appTPV03 - Cash register Approx - Free user manual and instructions

Product Type	POS Terminal / Cash Register
Model	appTPV03
Brand	Approx
Display Size	15.1 inches
Display Type	LED backlit, 5-wire resistive touch
Max Resolution	1024 x 768
Processor	Intel Celeron J1900 Quad Core 2.0 GHz
System Memory	4 GB SO-DIMM
Storage	64 GB SSD (mSATA)
USB Ports	5x USB 2.0, 1x USB 3.0
COM Ports	4x RS232
Video Output	1x HDMI, 1x VGA
Audio	1x line out, 1x line in
LAN	1x RJ45 10/100 Mbps
Power Supply	12V DC, 5A adapter
Operating Temperature	-10°C to 50°C (estimate)
Relative Humidity	0% to 95% non-condensing
Supported OS	Windows 7, 8.x, 10, Linux
Certifications	CE, RoHS
Cleaning	Soft dry cloth; mild detergent for stains; ammonia-based glass cleaner for screen
Battery	CR2032 (internal coin cell) – replace per local regulations
Recycling	Subject to WEEE Directive 2002/96/EC – use separate collection

Frequently Asked Questions - appTPV03 Approx

How do I install an operating system on the appTPV03?

OS installation is highly discouraged for units without preloaded OS due to complexity. Refer to the motherboard guide if necessary. The device supports Windows 7, 8.x, 10, and Linux.

What type of touch screen does the appTPV03 use?

It uses a 15.1-inch 5-wire resistive touch screen with 1024x768 resolution.

How should I clean the touch screen?

Use a soft dry cloth. For stains, moisten with mild neutral detergent. Avoid acryl or polycarbonate solvents. Ammonia-based glass cleaner is safe for the screen.

What are the power requirements?

The device requires a 12V DC 5A power adapter. Always use the manufacturer-recommended adapter.

Can I connect peripherals like a barcode scanner or printer?

Yes, it has 4 COM ports, 5 USB 2.0, 1 USB 3.0, and a LAN port for connecting various peripherals.

Is the internal battery replaceable?

Yes, there is a coin cell battery (CR2032). Replace only with the same type. Dispose of old batteries according to local regulations.

What should I do if the touch screen is unresponsive?

First, clean the screen. If still unresponsive, check connection cables. If problem persists, contact service center – no user-serviceable parts inside.

Does the appTPV03 come with a warranty?

Warranty terms are not specified in the manual. Contact Approx support at [e-mail] for details.

How do I properly recycle the device?

Do not dispose with household waste. Follow local regulations for WEEE. Use designated recycling bins to reduce environmental impact.

Can I use the device in a humid environment?

Operating humidity is 0% to 95% non-condensing. Avoid locations near water or classified as wet. Ensure proper ventilation.

USER MANUAL appTPV03 Approx

15" 5 Wire Resistive

Touch POS Terminal

Thank you for choosing appTPV03 Approx POS terminal. Please always read thoroughly all the instructions and documents delivered with the product before you do anything about it. The company reminds you that the proper use will improve the use affect and authentication speed. Operation of this equipment in a residential area is likely to cause interference in which case the user at his own expense will be required to take whatever measures to correct the interference.

Approx will assume no liability for any technical inaccuracies or editorial or other errors or omissions contained herein, nor for direct, indirect, incidental, consequential or otherwise damages, including without limitation loss of data or profits, resulting from the furnishing, performance, or use of this material. This information is provided "as is" and Approx expressly disclaims any warranties, expressed, implied or statutory, including without limitation implied warranties of merchantability or fitness for particular purpose, good title and against infringement.

The information in this manual contains only essential hardware concerns for general user and is subject to change without notice. Approx reserves the right to alter product designs, layouts or drivers without notification. The system integrator shall provide applicative notices and arrangement for special options utilizing this product.

All data should be backed-up prior to the installation of any drive unit or storage peripheral. Approx will not be responsible for any loss of data resulting from the use, disuse or misuse of this or any other Approx's post terminal product.

Daily maintenance guide

For regular cleaning of POS touch screen, please use only soft haired brush or dry soft cloth. You may use moist soft cloth to remove stains when necessary. Apply only proper amount of mild neutral detergent for obstinate stains. Please note that never use Acryl dissolving solvent or Polycarbonate dissolving solvent. You may apply ammonia-based glass cleaner only on the screen surface.

Caution

• Risk of explosion if battery is replaced by an incorrect type.
• Dispose of used batteries according to local regulations.
• Do not remove the cover, and ensure no user serviceable components are inside. Take the unit to the service center for service and repair.
• Lay this equipment on a reliable surface when install. A drop or fall could cause injury.

Specifications

Display size 15.1" L Touch Display Max. res	CD (LED back lit)
	solution 1024x768
	Touch type	5	wire	resistive
Main Board Processor	Intel Celeron J1900 Quad Core 2.0GHz
	System memory	SO-DIMM		4GB
Storage	HDD	64GB	SSD	mSA
I/O Audio Port x	USB	x	5 (USB 2.0)
		x	1 (USB 3.0)
	COM	x	4
	HDMI	x	1
	1 line out x 1 line in
	LAN	x	1 (RJ45)	10/1C
	VGA	x	1
Environmental Relative		Operation temperature -10° to
		humidity 0% to 95% non-condensing
Power Supply 12V 5A		power adapter
OS Support Windows		7, 8.X, 10, Linux
Certifications		CE/RoHS

Operating system installation

This product is highly professionalized equipment. The installation of an OS into a machine without any preloaded OS could be a major difficulty for average user or obstacle by possibly unintentional negligence even for PC veterans to accomplish such a task. Therefore, OS installation into a system without preloaded OS is highly discouraged. Please kindly refer to our Motherboard User Guide.

Safety, maintenance and recycling instructions

1. Caution: Never open the device, the internal parts are danger, electrical shock.
2. Do not install this unit near water, for example, in a wet basement, in an unprotected outdoor installation or in any area classified as a wet.
3. Do not insert objects of any kind into this unit through openings as they may touch voltage points and short out parts that could result in fire or electric shock.
4. Do not spill any liquid on the unit. Danger of explosion!
5. Do not crush power cables, danger of short circuit!
6. Always connect to the manufacturer's recommended tension.
7. Clean the product with a soft and dry cloth.
8. Follow local regulations for disposing of the product.

Recycled

AEE REI-RAEE 5548 In this manual, the container (bin) symbol indicates that the product is subject to the European directive 2002/96 / EC, electrical and electronic products, batteries, and batteries and other accessories must necessarily be subject to a selective collection.

At the end of the life of the device, make use of the recycling bins. This gesture Will help reduce the

health risks and preserve the environment.

Municipalities and distributors, Will provide essential details on recycling your old device. If this device carries an internal battery, it must be removed and deposited separately for proper management.

Importado por / Imported by:

APPROX IBERIA S. L.

CIF: B-91202499

APPROX TPV

Tlf.: 954 323 886

Email: [e-mail]

El contenido de esta guía está sujeto a errores tipográficos The content of this guide is subject to typographical errors
