F22B7000E - Television DEXP - Free user manual and instructions
Find the device manual for free F22B7000E DEXP in PDF.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product Type | LED Television |
| Brand | DEXP |
| Model | F22B7000E |
| Screen Size | 22 inches (55.9 cm) |
| Resolution | HD Ready (1366 x 768 pixels) |
| Display Technology | LED |
| Refresh Rate | 60 Hz |
| Dimensions (with stand) | 51.5 x 32.0 x 15.0 cm |
| Dimensions (without stand) | 51.5 x 30.5 x 4.5 cm |
| Weight (with stand) | 3.0 kg |
| Weight (without stand) | 2.8 kg |
| Power Consumption (typical) | 30 W |
| Power Consumption (standby) | < 0.5 W |
| Power Supply | AC 100-240 V, 50/60 Hz |
| Inputs | 2x HDMI, 1x USB 2.0, 1x VGA, 1x AV (composite), 1x RF (antenna) |
| Outputs | 1x Audio Out (3.5 mm), 1x Headphone Jack |
| Speakers | 2 x 3 W |
| Remote Control | Included (CR2025 battery) |
| Wall Mount | VESA 100 x 100 mm |
| Stand Type | Desktop stand (included) |
| Compliance | CE, RoHS, ErP |
| Cleaning Instructions | Wipe with a soft, dry cloth; do not use water or cleaning agents |
| Safety Certifications | IEC 60065, EN 55013 |
| Repair Information | Contact authorized service center; do not open the device |
Frequently Asked Questions - F22B7000E DEXP
How do I connect my laptop to the TV?
Use an HDMI cable. Connect one end to your laptop's HDMI port and the other to any HDMI port on the TV. Then, press the Source button on the remote and select HDMI.
Why is there no picture when I turn on the TV?
Check that the power cable is plugged in and the TV is switched on. Ensure the correct input source is selected. If using an antenna, verify the antenna connection and try a channel scan via the Menu.
How do I clean the TV screen?
Turn off the TV and let it cool. Use a soft, dry microfiber cloth to gently wipe the screen. Do not use water, alcohol, or abrasive cleaners, as they can damage the screen.
Can I mount the TV on a wall?
Yes, the TV is VESA compatible (100 x 100 mm). Use a suitable wall mount kit designed for this size and weight. Follow the instructions provided with the mount.
How do I perform a factory reset?
Press the Menu button on the remote, go to Settings > System > Factory Reset. Select Yes and confirm. This will erase all custom settings and data.
What should I do if the remote control stops working?
Check the battery compartment and replace the CR2025 battery if needed. Ensure there are no obstacles between the remote and the TV's sensor. If still not working, try resetting the TV by unplugging it for 30 seconds.
How do I connect USB devices?
Insert a USB flash drive into the USB port on the TV. Use the remote to select USB from the Source menu. The TV will automatically detect media files (photos, music, videos) and display them.
Can I use headphones with the TV?
Yes, plug your headphones into the 3.5 mm headphone jack on the side of the TV. The TV speakers will automatically mute when headphones are connected.
Is the TV energy efficient?
The TV consumes 30 W during typical operation and less than 0.5 W in standby mode. It complies with ErP standards for energy efficiency.
Where can I find the user manual for this TV?
The user manual is available for free download on notice-facile.com in PDF format. It contains detailed setup instructions, troubleshooting tips, and specifications.
User questions about F22B7000E DEXP
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
No questions yet. Be the first to ask one.
Download the instructions for your Television in PDF format for free! Find your manual F22B7000E - DEXP and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. F22B7000E by DEXP.
USER MANUAL F22B7000E DEXP
3
Описание функций
Меню изображения
Прочие функции
