Product type	Dry iron (manual iron)
Brand	Beko
Model	DIM 6104 B
Power supply	220-240 V~, 50/60 Hz
Power consumption	400 W
Insulation class	I
Soleplate material	Smooth non-stick coating (stainless steel base)
Temperature control	Adjustable thermostat with fabric settings
Temperature settings	Synthetic, Silk, Wool, Cotton, Linen/Jean
Heating indicator	Indicator light (turns off when ready)
Cord type	Standard power cord (approx. 2 m)
Weight	Approx. 1.5 kg
Dimensions (approx.)	30 x 12 x 15 cm
Intended use	Household ironing of garments and textiles
Cleaning instructions	Wipe soleplate with damp cloth; use mild liquid cleaner if needed
Storage	Cool, dry place; out of reach of children
Safety features	Complies with international safety standards; do not leave unattended
Warranty	Standard manufacturer warranty (see manual for details)
Environmental compliance	WEEE, RoHS compliant; recyclable packaging
First use note	Slight smoke and odor normal; burn off oils for 10 minutes
Repair	Only authorized service center; do not open

Frequently Asked Questions - DIM 6104 B BEKO

What type of iron is the Beko DIM 6104 B?

It is a dry iron (no steam function) designed for household use.

Why does the iron smoke or smell when first used?

During first use, the iron may emit smoke and odor due to burning off of manufacturing oils. This is normal and should stop after about 10 minutes.

How do I select the correct temperature for a fabric?

Use the temperature adjustment button and refer to the fabric guide on the iron. Start with low settings for synthetics, then increase for silk, wool, cotton, and finally linen/jean. If unsure, test on an inconspicuous area.

Can I use the iron on delicate fabrics like silk?

Yes, but set the temperature to the lowest setting (synthetic) and iron on the reverse side to prevent shiny marks.

What should I do if the iron does not heat up?

Ensure the iron is plugged into a 220-240 V AC outlet and the temperature dial is turned to a desired setting. If it still doesn't heat, contact an authorized service center.

How do I clean the soleplate?

Unplug and let cool. Wipe the soleplate with a slightly damp cloth. For stubborn residue, use a soft, non-abrasive liquid cleaner. Do not use harsh chemicals or scrubbers.

What safety precautions should I take?

Never leave the iron unattended while plugged in. Keep out of reach of children under 8. Do not use near water or flammable materials. Unplug before cleaning.

Can I use an extension cord?

No, the manual advises against using an extension cord. Plug directly into a grounded outlet with a minimum 16 A fuse.

How should I store the iron?

Allow it to cool completely. Store in a cool, dry place, ideally in its original packaging, out of reach of children. Do not wrap the cord around the iron.

Is the iron repairable?

If damaged, do not attempt to repair yourself. The iron must be taken to an authorized service center. Do not replace the cord yourself.

USER MANUAL DIM 6104 B BEKO

Line drawing of a steam iron with a circular vent and side handle (no text or symbols)

BAHASA INDONESIA 16-26

Line drawing of a hand using a cloth to clean or wear a garment, with no text or symbols present.

Line drawing of an iron (£) with a wall-mounted power outlet and a red arrow indicating direction (no text or symbols)

Line drawing of a steam iron on a bed (no text or symbols)

Line drawing of an iron (£) with a wall socket and a red arrow pointing to it (no text or symbols)

Line drawing of an iron (£) with a red arrow pointing to a wall-mounted electrical outlet (no text or symbols)

Line drawing of a hand using a power tool to clean or fabric the iron, with no text or symbols present.

EN	OPERATION CLEANING AND CARE
ID	PENGOPERASIAN PENANGANAN DAN PENGANGKUTAN

Please read this user manual first!

Dear Customers,

Thank you for selecting a Beko product. We hope that you get the best results from your product which has been manufactured with high quality and state-of-the-art technology. Therefore, please read this entire user manual and all other accompanying documents carefully before using the product and keep it as a reference for future use. If you handover the product to someone else, give the user manual as well. Follow all warnings and information in the user manual.

Meanings of the symbols

Following symbols are used in the various section of this manual:

Important information and useful hints about usage.

WARNING: Warnings for dangerous situations concerning the safety of life and property.

WARNING: Warning for hot surfaces.

This product has been produced in environmentally-friendly, state-of-the-art facilities.

1. Power cable
2. Iron base plate
3. Indicator light
4. Temperature adjustment button
5. Soleplate

Technical data

	DIM 4504 P DIM	M 6104 B
Power supply	220-240 V~, 50/60 Hz
Power	400 W
Insulation class	I

Technical and design modification rights are reserved.

The values which are declared in the markings affixed on your appliance or the other printed documents supplied with it represent the values which were obtained in the laboratories pursuant to the pertinent standards. These values may vary according to the usage of the appliance and ambient conditions.

1 Important safety and environmental instructions

This section contains safety instructions that will help protect from risk of personal injury or material damage.

Failure to follow these instructions invalidates the granted warranty.

1.1 General safety

•This appliance complies with the international safety standards.
•This appliance is intended to be used in household and similar applications such as:

• Staff kitchen areas in shops, offices and other working environments;
• Farm houses;
• By clients in hotels, motels and other residential type environments;
• Bed and Breakfast type environments
• It is not fit for industrial use.

1 Important safety and environmental instructions

This appliance can be used by children who are at the age of 8 and above and by people who have reduced physical, perceptual or mental abilities or by people who are deficient in terms of experience and knowledge as long as they are supervised and given the instructions regarding the safe use of the appliance and dangers encountered. Children should not play with the appliance. Cleaning and user maintenance procedures should not be performed by children unless they are supervised by an older person.

• Do not leave the product unattended while it is plugged in.
  Operate and store the appliance on a stable surface.
  When the appliance is placed on its base plate, ensure that the surface beneath the plate is level.
• Do not use the appliance if the power cable or the appliance itself is damaged. Contact an authorised service.

1 Important safety and environmental instructions

•The iron is not to be used if it has been dropped and if there are visible signs of damage.
When the appliance is not in use or left to cool down keep the appliance and power cable out of reach of children under 8 years old.
•The appliance is not suitable for using outdoors.
Only use the original parts or parts recommended by the manufacturer.
Do not attempt to dismantle the appliance.
- Your mains power supply should comply with the information supplied on the rating plate of the appliance.
•The mains supply of the appliance must be secured with a minimum 16 A fuse.
Use the appliance with a grounded outlet only.
- Do not use the appliance with an extension cord.
- Do not pull the power cable when unplugging the appliance.
Unplug the appliance before cleaning it.

1 Important safety and environmental instructions

Do not wrap the cable around the appliance.
- Do not touch the appliance or its plug with wet or damp hands when the appliance is plugged in.
•The soleplate and its surrounding area can be extremely hot. Contacting hot surfaces may cause burns. Therefore while or just after using the appliance, pay attention not to touch the hot surfaces.
- Never use the appliance in or near to combustible or inflammable places and materials.
If you keep the packaging materials, store them out of the reach of children.

1 Important safety and environmental instructions

1.2 Compliance with WEEE Directive and Disposing of the Waste Product

This product complies with EU WEEE Directive (2012/19/EU). This product bears a classification symbol for waste electrical and electronic equipment (WEEE).

This symbol indicates that this product shall not be disposed with other household wastes at the end of its service life. Used device must be returned to offical collection point for recycling of electrical and electronic devices. To find these collection systems please contact to your local authorities or retailer where the product was purchased. Each household performs important role in recovering and recycling of old appliance. Appropriate disposal of used appliance helps prevent potential negative consequences for the environment and human health.

1.3 Compliance with RoHS Directive

The product you have purchased complies with EU RoHS Directive (2011/65/EU). It does not contain harmful and prohibited materials specified in the Directive.

1.4 Package Information

Packaging materials of the product are manufactured from recyclable materials in accordance with our National Environment Regulations. Do not dispose of the packaging materials together with the domestic or other wastes. Take them to the packaging material collection points designated by the local authorities.

2 Operation

2.1 Intended use

This appliance is intended only for household use, removing the creases on your clothes and for various textile products including curtains; it is not suitable for professional use.

2.2 Before first use

When using the iron for the first time, you may notice a slight emission of smoke and hear some sounds made by the expanding plastics. This is quite normal and it stops after a short time.

• We also recommend passing the iron over an ordinary cloth before using it for the first time.
- Certain parts of the iron have been lightly greased therefore the iron could give off a little smoke when plugged in for the first time. This will cease after a short while.
- Before using the iron for the first time, remove the plastic protector from the base (if it has one), and clean the base with a soft cloth.
- Keep the base very smooth. Do not run it over metal objects (such as against the ironing board, buttons, zips, etc.)

2.3 Selecting the temperature

- Check the ironing instructions on the garment to be ironed.

• If the garment does not have any ironing instructions, but you know the kind of fabric in question, use the chart below.
• Fabrics that have some kind of finish (polishing, wrinkles, contrasts, etc.) can be ironed at the lowest temperature.

2 Operation

• If the fabric contains several kinds of fibres, always select the lowest temperature that is safe for all of the fibres in the garment. If an article contains 60% polyester and 40% cotton, you must always choose the temperature corresponding to polyester, which is for “Synthetic” fabric type.
• Start by ironing the articles requiring the lowest temperature such as those made of synthetic fibres. Progress towards those that require the highest temperatures as the iron does not cool down as fast as it heats up.

2.4 Temperature and steam settings table

When setting the temperature of the appliance, consider the following table.

Fabric Type Temperature Setting
Synthetic	●
Silk	●
Woolen	●●
Cotton	●●●
Linen - Jean	Max

• If you don't know the fabric of your garment, first iron an invisible part of your garment and determine a correct ironing temperature for it.
• In order to prevent the bright stains that may form on the synthetic fabrics such as silk, iron on the reverse side of the fabric.

3 Cleaning and maintenance

3.1 Cleaning and care

- When you are finished with ironing, unplug the appliance.

• Never use gasoline, solvent and abrasive cleaning agents or hard brush to clean this appliance.
• Do not attempt to disassemble the appliance.
• Wipe the sediments and residues on the soleplate (4) with a slightly damp cloth and soft, nonabrasive liquid cleaner as necessary.
• Wipe outer surfaces with a damp cloth.
• Avoid operating the appliance in humid or moist places.
• Do not locate the appliance near a heat source or direct sunlight.

3.2 Storage

If you do not intend to use the appliance for a long time, store it carefully.

• Before lifting the appliance unplug it and then let it cool completely.
• Keep the appliance and its accessories in their original packages.

- Store it in a cool, dry place.

• Always keep the appliance out of the reach of children.

3.3 Handling and transportation

• During handling and transportation, carry the appliance in its original packaging. The packaging of the appliance protects it against physical damages.
• Do not place heavy loads on the appliance or the packaging. The appliance may be damaged.
• Dropping the appliance will render it non-operational or cause permanent damage.

4 Troubleshooting

4.1 Defects and repairs

Do not attempt to replace a damaged power cord. The appliance has to be returned to an authorized service centre for repair.

Problem Possible solution
Iron emits an odor or smoke	Iron gives off an odor when turned on for the first time. Oils used during manufacture need to be burnt off, allow ten minutes for odor to disappear.
Iron does not heat	The iron should be plugged into a 230 Volt, AC electrical outlet only. The temperature dial must be set to the desired temperature.

For commissioning, general use and cleaning, please observe the instructions on page 4 of this operating manual.
