Product Type	Backsplash (Crédence)
Brand	Smeg
Model	SPG9075VE
Material	Tempered glass
Width	90 cm
Height	75 cm
Thickness	6 mm
Weight	Approx. 8 kg
Color	Victoria (white with green trim)
Design	Retro 1950s style, glossy finish
Installation	Wall-mounted with adhesive or screws
Cleaning	Wipe with a damp cloth and mild detergent
Scratch Resistance	High (tempered glass)
Heat Resistance	Up to 150°C
Application	Behind hob or sink
Compatible Hobs	All standard sizes (60-90 cm)
Spare Parts Availability	Contact Smeg authorized service centers
Warranty	2 years (EU)
Certifications	CE, RoHS

Frequently Asked Questions - SPG9075VE SMEG

How do I clean the Smeg SPG9075VE backsplash?

Use a soft, damp cloth with mild detergent. Avoid abrasive cleaners or scouring pads to prevent scratches. Rinse with clean water and dry with a soft towel.

Is the backsplash heat resistant?

Yes, the tempered glass can withstand temperatures up to 150°C, making it suitable for use behind a hob.

Can I install this backsplash behind an induction hob?

Absolutely. The glass backsplash is compatible with all types of hobs, including induction, gas, and ceramic.

What are the dimensions of the SPG9075VE?

The backsplash measures 90 cm in width and 75 cm in height, with a thickness of 6 mm.

How do I install the backsplash?

It can be mounted using strong adhesive or screws (not included). Ensure the wall is clean, dry, and level before installation. For best results, consult a professional.

Is the glass backsplash safe?

Yes, it is made of tempered glass, which is strong and shatter-resistant. If broken, it cracks into small harmless pieces.

Can I cut the backsplash to size?

No, cutting tempered glass is not possible. Order the exact size needed or consult a specialist for custom solutions.

What is the weight of the backsplash?

It weighs approximately 8 kg, so ensure your wall can support this weight.

Are replacement parts available?

Yes, contact Smeg's customer service or an authorized dealer for spare parts or a replacement backsplash.

What color options are available for this model?

The SPG9075VE typically comes in 'Victoria' (white with green trim). Other colors may be available on request.

USER MANUAL SPG9075VE SMEG

Modern kitchen interior with black oven, stainless steel stove, and fluted vases (no visible text or symbols)

BEFORE STARTING:

• Read the checklist at the back of these instructions.
• Read the assembly guide overleaf.
• Check that you have all the tools needed (see overleaf).

FITTING STEPS – SPLASHBACKS / UPSTANDS

Isometric line drawing of a kitchen appliance with ovens and cabinetry (no text or symbols)

First check the dimensions.

Isometric line drawing of a kitchen appliance with stove and oven (no text or symbols)

Ensure the surface being fixed to is flat, non-porous, dry and dust free.

Hold up the back of the splashback/upstand to the worktop/wall to check fit. Use the spacers to achieve a good fit.

Two technical diagrams showing a flat panel mounted on a base and a folded panel mounted on a platform, with no visible text or symbols.

Take the splashback/ upstands away making sure to keep all corners safe from hard surfaces and then remove the covering from self adhesive backing. Fit the splashback on top of the spacers.

Place the bottom edge of the splashback/ upstand on the spacers, then push the splashback/ upstand to the wall and apply firm pressure evenly over the whole surface area. Ensure that a 2mm space is left. Finally (2-3 hours) remove spacers.

Seal the edges of the splashback/upstand with a bead of silicone sealant not less than 2.5 mm in thickness.

Isometric illustration of a kitchen interior with a stove and oven, showing a hand holding a glove near stairs (no text or symbols)

Complete the surrounding wall covering.

ASSEMBLY GUIDE - SPLASHBACKS / UPSTANDS

IMPORTANT

Unfitted glass is fragile. Do not place on hard surfaces prior to fitting. Special care should be taken with the corners of the product as impact will cause the product to crack.

CHECK LIST

• Do you have everything you need to start the job?
• Check that the splashback / upstands fits.
  • Is it the right colour?
• Ensure that your worktop is fitted securely.
• Check that your worktop is level.
• Clear all dust from the worktop.

- Ensure that your hob is fitted in accordance with the manufacturer's instructions.

- Make sure that your extractor is securely fitted in accordance with the manufacturer's instructions.

DO NOT

• Fit the splashback / upstands directly onto a hob or work surface - use spacers.
• Place the splashback / upstands on its edge or on any hard surface during the fitting process.
• Use the product until the silicone has cured (follow the manufacturer's instructions).

To prevent product failures ensure that:

• All fitting steps are completed.
• A space of 2mm is left between the product and all surfaces. The gaps must be filled with silicone.
• The surface to which the product is applied is flat, variations in level in excess of 5mm should be packed with silicone prior to fitting.
• You do not use any form of adhesive other than silicone as certain adhesives will degrade the finish of the glass.

SAFE HANDLING OF GLASS

All products are supplied with a safety packing but we recommend that glass is handled with care and in particular eye protection and suitable gloves should be worn.

AFTER CARE

Do not use abrasive cleaners. For the best results use hot water with a mild soap detergent.

BEFORE YOU START

• Check that all components are present.
• Ensure that you have all tools to hand.

TOOLS (NOT INCLUDED)

- Tape measure

- Sealant gun

- Silicone sealant

Only use Low Modular Neutral Cure Silicone (BS 5889 A)

- Packing shim (spacers) 2mm thick

Line drawing of a syringe with three different components (no text or symbols)

Pure geometric diagram of a parallelogram with internal lines and dots, no text or symbols present

Glass Splashbacks

Pure technical line drawing of a rectangular panel with internal slots, no text or symbols present

Glass Upstands

Drilling should only be undertaken by a suitably trained person with the correct machinery.
