CMXGSAMCN4216 - Saw Craftsman - Free user manual and instructions
Find the device manual for free CMXGSAMCN4216 Craftsman in PDF.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product Type | Sliding Compound Miter Saw |
| Brand | Craftsman |
| Model | CMXGSAMCN4216 |
| Blade Diameter | 12 inches (305 mm) |
| Motor Power | 15 Amps |
| No-Load Speed | 3,800 RPM |
| Bevel Capacity | 0 to 45 degrees left |
| Miter Capacity | 0 to 60 degrees left and right |
| Cutting Capacity (90°) | 2x12 lumber at 90° |
| Cutting Capacity (45° bevel) | 2x8 lumber at 45° |
| Weight | 42 lbs (19 kg) |
| Dimensions (L x W x H) | 20 x 24 x 18 inches |
| Power Source | Corded electric |
| Voltage | 120 V AC |
| Dust Collection | Dust bag included |
| Warranty | 3-year limited warranty |
| Blade Included | Yes, 12-inch carbide-tipped |
| Laser Guide | Built-in laser for alignment |
| Maintenance | Clean dust, lubricate moving parts |
| Safety Features | Electric brake, blade guard, trigger lock |
| Spare Parts Availability | Replaceable brushes, belts, and blades |
Frequently Asked Questions - CMXGSAMCN4216 Craftsman
What type of saw is the Craftsman CMXGSAMCN4216?
The Craftsman CMXGSAMCN4216 is a 12-inch sliding compound miter saw designed for crosscuts and miter cuts in wood and composite materials.
How do I change the blade on this saw?
To change the blade, first unplug the saw. Use the spindle lock to hold the blade, then loosen the arbor bolt with the provided wrench. Remove the old blade and install the new one, ensuring the teeth point downward. Tighten the arbor bolt securely.
What is the maximum cutting capacity at 90 degrees?
At 90 degrees, the saw can cut through 2x12 lumber (nominal) or up to 6-3/4 inches thick by 13-1/2 inches wide.
Does the saw come with a laser guide?
Yes, the CMXGSAMCN4216 includes a built-in laser guide to help align cuts. The laser requires two AAA batteries (not included).
How do I adjust the miter angle?
To adjust the miter angle, unlock the miter handle, rotate the table to the desired angle (up to 60 degrees left or right), and lock the handle. Positive stops are provided at common angles (0, 15, 22.5, 30, 45 degrees).
Is the saw corded or cordless?
The Craftsman CMXGSAMCN4216 is a corded electric saw that operates on 120V AC power, with a 15-amp motor.
What safety features does this saw have?
Safety features include an electric brake that stops the blade quickly, a transparent blade guard, and a trigger lock to prevent accidental starts.
How do I maintain the saw?
Regular maintenance includes cleaning dust from the blade guard and motor vents, lubricating sliding bearings with dry lubricant, and checking the blade for dullness. Replace the blade when cuts become rough.
What is the warranty period?
The Craftsman CMXGSAMCN4216 comes with a 3-year limited warranty against defects in materials and workmanship.
Can I use the saw for bevel cuts?
Yes, the saw can bevel from 0 to 45 degrees to the left. Adjust the bevel lock lever to set the angle, and ensure the sliding fence is properly positioned for bevel cuts.
