IK1101 - Kettle IDEAL - Free user manual and instructions

Brand	IDEAL
Model	IK1101
Product Type	Kettle
Material	Stainless steel and plastic
Color	Silver and black
Capacity	1.7 liters
Power Rating	2200 W
Voltage	220-240 V, 50/60 Hz
Dimensions (W x D x H)	22 x 15 x 15 cm
Weight	1.0 kg
Power Cord Length	0.75 m
Auto Shut-Off	Yes
Boil-Dry Protection	Yes
Water Level Indicator	Yes, with markings
Lid Opening	One-touch button
Spout Filter	Removable mesh filter
Base	360° cordless base
Handle	Ergonomic, cool-touch
Cleaning and Maintenance	Descaling regularly with vinegar or citric acid
Safety Features	Auto shut-off, boil-dry protection, overheat protection
Spare Parts Available	Lid, base, filter
Manual Languages	English, Polish

Frequently Asked Questions - IK1101 IDEAL

How do I descale the kettle?

Mix equal parts water and white vinegar or use a descaling solution. Fill the kettle halfway, boil, let sit for 30 minutes, then rinse thoroughly. Repeat if needed. Regular descaling prolongs the kettle's life.

What is the capacity of the IK1101?

The kettle has a capacity of 1.7 liters, suitable for boiling up to 6-7 cups of water at once.

Can I boil less than the minimum water level?

No, always fill above the minimum level indicator to prevent boil-dry damage. The minimum is typically around 0.5 liters.

How do I clean the spout filter?

The filter is removable. Gently pull it out, rinse under running water, and use a soft brush if needed. Reattach after cleaning. Replace if damaged.

What does the auto shut-off feature do?

The kettle automatically turns off when the water reaches a full boil, saving energy and preventing overheating. It also shuts off if switched on empty (boil-dry protection).

Is the kettle cordless?

Yes, the kettle lifts off the 360° swivel base for easy pouring and returning. The base connects to the power outlet.

Can I boil milk or other liquids?

No, this kettle is designed for water only. Boiling milk or other liquids can damage the heating element and create safety hazards.

What safety precautions should I take?

Keep the kettle out of reach of children. Do not operate with wet hands. Do not immerse the base in water. Unplug when not in use. Use only with the original base.

How do I remove stubborn limescale?

For heavy limescale, use a commercial descaling product or a solution of citric acid (1 tablespoon per liter of water). Boil, let soak, then rinse thoroughly.

Where can I find spare parts?

Contact IDEAL customer service or authorized dealers. Common spares include the lid, base, and filter. Check the manual for part numbers.

USER MANUAL IK1101 IDEAL

Line drawing of a modern kettle with lid and side handle (no text or symbols)

Eldom Sp. z o.o. • ul. Pawła Chromika 5a • 40-238 Katowice, POLAND tel: [phone] • fax: [phone] • www.eldom.eu

_

| _

一

1

/EN/ The disposal of used electrical and electronic equipment (applies to European Union countries and other European countries with separate waste-collection systems).

This symbol on the product or its packaging indicates that it should not be classified as household waste. It should be handed over to an appropriate company dealing with the collection and recycling of electrical and electronic equipment. The correct disposal of the product will prevent potential negative consequences for the environment and human health resulting from hazardous substances present in the product. Electrical devices must be handed over to restrict their re-use and further treatment. If the device contains batte ries, remove them, and hand them over to a storage point separately. DO NOT THROW EQUIPMENT INTO THE MUNICIPAL WASTE BIN. Material recycling helps to preserve natural resources. For detailed information on how to recycle this product, please contact your local authority, the recycling company, or the shop where you bought it.

INSTRUKCJE DOTYCZĄCE BEZPIECZEŃSTWA

Before first use, please thoroughly read the entire manual. It is recommended to keep this instructions manual for future reference.

1. Connect the kettle only to a suitably earthed socket compatible with the parameters indicated in the instructions.
2. The appliance should be placed on a stable and dry surface.
3. Before operating, make sure that there is water inside the kettle.
4. You should not switch the kettle on when empty.
5. You must not exceed the maximum water level mark. Filling over the maximum mark on the exterior of the kettle may result in the boiling water splashing out from the kettle (which may result in a short-circuit).
6. The device can be used by children aged 8 and older and by persons with limited physical, sensory or mental capabilities, or persons without sufficient experience and knowledge only under supervision or if previously instructed on the safe use of the appliance and the possible risks. Children shall not play with the appliance.
7. Cleaning and maintenance that are the responsibility of the user shall not be carried out by children without supervision. Protect the appliance and the power cord against children under 8 years old.
8. Do not leave the kettle unattended when in use, when plugged-in or containing hot water, the kettle may expose children to hazard, if left unattended.
9. Never immerse the kettle in water while washing-up.
10. You should be cautious about the steam coming from the kettle during the heating process.
11. The appliance is made of materials which can be recycled.

12. It should be handed over to the applicable collection point for the recycling of electrical and electronic equipment.

13. This appliance is designed for domestic use only; when used for industrial purposes outside the product's specifications, or used not in accordance with the instructions, no liability is assumed and the warranty is nullified.

14. The company Eldom sp. z o. o. shall bear no responsibility for any possible damages resulting from the improper usage of the appliance.

WARNING: Improper use of the appliance may cause injury

WARNING: Plastic bag can be dangerous, to avoid danger of suffocation keep this bag away from babies and children.

ENVIRONMENTAL PROTECTION

• The appliance is made of materials which can be recycled.
• It should be handed over to the applicable collection point for the recycling of electrical and electronic equipment.

WARRANTY

• This appliance is designed for domestic use only.
  – It cannot be used for professional purposes or for other than the intended use.
• Improper use will nullify the guarantee.

EN

1. Spout Spout
2. Opening lid
3. Lid release handle
4. On/off switch
5. Handle
6. Water level indicator
7. Base
8. Glass body with LED light

TECHNICAL DATA

• power: 1500W
• mains voltage: 220-240V\~ 50-60Hz
• 1.8 litre capacity

2 1 8 5 MAX 1.8L 1.5L 1.0L 0.5L MIN 6 7

Cordless kettle IK1101 is for boiling water. It is possible to boil 0.5 – 1.8 litre of water in the kettle.

The kettle base (7) must be put on a flat and dry surface. In the base there is some space for an excess cord. It is important for the cord to be led from the base (7) through a special groove so that the appliance could be stable.

Before using the kettle for the first time fill it up (2-3 times) with water, boil the water and then empty the kettle.

The kettle can be filled with water directly through the spout (1) or after opening the lid (2). Open the cover using the handle (3). The lid should be closed by pressing until you hear it snapp. The kettle must not be filled up when on the base. The minimum level of boiling water is 0.5 l. The maximum water level (1.8 l) is marked on the indicator (6). The kettle starts working after putting the switch (4) in the position 'l'. Operation of the device is indicated by illumination of the tank (8). The kettle switches off automatically after the water has boiled. You can stop heating water at any time by putting the switch (4) in the position '0'.

CLEANING AND MAINTENANCE

• Allow the unit to cool down completely before cleaning.
• Do not immerse the kettle in water while washing up.
• The outside of the kettle may be wiped over with a damp cloth and washing-up liquid.
• Water stains inside the kettle can be removed by rubbing with a cloth moisten with white vinegar; rinse the inside with water afterwards.

• Limescale should be removed in the following way:

• Fill the kettle with 0.5 litre of water and bring it to boil.

• Switch the kettle off and disconnect the kettle from the power supply.
• Pour 0.1 litre of white vinegar into the kettle.
• Allow to stand overnight.
• Discard the solution and rinse the inside with water.
• Fill the kettle with 1 litre of water and bring to boil.
• Discard the water and rinse the inside with water.

If the scale is persistent, the cleaning should be done in the following way:

• fill the kettle with 0.5 litre of white vinegar.
• Bring the vinegar to boil and leave the hot solution inside the kettle for about 30 minutes.
• Bring the vinegar to boil again.
• Discard the vinegar and rinse the inside with water.
• Fill the kettle with 1.0 litre of water and bring it to boil.

• Discard the water and rinse the inside with water.

• No timely removal of the scale from the heating element results in the heating element's quicker wear.

• Any damage resulting from applying harsh descalling products available in the market are not covered by the producer's warranty.
• If the power cord is damaged, it can be replaced only by an especially constructed one (with appropriate plugs and endings).

ideal
