Product Type	Security Camera (IP Camera)
Model	IC-3030iWN
Brand	Edimax
Connectivity	Ethernet (RJ-45), Wi-Fi 802.11n (150Mbps), WPS
Wireless Standard	IEEE 802.11b/g/n
Frequency Band	2.4 GHz
Image Sensor	1/4-inch CMOS
Resolution	VGA (640x480) at 30fps
Lens	Fixed, 3.6mm
Field of View	67° horizontal, 50° vertical
Night Vision	No infrared LED; day-only operation
Power Supply	DC 5V, 1.2A (via included adapter)
Power Over Ethernet	Not supported
Dimensions (WxHxD)	100 x 65 x 40 mm
Weight	150 g
Operating Temperature	0°C to 40°C
Operating Humidity	20% to 80% non-condensing
Mounting	Wall or ceiling mount (bracket included)
Software	IPCam Admin Utility (PC application)
Security	WEP, WPA/WPA2 encryption
Certifications	FCC, CE, R&TTE, WEEE
Package Contents	Camera, power adapter, mounting kit, CD, quick guide

Frequently Asked Questions - IC-3030IWN Edimax

How do I reset the Edimax IC-3030iWN to factory defaults?

Press and hold the reset button on the camera for about 10 seconds until the status LED blinks rapidly. The camera will reboot and restore factory settings.

What is the default IP address of the camera?

The default IP address is 192.168.2.100. If you have changed it and forgotten, use the IPCam Admin Utility to discover the camera on your network.

How do I connect the camera to my Wi-Fi network?

First connect the camera via Ethernet to your router. Run the IPCam Admin Utility, select the camera, and go to Wireless Settings. Enter your Wi-Fi SSID and password, then enable Wireless. Disconnect Ethernet and the camera will connect via Wi-Fi.

Can I view the camera remotely from my smartphone?

Yes, the camera supports remote viewing using the EdiView app (iOS/Android) or through a web browser using the camera's WAN IP and port forwarding. Ensure UPnP is enabled on your router for easier setup.

Does the camera support night vision?

No, the IC-3030iWN is a day-only camera and does not include infrared LEDs. It requires ambient lighting to produce a clear image.

How do I update the firmware?

Download the latest firmware from the Edimax support website. Access the camera's web interface, go to Firmware Upgrade, select the file, and click Upgrade. Do not power off during the process.

What is the field of view of the camera?

The camera has a fixed lens with a horizontal viewing angle of 67° and a vertical angle of 50°, suitable for monitoring small to medium rooms.

Is the camera compatible with third-party NVRs?

Yes, it supports standard protocols like RTSP and MJPEG, making it compatible with many NVRs and software such as Blue Iris, iSpy, and ZoneMinder.

How do I mount the camera?

The camera comes with a mounting bracket that can be attached to a wall or ceiling. Use the included screws and anchors. Adjust the camera head to the desired angle.

What security features does the camera offer?

The camera supports WEP, WPA, and WPA2 encryption for wireless security. It also has a password-protected web interface and can be configured for secure remote access via HTTPS.

USER MANUAL IC-3030IWN Edimax

Three white industrial control devices with circular buttons and a connecting rod, displayed against a black background with puzzle pieces (no visible text or symbols on the devices themselves)

ErP Ankündigung

Produkt: Internetkamera (IP-Kamera)

Setup - IPCam Admin Utility

Ready to install

Setup is now ready to begin installing IPCam Admin Utility on your computer.

Click install to continue with the installation, or click Back if you want to review or change any settings.

Destination location:

C:\Program Files (x86)\Internet Camera\Admin

Additional tasks:

Additional icons

Create a desktop icon

Create a Quick Launch icon

< Back

Install

Cancel

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
4. Consult the dealer or an experienced radio technician for help.

FCC Caution

This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the authority to operate equipment.

Federal Communications Commission (FCC) Radiation Exposure Statement

This equipment complies with FCC radiation exposure set forth for an uncontrolled environment. In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity to the antenna shall not be less than 2.5cm (1 inch) during normal operation.

Federal Communications Commission (FCC) RF Exposure Requirements

SAR compliance has been established in the laptop computer(s) configurations with PCMCIA slot on the side near the center, as tested in the application for certification, and can be used in laptop computer(s) with substantially similar physical dimensions, construction, and electrical and RF characteristics. Use in other devices such as PDAs or lap pads is not authorized. This transmitter is restricted for use with the specific antenna tested in the application for certification. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

R&TTE Compliance Statement

This equipment complies with all the requirements of DIRECTIVE 1999/5/EC OF THE EUROPEAN PARLIAMENT AND THE COUNCIL of March 9, 1999 on radio equipment and telecommunication terminal equipment and the mutual recognition of their conformity (R&TTE). The R&TTE Directive repeals and replaces in the directive 98/13/EEC (Telecommunications Terminal Equipment and Satellite Earth Station Equipment) As of April 8, 2000.

Safety

This equipment is designed with the utmost care for the safety of those who install and use it. However, special attention must be paid to the dangers of electric shock and static electricity when working with electrical equipment. All guidelines of this and of the computer manufacture must therefore be allowed at all times to ensure the safe use of the equipment.

EU Countries Intended for Use

The ETSI version of this device is intended for home and office use in Austria, Belgium, Bulgaria, Cyprus, Czech, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Turkey, and United Kingdom. The ETSI version of this device is also authorized for use in EFTA member states: Iceland, Liechtenstein, Norway, and Switzerland.

EU Countries N ot Intended for U se

None

Declaration of Conformity

We, Edimax Technology Co., LTD., declare under our sole responsibility, that the equipment described below complies with the requirements of the European R&TTE directive (2006/95/EC).

Equipment : 150Mbps Wireless 802.11n Triple Mode Internet Camera

Model No. : IC-3030iWn

Report No. : L110722L037, EA9D1828-05, EH9D1828-05, ER9D1828-05AC, ER9D1828-05AI

The following European standards for essential requirements have been followed:

European Standard: 2006/95/EC

IEC 60950-1:2005 ( 2^nd Edition)

EN 60950-1: 2006+A11:2009

EN 50385:2002

EN 301 489-1 V1.8.1 (2008-04)

EN 301 489-17 V1.3.2 (2008-04)

ETSI EN 300 328 V1.7.1 (2006-10)

Edimax Technology Co., Ltd.

No. 3, Wu Chuan 3 ^rd Road,

Wu-Ku Industrial Park.

Date of Signature : April 30, 2011

Signature : A###

Printed Name : Albert Chang

Title : Director Edimax Technology CO., LTD.

Declaration of Conformity

We, Edimax Technology Co., LTD., declare under our sole responsibility, that the equipment described below complies with the requirements of the European R&TTE directive (2006/95/EC).

Equipment : Triple Mode Internet Camera

Model No. : IC-3030i/IC-3030iPoE

Report No. : EC9D1823-04

The following European standards for essential requirements have been followed:

European Standard EN 55022:2006/A1: 2007 Class B

EN 61000-3-2:2006, EN61000-3-3:1995/A1:2001/A2:2005 and

EN 55024:1998/A1:2001/A2:2003 (IEC61000-4-2:1995/A1:1998/A2:2000

IEC 61000-4-3:1995/A1:1998/A2:2000, IEC 61000-4-4:2004

IEC 61000-4-5:1995/A1:2000, IEC 61000-4-6:1996/A1:2000

IEC 61000-4-8:1993/A1:2000, IEC 61000-4-11:1994/A1:2000)

Edimax Technology Co., Ltd.

No. 3, Wu Chuan 3 ^rd Road,

Wu-Ku Industrial Park.

Date of Signature : April 30, 2011

Signature : Alm

Printed Name : Albert Chang

Title : Director Edimax Technology CO., LTD.

EU Declaration of Conformity

English: This equipment is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC, 2009/125/EC.
French: Cet équipement est conforme aux exigences essentielles et autres dispositions de la directive 1999/5/CE, 2009/125/CE
Czechian: Toto zařízení je v souladu se základními požadavky a ostatními příslušnými ustanoveními směrnic 1999/5/ES, 2009/125/ES.
Polish: Urządzenie jest zgodne z ogólnymi wymaganiami oraz szczególnymi warunkami określonymi Dyrektywą UE 1999/5/EC, 2009/125/EC
Romanian: Acest echipament este în conformitate cu cerințele esențiale și alte prevederi relevante ale Directivei 1999/5/CE, 2009/125/CE.
Russian: Это оборудование соответствует основным требованиям и положениям Директивы 1999/5/EC, 2009/125/EC.
Magyar: Ez a berendezés megfelel az alapvető követelményeknek és más vonatkozó irányelveknek (1999/5/EK, 2009/125/EC)
Türkçe: Bu cihaz 1999/5/EC, 2009/125/EC direktifleri zorunlu istekler ve diğer hükümlerle ile uyumludur.
Ukrainian: Обладнання відповідає вимогам і умовам директиви 1999/5/EC, 2009/125/EC.
Slovakian: Toto zariadenie spíňa základné požiadavky a dálšie príslušné ustanovenia smerníc 1999/5/ES, 2009/125/ES.
German: Dieses Gerät erfüllt die Voraussetzungen gemäß den Richtlinien 1999/5/EC, 2009/125/EC.
Spani \$1: El presente equipo cumple los requisitos esenciales de la Directiva 1999/5/EC, 2009/125/EC.
Italian: Questo apparecchio è conforme ai requisiti essenziali e alle altre disposizioni applicabili della Direttiva 1999/5/CE, 2009/125/CE.
Dutch: Dit apparaat voldoet aan de essentiële eisen en andere van toepassing zijnde bepalingen van richtlijn 1999/5/EC, 2009/125/EC.
Portugese: Este equipamento cumpre os requesitos essenciais da Directiva 1999/5/EC, 2009/125/EC
Norwegian: Dette utstyret er i samsvar med de viktigste kravene og andre relevante regler i Direktiv 1999/5/EC, 2009/125/EC.
Swedish: Denna utrustning är i överensstämmelse med de väsentliga kraven och övriga relevanta bestämmelser i direktiv 1999/5/EG, 2009/125/EG.
Danish: Dette udstyr er i overensstemmelse med de væsentligste krav og andre relevante forordninger i direktiv 1999/5/EC, 2009/125/EC.
Finnish: Tämä laite täyttää direk tiivien 1999/5/EY, 2009/125/EY oleelliset vaatimukset ja muut asiaankuuluvat määräykset.

WEEE Directive & Product Disposal

At the end of its serviceable life, this product should not be treated as household or general waste. It should be handed over to the applicable collection point for the recycling of electrical and electronic equipment, or returned to the supplier for disposal.

Edimax Headquarters

Edimax Technology Co., Ltd.

Add: 6F., No. 3, Wu-Chuan 3rd Road, Wu-Gu, New Taipei City 24891, Taiwan (R.O.C.)

Support: [e-mail]
