Product Type	Freestanding Washing Machine
Model	WM 607SD
Brand	LERAN
Energy Class	A+++ (typical)
Capacity (kg)	6 kg
Maximum Spin Speed (rpm)	1200 rpm
Dimensions (H x W x D)	85 cm x 60 cm x 54 cm
Weight (kg)	Approx. 65 kg
Power Supply	220-240 V, 50 Hz
Rated Power (W)	2000 W
Water Connection	Cold water only
Number of Programs	15 (including Cotton, Synthetics, Delicates, Quick, etc.)
Noise Level - Wash (dB)	56 dB
Noise Level - Spin (dB)	78 dB
Display Type	LED
Child Lock	Yes
Overflow Protection	Yes
Self-Cleaning Drum	Yes
Detergent Drawer	3 compartments (main, pre-wash, softener)
Spare Parts Availability	Standard parts available via authorized service centers
Repairability Index (if applicable)	7.5/10 (estimated)

Frequently Asked Questions - WM 607SD LERAN

How to install the washing machine?

Remove all packaging and transport bolts. Place the machine on a sturdy, level surface. Connect the water inlet hose to a cold water tap and the drain hose to a standpipe or sink. Plug into a grounded outlet. Refer to the installation manual for detailed steps.

What does error code E01 mean?

Error E01 indicates a water supply issue. Check if the water tap is open and the inlet hose is not kinked. Also clean the inlet filter. If the problem persists, contact service.

How to clean the detergent drawer?

Press the release button inside the drawer and pull it out. Wash it under warm water using a soft brush. Dry thoroughly before reinserting. Clean the drawer compartment with a damp cloth.

Why is the machine not spinning?

Ensure the load is balanced and not too heavy. Check if the drain hose is blocked. Also verify that the spin speed is not set to 'No Spin'. If the problem continues, there may be a motor or belt issue.

Can I wash a duvet in this machine?

Yes, but only if the duvet is machine-washable and fits within the drum without overfilling. Use a gentle cycle with lower spin speed. Max capacity for bulky items is about 3 kg.

How to descale the machine?

Use a descaling agent specifically for washing machines. Run an empty hot water cycle (90°C) with the descaler. Alternatively, use a mixture of citric acid or vinegar for a natural option.

The machine is vibrating excessively. What to do?

Check that all transport bolts are removed. Ensure the machine is level on the floor. Adjust the leveling feet. Also avoid overloading or unbalanced loads.

How to unlock the door during a cycle?

Wait for the cycle to complete or press the Pause button. If the door remains locked due to water level or temperature, use the emergency drain hose to lower the water level. Refer to the manual for emergency unlock.

What is the recommended detergent?

Use high-efficiency (HE) detergent for front-load washers. Amount depends on load size and soil level. Avoid excess foam. For cold washes, use liquid detergent.

How to reset the machine?

Unplug the machine for 10 minutes, then plug it back in. Alternatively, press and hold the Start/Pause button for 3 seconds to reset the current cycle. For factory reset, see manual.

USER MANUAL WM 607SD LERAN

Simple line drawing of a circular mechanical component with a central hub and attached cable (no text or symbols)

Шланг подачи воды

Diagram showing a 3D box being inserted into a base with an inset magnified view of a mechanical component (no text or symbols)

Hand holding a tool inside a device with a circular component, no visible text or symbols

Simple line drawing of a washing machine with a crossed X mark on its side (no text or symbols)

Mechanical assembly diagram showing a wrench inserted into a housing component with a curved arrow indicating motion (no text or symbols present)

Diagram of a mechanical assembly with a rotating shaft and flanged components (no text or symbols)

Затяните гайку

Diagram of a mechanical assembly with a spring and pipe connection (no text or symbols)

Соединение готово

Diagram showing a faucet being adjusted to form a tap (no text or symbols present)

Line drawing of a kitchen sink with faucet and sink (no text or symbols)

Simple line drawing of a sweater with a tag and patterned tie (no text or symbols)

Line drawing of two fabric pouches with circular designs and ribbon handles (no text or symbols)

Line drawing of a money bag with a fish inside, placed on a grid background (no text or symbols)

Line drawing of a shirt with three arms and textured body (no text or symbols)

Simple line drawing of a basket with plastic bags and an open bag, showing a process with arrows indicating rotation (no text or symbols)

Сортируйте одежду

!

Hand holding a small object with an arrow pointing to a wall-mounted device (no text or symbols visible)

Подключить

Simple line drawing of a faucet with handle and base (no text or symbols)

Открыть кран

Simple line drawing of a mechanical component with no text or symbols

Загрузить белье

Simple line drawing of a hand holding a coiled cable or ring, with an arrow indicating rotation (no text or symbols)

Закрыть дверцу

Technical line drawing of a mechanical component with no visible text or symbols

Добавить порошок

Simple diagram of a circular flow with two curved arrows indicating clockwise motion (no text or symbols)

Выбрать программу

Hand pointing at four labeled buttons arranged in a rectangular frame (no text or symbols)

Выбрать функцию

Hand icon pointing at a button with a play symbol (no text or numbers)

Запустить

Line drawing of a hand cleaning a washing machine (no text or symbols)

Очистка барабана

Line drawing of a hand gripping a curved object (no text or symbols)

Line drawing of a mechanical device with internal compartments and a downward arrow indicating motion (no text or symbols)

Line drawing of a mechanical device with a handle and internal components (no text or symbols)

Line drawing of a hand using a tool to clean or store contents inside a rectangular frame (no text or symbols)

Technical line drawing of a mechanical or electronic component with internal compartments and a lever (no text or symbols)

Diagram showing a mechanical assembly with rotating arms and a base, no text or symbols present

Line drawing of a hand holding a connector with a cable (no text or symbols)

Illustration of a hand using a tool to adjust or install a component, with no visible text or symbols.

Line drawing of a hand holding a magnifying glass over a screen, with no visible text or symbols

Simple line drawing of a mechanical component with a circular feature and rotation arrow (no text or symbols)

Line drawing of a front-mounted toilet with a circular vent and base plate (no text or symbols)

Line drawing of a kitchen appliance with a plate, sink, and bowl (no text or symbols)

Hand holding a rotary knob on a device with directional arrows (no text or symbols)

Technical line drawing of a mechanical assembly with rotating components (no text or symbols)

Symbol of a trash bin crossed out by two crossed lines, with a solid black rectangle below (no text or labels)
