BTB2312 - Food processor Becken - Free user manual and instructions

Type	Food Processor
Brand	Becken
Model	BTB2312
Power	800 W
Bowl Capacity	2.0 L
Speed Settings	2 speeds + pulse
Pulse Function	Yes
Blade Material	Stainless steel
Bowl Material	BPA-free plastic
Safety Lock	Lid lock mechanism
Overload Protection	Yes
Non-Slip Feet	Yes
Cord Length	1.2 m
Dishwasher Safe Parts	Bowl, lid, blades
Dimensions (L x W x H)	30 x 25 x 40 cm
Weight	4.0 kg
Accessories Included	Chopping blade, slicing disc, shredding disc, dough blade
Color	White/Black

Frequently Asked Questions - BTB2312 Becken

How do I assemble the food processor?

Place the bowl on the base and turn clockwise to lock. Insert the desired accessory onto the shaft, then close the lid and lock it. Finally, plug in and select speed.

Can I process hot ingredients?

No, allow ingredients to cool to room temperature before processing. Hot ingredients can damage the bowl and cause leaks.

Why does the appliance stop during use?

The overload protection may activate if the motor is strained. Turn off, unplug, and reduce the load. Let it cool for a few minutes before restarting.

How do I clean the parts?

Remove the bowl, lid, and accessories. Wash them in warm soapy water or place on the top rack of the dishwasher. Wipe the motor base with a damp cloth. Do not immerse the base in water.

What is the maximum capacity for dry ingredients?

Do not fill the bowl more than half full for dry ingredients like flour or nuts to ensure proper mixing and avoid motor strain.

Can I crush ice with this food processor?

Yes, using the pulse function. Add ice cubes gradually and pulse in short bursts. Do not run continuously.

How do I replace the blade or disc?

Always unplug the appliance. Remove the lid, then pull the accessory straight up. To install, align the slot and push down until it clicks into place. Be careful of sharp edges.

Is the bowl microwave safe?

No, the bowl is not microwave safe. Only use it with the food processor base.

What should I do if the lid doesn't lock?

Ensure the bowl is correctly seated and the lid aligns with the locking mechanism. Check for obstructions. Do not force it.

Where can I buy spare parts?

Contact Becken customer service or visit the official website. Use only genuine Becken accessories to ensure safety and performance.

USER MANUAL BTB2312 Becken

Easy Juicer Easy Juicer

MANUAL DE INSTRUÇÕES

Dear client,

Thank you for purchasing this product.

The quality of this appliance has been certified by several laboratory tests. This instructions manual is provided to simplify the use of the appliance as well as to guarantee a safe use.

Please read carefully the instructions and safety measures described in this manual.

We sincerely hope you will be satisfied when using your new appliance.

INDEX

1. SAFETY INSTRUCTIONS 4

1.1. Power Supply 5
1.3. Humidity and Water 5
1.4. Cleaning 6
1.5. General Precautions 6

1.2. Power Cord and Other Cables 5

2. OPERATING INSTRUCTIONS 7

2.1. Product Description 7
2.2. Using the Product 8
2.3. Maintenance 9

3. POST-SALE SERVICE 10

4. ENVIRONMENTAL PROTECTION 10

1. SAFETY INSTRUCTIONS

	WARNING
	RISK OF ELECTRIC SHOCKDO NOT OPEN
Warning: to avoid the risk of electric shock, do not remove the cover. The interior does not contain any parts that can be repaired by the user. Ask for assistance from qualified personnel.

Important Warnings

Before using your appliance read this instructions manual carefully and keep it in a safe place as you may need to consult it in the future.

Before turning on your appliance, and to ensure a safe and correct operation, do not use if:

• It has fallen to the ground;
- You notice any evidence of damage;
- Any anomaly occurs during its operation.

To avoid hazards or deterioration of your appliance through incorrect use it is advisable to read these instructions thoroughly.

Your appliance may not be used for other purposes than the ones intended and solely for household use. Any damage resulting from using the appliance outside this scope, any incorrect use, as well as any manual modifications to the product will not be covered and automatically voids the warranty.

[you can trust]

Assistance

In case of malfunction, take your appliance to a qualified technician for assistance.

This appliance can be used by children from the age of 8 and by people with reduced physical, sensorial or mental capabilities and/or lack of experience and knowledge if they have been given instructions on using the appliance safely and if they understand the hazards involved. Children may not play with the appliance. Cleaning and maintenance must not be carried out by children without supervision.

These instructions are also available at www.suporteworten.pt

1.1. Power Supply

Make sure the main voltage is compatible with the appliance's. If this is not the case please consult the Customer Support Service.

1.2. Power Cord and Other Cables

Do not tangle the cord or pull it to disconnect the appliance. Also, keep the cord away from warm surfaces.

Never use the appliance if it has a damaged cable or socket.

Take it to the Technical Support Service for replacement.

1.3. Humidity and Water

Do not use your appliance in humid places. Do not allow the appliance to become wet under any circumstances as this may be dangerous. To avoid fire hazard or electric shock do not expose your appliance to humidity or water. Furthermore, do not place your appliance under water (e.g. for cleaning).

Before cleaning, be sure to switch off the appliance and remove the plug from the main power supply. Always allow the unit to cool down before cleaning.

To clean the exterior of the product use a dry soft cloth only.

1.5. General Precautions

• Please follow the instructions in the user manual which help to properly install and operate this product and enjoy its advanced features. Please keep the instructions for future reference.
• Read all instructions before using the product.
• Maintenance and service operations are only to be carried out by authorized professionals.
• Any damage caused by manual modifications to the product is not covered by the warranty.
• If this product is used for other purposes than the ones originally intended, or if it is not correctly connected, the product may become damaged and the warranty will be voided.

[you can trust]

2. OPERATING INSTRUCTIONS

2.1. Product Description

Key parts name and location

1 Top cover
2 Mixing cup cover
3 Mixing cup
4 Sealing ring
5 Mixing blade
6 Mixing blade holder
7 Rotor
8 Main machine
9 Position switch

Features

1. The machine can be used for all your blending and grinding needs.
2. Of simple and refined design, this beautiful, integrated structure is easy to operate and to clean.
3. High rotating speed electrical machinery with overheat protection, high efficiency, time and energy saving, increase service life for electrical machinery.
4. Safety lock device ensures safe and reliable operation.

1. The machine has a safety protection device. The electrical machine does not work is not properly locked into position or if the blade holder is not screwed in tightly.
2. Please check if the power supply is according to the rated voltage before using the appliance in order to avoid injuries.
3. Clean all dismountable parts (refer to "Maintenance and clean")
4. Please read carefully the "Key parts name and location" section for assembling.
5. Please read carefully the "Instruction" section before use.

Operation time

The machine has a O position, a I position, a II position and a P button switch (O is to stop, I is weak, II is strong and P for pulse function). Select the pulse function and strong function for meat blending, mincing, and grinding. Process for 10 seconds and then stop for 5 seconds, turn on the machine after 1 minute rest when processing for one minute. Select the pulse or strong functions for blending vegetables, fruits and soybean milk. Select weak function for mixing eggs. Select strong function for preparing juices. Let the machine rest for 15 minutes when the above mentioned jobs are done three times consecutively. Turn on the machine again after the electrical machinery cools down. This way, we can prolong the appliance's useful life.

Blending

1. Firstly, check if the pulse switch is off (if the switch is restored to the origin position)
2. Place the sealing ring into the mixing blade, and then screw the mixing cup tightly into the mixing blade holder. (Lock tightly

[you can trust]

clockwise and loose anti clockwise) Cover the mixing cup and the mixing cup cover.

1. Hold the blade holder and screw it clockwise into the main machine. Don't hold the mixing cup to dismantle it, otherwise it will disconnect from the mixing blade and the food inside the mixing cup will burst.

Stirring eggs

Put the eggs into the mixing cup and an appropriate amount of hot water. Add some flour. Cover the mixing cup lid tightly. Press the weak position switch for about one minute.

Stirring vegetables and fruits

Peel fruit and vegetables, remove the pits/seeds and dice them. Add 250 g - 350 g of it and an appropriate amount of hot water. Assemble according to assembling and use instruction, then turn on the machine.

2.3. Maintenance

1. We recommend you use the appliance often in order to keep the electric machinery dry.
2. Store the appliance in a dry place to avoid electric components getting wet and mouldy.
3. Don't flush the main machine with water. Wipe it clean with a wet cloth. Other parts, like the fruit pusher, the top cover, the middle holder, the mixing cup, etc, can be washed with water.
4. It is recommended to dismantle the blade from the mixing cup. Place some food oil onto the blade shaft and bearings for lubrication.
5. When cleaning the mixing cup, add warm water and detergent to the mixing cup, lock it into position on the rotor, cover the cup lid and switch it on. Leave it on for 30 seconds then rinse it with running water.

BECKEN has designed this appliance in order to guarantee maximum reliability. However, if a problem occurs do not attempt to open the appliance - there is a risk of electrical shock. If you are not able to solve the problem, please contact the Costumer Support Service of any Worten, Modelo or Continente store in order to be assisted. Worten Equipamentos para o Lar provides a 2-year warranty for manufacturing defects from the date of purchase of the appliance.

WARNING: Any attempt to repair the appliance without contacting the manufacturer or seller will void the warranty.

All users must be familiar with these instructions. Knowing what could go wrong can help prevent problems from occurring.

4. ENVIRONMENTAL PROTECTION

In order to protect the environment we strive to reduce the volume of packaging used, limiting it to three easily sorted materials: cardboard, paper and plastic. The appliance is manufactured using recyclable materials after disassembled by a specialized company. Please comply with local regulations concerning the recycling of all materials.

Symbol of a trash bin crossed with no visible text or numbers, accompanied by a black rectangular base (no text or symbols)

[you can trust]

Solid red vertical bar with no text or symbols

Symbol of a waste bin with no text or numbers, crossed by two diagonal lines and a solid black rectangle below (no text or symbols present)

[you can trust]

Solid pink vertical bar with no text or symbols

Symbol of a trash bin crossed with no visible text or numbers

[you can trust]

Solid red vertical bar with no text or symbols

Imported, produced and distributed by:

Worten Equipamentos p/o Lar S.A.
