Multiple washbasins made of MIRANIT
MIRANIT - THE MINERAL MATERIAL FOR HIGH DEMANDS AND EXCEPTIONAL DESIGN
Smart Hygiene Solutions.
MIRANIT – The name for a new composite granite material
MIRANIT, a new composite granite material, is a unique combination of strength and design capabilities used to create a new generation of wash-basins. This material is a stable compound consisting of approximately 80% natural minerals such as calcium carbonate and quartz as well as approximately 20% of a high-quality unsaturated polyester resin. Due to its exceptional moulding properties, this resin-bonded mineral material can be formed into any shape, even when thin material thicknesses are required. With this material, MIRANIT
washbasins offer a completely new approach to the design of wash areas, because in spite of their flat and elegant impression the washbasins provide high durability. Small radii of just 2 mm underscore the clear and expressive shapes that the new MIRANIT wash solutions offer.
A graceful and clean appearance with in-built strength - only MIRANIT, the mineral material specifically designed to meet the requirements of commercial and public sanitary facilities, can provide this combination. The stable
and fracture-resistant material has a smooth, pore-free and high-gloss exterior skin. The Gelcoat layer that provides the Alpine White colour is easy to clean, impact resistant, non-abrasive and offers good resistance to alkalines and acids. Even water temperatures up to 80^ will not harm the Gelcoat surface.
① High stability with reduced material thickness
② Wash bowl has excellent shape retention
③ Small radii for new design possibilities
④ Clearly contoured rear edge
① MIRANIT- fracture-resistant compound made of natural minerals and unsaturated polyester resin
② Hygienic surface, temperature-resistant up to 80^
③ Smooth, pore-free and high-gloss Gelcoat surface
The installer can use a disc grinder to adapt the length of niche washbasins.
This is the time for design and functionality
QUADRO – The new form of modern sanitary room design
The architectural requirements for equipment used in sanitary rooms that are frequented by many people vary considerably. However, the optimum use of space is always a key concern. Experience has shown that washbasin combinations of different lengths and having several wash bowls are well suited for commercial and public washroom designs. For this reason the standard unit width of the new single wash basin is 600~mm . Where there are several wash bowls in a multiple unit, the centre to entredistance of the bowls is 700~mm
The clear, functional lines of QUADRO multiple washbasins makes them very suitable for providing a modern design to sanitary rooms. The rectangular shape of the basin merges gracefully over into a flowing bowl, it's flat form offering particularly convenient washing. The lightness and discreteness of this shape reveals the design opportunities that mineral granite offers.
Washing room with two QUADRO multiple washbasins, each as a triple unit
Multiple washing system with QUADRO single wash-basins, AQUAMIX-C self-closing fittings and XINOX® Touch free soap dispensers
QUADRO multiple washbasins with self-closing single mixer AQUAMIX-C
Modern sanitary room design
RONDA – Harmonious design for every washroom
The elegant shape of the Ronda bowl has a circular form with a flat back face that runs parallel to the wall. The optically pleasing design fits harmoniously into every wash room while providing generous basin space to make washing easy for users. Due to the small contoured rear edge and an apron height of only 60~mm , the new
multiple washing systems appear very modern and well proportioned.
Depending on the installation requirements, RONDA washbasins are available as single, double and triple units and can also be formed with extended flat areas to fit into recesses between two walls.
Sport facility with two RONDA double washbasins with AQUAMIX-S self-closing single mixer, XINOX® accessory series
RONDA multiple washbasins fit exceptionally well into the architecture of modern designed sanitary rooms. Their timeless bowl form allows them to be combined both with more classic as well as very modern designs.
RONDA multiple washbasins with PROTRONIC-S electronic washbasin fittings
A clean solution, right into the last corner
QUADRO niche washbasins – variable solutions
Modern and individual washroom layouts in new buildings or buildings to be refurbished can be a special issue when custom-fitting washbasins are required. Variable niche washbasins offer custom-tailored solutions for this purpose. The washbasins can have one or two bowls and are available with a maximum length up to 2100 mm. Designs with only one washing bowl located either in the
middle, to the left or to the right, offer an especially large flat surface for the convenience of users. The particular advantages that the MIRANIT material offers become clear when installing niche washbasins between two walls. In spite of its strength, the material can still be cut mechanically on site to adapt it to the space available.
QUADRO niche washbasin with two bowls, AQUAMIX-C self-closing fitting, soap dispenser and hand dryer from the the XINOX® series of accessories.
QUADRO niche washbasins with a bowl on the left in combination with AQUAMIX-C self-closing fitting and integrated CHRONOS soap dispenser
Niche washbasins – easy to clean and hygienic
RONDA - timeless washbasin design
It is particularly the timeless and appealing design variation RONDA that develops a special attraction as a niche washbasin. The perfect and easy-to-clean surface that has no joints or seams provides a comfortable environment for users to enjoy. Due to the large flat surfaces the niche models are particularly suitable for applications in hotels, leisure facilities or even in apartments or studios.
All washbasin variations are opti- onally available with or without a taphole, and are very well suited for combining with manual self-closing or electronic taps also available in the Franke range of products.
RONDA niche washbasin, bowl on right, opto-electronic PROTRONIC-C washbasin fitting
RONDA recess washbasins with two bowls, AQUALINE-S fittings, XINOX® accessories
As a result of their modern and timeless design, RONDA niche washbasins are also well suited for applications in leisure centres and hotels as well as for up-market office buildings.
LOTOS – A washbasin blossoms out
Natural material in a natural form
The leaf of the lotus flower is reflected in the design of the LOTOS washbasin. The simple proportions of the shape and the size of the bowl makes an attractive washroom even better. Just like the blossom, the almost delicate effect of LOTOS washbasins is underscored by the thin material
thickness of only 10mm and shows clearly the advantages that the MIRANIT material offers with respect to design and strength.
LOTOS washbasins provide an optical highlight for room recesses in combination with large mirrors. Ideally the
washbasins are combined with automatically operating fittings to provide increased hygiene and water savings.
LOTOS single washbasins with PROTRONIC-S electronic fittings
LOTOS washbasins without a tap landing are specially designed for applications with wall-mounted fittings.
The ideal combination of function and design can be seen in the LOTOS washbasin combined with the new electronic fittings. The PROTRONIC-S washbasin fitting is specially suited for non-touch water control.
QUADRO single washbasin
made of MIRANIT resin-bonded mineral material, colour Alpine White. With seamless rectangular bowl, without overflow. Integral back panel with integrated brackets and holes for fixing. Rear contoured edge. Mounting material included (hanger bolts and dowels).
Length of washbasin: 600
Bowl dimensions (LxWxH): 520x375x40/90
Three-sided apron 60
ANMW 411 with taphole
7612982099830
ANMW 410 without taphole
7612982099878
Accessories:
Strainer waste DN 32
7612982100178
Dome waste DN 32
7612982100161
Pop-up waste and overflow set DN 32*
7612982097812
QUADRO double washbasin
made of MIRANIT resin-bonded mineral material, colour Alpine White. With two seamless rectangular bowls, without overflow. Integral back panel with integrated brackets and holes for fixing. Rear contoured edge. Mounting material included (hanger bolts and dowels).
Length of double washbasin: 1400
Bowl dimensions (LxWxH): 580x360x40/90
Centre-to-centre distance of the bowls 700
Three-sided apron 60
ANMW 421 with tapholes
7612982099823
ANMW 420 without tapholes
7612982099861
Accessories:
Strainer waste DN 32
7612982100178
Dome waste DN 32
7612982100161
Pop-up waste and overflow set DN 32*
7612982097812
QUADRO triple washbasin
made of MIRANIT resin-bonded mineral material, colour Alpine White. With three seamless rectangular bowls, without overflow. Integral back panel with integrated brackets and holes for fixing. Rear contoured edge. Mounting material included (hanger bolts and dowels).
Length of triple washbasin: 2100
Bowl dimensions (LxWxH): 580x360x40/90
Centre-to-centre distance of the bowls 700
Three-sided apron 60
ANMW 431 with tapholes
7612982099847
ANMW 430 without tapholes
7612982099854
Accessories:
Strainer waste DN 32
7612982100178
Dome waste DN 32
7612982100161
Pop-up waste and overflow set DN 32*
7612982097812
View
all measurements in mm
Type / Design
Code
RONDA single washbasin
made of MIRANIT resin-bonded mineral material, colour Alpine White. With seamless round bowl, flattened out at the rear, without overflow. Integral back panel with integrated brackets and holes for fixing. Rear contoured edge. Mounting material included (hanger bolts and dowels).
Length of washbasin: 600
Bowl dimensions (ØxWxH): 520x380x90
Three-sided apron 60
ANMW 211 with taphole
7612982099885
ANMW 210 without taphole
7612982099892
Accessories:
Strainer waste DN 32
7612982100178
Dome waste DN 32
7612982100161
Pop-up waste and overflow set DN 32*
7612982097812
RONDA double washbasin
made of MIRANIT resin-bonded mineral material, colour Alpine White. With two seamless round bowls, flattened out at the rear, without overflow. Integral back panel with integrated brackets and holes for fixing. Rear contoured edge. Mounting material included (hanger bolts and dowels).
Length of double washbasin: 1400
Bowl dimensions (ØxWxH): 540x380x90
Centre-to-centre distance of the bowls 700
Three-sided apron 60
ANMW 221 with tapholes
7612982099908
ANMW 220 without tapholes
7612982099915
Accessories:
Strainer waste DN 32
7612982100178
Dome waste DN 32
7612982100161
Pop-up waste and overflow set DN 32*
7612982097812
RONDA triple washbasin
made of MIRANIT resin-bonded mineral material, colour Alpine White. With three seamless round bowls, flattened out at the rear, without overflow. Integral back panel with integrated brackets and holes for fixing. Rear contoured edge. Mounting material included (hanger bolts and dowels).
Length of triple washbasin: 2100
Bowl dimensions (ØxWxH): 540x380x90
Centre-to-centre distance of the bowls 700
Three-sided apron 60
ANMW 231 with tapholes
7612982099922
ANMW 230 without tapholes
7612982099939
Accessories:
Strainer waste DN 32
7612982100178
Dome waste DN 32
7612982100161
Pop-up waste and overflow set DN 32*
7612982097812
Example of a niche washbasin with laterally positioned bowl
QUADRO niche washbasin
made of MIRANIT resin-bonded mineral material, colour Alpine White. With one centrally positioned, seamless rectangular bowl, without overflow. Integral back panel in the bowl area, with integrated brackets and holes for fixing. Rear contoured edge. Mounting material included (hanger bolts, dowels and wall-connector brackets). The installer can use a disc grinder to adapt the length.
Length of washbasin: 700 to 1600
Bowl dimensions (LxWxH): 580x360x40/90
Front apron 60
Length 1300
ANMW 511 with taphole 7612982106538
ANMW 510 without taphole 7612982106545
Length 1600
ANMW 515 with taphole 7612982106552
ANMW 516 without taphole 7612982106569
Laterally positioned bowl, precise measurement production and side edgings available on request. Length of washbasin 700 to 1600mm .
Accessories:
Strainer waste DN 32 7612982100178
Dome waste DN 32 7612982100161
7612982097812
QUADRO niche washbasin
made of MIRANIT resin-bonded mineral material, colour Alpine White. With two seamless rectangular bowls, without overflow. Integral back panel in the bowl area, with integrated brackets and holes for fixing. Rear contoured edge. Mounting material included (hanger bolts, dowels and wall-connector brackets). The installer can use a disc grinder to adapt the length.
Length of washbasin: 1400 to 2100
Bowl dimensions (LxWxH): 580x360x40/90
Centre-to-centredistanceofthebowls700
Front apron 60
Length 2100
ANMW 521 with tapholes 7612982110108
ANMW 520 without tapholes 7612982106576
Precise measurement production and side edgings available on request.
Accessories:
Strainer waste DN 32 7612982100178
Dome waste DN 32 7612982100161
7612982097812
Example of a niche washbasin with laterally positioned bowl
RONDA niche washbasin
made of MIRANIT resin-bonded mineral material, colour Alpine White. With one centrally positioned, seamless round bowl, without overflow. Integral back panel in the bowl area, with integrated brackets and holes for fixing. Rear contoured edge. Mounting material included (hanger bolts, dowels and wall-connector brackets). The installer can use a disc grinder to adapt the length.
Length of washbasin: 700 to 1600
Bowl dimensions (ØxWxH): 540x380x90
Front apron 60
Length 1300
ANMW 551 with taphole 7612982106583
ANMW 550 without taphole 7612982106590
Length 1600
ANMW 555 with taphole 7612982106606
ANMW 556 without taphole 7612982106613
Laterally positioned bowl, precise measurement production and side edgings available on request. Length of washbasin 700 to 1600mm .
Accessories:
Strainer waste DN 32 7612982100178
Dome waste DN 32 7612982100161
Pop-up waste and overflow set DN 32* 7612982097812
RONDA niche washbasin
made of MIRANIT resin-bonded mineral material, colour Alpine White. With two seamless round bowls, without overflow. Integral back panel in the bowl area, with integrated brackets and holes for fixing. Rear contoured edge. Mounting material included (hanger bolts, dowels and wall-connector brackets). The installer can use a disc grinder to adapt the length.
Length of washbasin: 1400 to 2100
Bowl dimensions (ØxWxH): 540x380x90
Centre-to-centre distance of the bowls 700
Front apron 60
Length 2100
ANMW 561 with tapholes 7612982106620
ANMW 560 without tapholes 7612982106637
Precise measurement production and side edgings available on request.
Accessories:
Strainer waste DN 32 7612982100178
Dome waste DN 32 7612982100161
7612982097812
View
all measurements in mm
Type / Design
Code
LOTOS-R - single washbasin
made of resin-bonded MIRANIT mineral material, colour Alpine White, for wall installation with screws and dowels. With seamless round bowl, without tap landing and overflow. Outlet with dome waste DN 32. Mounting material included.
Dimensions (LxWxH): 600x547x100
RNDW 221
7612982098987
Accessories:
Pop-up waste and overflow set DN 32^
7612982097812
LOTOS-R - single washbasin
with tap landing and taphole 035mm made of resin-bonded MIRANIT mineral material, colour Alpine White, for wall installation with screws and dowels. With seamless round bowl form. Without overflow. Outlet with dome waste DN 32. Mounting material included.
Dimensions (LxWxH): 600x547x120
RNDW 226
7612982109287
Accessories:
Pop-up waste and overflow set DN 32^
7612982097812
LOTOS-H - single washbasin
made of resin-bonded MIRANIT mineral material, colour Alpine White, for wall installation with screws and dowels. With seamless hexagonal bowl, without tap landing and overflow. Outlet with dome waste DN 32. Mounting material included.
Dimensions (LxWxH): 600x525x100
RNDW220
7612982098994
Accessories:
Pop-up waste and overflow set DN 32^
7612982097812
Overview of MIRANIT Multiple Washing Systems and Niche Washing Systems
LOTOS single washbasins:
Multiple washbasins:
RONDA
QUADRO
Niche washbasins:
Franke Washroom Systems
franke.ws@franke.com
www.franke-ws.com
