UPS-LIT20MD - Inverter Mach Power - Free user manual and instructions

Product Type	Uninterruptible Power Supply (UPS)
Model	UPS-LIT20MD
Brand	Mach Power
Power Capacity	600 VA / 360 W
Input Voltage	220-240 VAC
Output Voltage	220-240 VAC (regulated)
Frequency	50/60 Hz (auto-sensing)
Waveform	Simulated sine wave
Battery Type	Sealed lead-acid, 12V / 7Ah
Backup Time (half load)	Approximately 15 minutes
Backup Time (full load)	Approximately 5 minutes
Charging Time	6-8 hours to 90% capacity
Automatic Voltage Regulation (AVR)	Yes
Surge Protection	Yes, built-in
Overload Protection	Yes
Short Circuit Protection	Yes
Cold Start	Yes (DC start without mains)
Communication Port	USB (for monitoring)
Dimensions (W x H x D)	140 x 85 x 280 mm
Weight	Approximately 4 kg
Operating Temperature	0°C to 40°C
Noise Level	< 40 dBA
Maintenance	Keep clean; replace battery every 3-5 years
Safety Certifications	CE, RoHS

Frequently Asked Questions - UPS-LIT20MD Mach Power

How do I connect my devices to the UPS?

Connect your critical devices (computer, monitor, router) to the battery-backed outlets. Avoid connecting surge protectors or power strips to the UPS.

What should I do if the UPS beeps continuously?

A continuous beep indicates the battery is low or the UPS is on battery. If the power is out, save your work and shut down. If power is on, check the power cable and try resetting the UPS.

Can I use the UPS with a power strip?

It is not recommended to connect a power strip to the UPS, as it may overload the UPS. Instead, plug devices directly into the UPS outlets.

How long does the battery last?

Under normal use, the battery lasts about 3-5 years. The actual lifespan depends on usage frequency and ambient temperature.

What is the backup time for my UPS?

At half load (180W), expect about 15 minutes. At full load (360W), about 5 minutes. Actual time varies based on connected equipment.

How do I replace the battery?

The battery is user-replaceable. Disconnect the UPS from mains, open the battery compartment, disconnect the old battery, and connect a new 12V/7Ah battery. Refer to the manual for details.

What does the AVR function do?

Automatic Voltage Regulation stabilizes the output voltage without switching to battery, protecting your devices from voltage fluctuations.

Can the UPS be used for medical equipment?

No, this UPS is designed for standard electronic devices like computers and peripherals. Do not use with life-support or medical equipment.

Why does the UPS not power on when pressing the button?

Ensure the UPS is connected to a working wall outlet. If the battery is completely discharged, plug it in and let it charge for at least 6 hours before attempting to power on.

How do I clean the UPS?

Unplug the UPS and wipe the exterior with a dry cloth. Do not use liquid cleaners or spray directly onto the device. Ensure vents are free of dust.

USER MANUAL UPS-LIT20MD Mach Power

Manufacturer's name and address Mach Power Italy s.r.l.

Via Alberigo Albricci, 8 – 20122 Milano (MI)

declare under our responsibility that the products:

Descrizione

Description

Uninterruptible Power Supply

Codice Prodotto

Item number

UPS-LIT60P, UPS-LIT80P, UPS-LIT10P, UPS-LIT13M, UPS-LIT20MD, UPS-LIR60D, UPS-LIR12D

Marca

Trademark

Parametri

Parameters

AC 220-240V 50/60Hz

They comply with the provisions of the following Community directives and related harmonized or national standards applied.

EMC Directive 2014/30/EU

EN 62040-2:2006, EN 61000-3-2:2014, EN 61000-3-3:2013

LVD Directive 2014/35/EU

EN 62040 1:2008 +A1: 2013

RoHS Directive 2011/65/EU and 2015/863/EU

IEC 62321-1:2013, IEC 62321-3-1:2013, IEC 62321-4:2013+A1:2017, IEC 62321-5:2013, IEC 62321-6:2015, IEC 62321-7-1:2015, IEC 62321-1-7-2:2017, IEC 62321-8:2017.

Based on the performed tests on submitted samples, the results of Pb, Cd, Hg, Cr(VI), PBBs, PBDEs, DPB, BBP, DEHP, DIBP comply with the limits as set by EU RoHS Directive 2011/65/EU and its amendment Directive EU 2015/863 (RoHS 2.0).

On condition that they are used with their intended purpose and/or in accordance with the current installation standards and/or with the manufacturer's specifications.

Luogo e Data

Milano 04/03/2020
