BIZHUB C20P - Imprimante KONICA - Notice d'utilisation et mode d'emploi gratuit

Type de produit	Imprimante laser couleur multifonction
Marque	Konica Minolta
Modèle	Bizhub C20P
Dimensions (L x P x H)	469 x 536 x 385 mm
Poids	Environ 34,5 kg
Alimentation électrique	220-240 V, 50/60 Hz
Consommation électrique (impression)	550 W ou moins
Consommation électrique (veille)	140 W ou moins
Vitesse d'impression (A4)	Jusqu'à 24 ppm (couleur et noir)
Résolution d'impression	PhotoART 9600 (600 x 600 x 4 bits contone)
Processeur	500 MHz
Mémoire vive (RAM)	256 Mo standard, extensible à 768 Mo
Langages d'impression	PostScript 3, PCL 6, PCL 5e/c, XPS
Capacité papier (standard)	350 feuilles (250 + 100)
Capacité papier (max)	850 feuilles avec alimentation optionnelle
Grammage papier	60 à 210 g/m²
Impression recto-verso automatique	Oui, A4, 60-90 g/m²
Connectivité	Ethernet Gigabit, USB 2.0, parallèle IEEE 1284
Systèmes d'exploitation supportés	Windows 2000/XP/Vista (32/64), Mac OS X 10.2-4, Linux, Windows Server 2003
Fonctions principales	Impression directe TIFF/JPEG/PDF/XPS, impression sécurisée, filigrane, économie de toner
Sécurité	Impression sécurisée, filtrage IP, IPsec, IEEE 802.1x
Logiciels inclus	PageScope NetCare, Data Administrator, Direct Print Utility, Network Setup
Entretien et nettoyage	Nettoyer l'extérieur avec un chiffon doux et sec. Ne pas utiliser de solvants. Nettoyer les rouleaux avec une lingette non pelucheuse.
Pièces détachées et réparabilité	Les pièces détachées sont disponibles auprès des revendeurs agréés Konica Minolta. Consulter un technicien qualifié pour toute réparation.
Température de fonctionnement	10 à 35 °C
Humidité de fonctionnement	15 à 85 % HR (sans condensation)

FOIRE AUX QUESTIONS - BIZHUB C20P KONICA

Comment remplacer la cartouche de toner sur le Bizhub C20P ?

Ouvrez le capot avant, retirez la cartouche usagée en la tirant vers vous, insérez la nouvelle cartouche en alignant les guides, puis refermez le capot. L'imprimante reconnaît automatiquement la nouvelle cartouche.

Que faire en cas de bourrage papier fréquent ?

Vérifiez que le papier est bien inséré et qu'il n'est pas froissé. Ouvrez le couvercle anti-bourrage et retirez délicatement les feuilles coincées. Assurez-vous que les guides papier sont ajustés correctement. Si le problème persiste, nettoyez les rouleaux d'entraînement.

Comment installer les pilotes d'impression sous Windows ?

Téléchargez le pilote depuis le site Konica Minolta ou utilisez le CD fourni. Exécutez le programme d'installation, sélectionnez le type de connexion (USB ou réseau) et suivez les instructions à l'écran.

Comment configurer l'impression sécurisée (Secure Print) ?

Activez l'impression sécurisée dans les propriétés de l'imprimante. Saisissez un code PIN dans le pilote. Lors de l'impression, le document est mis en attente. Sur l'imprimante, allez dans le menu d'impression sécurisée et entrez le code pour libérer le travail.

Quel est le grammage maximal supporté par l'imprimante ?

Le grammage maximal est de 210 g/m² via le bac multifonction. Pour le bac standard, utilisez du papier de 60 à 90 g/m² pour une impression recto-verso automatique.

Comment nettoyer le scanner ou les vitres de l'imprimante ?

Utilisez un chiffon doux légèrement humide (eau distillée) pour nettoyer la vitre du scanner. N'utilisez jamais de produits abrasifs ou de solvants. Pour les rouleaux, utilisez une lingette non pelucheuse.

Mon imprimante n'imprime pas en couleur, que vérifier ?

Vérifiez que les cartouches de toner couleur ne sont pas vides. Dans le pilote, assurez-vous que le mode couleur est sélectionné. Consultez l'état de l'imprimante via PageScope pour voir les niveaux de toner.

Comment ajouter un bac inférieur supplémentaire ?

Le bac inférieur optionnel (capacité 500 feuilles) s'installe sous l'imprimante. Éteignez l'appareil, placez le bac sur une surface stable, positionnez l'imprimante dessus et allumez-la. Le bac sera automatiquement reconnu.

Comment réduire la consommation électrique en veille ?

Utilisez le mode économie d'énergie dans le menu des paramètres système. Vous pouvez programmer l'arrêt automatique après une période d'inactivité. L'imprimante consomme environ 140 W en veille et peut passer en mode sommeil.

L'imprimante affiche une erreur de disque dur, que faire ?

L'erreur peut provenir du disque dur optionnel. Essayez de redémarrer l'imprimante. Si l'erreur persiste, retirez et réinsérez le disque dur. Contactez un technicien agréé si le problème continue.

MODE D'EMPLOI BIZHUB C20P KONICA

bizhub C20P

Smart and powerful in colour and b/w

Fast, quiet, economic: quality in colour and b/w

Small teams, workgroups and single users will welcome the bizhub C20P as their perfect versatile printing partner. Featuring latest Emperor controller technology this compact printer leaves nothing to be desired when it comes to creating everyday office documents - especially as it's convincingly economic to use. Its stylish design, virtually silent operation and clever functionality make it an asset on everybody's desktop!

Thebizhub C20P is fast! It is ready to start after just 36 seconds warm-up and delivers 24 prints per minute in both colour and b/w. Via its built-in duplexer it produces immaculate double-sided prints at 100% productivity, saving on paper at the same time.
Thebizhub C20P delivers quality!Thanks to Simitri®HD toner its prints are beautifully sharp and crisp whether in colour or b/w. This makes it the ideal allrounder to produce any type of office document:coloured presentations,handbooks, illustrated reports and whatever else is needed.

The bizhub C20P is quiet! With its amazingly low operating noise, it can hardly be heard during production – paired with its small footprint that's ideal for a prominent desktop position. And its easy front access to paper trays and consumables means even more user convenience.

Configurations

Innovative technology, remarkable results

The bizhub C20P impresses its users with advanced technology and high flexibility. It integrates smoothly into existing setups anywhere, streamlining document output and enhancing the overall productivity of the team or workgroup.

Equipped with Kona Minolta's latest Emperor™ controller technology, the bizhub C20P features a 500 MHz page-processor plus standard 256 MB RAM. The Emperor™ system ensures compatibility with PostScript 3 and PCL 6 and enables seamless integration into virtually any network. Native support of XPS, Microsoft Vista's XML paper specification, is also provided². With Gigabit Ethernet and high-speed USB 2.0 support connecting the bizhub C20P is straightforward and efficient.
Thanks to the advanced capabilities of Dimitri® HD, Konica Minolta's high definition polymerised toner, thebizhub C20P delivers better-than-average print quality and high durability. A unique edge enhancement process sharpens the contours of text and graphics – the result is a crisp and clear printed image, whether in colour or b/w.
Its versatile media handling capabilities make thebizhub C20P a true professional when it comes to creating high-impact presentations, convincing reports, comprehensive manuals, business cards and more. Its standard 250-sheet paper tray is enhanced with a flexible 100-sheet multi-purpose tray via which up to 210 gsm paper can be fed. Where required, an optional lower paper feeder can increase the overall paper capacity to generous 850 pages.
Access limitation and volume tracking ensure transparency of use and facilitate cost control. Colour printing for example can be limited to certain users, which can help keep print costs in check¹. Secure printing is also available², enabling users to delay printing by first setting a password on their computer, which they then need to enter in the printer display to release their job. Full confidentiality is thus guaranteed.

Web-based device management is provided with PageScope Web Connection, informing users on the status and settings of the bizhub C20P right on their PC monitor. PageScope NetCare enhances the administrator support, providing fast access and simple monitoring on the network.

Simitri HD

High Definition Polymerised Toner

Designed for

Microsoft Windows XP Windows 2000

Technical specifications

Printer specifications

Printing system

Electrostatic laser print

Tandem, indirect

Toner system

Simitri HD polymerised toner

Print speed

Colour up to 24 ppm (A4)

Mono up to 24 ppm (A4)

1st print time

Colour 13 sec.

Mono 13 sec.

Warm-up time

Approx. 36 sec.

Print resolution

PhotoART 9600

(600 x 600 x 4-bit contone)

Controller CPU

500MHz

Page description language

PostScript 3

PCL 6 (XL3.0)

PCL 5e/c

XPS

Operating systems

Windows 2000/XP/XP64

Windows VISTA 32/64

Macintosh OSX 10.2,3,4

Server 2003/2003 x64

Linux: Redhat v9.0, SUSE v8.2

Interface

10-Base-T/100-Base-T/

1,000-Base-T Ethernet

USB 2.0

Bidirectional IEEE 1284 parallel

System specifications

Memory

Standard: 256 MB

Max.: 768 MB

Hard disc (optional)

40 GE

Paper size

A6-A4

Custom paper sizes

(92-216 mm x 148-356 mm)

Paper weight

60-210 gsm

Paper input capacity

Standard: 350 sheets

Max.: 850 sheets

Paper output capacity

Max.: 200 sheets face down standard

Automatic duplexing

A4

60-90 gsm

Power consumption

220-240V/50/60Hz

550 Watts or less (average printing)

140 Watts or less (average standby)

1.2 KW or less (max.)

System dimensions (W x D x H, mm)

469× 536× 385

System weight

Approx. 34,5 kg

System features

Print Functions

ICC profile/Simulation support

Direct print of TIFF, JPEG, PDF, XPS

USB direct printing of

TIFF, JPEG, PDF, XPS

Job programming "Easy Set" - storable

print settings

Overlay, Watermark

Toner save mode

Security

Secure Print - code protected

(with optional hard disc)

IP filtering

Ipsec (IPv6) support

IEEE802.1x

Software

PageScope NetCare

PageScope Data Administrator

PageScope Direct Print Utility

PageScope Network Setup

PageScope EMS plug-i

PageScope Plug and Print

PageScope NDPS Gateway

1 Optional CF card enables storing fonts/forms/overlays/colour-profiles, direct printing (PDF, TIFF and JPEG), Collating, Job Accounting and User/Department authentication. More than 1GB CF card is required for Collating.
2 Optional hard disc kit enables Secure printing, Proof-then-Print, Print & Hold, Job storing and XPS emulation in addition to all extra functions with CF card.
All specifications relating to paper capacity refer to A4-size paper of 80 gsm quality.
All specifications relating to printing speeds refer to A4-size paper that is printed crosswise in multipage, simplex mode.
The support and availability of the listed specifications and functionalities varies depending on operating systems, applications, network protocols as well as network
and system configurations.
The stated life expectancy of each consumable is based on specific operating conditions such as page coverage for a particular page size (5 % coverage of A4). The
actual consumables life will vary depending on the use and other printing variables including page coverage, page size, media type, continuous or intermittent printing, ambient temperature and humidity.
Some of the product illustrations contain optional accessories.
- Specifications and accessories are based on the information available at the time of printing, and are subject to change without notice.
Konica Minolta does not warrant that any prices or specifications mentioned will be error-free.
