| Product Type | Active Studio Monitor Speaker |
| Model | HQLM-3120W |
| Brand | Ikegami |
| Dimensions (H x W x D) | 320 mm x 220 mm x 280 mm |
| Weight | 7.5 kg |
| Power Output (RMS) | 100 W (50 W per channel, bi-amped) |
| Frequency Response | 50 Hz - 20 kHz (±3 dB) |
| Input Types | XLR balanced, TRS balanced, RCA unbalanced |
| Crossover Frequency | 2.5 kHz |
| Woofer Size | 6.5 inches (165 mm) |
| Tweeter Size | 1 inch (25 mm) silk dome |
| Enclosure Type | Bass-reflex (rear ported) |
| Protection | Overload, overcurrent, thermal |
| Power Supply | AC 100-240 V, 50/60 Hz |
| Power Consumption | 120 W max |
| Standby Power | <0.5 W |
| Supported Sampling Rates | Up to 192 kHz |
| Bit Depth | Up to 24-bit |
| Operating Temperature | 5 °C to 35 °C |
| Storage Temperature | -20 °C to 60 °C |
| Warranty | 2 years (subject to terms) |
Frequently Asked Questions - HQLM-3120W Ikegami
How do I connect the HQLM-3120W to my audio interface?
Use a balanced XLR or TRS cable from the interface output to the speaker input. Ensure both devices are powered off before connecting.
What is the recommended placement for the speaker?
Place the speakers at ear level and form an equilateral triangle with your listening position. Keep them away from walls to avoid bass buildup.
Can I use this speaker with a subwoofer?
Yes, connect the subwoofer between the audio source and the speakers using the outputs on your interface or a dedicated crossover.
How do I clean the speaker cabinet and grille?
Use a soft dry cloth for the cabinet. For the grille, gently vacuum with a brush attachment. Avoid liquid cleaners.
What should I do if the speaker produces no sound?
Check power, cable connections, volume, and that the audio source is active. Try a different cable or input.
Is there a standby mode to save power?
Yes, the speaker enters standby after 20 minutes of no signal. It wakes up automatically when an audio signal is detected.
Can I mount the HQLM-3120W on a wall or speaker stand?
Yes, the bottom has threaded inserts (M8) for standard speaker stands. Wall mounting requires a bracket (not included)
What are the optimal input level settings?
Set your audio interface to unity gain and adjust the speaker's input sensitivity trim to match. Aim for -10 dBV consumer or +4 dBu pro levels.
How do I reduce hum or noise from the speakers?
Ensure all cables are shielded and properly grounded. Avoid running audio cables parallel to power cables. Use balanced connections.
What replacement parts are available?
Contact Ikegami support for replacement woofers, tweeters, amplifier modules, and input boards. Do not attempt internal repairs yourself.
