WMS 14085 WD - Washing machine LERAN - Free user manual and instructions

Product Type	Freestanding Front-Loading Washing Machine
Model	WMS 14085 WD
Brand	LERAN
Capacity	8 kg
Maximum Spin Speed	1400 rpm
Energy Efficiency Class	A+++ (Estimated)
Washing Efficiency Class	A
Spin Drying Efficiency Class	B
Annual Energy Consumption	Approximately 190 kWh
Annual Water Consumption	Approximately 10,500 L
Noise Level (Wash/Spin)	56 dB / 76 dB
Dimensions (H x W x D)	85 cm x 60 cm x 60 cm
Net Weight	72 kg
Power Supply	220-240 V ~ 50 Hz
Current	10 A
Number of Programs	16 (including Cotton, Synthetics, Delicates, Quick 15 min, etc.)
Additional Features	Delay Start, Child Lock, Load Sensing, Foam Control
Drum Material	Stainless Steel
Door Opening	Left hinge, 180° opening
Water Connection	Cold water only
Hose Lengths	Inlet: 1.5 m, Drain: 1.5 m
Self-Cleaning	Drum Clean program recommended monthly

Frequently Asked Questions - WMS 14085 WD LERAN

How do I properly install the washing machine?

Ensure the machine is on a solid, level floor. Remove all transport bolts using a wrench. Connect the water inlet hose to a cold water tap with a 3/4 inch thread, and the drain hose to a suitable drain or sink. Plug into a grounded outlet with 220-240V. Level the machine by adjusting the feet.

What detergent should I use for this model?

Use high-efficiency (HE) detergent suitable for front-loading machines. For cotton programs, use powder detergent; for synthetics or delicates, use liquid detergent. Avoid overdosing to prevent foam issues. Refer to the detergent manufacturer's instructions.

How can I clean the drum and prevent odors?

Run the 'Drum Clean' program monthly with an empty drum. Alternatively, use a washing machine cleaner or a cup of white vinegar. After each wash, leave the door and detergent drawer slightly ajar to dry. Clean the rubber seal gasket regularly with a damp cloth.

What does the error code 'E10' mean and how do I fix it?

Error E10 indicates a water inlet problem. Check that the water tap is fully open, the inlet hose is not kinked, and the filter at the water inlet valve (behind the machine) is clean. If the issue persists, the inlet valve may need replacement. Reboot the machine by unplugging for 30 seconds.

How often should I clean the filter?

Clean the drain pump filter every 2-3 months or if the machine displays a filter cleaning alert. Open the lower access panel, unscrew the filter cap, and remove any fluff or objects. Place a towel to catch water. Ensure the filter is securely tightened before use.

Can I wash a duvet or large bedding?

Yes, but ensure the duvet is suitable for machine washing. Use the 'Large Items' or 'Bedding' program (if available) or a synthetic program with a gentle spin. To balance the load, add a few towels. Do not exceed the machine's 8 kg capacity.

Why does the machine not spin properly?

Common causes: unbalanced load (redistribute clothes), drain hose blocked, or filter clogged. Check that the machine is level and not overloaded. If using a low spin speed program, select a higher speed. Also ensure the drain pump filter is clear.

How do I use the delay start function?

Select a washing program and adjust any settings. Press the 'Delay' button repeatedly to set the delay time (e.g., 3 hours). The machine will start automatically so that it finishes at the desired time. Confirm the door is closed, then press Start. You can cancel the delay by turning the dial to Off.

What maintenance should I perform regularly?

Monthly: run a drum clean cycle, clean the door seal, and check the inlet hose for leaks. Every 3 months: clean the drain pump filter and the detergent drawer. Annually: inspect the water inlet filter and replace the hose if worn. Also verify the machine is level.

How can I reduce energy consumption?

Wash at lower temperatures (30-40°C) for most loads. Use the 'Eco' program for cotton. Load the machine fully but not overstuffed. Clean the filter regularly to maintain efficiency. Avoid pre-wash unless heavily soiled. Use the half-load setting if applicable.

USER MANUAL WMS 14085 WD LERAN

Diagram showing a box with an arrow pointing upward and a magnified inset of a mechanical component (no text or symbols)

Diagram of fluid flow around a valve with an arrow indicating direction (no text or labels)

Mechanical assembly diagram showing a wrench and nut assembly with a curved arrow indicating motion (no text or symbols)

Diagram of a pipe joint being inserted into a flanged housing with a circular arrow indicating rotation (no text or symbols)

Затяните гайку

Diagram of a mechanical or electrical component with a coiled spring and upward arrow indicating motion (no text or symbols)

Соединение готово

Diagram showing a faucet being adjusted to its base, with no text or symbols present

Line drawing of a kitchen sink with faucet and chain (no text or symbols)

Сортировка белья

Illustration of a bag with a broken leg and a small object inside, set against a grid background (no text or symbols)

Hand using a compass to adjust or install an electrical outlet (no text or symbols visible)

Подключить

Line drawing of a faucet with handle and valve (no text or symbols)

Открыть кран

Simple line drawing of a rabbit inside a circular frame with an arrow indicating rotation (no text or symbols)

Загрузить белье

Hand holding a coiled rope with an arrow indicating rotation (no text or symbols)

Закрыть дверцу

Добавить порошок

Включить

Simple diagram showing a circular flow with two curved arrows indicating clockwise motion (no text or symbols)

Выбрать программу

Выбрать функцию

Hand pointing at a button with a play symbol and double vertical line (no text or numbers)

Запустить

Примечание:

Line drawing of a mechanical component with labeled section A (no text or symbols beyond label)

Извлеките лоток, нажав на «стрелку»и потянув

Simple line drawing of a boat with a person standing on top, no text or symbols present

Line drawing of a hand inserting a small object into a container (no text or symbols)

Line drawing of a refrigerator interior with drawer and door (no text or symbols)

Diagram of a mechanical device with rotating components and a cylindrical base (no text or symbols)

Line drawing of a hand holding a tool with a circular component inserted (no text or symbols)

Hand holding a tool interacting with a mechanical component (no text or symbols visible)

Simple line drawing of a hand inserting a device into a box (no text or symbols)

Simple line drawing of a mechanical component with arrows indicating direction (no text or symbols)

Hand holding a rotary knob on a device panel, with no visible text or symbols

Diagram of a pipe valve mechanism with rotating arrows indicating flow direction (no text or labels)

Symbol of a trash bin crossed with a diagonal line, no text or numbers present

	10.0	10.0
	10.0	10.0
	10.0	10.0
	10.0	10.0
	10.0	10.0
	10.0	10.0
	10.0	10.0
	10.0	10.0
	10.0	12.5
	10.0	12.5
	10.0	12.5
	10.0	12.5
	10.0	12.5
	10.0	12.5
	10.0	12.5
	10.0	12.5
	10.0, 12.5, 13.5, 14.5, 15.5, 16.5, 17.5, 18.5, 19.5, 20.5, 21.5, 22.5, 23.5, 24.5, 25.5, 26.5, 27.5, 28.5, 29.5, 30.5, 31.5, 32.5, 33.5, 34.5, 35.5, 36.5, 37.5, 38.5, 39.5, 40.5, 41.5, 42.5, 43.5, 44.5, 45.5, 46.5, 47.5, 48.5, 49.5, 50.5, 51.5, 52.5, 53.5, 54.5, 55.5, 56.5, 57.5, 58.5, 59.5, 60.5, 61.5, 62.5, 63.5, 64.5, 65.5, 66.5, 67.5, 68.5, 69.5, 70.5, 71.5, 72.5, 73.5, 74.5, 75.5, 76.5, 77.5, 78.5, 79.5, 80.5, 81.5, 82.5, 83.5, 84.5, 85.5, 86.5, 87.5, 88.5, 89.5, 90.5, 91.5, 92.5, 93.5, 94.5, 95.5, 96.5, 97.5, 98.5, 99.5, 100 .
