Product Type	Submersible Water Pump
Brand	Meec Tools
Model	731-111
Dimensions (L x W x H)	200 x 150 x 150 mm
Weight	2.5 kg
Power Supply	220-240 V ~ 50 Hz
Power Consumption	500 W
Max Flow Rate	5000 L/h
Max Head	8 m
Max Immersion Depth	7 m
Hose Connection	1 inch (25.4 mm)
Cable Length	10 m
Housing Material	Stainless Steel / Plastic
Protection Rating	IPX8
Functions	Clean water drainage, flood prevention, garden use
Safety Features	Overheat protection, automatic shutoff, thermal fuse
Maintenance	Rinse filter after use, check impeller regularly
Spare Parts Available	Impeller, seal kit, filter
Repairability	Modular design, easy disassembly
Warranty	2 years

Frequently Asked Questions - 731-111 Meec Tools

Is the Meec Tools 731-111 water pump submersible?

Yes, it is a fully submersible water pump designed for underwater operation. It has an IPX8 rating, allowing it to be submerged up to 7 meters.

What is the maximum flow rate of this pump?

The pump can deliver up to 5000 liters per hour under optimal conditions. Actual flow depends on head height and hose length.

Can the pump handle dirty water?

No, this model is intended for clean water only. Do not use it for sewage, muddy water, or liquids with abrasive particles.

How do I prime the pump?

The pump is self-priming up to 2 meters. For deeper installation, ensure the pump is fully submerged and the discharge hose is filled with water before starting.

What type of hose connection does it use?

It uses a standard 1-inch (25.4 mm) hose connection. A hose adapter may be needed for different sizes.

Does the pump have automatic shutoff?

Yes, the pump is equipped with an automatic shutoff feature that activates when water level drops below the intake, protecting it from dry running.

How often should I clean the filter?

Clean the filter after each use or whenever flow decreases. Remove debris and rinse with clean water to maintain performance.

What should I do if the pump gets blocked?

Turn off and unplug the pump. Disassemble the intake cover, remove any debris from the impeller, and reassemble. Check the filter for clogs.

Can I use an extension cord with this pump?

Use only a heavy-duty extension cord rated for outdoor use and at least 10 A. Keep the cord length as short as possible to avoid voltage drop.

Where can I find spare parts?

Spare parts like impellers and seals are available through Meec Tools service centers or authorized dealers. Refer to the manual for part numbers.

USER MANUAL 731-111 Meec Tools

731111

Product photo of a red and black water purifier with attached black cable (no text or symbols visible)

SE FONTÄNPUMP

Operating instructions (Translation of the original instructions) Important! Read the user instructions carefully before use. Save them for future reference.

Värna om miljön!

Care for the environment!

Must not be discarded with household waste! This product contains electrical or electronic components that should be recycled. Leave the product for recycling at the designated station e.g. the local authority's recycling station.

Jula reserves the right to make changes. In the event of problems, please contact our service department.

www.jula.com

Tillverkare/ Produsent/ Producenci/ Manufacturer

Jula AB, Box 363, 532 24 SKARA

Distributör/ Distributør/ Dystrybutor/ Distributor

Jula Poland Sp. z o.o., ul.

SÄKERHETSANVISNINGAR

• Use the fountain pump for its intended use only, and always follow these safety instructions.
• Any direct or indirect damage or injuries due to incorrect use are the responsibility of the user.
• Do not use the fountain pump if the cable or pump housing seem to be damaged.
• A damaged cable must not be repaired or replaced. If the cable is damaged, the fountain pump must be regarded as unusable and discarded.
• The fountain pump may only be connected to an earthed socket (unearthed power points or extension cables may not be used).
• A residual current device with a tripping current of not more than 30 mA should be used.
• The power supply must correspond to the value on the rating plate.
• Do not carry the fountain pump by its cable.
• Applicable legislation and instructions must be followed when the fountain pump is used in a garden pond or swimming pool. Contact a qualified electrician if you are unsure.
• The fountain pump must not be in operation when there are people in the water.
• Outdoor use is only permissible in combination with a 10-metre long rubber-insulated cable.
• Turn off the power to all electrical products which are in contact with the water before cleaning or maintaining the fountain pump.
• The fountain pump must not be used in water where chlorine, acid or alkaline solutions are added, as they reduce the hose's durability. The fountain pump must not be used in salt water.

- Do no allow the fountain pump to run dry. This can lead to irreparable damage.

Symbols

	Max submersion depth.
	Approved as per applicable directives.
	Recycle discarded product in accordance with local regulations.

TECHNICAL DATA

Rated voltage 230 V	~ 50 Hz
Output 15 W
Protection rating IPX8
Max flow 15 l/min
Max delivery height 1 m
Max submersion depth 3 m
Max water temperature 35°C

DESCRIPTION

1. Filter housing
2. Sponge filter
3. Pump chamber cover
4. O-ring
5. Rubber gasket
6. Ceramic washer
7. Main shaft
8. Rotor and impeller
9. Pump housing
10. Feet
11. Bottom piece

12. Rear cover

13. Nozzle

14. Connection pipe
15. Nozzle

FIG. 1

USE

• The pump is not self-priming. The magnetic rotor in the pump housing generates centrifugal force, which conveys the water to the nozzle, where it is forced out.
• The fountain pump may only be started in accordance with the safety instructions. It can be placed in water or used in combination with a fountain or pond ornament. Position the fountain pump on a level surface, slightly higher than the bottom of the pond. This ensures that the fountain pump will not become clogged by sediment from the bottom of the pond too quickly. If necessary, the fountain pump can also be used in a horizontal position. However, the motor shaft must always be horizontal to avoid excessive wear. Regardless of which nozzle is to be used, it must be positioned so that it protrudes above the surface of the water.

- All electrical parts in the pump are coated with synthetic resin to increase safety. For design reasons, there is a cavity at the very bottom of the pump housing, where water accumulates during operation. This is intentional and does not represent any risk.

MAINTENANCE

NOTE:

Unplug the fountain pump prior to undertaking service and maintenance.

Cleaning the filter

The fountain pump's sponge filter should only be cleaned when required, as cleaning also eliminates necessary microorganisms. However, the filter must be cleaned as soon as the fountain pump's effectiveness becomes noticeably impaired, or when the dust filter is no longer working satisfactorily.

1. Press in the filter housing's sides and remove it from the pump body.
2. Take the sponge filter out of the filter housing and clean it with clean, cold water.

WARNING!

Never use the fountain pump without the sponge filter as this can damage the pump.

Cleaning mechanical parts

Only when visibly dirty:

1. Open the cover to the pump chamber (3) by turning the bayonet coupling for the pump housing (9) one quarter turn.
2. Carefully take the magnetic rotor (8) off the shaft (7). It is necessary to pull sufficiently firmly to overcome the magnet's force.
3. Do not use any tools to clean the pump's interior, simply rinse it out with warm water.

4. Use a soft sponge to wash away any residual dirt.

5. Reassemble the fountain pump. Carefully replace the rotor on the shaft. When the rotor reaches a certain position, it is pulled towards the pump housing by the magnet.

6. Check that the ceramic washer (6) and the rubber gasket (5) are correctly positioned.

7. Check that the O-ring (4) is correctly positioned before replacing the cover (3) to the pump chamber.

8. Connect the power cable briefly (3 seconds) to check that the magnetic rotor (8) is moving freely. Some noise will be heard during this dry running. This is not a fault. When the fountain pump is subsequently used in water, it will be silent.

Winter storage

Place the fountain pump in a container filled with water in a frostproof room. Storing the pump in water avoids deposits accumulating. If the pump is stored in a dry place, it can lead to deposits blocking the rotor.
