ST-VC0250 - Vacuum Cleaner Saturn - Free user manual and instructions

Product Type	Cylinder Vacuum Cleaner
Model	ST-VC0250
Brand	Saturn
Dimensions (approx.)	400 x 250 x 250 mm
Weight	5 kg
Power Consumption	800 W
Dust Capacity	1.5 L
Filtration System	HEPA filter
Bag Type	Bagless (cyclonic)
Cord Length	5 m
Cleaning Radius	8 m
Noise Level	75 dB
Accessories Included	Crevice tool, upholstery brush, floor brush
Maintenance	Empty dust container after each use; clean filter monthly
Safety Features	Automatic shut-off when overheated; do not vacuum liquids
Spare Parts Available	Filters, brush roll, dust container
Repairability	User replaceable filters and brush; motor service by professional
General Information	Suitable for hard floors and low-pile carpets; color may vary

Frequently Asked Questions - ST-VC0250 Saturn

How do I assemble the Saturn ST-VC0250 vacuum cleaner?

Attach the hose to the main unit, then connect the extension tube and desired floor nozzle. Ensure all parts click securely into place.

How do I empty the dust container?

Press the release button on top of the dust container, lift it out, and empty it into a trash bin. For thorough cleaning, rinse the container with water and dry completely before reattaching.

How often should I clean the HEPA filter?

Clean the HEPA filter at least once a month. Tap it gently to remove dust, or rinse with water if indicated. Allow to dry for 24 hours before reinstalling.

Can I use this vacuum for wet cleaning?

No, this vacuum is designed for dry pick-up only. Using it on wet surfaces or liquids can damage the motor and void the warranty.

What should I do if the vacuum loses suction?

Check for blockages in the hose, tube, or floor head. Also empty the dust container and clean the filter. If problem persists, inspect the brush roll for hair tangles.

How do I replace the brush roll?

Turn off and unplug the vacuum. Remove the floor head, press the release tabs to open the brush cover, lift out the old brush, and insert the new one. Close the cover securely.

Does the vacuum come with a crevice tool?

Yes, the ST-VC0250 includes a crevice tool, upholstery brush, and a combination floor brush for various surfaces.

How long is the power cord?

The power cord is 5 meters long, providing a cleaning radius of approximately 8 meters.

Is the vacuum bagless or bagged?

It is a bagless cylinder vacuum with a cyclonic filtration system, so no replacement bags are needed. Simply empty the dust container.

Where can I purchase spare filters or parts?

Spare parts are available through Saturn's customer service or authorized retailers. Use the model number ST-VC0250 when ordering.

USER MANUAL ST-VC0250 Saturn

Exterior view of a modern vacuum cleaner with blue and black casing (no text or symbols visible)

GB

VACUUM CLEANER

Dear Buyer!

We congratulate you on having bought the device under trade name "Saturn". We are sure that our devices will become faithful and reliable assistance in your housekeeping.

Avoid extreme temperature

changes. Rapid temperature change (e.g. when the unit is moved from freezing temperature to a warm room) may cause condensation inside the unit and a malfunction when it is switched on. In this case leave the unit at room temperature for at least 1.5 hours before switching it on. If the unit has been in transit, leave it indoors for at least 1.5 hours before starting operation.

DESCRIPTION

A. Extension tube

B. Wind control knob

C. Handle

D. Flexible tube E. Cord rowind

E. Cord rewind button E. Plug

F. Plug C. Plot

G. Plate for wind output H. Speed adjust

H. speed adjust H. ON/OFF butt

I. Vac gauge

1. Air Intake

K. Plug tube

L. Front cover button

M. Floor brush

IMPORTANT

- Read this instruction booklet care-

fully

- Before using the appliance, check that the mains power voltage corresponds to the voltage shown on the rating plate.

• This appliance should be con-
nected to a correctly-earthed power socket.
• Always remove the plug from the power socket, when the appliance is not in use and before carrying out any cleaning or maintenance operations.
• Always remove the plug from the power socket before opening the appliance.
- Never use methylated spirits or other solvents to clean the appliance.
- Do not use the appliance to vacuum liquids.
- Never leave the appliance unattended, when it is switched and keep the appliance out of the reach of children or the infirm persons.
- This appliance is for domestic use only. Use as described in this instruction booklet.
- Do not switch the appliance on, if it appears to be faulty in any way. - For repairs or accessories, contact your dealer or an authorized service centre.
- If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person, in order to avoid a hazard.

Do not run the appliance over the power cable.

Do not remove the plug from the socket by pulling the cable or the appliance itself.

Do not use the appliance to vacuum lighted matches, cigarette ends or hot ash.

Do not use the appliance on wet surfaces.

Do not obstruct the air intake or outlet vents.

Do not use the appliance to vacuum needles, drawing-pins or string.

Two hand-drawn sketches of a fish-like object with cross marks, one showing a broken body and the other with a stick (no text or symbols)

ASSEMBLYING THE VACUUM CLEANER

Always remove the plug from the power socket before fitting or removing accessories.

Fitting the flexible tube

Insert the flexible tube into the air intake duct on the appliance. To do this, slide the intake duct cover, insert the tube and press until it clicks into position.

Removing the flexible tube

Remove the plug from the power socket. To release the flexible tube, press the button on the end of the tube firmly the air intake duct.

Fitting the extension tubes and accessories

extension tube

brush

Removing the extension tubes and accessories

To remove the accessories, pull firmly apart.

INSTRUCTION FOR USE

1. Before using the appliance, unwind length of cable and insert the plug into the power socket. A YELLOW mark on the power cable shows the ideal cable length. Do not extend the cable beyond the RED mark. To rewind the power cable, press the rewind button with one hand, and guide the other hand to ensure that it does not whip causing damage. If the power cable can't rewind completely, please pull out the power cable a little bit and press the rewinder button again. You can repeat the re-winding steps until the cable is re-winded completely.
2. Press the ON/OFF button to switch the appliance on. It is advisable to set the electronic power regulator to MIN, before switching on the appliance.
3. By turning the speed control knob, the absorption power can be adjusted.

REPLACING THE DUST BAG

1. After removing the flexible tube, open front cover by pressing the button and pulling upwards.
2. Remove the dust bag.

MAINTENANCE

1. When the motor filter is dirty, remove the filter and wash carefully in liquid or water. Allow the filter to dry completely before replacing it.
2. To clean or replace the air outlet filter, first detach the grille by pulling firmly away from the appliance.

Line drawings of two types of household appliances, one open and one closed, with no visible text or symbols.

1. Remove the filter from the appliance. Clean or replace the filter. The filter should be washed regularly under the tap and allowed to dry before replacing it in the filter grille.
2. Replace the filter every 2-3 months, depending on how frequently it is used.

USING THE CLEANING ACCESSORIES

Dual-position carpet/floor brush

Pos. 1: bristles extended, for hard floors

Pos. 2: bristles retracted, for carpets

Accessory compartment

The narrow nozzle and small brush are stored in the accessory compartment. ATTENTION

In order to reach high-level efficiency while cleaning, please clean the floor brush regularly.

AFTER USING

You may fix the stands both for floor brush and accessories onto the vacuum cleaner.

This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.

Specifications:

• Power: 1500 W
• Nominal Voltage: 220-230 V
• Rated Frequency: 50 Hz
• Rated Current: 6.8 A
- Dust Bag Capacity: 1.5 L - Noise level: ≤ 73 dB

Set

VACUUM CLEANER....1 INSTRUCTION MANUAL WITH WARRANTY BOOK....1 PACKAGE....1

ENVIRONMENT
FRIENDLY
DISPOSAL
You can help protect the
protect the environment

Please remember to respect the local regulations: hand in the non-working electrical equipments to an appropriate waste disposal

center.

The manufacturer reserves the right to change the specification and design of goods.

RU

ПЫЛЕСОС

ОПИСАНИЕ

A. Выдвижная трубка

Simple line drawing of a mechanical device with circular components and a central vertical axis (no text or symbols)

ОПИС

Line drawings of two open and closed air purifiers (no text or symbols)

The Warranty is provided for the period of 2 years or more if the Law on User Right of the country where the appliance was bought provides for a greater minimum warranty period.

All terms of warranty comply with to the Law on Protection of the Consumer Rights and are governed by the legislation of the country where the product was bought.

The warranty and free of charge repair are provided in any country where the product is delivered to by Saturn Home Appliances or authorized representative thereof, and where no restriction of import or other legal provisions interfere with rendering of warranty services and free of charge repair.

Cases uncovered by the warranty and free of charge repair:

1. Guarantee coupon is filled in improperly.

2. The product has become inoperable because of the Buyer's non-observance of the service regulations indicated in the instruction.

3. The product was used for professional, commercial or industrial purposes (except for the models, specially intended for this purpose that is indicated in the instruction).

4. The product has external mechanical damage or damage caused by penetration of the liquid inside, dust, insects and other foreign objects.

5. The product has damages caused by non-observance of the rules of power supply from batteries, mains or accumulators.

6. The product was exposed to opening, repair or modification of design by the persons, unauthorized to repair; independent cleaning of internal mechanisms etc. was made.

7. The product has natural wear of parts with limited service life, expendables etc.

8. The product has deposits of scale inside or outside of fire-bar elements, irrespective of used water quality.

9. The product has damages caused by effect of high (low) temperatures or fire on non-heat resistant parts of the product.

10. The product has damages of accessories and nozzles which are included into the complete set of product shipment (filters, grids, bags, flasks, cups, covers, knives, sealing rings, graters, disks, plates, tubes, hoses, brushes, and also power cords, headphone cords etc.).

On the warranty service and repair, please contact the authorized service centers of Saturn Home Appliances.

CZ

MEZINÁRODNÍ ZÁRUKA

When purchasing the product, please require its checking before

you;

BE SURE

that the goods sold to you, are functional and complete and that the warranty coupon is filled in correctly.

This warranty coupon confirms the absence of any defects in the product you purchased and provides for free of charge repair of the product failed through the fault of the manufacturer throughout the period of warranty service and free of charge repair.

Failing the presentation of this coupon, in case of its improper filling in, infringement of factory seals (if any), and also in cases indicated in the warranty obligations, the claims are not accepted, and no warranty service and free of charge repair is made!

The warranty coupon is valid only in the original copy with the stamp of trading organization, signature of the seller, date of sale and signature of the buyer.

ZÁRUČNÍ LIST

Buyer's Signature confirming the acquaintance and consent with conditions of free of charge maintenance service of the product, and absence of the complaints on appearance and color of the product.
