Product type	Electric griddle
Brand	Vivax
Model	PM-1200TB
Power consumption	1200 W
Voltage	220-240 V
Frequency	50/60 Hz
Cooking surface diameter	30 cm
Weight	2.2 kg
Non-stick coating	Yes
Adjustable temperature	Yes, with thermostat
Indicator light	Power and ready light
Cool-touch handle	Yes
Base material	Aluminum
Heating element	Embedded tubular
Cord length	1.0 m
Cleaning	Wipe with damp cloth, do not immerse
Safety features	Overheat protection
Warranty	2 years

Frequently Asked Questions - PM-1200TB Vivax

How do I use the griddle for the first time?

Remove all packaging, wipe the surface with a damp cloth, and heat it empty for 5 minutes to burn off any residues. Let it cool, then wipe again before cooking.

What is the maximum temperature?

The adjustable thermostat allows temperatures up to approximately 200°C, ideal for crepes, pancakes, and eggs.

Can I use metal utensils on the non-stick surface?

No, use only plastic, silicone, or wooden utensils to avoid scratching the non-stick coating.

How do I clean the griddle?

Unplug and let it cool completely. Wipe with a soft, damp cloth. Do not immerse in water or use abrasive cleaners.

Does it have an automatic shut-off?

No, it does not have an auto shut-off. You must unplug after use.

What foods can I cook on this griddle?

It is suitable for crepes, pancakes, eggs, bacon, grilled sandwiches, and flatbreads.

Is the handle heat-resistant?

Yes, the handle is designed to stay cool to the touch during normal use.

Can I use the griddle on an induction stove?

No, this is a standalone electric appliance with its own heating element, not for use on cooktops.

What is the warranty period?

Vivax offers a 2-year warranty against manufacturing defects.

Where can I find the model number?

The model number is printed on the rating label located on the underside of the griddle.

USER MANUAL PM-1200TB Vivax

Line drawing of a circular mechanical component with a central knob and three small holes (no text or symbols)

220-240V\~, 50/60Hz, 1200W, Class I

Važno je da prije uporabe uređaja u potpunosti pročitate ove upute te ih sačuvate na sigurnom mjestu za buduću potrebu.

DOBRODOŠLI!

Ovaj uređaj zadovoljava najviše standarde, inovativnu tehnologiju i visoku udobnost i učinkovitost korištenja.

VAŽNA UPOZORENJA I SIGURNOSNE UPUTE

Munja sa simbolom strelice unutar jednakostraničnog trokuta upozorava korisnika na prisutnost opasnog i neizoliranog napona unutar proizvoda koji može biti dovoljno snažan da predstavlja opasnost od strujnog udara.

Uskličnik unutar jednakostraničnog trokuta upozorava korisnika na prisutnost važnih uputa za uporabu i održavanje u dokumentu priloženom uz proizvod.

OPREZ

OPASNOST OD STRUJNOG UDARA NE OTVARATI

Ne skidajte poklopac uređaja. Ni u kojem slučaju korisniku nije dozvoljeno da provodi bilo kakve radnje popravka ili prepravke uređaja. Prepustite taj posao kvalificiranom ovlaštenom serviseru.

SIGURNOSNE MJERE OPREZA

Line drawing of a circular mechanical component with mounting holes and a central knob (no text or symbols)

220-240V\~, 50/60Hz, 1200W, Class I

VAŽNA UPOZORENJA I SIGURNOSNA UPUTSTVA

Simbol - munja unutar jednakostraničnog trougla upozorava korisnika na prisustvo opasnog napona unutar proizvoda, koji može da bude dovoljno snažan da predstavlja opasnost od strujnog udara.

Uzvičnik unutar jednakostraničnog trougla upozorava korisnika da postoje važna uputstva za upotrebu i održavanje u (ovom) dokumentu, priloženom uz proizvod.

OPREZ

OPASNOST OD STRUJNOG UDARA! NE OTVARATI!

Line drawing of a cylindrical appliance with a circular top and side ports (no text or symbols)

220-240V\~, 50/60Hz, 1200W, Class I

ВНИМАНИЕ

Тролла површина

Rm.1503A,15/F,Shun Kwong Commercial Bldg.,No.8 Des Voeux Road West,Sheu Wan,Hong Kong

member of M SAN Grupa

KOMPANI

Rm.1503A,15/F,Shun Kwong Commercial Bldg.,No.8 Des Voeux Road West,Sheu Wan,Hong Kong

Subjekti i deklaratës:

Produkt: PRODHUES E PETULLAVE

member of M SAN Grupa

KOMPANI

Line drawing of a cylindrical device with a central knob and two small circular ports (no text or symbols)

220-240V\~, 50/60Hz, 1200W, Class I

Galeta të shijshme me miell hikërror (Buckwheat flour savoury galettes):

Line drawing of a cylindrical appliance with a central knob and three small circular ports (no text or symbols)

220-240V\~, 50/60Hz, 1200W, Class I

Line drawing of a cylindrical appliance with a circular top and side ports (no text or symbols)

220-240V\~, 50/60Hz, 1200W, Class I

It is important that you read these instructions before using your product and we strongly recommend that you keep them in a safe place for future reference.

WELCOME!

This device meets the highest standards, innovative technology and high comfort use.

Read these instructions carefully before using your new unit, and keep it carefully.

If you follow the instructions, your new appliances will provide you with many years of good service.

READ CAREFULLY THIS MANUAL AND KEEP THEM FOR FUTURE REFERENCE!

IF YOU SELL OR TRANSFER DEVICE TO OTHER PEOPLE, BE SURE TO INCLUDE THESE INSTRUCTIONS!

IMPORTANT SAFETY INSTRUCTIONS WARNING

The flash with the symbol of arrowhead, inside an equilateral triangle alerts the user about the presence of a dangerous tension not isolated inside the product which can be sufficiently powerful to constitute a risk of electrocution.

The point of exclamation inside an equilateral triangle alerts the user about the presence of important operating instructions and maintenance in the document enclosed in the package.

CAUTION

RISK OF ELECTRIC SHOCK DO NOT OPEN

Do not open the cover. In no case the user is allowed to operate inside the unit. Only a qualified technician from the manufacture is entitled to operate. By ignoring the safety instructions, the manufacturer cannot be hold responsible for the damage.

SAFETY PRECAUTIONS

1. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction.
2. Children being supervised to ensure that they do not play with the appliance.
3. The appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
4. Children shall not play with the appliance.
5. Keep the appliance and its cord out of reach of children less than 8 years.
6. Cleaning and user maintenance shell not be made by children unless they are older than 8 and supervised.
7. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
8. Never unplug the feed cable from the plug by tugging on the cable. Do not touch the feed cable with wet hands. Never move the appliance by pulling the cord and make sure the cord cannot become entangled.
9. Cooking appliance should be positioned in a stable position to avoid turning the unit.
10. The user must not leave the device unattended while it is connected to the supply. Bread can burn, therefore the appliance must not be used near or below curtains and other combustible materials such as curtains, drapes or wood (shelving, cupboards...) it should be attended when in use.

11. This appliance is only to be used for household purposes and only for the purpose it is made for.

12. This appliance is intended for indoor use only

13. To protect yourself against an electric shock, do not immerse the cord, plug or appliance in the water or any other liquid.
14. The appliance is not intended to be operated by means of an external timer or a separate remote-control system. Your device must not be used connected to the same power cable or fuse with another device.
15. Only use the appropriate power plug and power socket for this device.
16. Do not use this appliance near water, in a wet basement or near a swimming pool. Do not expose the device to direct sunlight, humidity or excessive dust.
17. Power cord must not be left on the hot body of the device or near it. Do not let cord hang over edge of table or counter.
18. This appliance is intended to be used in household and similar applications such as:
19. staff kitchen areas in shops, offices and other working environments;
20. farm houses
21. by clients in hotels, motels and other residential type environments

22. bed and breakfast type environments

23. Failure to maintain the appliance in a clean condition could lead to damage of the surface that could adversely affect the life of the appliance and possibly result in a hazardous situation. Such damages are not included in the warranty.

24. WARNING: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements.

25. The temperature of the cabinet or the outer surface may be high when the appliance is operating. Touch and use only buttons and handles.

26. Children less than 8 years of age shall be kept away unless continuously supervised.

27. Steam cleaner is not to be used.
28. If your device will not be used for a long period of time, the device must be unplugged. It must be ensured that

the device has cooled down. Store your device in dry and enclosed locations.

1. Device must be unplugged from the mains during mounting and maintenance or repair works.
2. The use of accessory attachments, not recommended or sold by the appliance manufacturer, may cause hazards.
3. Do not place on or near a hot gas or electric burner, or in a heated oven.
4. Do not use appliance other than for its intended use.

CAUTION Hot Surface

Electrical connection

Make sure that the voltage (see name plate) and your home power supply match.

The mains plug should only be inserted into a correctly installed 220-240 V \~ 50/60 Hz socket with earthing contact. No user-serviceable parts inside. Refer servicing to qualified service personnel.

A short power-supply cord is provided to reduce the hazards resulting from entanglement or tripping over a long cord. An extension cord may be used with care, however, the marked electrical rating should be at least as great as the electrical rating of this appliance.

The extension cord should not be allowed to drape over the counter or tabletop where it can be pulled by children or tripped over.

UNIT PARTS

1. Thermostat knob

2. Ready Light (Green)

3. Power Light (Red)

4. Housing

5. Non-sticking Hot plate

6. Bottom Housing

BEFORE FIRST USE

• Read all instructions carefully and keep them for future reference.
• Remove all packaging
• Clean the Cooking Plates by wiping a sponge or cloth dampened in warm water.

DO NOT IMMERSE THE UNIT AND DO NOT RUN WATER DIRECTLY ON THE COOKING SURFACES.

• Dry with a cloth or paper towel.
- For best results, lightly coat the cooking plates with a little cooking oil or cooking spray.

Notice: When your Health Grill is heated for the first time, it may emit slight smoke or odor. This is normal with many heating appliances. This does not affect the safety of your appliance.

ATTENTION: Don't leave wooden T-scraper permanently on the Hot plate!

RECIPES FOR SWEET CREPES AND SAVOURY BUCKWHEAT GALETTES

Wheat flour crepes:

For 15 crepes-In a bowl, place: 100 to 125 gr. Sugar

a pinch of sea salt

2 eggs

25gr. melted butter or 1 tablespoon of cooking oil

1 teaspoon vanilla flavouring

3/4 glass of water (10 cl.)

Beat together and gradually add 250 gr. of wheat flour and half a glass of milk (taken from 1/2 litre of semi-skimmed milk) until you obtain a thick but lump-free batter. Then mix in the rest of the milk.

Buckwheat flour savoury galettes:

for 20 galettes—In a bowl, place: 250 gr. buckwheat flour

1 tablespoon wheat flour

1 teaspoon sea salt

1 egg

a 12 cl. Glass of water.

Mix to obtain a perfectly lump-free batter. Gradually add 3 further glasses of milk.

USING THE SPREADER DEVICE

The words in bold type will remind you of the important points to pay attention to:

1. Your crepe maker is plugged in and the thermostat cursor on 3/4 power. The light indicator light up when the desired temperature has been reached. The thermostat automatically regulates heat temperature throughout the period of use.

Lightly grease the Hot plate and its guiding groove using a cotton cloth moistened with cooking oil. Check that the spreader is perfectly clean and let it stead in the water container.

1. a) Using the left hand, fill the ladle right to the top.

b) Using the right hand, place the spreader facing you in the groove on the griddle.

1. Pour the batter into the spreader in one go, without spreading it around, and immediately turn in clockwise direction. The first turn must be done in 4 seconds.

Gently continue to rotate until you have spread the surplus batter which remains in the spreader, the replace the spreader in the water container. The batter surplus can also be spread with the wooden scraper.

*** You must begin rotation while pouring the batter into the spreader.

1. Allow the pancake to cook for about 10 to 15 seconds before turning it over. Gently slide the wooden spatula under the edge of the crepe.

2. Give a half twist to your wrist and pick the pancake right up. Turn it over quickly so that it isn't over-cooked. For crepes to be eaten cold, slightly cook the second side.

3. Wipe the griddle and guiding groove with the cotton cloth. Clean the spreader with the brush and replace it in the water.

PRACTICAL ADVICES

Spreading is always done in clockwise direction and you must never come back in opposite direction.

The spreader device must exert slight pressure on the griddle during rotation.

Left handed users can invert the batter and the water container on the work station.

Always use lump-free batter. If necessary sieve it.

To re-heat crepes use thermostat positions lower than 3.

Some ready to use batters cannot be spread using the spreader device or the wooden scraper.

To ensure long life to the surface of your griddle, only use plastic or wooden accessories.

We advise you to keep the original packaging to store you appliance and accessories in.

CARE AND CLEANING

• Ensure that the appliance is unplugged before cleaning.
• Let the unit completely cool down.
• The non-stick griddle does not require any special maintenance. After each crepe has been cooked, simply wipe it with a cotton cloth. Cotton is less aggressive than some kitchen papers.
• Do not use abrasive detergents. Any organic solvents or aggressive chemicals.
• Wipe outside with soft dry cloth when waffle maker is cold, never use metal polish.

DO NOT IMMERSE IN WATER OR ANY LIQUID

STORAGE

• Switch off and unplug the appliance, let it completely cool.
• Complete all requirements of chapter CARE AND CLEANING.
• Reel on the power cord.
• Keep the appliance in a dry cool place.

TRANSPORT

CAUTION: Pay attention not to run down the device. If you run down the device during operation, firstly unplug it. Some parts may be broken and device may be damaged during falling, in this case, have device checked by authorized service before operation.

WARNING: Handling and transportation. It is required to perform transportation of device in its own original box. Plastic parts may be broken during Incorrect packaging. Its electrical parts may be damaged.

Unplug It while It is operating for transport, maintenance or repair purposes.

TECHNICAL INFORMATION:

Input voltage: 220-240V

Frequency: 50/60Hz

Power: 1200W

DISPOSAL OF ELECTRICAL AND ELECTRONIC EQUIPMENT

To protect our environment and to recycle the raw materials used as completely as possible, the consumer is asked to return unserviceable equipment to the public collection system for electrical and electronic.

The symbol of the crossed indicates that this product must be returned to the collection point for electronic waste to feed it by recycling the best possible raw material recycling.

By ensuring this product you will prevent possible negative effects on the environment and human health, which could otherwise be caused due to improper disposal of that product.

The recycling of materials from this product, you will help to preserve a healthy environment and natural resources.

For detailed information about the collection of EE products contact the dealer where you purchased the product.

EU DECLARATON OF CONFORMITY

This device is manufactured in accordance with the applicable European standards and in accordance with all applicable Directives and Regulations.

EU declaration of conformity can be downloaded from the following link: www.msan.hr/dokumentacijaartikala

JAMSTVENI LIST HR

VIVAX

MODEL UREĐAJA

SERIJSKI BROJ

DATUM PRODAJE

BROJ RAČUNA PRODAVATELJA

POTPIS I PEČAT PRODAVATELJA

POŠTOVANI!

Zahvaljujemo na kupnji Vivax uređaja i nadamo se da ćete biti zadovoljni odabirom. Ako u jamstvenom roku bude potreban popravak proizvoda, molimo savjetujte se sa ovlaštenim prodavačem koji Vam je proizvod prodao ili nas kontaktirajte na dolje navedene brojeve i adrese. MOLIMO VAS DA PRIJE UPORABE PROIZVODA PAŽLIVO PROČITATE UPUTE PRILOŽENE UZ PROIZVOD!

1. Ovim jamstvom M SAN Grupa kao davatelj jamstva u Republici Hrvatskoj jamči besplatan popravak istog u skladu s važećim propisima i u skladu s uvjetima opisanim u ovom jamstvenom listu.
   Ovim jamstvom jamčimo da će predmet ovog jamstva raditi bez pogreške uzrokovane eventualnom lošom izradom ili lošim materijalom izrade. Svi, eventualno nastali, kvarovi biti će besplatno otklonjeni u ovlaštenom servisu u jamstvenom roku.

2. UVJETI JAMSTVA Jamstveni rok počinje od dana kupnje proizvoda i traje 12 mjeseci.

3. U slučaju kvara na proizvodu koji je predmet ovog jamstva, obvezujemo se da ćemo isti popraviti u najkraćem mogućem roku, a najkasnije u roku od 45 dana. Ako se proizvod ne može popraviti ili se ne popravi u roku od 45 dana, biti će zamijenjen novim. Jamstvo će biti produženo za vrijeme trajanja popravka.

4. Jamstvo se priznaje samo uz račun o kupnji, te uz ovaj jamstveni list koji mora biti ispravno popunjen odnosno mora sadržavati datum prodaje, pečat i potpis prodavatelja.

5. JAMSTVO NE OBUHVAĆA

POTPIS I PEČAT PRODAVATELJA

POŠTOVANI!

Zahvaljujemo na kupnji Vivax uređaja i nadamo se da ćete biti zadovoljni odabirom. Ako u garantnom roku bude potreban popravak, molimo da sljedite donje upute!

GARANCIJSKA IZJAVA

UVJETI GARANCIJE:

GARANCIJA NE OBUHVAĆA:

1. Ovom garancijom garantira proizvođač proizvoda, preko KIM TEC d.o.o., kao uvoznika i davatelja garancije u Republici Bosni i Hercegovini besplatan popravak istog u skladu s važećim propisima i u skladu s uvjetima opisanim u ovom garantnom listu. Ovom garancijom garantiramo da će predmet ove garancije raditi bez greške uzrokovane eventualnom lošom izradom i lošim materijalom izrade. Svi eventualno nastali kvarovi biti će besplatno otklonjeni u ovlaštenom servisu u garantnom roku.
   Garantni rok počinje teći od dana kupnje proizvoda i traje 12 mjeseci.
2. U slučaju kvara na proizvodu koji je predmet ove garancije, obavezujemo se da ćemo isti popraviti u najkraćem mogućem roku, a najkasnije u roku od 30 dana. Ako se proizvod ne može popraviti ili se ne popravi u roku od 30 dana, biti će zamijenjen novim. Ako popravak proizvoda traje duže od 10 dana, garancija se produljužuje za vrijeme trajanja popravka.
3. Garancija se priznaje samo uz račun o kupnji, te uz ovaj garantni list koji mora biti ispravno popunjen odnosno mora sadržavati datum prodaje, pečat i potpis prodavatelja.
4. Davalac garancije osigurava servis i rezervne dijelove 7 godina od datuma kupnje.
5. Redovnu provjeru, održavanje uz zamjenu dijelova koji se troše normalnom upotrebom. Prilagođavanje ili promjene za poboljšanje proizvoda za primjenu koji nisu opisane u tehničkim uputama za korištenje, osim ako je za te preinake predočena suglasnost KIM TEC d.o.o.

6. Garancija se ne priznaje u sljedećim slučajevima:

7. Ako kupac ne predoči ispravan garantni list i račun o kupnji. Ako se kupac nije pridržavao uputa o korištenju proizvoda. Ako je proizvod otvaran, prepravljan ili popravljan od neovlaštene osobe.

8. Ako su kvarovi na proizvodu nastali djelovanjem više sile kao što su: udar groma, strujni udar u eletoričnoj mreži, elementarne nepogode i slično. Ako su kvarovi nastali oštećivanjem zbog nepropisane upotrebe ili nepravilnim transportiranjem. Ako je kvar nastao greškom u sustavu na koji je proizvod priključen.

9. Ovaj garantni list ne mijenja zakonska potrošačka prava važeća u Bosni i Hercegovini u odnosu na ona koja propisuje proizvođač. EU Izjava o sukladnosti dostupna je na stranici: www.msan.hr/dokumentacijaartikala
