System	MPEG2 (CBR/VBR)
Input Connectors	Antenna (ANTENNA IN), L-1 (21-pin), L-2 (21-pin/decoder), DV (i.Link), S-Video, Composite Video, Audio (L/R)
Output Connectors	Antenna (ANTENNA OUT), L-1 (21-pin), S-Video, Component Video (Y, Pb/Cb, Pr/Cr), Audio (L/R), Digital Audio (optical/coaxial)
Special Features	SHOWVIEW System, Timer Recording, Library Navigation, editing (copy, edit), Live Memory playback, satellite control
Supplied Accessories	RF cable, SCART 21-pin cable, satellite controller, infrared remote control, R6 batteries x2
Maintenance and Cleaning	Clean the casing with a soft dry cloth. For discs, wipe from the center outward with a soft cloth. Do not use solvents.
Safety	Unplug the device during prolonged non-use. Do not expose to moisture or heat sources. Use on a stable, horizontal surface.
Spare Parts and Repairability	For repairs, contact qualified personnel. Spare parts are available from authorized JVC service centers.
General Information	Combined DVD recorder and hard disk drive. Allows recording and playback of various media. Equipped with PAL/SECAM TV tuner.

Frequently Asked Questions - DR-MH20SEF JVC

What types of discs can I use with the JVC DR-MH20SEF?

You can use the following discs: DVD-RAM (version 2.0/2.1), DVD-RW (Video or VR mode), DVD-R (Video mode), DVD Video, Audio CD, Video CD (VCD), Super Video CD (SVCD), as well as CD-R/RW containing MP3 or JPEG files. Double-layer discs are also compatible.

How to record a TV program using the SHOWVIEW system?

Press the PROGRAMME button, select 'SHOWVIEW', then enter the SHOWVIEW number using the numeric keys. Verify the displayed information and confirm. Ensure that the clock and guide numbers are set correctly.

Why does the timer recording not start?

Check that the clock is set correctly (page 75 of the manual). Make sure the hard disk or DVD is properly inserted and has sufficient space. Also check that no other timer recordings are in conflict.

How to copy recordings from the hard disk to a DVD?

Insert a blank DVD-RAM or DVD-RW. Press DUBBING, select 'HIGH SPEED' or 'SIMPLE COPY' as needed, then choose the titles to copy and confirm. High-speed copying is faster but requires a compatible disc.

What to do if the screen displays 'REGION CODE ERROR'?

This message indicates that the disc's region code does not match the unit's (region code 2). Use a disc whose region code includes '2' or 'ALL' (all regions). See page 7 of the manual for more information.

How to set the menu and subtitle language?

Press SET UP, go to 'DVD VIDEO SET' then 'LANGUAGE SET'. You can select the language for menus, audio, and subtitles. During playback, use the AUDIO and SUBTITLE buttons to change temporarily.

Can I play MP3 or JPEG files on this unit?

Yes, insert a CD-R/RW or CD-ROM containing MP3 or JPEG files in ISO 9660 or Joliet format. Press NAVIGATION, then select 'MP3/JPEG' to browse folders and start playback. Maximum JPEG resolution is 2812 x 2112 pixels.

How to use the 'Live Memory' function?

This function allows you to pause a live broadcast and resume it later. Press LIVE while watching to activate the temporary memory. Use search buttons to navigate in the recording. The maximum duration depends on disk space.

What does the message 'PROGRAMMING CAPACITY REACHED' mean?

You have reached the maximum of 32 timer recordings. To add new ones, delete unnecessary timers via the 'PROGRAMME' menu by selecting 'CANCEL'.

How to maintain the unit and discs?

Clean the casing with a soft, dry cloth. For discs, wipe them from the center outward with a soft cloth; never use solvents. Avoid exposure to sunlight, moisture, and magnetic fields. Ensure adequate ventilation around the unit.

USER MANUAL DR-MH20SEF JVC

D'ÉLECTROCUTION, NE PAS EXPOSER CET

APPAREL À LA PLUIE NI À L'HUMIDITE.

ATTENTION :

CET APPAREIL EST UN PRODUIT LASER DE CLASSE 1.
CEPENDANT, CET APPAREIL UTILISE UN FAISCEAU LASER
VISIBLE QUI POT ENTRAINER UNE EXPOSITION
DANGEREUSE AUX RAYONNEMENTS. S'ASSURER DE
FAIRE FONCTIONNER L'APPAREIL CORRECTEMENT, EN
RESPECTANT LES INSTRUCTIONS.
LORSQUE CET APPAREIL EST BRANCHÉ À UNE PRISE
MURLE, NE PAS PLACER SES YEUX PRÉS DE
L'OUVERTURE DU TIROIR POUR DISQUE OU D'AUTRES
OUVERTURES DANS LE BUT D'OBERVER L'INTÉRIEUR DE
L'APPAREIL.

UN EMPLOI DES COMMANDES, RÉGLAGES OU PROCÉDURES DE PERFORMANCE AUTRE QUE CELUI SPECIFIÉ DANS CE DOCUMENT RISQUE D'ENTRAîNER UNE EXPOSITION DANGEREUSE AUX RAYONNEMENTS. NE PAS OUVRIR NI RÉPARER DE VOUS-MÈME. FAIRE APPEL À UN PERSONNEL QUALIFIÉ POUR L'ENTRETIEN.

IMPORTANT :

PRODUIT LASER DE CLASSE 1

REPRODUCTION DES ETIQUETTES

ÉTIQUETTE D'AVERTISSEMENT A L'INTÉRIEUR DE

L'APPAREIL

CAUTION

VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN. AVOID EXPOSURE TO BEAM. DO NOT STARE INTO BEAM OR VIEW DIRECTLY WITH OPTICAL INSTRUMENTS.

ADVARSEL

SYNLIG OG USYNLIG LASERSTRÄLING VED ÅBNING. UNDGA UDSAETTELSE FOR STRÄLING SE IKKE IND I STRÄLEN - HELLER IKKE MED OPTISKE INSTRUMENTER.

ADVARSEL

SYNLIG OG USYNLIG LASERSTRÁLING Nár DEKSEL ÅPNES. UNDGÅ EKGSPONERING FOR STRÄLEN STIRR IKKE INN I STRÄLEN ELLER SE DIREKTE MED OPTISKE INSTRUMENTER.

VARO!

AVATTAESSA OLET ALTTIINA NAKYVÄÄ JA NAKYMÄTÖN LASERSÄTEILYLLE.
ALÄ TUIJOTA SÄTESEEN ALÄKA KATSO SITA OPTISEN LAITTEEN LÄPI.

WARNING

SYNLIG OCH OSYNLIG LASERSTRALNING NAR DENNA DEL AR ÖPPNAD. STRALEN AR FARLIG STIRRA EJ IN I STRALEN OCH BETRAKTA EJ STRALEN MED OPTISKA INSTRUMENT.

Recadrage/Letter-box

Initialisation (Platine DVD commencement)

COPIE INTERDITE LECTURE IMPOSSIBLE
