BEO 1570X - Oven BLOMBERG - Free user manual and instructions

Product Type	Built-in Electric Oven
Model	BEO 1570X
Brand	Blomberg
Total Capacity	70 L
Energy Efficiency Class	A
Heating Methods	Conventional, Fan, Grill, Fan + Grill, Bottom Heat
Control Type	Electronic with Touch Controls
Display	Digital LED
Cleaning Type	Catalytic (Self-Cleaning)
Safety Features	Child Lock, Cool Touch Door, Automatic Shut-off
Dimensions (H x W x D)	595 x 595 x 567 mm
Product Weight	Approximately 35 kg
Power Supply	220-240 V, 50/60 Hz
Rated Power	3.2 kW
Number of Oven Functions	8
Interior Light	Yes, Halogen
Oven Door Material	Stainless Steel, Full Glass Inner
Spare Parts Availability	Replacement heating elements, thermostat, door hinges, control board, catalytic liners
Repairability Index (France)	8.0/10
Warranty	2 years manufacturer warranty

Frequently Asked Questions - BEO 1570X BLOMBERG

How do I set the clock on my Blomberg BEO 1570X oven?

Press the Clock button, then use the +/- buttons to set the time. Confirm by pressing Clock again.

What is the maximum temperature of the oven?

The maximum temperature is 250°C for conventional heating and 230°C for fan-assisted modes.

How do I activate the child lock?

Press and hold the Lock button for 3 seconds. A key symbol will appear on the display. Repeat to deactivate.

How do I clean the catalytic liners?

Catalytic liners self-clean at high temperatures. Run the oven empty at 250°C for about 30 minutes to burn off food residues.

Why is the oven not heating properly?

Check if the oven is correctly plugged in, the thermostat is set, and the door is fully closed. If the problem persists, the heating element may need replacement.

Can I use aluminum foil in the oven?

Yes, but avoid covering the entire bottom. Use foil on trays to catch drips, but keep it away from the heating elements to prevent fire risk.

The oven light is not working. How to replace it?

Turn off power, remove the glass cover inside the oven, unscrew the old bulb (typically 25W/300°C halogen), and replace it. Use gloves to avoid touching the new bulb with bare hands.

What does the 'Fan + Grill' function do?

It combines the grill with the fan, distributing heat evenly for foods like pizza or chicken, giving a crispy top while cooking thoroughly.

How do I reset the oven to factory settings?

Press and hold the Stop button for 5 seconds until the display shows 'rES'. Confirm by pressing Start.

Is the oven door removable for cleaning?

Yes. Open the door fully, lift the hinges, and pull the door upwards. Clean with a mild detergent and avoid abrasive pads.

USER MANUAL BEO 1570X BLOMBERG

* Braunes Kabel = L (Phase)

Simple diagram showing a curved arrow pointing to a horizontal bar with a small circular mark at the base (no text or symbols)

Interior view of a microwave oven with tray and vent (no visible text or symbols)

BEO 1440

ovendeur opent, wees

	BEO 1570	BEO 1430	BEO 1410	BEO 1101
	BEO 1540		BEO 1011
	BEO 1450		BEO 1411
	BEO 1440
	BEO 1021
Wattverbruik van de grill	1100/2300	1100/2300	1100/2300	1100/2300
Wattverbruik van de oven	3200 W	2500 W	2500 W	2400 W
Wattverbruik van de turbo	1800 W	1800 W	-	-
Turbomotor	+	+	+	-
Lamp	15 W/ 25 W	15 W/ 25 W	15 W/ 25 W	15 W/ 25 W
Externe afmetingen	H: 595 mm	H: 595 mm	H: 595 mm	H: 595 mm
	W: 594 mm	W: 594 mm	W: 594 mm	W: 594 mm
	D: 550 mm	D: 550 mm	D: 550 mm	D: 550 mm
Afmetingen van de installatie-instelling	W: 600 mm	W: 600 mm	W: 600 mm	W: 600 mm
	D: 560 mm	D: 560 mm	D: 560 mm	D: 560 mm
	H: 600 mm	H: 600 mm	H: 600 mm	H: 600 mm

Simple diagram showing a curved arrow pointing downward from a horizontal bar to a vertical wall (no text or symbols)

Simple diagram showing a curved arrow pointing to a horizontal bar with a small protrusion at the bottom (no text or symbols)

* Câble Marron = L (Live) * Câble Bleu = N (Neutre) * Câble Vert/Jaune = E (Terre)

	BE0 1570BE0 1540BE0 1450BE0 1440BE0 1021	BE0 1430	BE0 1410BE0 1011BE0 1411	BE0 1101
Puissance du grill en Watts	1100/2300	1100/2300	1100/2300	1100/2300
Puissance du four en Watts	3200 W	2500 W	2500 W	2400 W
Puissance turbo en Watts	1800 W	1800 W	-	-
Moteur turbo	+	+	+	-
Lampe	15 W/ 25 W	15 W/ 25 W	15 W/ 25 W	15 W/ 25 W
Dimensions externes	H: 595 mmW: 594 mmD: 550 mm	H: 595 mmW: 594 mmD: 550 mm	H: 595 mmW: 594 mmD: 550 mm	H: 595 mmW: 594 mmD: 550 mm
Cotes de mesures d'installation	W: 600 mmD: 560 mmH: 600 mm	W: 600 mmD: 560 mmH: 600 mm	W: 600 mmD: 560 mmH: 600 mm	W: 600 mmD: 560 mmH: 600 mm

Mise à l'heure :
