Product Type	Smart Doorbell
Model	DK7 3MP
Brand	Imou
Camera Resolution	3MP (2304 x 1296)
Field of View	166° diagonal
Night Vision	Infrared LED, up to 10m
Audio	Two-way audio with noise cancellation
Power Supply	Rechargeable battery (built-in, 5200mAh) or wired 12-24V AC/DC
Connectivity	2.4GHz Wi-Fi (802.11 b/g/n)
Motion Detection	PIR sensor, adjustable sensitivity
Storage	Cloud storage (subscription) or microSD card (up to 128GB)
Water Resistance	IP65
Dimensions	5.1 x 2.8 x 1.2 in (130 x 70 x 30 mm)
Weight	5.3 oz (150 g)
Operating Temperature	-10°C to 45°C (14°F to 113°F)
Supported Apps	Imou Life (iOS/Android)
Smart Home Integration	Amazon Alexa, Google Assistant
Installation	Adhesive or screw mounting included
Whats in the Box	Doorbell, mounting bracket, screws, anchor plugs, USB charging cable, quick start guide

Frequently Asked Questions - DK7 3MP IMOU

How do I install the Imou DK7 3MP doorbell?

You can either mount it with the included adhesive tape or use the screws and anchors. Ensure the surface is clean and dry. After mounting, download the Imou Life app, create an account, and scan the QR code on the device to add it.

How do I pair the doorbell with the app?

Press and hold the reset button on the doorbell for 5 seconds until the indicator light flashes blue. Open the Imou Life app, tap 'Add Device', and follow the in-app instructions. Scan the QR code or enter the device's serial number.

What should I do if the doorbell is not connecting to Wi-Fi?

Make sure your phone is on a 2.4GHz Wi-Fi network (not 5GHz). Check the Wi-Fi signal strength near the doorbell. Restart the doorbell by pressing the reset button for 10 seconds, then try the pairing process again.

How do I reset the doorbell to factory settings?

Press and hold the reset button (located on the back of the device) for 10 seconds until you hear a beep and the indicator light turns solid red. This will erase all settings and restore the factory defaults.

How long does the battery last and how do I charge it?

The built-in rechargeable battery typically lasts 2-6 months depending on usage and motion detection events. Charge it using the included USB cable (5V/1A or higher). A full charge takes about 6-8 hours.

Is the doorbell weatherproof?

Yes, it has an IP65 rating, meaning it is dust-tight and protected against low-pressure water jets. It can withstand rain and splashes, but avoid direct exposure to heavy rain or submersion.

Can I use the doorbell with Alexa or Google Assistant?

Yes, the Imou DK7 supports Amazon Alexa and Google Assistant. Enable the Imou Life skill in the Alexa app or link your Imou account in the Google Home app to use voice commands and view the live feed on smart displays.

How do I adjust the motion detection sensitivity?

Open the Imou Life app, go to the device settings, and select 'Motion Detection'. You can adjust the sensitivity slider from low to high, and also set activity zones to avoid false alerts from passing cars or trees.

What happens when someone rings the doorbell?

When the doorbell button is pressed, you will receive a push notification on your phone and the doorbell will chime (if an optional mechanical or electronic chime is installed). You can then open the app to see the live video and talk to the visitor via two-way audio.

Can I view recorded footage without a subscription?

Yes, if you insert a microSD card (up to 128GB) into the doorbell, you can record and playback footage locally via the app. Cloud storage is optional and requires a subscription for extended history.

USER MANUAL DK7 3MP IMOU

Scan the QR code with the Imou Life App to add the device.

[e-mail]

https://www.imoulife.com

@imouglobal

English Use this QR code or URL to get guidance.
Tiếng Việt Sử dụng mã QR hoặc URL này để nhân hướng dẫn.
ภาษาไทย ใช้รหัส QR นี้หรือ URL เพื่อรับค่าแนะน์
Français Utilisez ce code QR ou cette URL pour obtenir des conseils.
Italiano Utilizzare questo codice QR o l'URL per ricevere aiuto.
हिंदी गाइडेस प्राप्त करने के लिए इस QR कोड या URL का इस्तेमाल करें
বাংলা নির্দেশিকা পাওয়ার জন্য এই QR কোড অথবা URL ব্যবহার করুল।
Español Use el código QR o la URL para obtener instrucciones.
Bahasa Indonesia Gunakan kode QR atau URL ini untuk mendapatkan panduan.
Polski Użyj tego kodu QR lub adresu URL, aby uzyskać wskazówki.
العربية استخدام رمز الاستجابة السérieة أو عنوان URL هذا لل正常使用 على إرشادات.
Română Utilizați acest cod QR sau URL pentru a vă îndruma,
Українська Використовуйте цей QR-код або URL-адресу, щоб отримати вказівки.
Русский Используйте этот QR-код для получения поддержки.
Deutsch Verwenden Sie diesen QR-Code oder die URL, um eine Anleitung zu erhalten.
Bahasa Melayu
Gunakan kod QR atau URL ini untuk mendapatkan panduan.
Nederlands Gebruik deze Qr-code of URL voor hulp.
Türkçe Yardım almak için bu QR kodunu veya URL'yi kullanın.
Magyar Útmutatóért használja ezt a QR-kódot vagy URL-t.
日本語 このQRコードまたはURLから詳細をご確認ください。
Български Използвайте този QR код или URL адреса, за да полулите насоки.
הכלה. מַרְׁעֹרָה URL-הַרְׁעֹרָה (בִי) QR
한국어 이 QR 코드나 URL을 사용하여 지침을 확인하십시오.
Português Utilize este código QR ou URL para obter orientações.
Svenska Använd denna QR-kod eller URL så får du vägledning.
Dansk Brug QR-koden eller webadressen for at få hjælp.
Norsk Bruk denne QR-koden eller URL-adressen for å få veiledning.
Čeština Pokyny získáte použitím tohoto kódu QR nebo adresy URL
Slovenčina Pokyny získajte použitím tohto kódu QR alebo URL adresy.
Srpski Koristite ovaj QR kõd ili URL da biste preuzeli uputstva.
Latviski Izmantojiet QR kodu vai URL, lai sanemtu norādijumus.
Suomi Hae ohjeet tämän QR-koodin avulla tai verkko-osoitteesta.
Eesti Juhiste saamiseks kasutage seda QR-koodi või URL-i.
Lietuvių Naudokite šj QR kodą ar URL, kad gautumėte pagalbos.
Ελληνικά Χρησιμοποιήστε αυτόν τον κώδικα QR ή τη διεύθυνση URL για να λάβετε καθοδήγηση.
Slovenščina Za navodila uporabite to kodo QR ali URL
Hrvatski Da biste dobili upute, upotrijebite ovaj QR kod.

Illustration of a hand interacting with a tablet device (no text or symbols)
