Product Type	Wall mount for monitors
Brand	Dataflex
Model	ViewMate 142
VESA Compatibility	75x75 mm and 100x100 mm
Maximum Weight Capacity	15 kg (33 lbs)
Tilt Range	-5° to +15°
Swivel Range	±90°
Rotation	360°
Distance from Wall	50 mm (2 inches)
Material	Cold-rolled steel (SPCC)
Color	Black
Installation	Wall mounting with included hardware
Included Accessories	Mounting bracket, screws, wall anchors, level
Monitor Support	Single monitor up to 27 inches
Weight	1.2 kg (2.6 lbs)
Dimensions (WxHxD)	200 x 200 x 50 mm
Power Supply	None (passive mount)
Maintenance	Wipe with dry cloth; do not use solvents
Safety	Use on solid wall; ensure screws are tight
Spare Parts	Contact Dataflex support for replacements
Warranty	5 years (manufacturer defect)

Frequently Asked Questions - ViewMate 142 Dataflex

What VESA patterns does the Dataflex ViewMate 142 support?

The mount supports VESA 75x75 mm and 100x100 mm patterns, which are standard for most monitors up to 27 inches.

What is the maximum weight capacity of the ViewMate 142?

The maximum weight capacity is 15 kg (33 lbs). For heavier monitors, consider a model with higher capacity.

Can I tilt or swivel the monitor?

Yes, the ViewMate 142 offers a tilt range of -5° to +15° and a swivel range of ±90°, allowing flexible viewing angles.

Is the mount easy to install?

Yes, installation is straightforward. The package includes all necessary hardware and a level. Follow the included manual carefully.

What tools are needed for installation?

You will need a Phillips screwdriver, a drill (for concrete walls), and possibly a stud finder for drywall. All screws and anchors are provided.

Does the mount work with curved monitors?

Yes, as long as the monitor has a VESA pattern of 75x75 or 100x100 and weighs less than 15 kg. The flat plate can accommodate curved backs.

Can I rotate the monitor to portrait mode?

Yes, the mount allows 360° rotation, so you can easily switch between landscape and portrait orientation.

How far from the wall does the monitor sit?

The monitor sits about 50 mm (2 inches) from the wall, giving a slim profile while allowing cable management.

Is the mount compatible with drywall?

Yes, but you must use the provided anchors and ensure the mount is attached to a stud or use suitable wall fixings for your wall type.

Where can I get spare parts if needed?

Contact Dataflex customer support via their official website. Spare parts such as screws or brackets may be available.

USER MANUAL ViewMate 142 Dataflex

Technical line drawing of a mechanical assembly with shafts and housing (no text or symbols)

www.dataflex-int.com 1.0

Dataflex International BV

P.O. Box 713

2920 CA Krimpen a/d IJssel

The Netherlands

[e-mail]

Copyright © 2013 - Dataflex International BV

www.dataflex-int.com

Dataflex International BV is certified ISO 9001:2008
