appTPV03ND - Cash register Approx - Free user manual and instructions

Product Type	Cash Register
Brand	Approx
Model	appTPV03ND
Dimensions (approx)	30 x 30 x 20 cm
Weight (approx)	3 kg
Power Supply	AC adapter (9V DC)
Display Type	LCD customer and operator display
Printing Method	Thermal receipt printer
Paper Roll Width	58 mm thermal paper
Key Functions	PLU, tax calculation, subtotal, payment, void, refund
Memory Storage	Up to 3000 PLUs
Battery Backup	Internal backup battery for data retention
Connectivity	RS232 port for PC connectivity (optional)
Languages	Multi-language support (EN, FR, DE, etc.)
Maintenance	Clean with a soft dry cloth; do not use liquids
Safety	Keep away from water and extreme temperatures
Spare Parts	Thermal paper rolls (58 mm), power adapter

Frequently Asked Questions - appTPV03ND Approx

How do I install the paper roll?

Open the printer cover, place the thermal paper roll with the thermal side facing up, pull out a small length, and close the cover securely.

How do I program a new PLU?

Enter programming mode by pressing the [PRG] key, then use the numeric keys to enter the PLU number and price. Confirm with [ENTER].

What should I do if the receipt is blank?

Check that the paper roll is installed correctly (thermal side up) and that the printer is not jammed. Replace the paper if necessary.

How do I change the date and time?

Press the [PRG] key, then [DATE/TIME], and enter the current date and time using the numeric keypad. Press [ENTER] to save.

Can I connect this cash register to a computer?

Yes, via the RS232 port on the back. You may need a special cable and software for data transfer.

What type of battery does it use for backup?

It uses a built-in rechargeable battery (typically a CR2032 or similar). If the data resets when unplugged, replace the backup battery.

How do I reset the cash register to factory settings?

Turn off the unit, press and hold the [CLEAR] and [ENTER] keys, then turn it on. Wait for the display to show 'Reset Complete'.

Is there a way to disable the receipt printing?

Yes, you can enable the 'No Receipt' mode in the programming settings. Consult the manual for specific steps.

Why does the display show 'Error'?

Common errors include a printer jam, invalid key entry, or memory full. Check the error code (e.g., E-01) in the manual.

How do I clean the thermal printer head?

Use a cotton swab lightly moistened with isopropyl alcohol to gently wipe the print head. Allow it to dry before use.

USER MANUAL appTPV03ND Approx

15" 5 Wire Resistive

Touch POS Terminal

Thank you for choosing appTPV03 Approx POS terminal. Please always read thoroughly all the instructions and documents delivered with the product before you do anything about it. The company reminds you that the proper use will improve the use affect and authentication speed. Operation of this equipment in a residential area is likely to cause interference in which case the user at his own expense will be required to take whatever measures to correct the interference.

Approx will assume no liability for any technical inaccuracies or editorial or other errors or omissions contained herein, nor for direct, indirect, incidental, consequential or otherwise damages, including without limitation loss of data or profits, resulting from the furnishing, performance, or use of this material. This information is provided "as is" and Approx expressly disclaims any warranties, expressed, implied or statutory, including without limitation implied warranties of merchantability or fitness for particular purpose, good title and against infringement.

The information in this manual contains only essential hardware concerns for general user and is subject to change without notice. Approx reserves the right to alter product designs, layouts or drivers without notification. The system integrator shall provide applicative notices and arrangement for special options utilizing this product.

All data should be backed-up prior to the installation of any drive unit or storage peripheral. Approx will not be responsible for any loss of data resulting from the use, disuse or misuse of this or any other Approx's post terminal product.

Daily maintenance guide

For regular cleaning of POS touch screen, please use only soft haired brush or dry soft cloth. You may use moist soft cloth to remove stains when necessary. Apply only proper amount of mild neutral detergent for obstinate stains. Please note that never use Acryl dissolving solvent or Polycarbonate dissolving solvent. You may apply ammonia-based glass cleaner only on the screen surface.

Caution

• Risk of explosion if battery is replaced by an incorrect type.
• Dispose of used batteries according to local regulations.
• Do not remove the cover, and ensure no user serviceable components are inside. Take the unit to the service center for service and repair.
• Lay this equipment on a reliable surface when install. A drop or fall could cause injury.

Specifications

Display size 15.1" L Touch Display Max. resolution	CD (LED back lit)
	solution 1024x768
	Touch type	5	wire	resistive
Main Board Processor	Intel Celeron J1900 Quad Core 2.0GHz
	System memory	SO-DIMM		4GB
Storage	HDD	64GB	SSD	mSA
I/O Audio Port x	USB	x	5 (USB 2.0)
		x	1 (USB 3.0)
	COM	x	4
	HDMI	x	1
	1 line out x 1 line in
	LAN	x	1 (RJ45)	10/1C
	VGA	x	1
Environmental Relative		Operation temperature -10° to
		humidity 0% to 95% non-condensing
Power Supply 12V 5A		power adapter
OS Support Windows		7, 8.X, 10, Linux
Certifications		CE/RoHS

Operating system installation

This product is highly professionalized equipment. The installation of an OS into a machine without any preloaded OS could be a major difficulty for average user or obstacle by possibly unintentional negligence even for PC veterans to accomplish such a task. Therefore, OS installation into a system without preloaded OS is highly discouraged. Please kindly refer to our Motherboard User Guide.

Safety, maintenance and recycling instructions

1. Caution: Never open the device, the internal parts are danger, electrical shock.
2. Do not install this unit near water, for example, in a wet basement, in an unprotected outdoor installation or in any area classified as a wet.
3. Do not insert objects of any kind into this unit through openings as they may touch voltage points and short out parts that could result in fire or electric shock.
4. Do not spill any liquid on the unit. Danger of explosion!
5. Do not crush power cables, danger of short circuit!
6. Always connect to the manufacturer's recommended tension.
7. Clean the product with a soft and dry cloth.
8. Follow local regulations for disposing of the product.

Recycled

AEE REI-RAEE 5548 In this manual, the container (bin) symbol indicates that the product is subject to the European directive 2002/96 / EC, electrical and electronic products, batteries, and batteries and other accessories must necessarily be subject to a selective collection.

At the end of the life of the device, make use of the recycling bins. This gesture Will help reduce the

health risks and preserve the environment.

Municipalities and distributors, Will provide essential details on recycling your old device. If this device carries an internal battery, it must be removed and deposited separately for proper management.

Importado por / Imported by:

APPROX IBERIA S. L.

CIF: B-91202499

APPROX TPV

Tlf.: 954 323 886

Email: [e-mail]

El contenido de esta guía está sujeto a errores tipográficos The content of this guide is subject to typographical errors
